- Page 1 X-Treme Gasoline Scooters Model: XG-470 Product Handbook PLEASE BE SAFE WHEN RIDING Page1...
- Page 2 Use 32:1 Gas/Oil Mixture. 4 oz. of oil for every gallon of High- Octane gasoline. Tanaka Perfect Mix, or similar quality 2-Cycle Engine Oil is recommended. Oil can be purchased from your local X-Treme Dealer, Outdoor Power Equipment Dealer, or a Power Sports Dealer High-Octane Fuel recommended.
- Page 3 DO NOT JUMP or ABUSE THIS PRODUCT! DO NOT RIDE IN WET/ICY CONDITIONS! Failure to follow these instructions will VOID YOUR WARRANTY! If you have any questions, please contact X-Treme customer service on the web at www.x-tremescooters.com IMPORTANT WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways.
-
Page 4: Quick Reference
Only use a container approved for fuel Do not smoke or allow smoking near the X-Treme XG-470 while working on the engine, or while the engine is running. Wipe up and clean all fuel spills before starting the engine. -
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION…………………………………….…..2 QUICK REFERENCE…………………………………………………4 TABLE OF CONTENTS……………………………….……………...5 GETTING TO KNOW YOUR X-TREME XG-470…………………..6 PACKING CONTENTS……………………………………………….7 GETTING STARTED………………..……………………………..…7 ASSEMBLY………………………………………………………..7 GAS TANK INSTALLATION……………………………………..8 FUELING…………………………………………………………..9 RIDING/BRAKING………………………………………………..9 TRANSPORTING AND STORAGE………………………..………..9 OPERATING PROCEDURES…………………………………….…10 STARTING………………………………………………………..10 MAINTENANCE………………………………………………………10 RECOMMENDED TOOLS……………………………………...10 CARBURETOR ADJUSTMENT…………………………….….10 BRAKE SYSTEM………………………………………………..12 Page5... -
Page 6: Getting To Know Your X-Treme Xg-470
TIRES AND WHEELS…………………………………………..14 ADJUSTING THE HEAD UNIT…………….…………………..14 ADJUSTING THE CHAIN…..………..……………….………..14 MAINTENANCE SCHEDULE……………………………………..15 OTHER QUESTIONS….……………………………………………..16 GENERAL INFORMATION/TECH SUPPORT……………………..16 GETTING TO KNOW YOUR X-TREME XG-470 Page6... - Page 7 PACKAGE CONTENTS Your X-Treme XG-470 comes with the following items in the box. Please locate all of the following: 1. The X-Treme XG-470 Gas Scooter 2. Seat/Seat Posts (2) and Clamps (2) 3. Trunk & Trunk Rack & Mounting Hardware 4.
-
Page 8: Getting Started
OPERATING PROCEDURES section, prior to starting or riding your XG-470 Assembly 1. Carefully remove the XG-470 from the box. 2. Locate the Handlebar Clamp. (Fig. 1) Slide the clamp up onto the T-handlebar. 3. Insert the T-handlebar onto the front fork. -
Page 9: Fueling
5. Install the enclosed Rear Fender bolts to secure the fender to the frame. There will be one for the rear of the fender, and two for the front. 6. Next, install the fuel tank and fuel lines. (Fig. 5) First run the fuel lines from the right side of the scooter under the fender to the left side of the scooter to the engine and locate the carburetor. -
Page 10: Transporting And Storage
2. Raise the kickstand to its upright position. 3. Make sure the engine is running. 4. Put one foot on the deck of the XG-470 while pushing off with the other foot, gently rotate the THROTTLE GRIP, on the right side of the handlebars. -
Page 11: Operating Procedures
MAINTENANCE RECOMMENDED TOOLS To adjust and service the X-Treme XG-470 you will need the following tools: Allen Wrenches: 3/4/5/6 mm Wrenches: 10/13 mm Open end wrench Large Adjustable Crescent Wrench ... - Page 12 Note: Standard idle RPM is about 2500-3000 RPM. WARNING! When the engine is idling, under no circumstances should your XG- 470 be moving. If the XG-470 continues to move after idle speed adjustment, contact X-Treme or your local X-Treme service center. Page12...
- Page 13 Cleaning the Air Filter It is a good idea to occasionally clean the air filter to insure optimum performance. To clean the air filter: 1. Using a Philips head screwdriver, remove the carburetor cover by turning the cover screw counter-clockwise. (Fig.10). 2.
-
Page 14: Brake System
The XG-470 uses both front wheel and rear wheel Hub Brake systems activated by hand levers (on either side of the handlebar). Squeezing the BRAKE LEVER with your left hand activates the rear brake, and squeezing the BRAKE LEVER with your right hand activates the front brake. Make sure to release the THROTTLE GRIP when engaging the brakes. -
Page 15: Tires And Wheels
Squeaky Brakes The brakes may squeak until they are broken in. This is normal and will not affect the function or performance of the brakes. With continued use the squeak should go away. TIRE AND WHEELS Tire Pressure The tire must be inflated to a maximum of 50 P.S.I. It is also recommended to use a tube additive like Slime purchasable from any motorcycle shop, to avoid inconvenient punctures. -
Page 16: Adjusting The Chain
ADJUSTING THE CHAIN The chain will come adjusted from the factory. However, it may be necessary to adjust the sprockets from time to time. The chain must be well aligned onto the sprockets in order to avoid uneven wear. This will result in shortened chain life. -
Page 17: Maintenance Schedule
For additional questions, service instructions, further information and important phone numbers, please go to the X-Treme website at www.x-tremescooters.com Thank you for purchasing an X-Treme XG-470 and please tell your friends how much fun you’re having on the X-Treme XG-470 For General Information or Parts Visit www.x-...
