This supplement is to be used together with the L300P Series Inverter Instruction Manual (NB604XA) The functions and settings in this supplement supercede those in the L300P Instruction Manual. Manual Number: NBZ601DX After reading this manual, keep it handy for future reference. Hitachi Industrial Equipment Systems Co., Ltd.
Revision History The Date Operation Revision Contents of Issue Manual No. Initial Release Oct.1999 NBZ601AX Change of Factory Default Settings Sep.2000 NBZ601CX Revised by HAL Jun. 2002 NBZ601DX - i -...
L300P Supplement Explanation of functions 1. Added functions RUN Permissive input signal for FW/REV [ROK] Related Functions ・Assign function 49 (ROK) to an intelligent input terminal. C001-C005 : Intelligent input setting ・When inverter is in the STOP mode, and the RUN Permissive input signal [ROK] is "ON,"...
Page 4
L300P Supplement Explanation of functions Inverter Action on Loss of Analog Frequency Reference Input Signal Related Functions P020 :Freq. During Loss of O/OI/O2 Set parameter P050 A020/A220 : 1 /multi-stage speed When the frequency reference is set by the O, OI, or O2 analog b082 : Start frequency adjustment input, if the reference signal remains less than start frequency...
L300P Supplement Explanation of functions 2. Function Parameter list Monitor mode Display Monitor or Data Range Function name code (digital operator) Output Frequency d001 0.00-99.99/100.0-400.0 (Hz) Monitor d002 Output Current Monitor 0.0-999.9 (A) Rotation Direction d003 F(forward)/o(stop)/r(reverse) Monitor Process Variable (PV) 0.00-99.99/100.0-999.9/1000.
Page 6
L300P Supplement Explanation of functions Function Mode LBRM/ LFU/HFU Display Monitor or Data Range HBRM Function name Initial code (digital operator) Initial Data Data 0.0, starting frequency to Maximum 15.00 F001 Output frequency 0.00 frequency (Hz) NOTE (1) F002 Acceleration (1) time 0.01-99.99/100.0-999.9/1000.-3600.(s) 60.00 30.00...
L300P Supplement Explanation of functions Function Mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data Frequency 00(VR)/01(terminal)/02(operator)/03(RS485)/ A001 setting selection 04(option1)/05(option2) Operation A002 01(terminal)/02(operator)/03(RS485)/04(option1)/05(option2) setting selection A003 Base frequency, 30. - maximum. frequency (Hz) Base frequency, A203 30.
Page 8
L300P Supplement Explanation of functions Function Mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data A041 Torque boost selection 00 (manual torque boost) / 01 (automatic torque boost) Torque boost selection, A241 00 (manual torque boost) / 01 (automatic torque boost) motor A042 Manual torque boost...
Page 9
L300P Supplement Explanation of functions Function Mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data A061 frequency upper limiter 0.00, 1 frequency lower limiter-maximum frequency(Hz) 60.00 0.00 A261 frequency upper limiter 0.00 , frequency lower limiter-2 setting maximum 60.00 0.00 frequency(Hz)
Page 10
L300P Supplement Explanation of functions Function mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data Rated current Rated b012 Electronic thermal level 0.2*constant current-1.20*constant current(A) current of inverter× of inverter 1.20 Rated current Rated Electronic thermal level b212 0.2*constant current-1.20*constant current(A) of inverter×...
Page 11
L300P Supplement Explanation of functions Function Mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data 01/(RV:Reverse Run/Stop)/02(CF1:Multi-speed1)/03(CF2:Multi-speed2)/ C001 Intelligent input1 setting 04(CF3:Multi-speed3)/05(CF4:Multi-speed4)/06(JG:Jogging)/ C002 Intelligent input2 setting 07(DB:External DC braking)/08(SET:2 control)/ 09(2CH:two-stage adjustable speed)/ C003 Intelligent input3 setting 11(FRS:Free-run)/12(EXT:External trip)/ 13(USP:Unattended start protection)/14(CS:commercial change)/ C004...
Page 12
L300P Supplement Explanation of functions Function mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data Intelligent input1a/b(NO/NC) C011 00(NO)/01(NC) selection Intelligent input2a/b(NO/NC) C012 00(NO)/01(NC) selection Intelligent input3a/b(NO/NC) C013 00(NO)/01(NC) selection Intelligent input4a/b(NO/NC) C014 00(NO)/01(NC) selection Intelligent input5a/b(NO/NC) C015 00(NO)/01(NC) selection...
Page 13
L300P Supplement Explanation of functions Function mode LBRM/HFBM LFU/HFU Code Function name Setting range Initial Data Initial data b034 RUN time/Power ON time level 0.-9999./1000-6553(10000-65530)hr b035 Operation direction restrict 00(Reverse is valid)/01(Only forward)/02(Only reverse) 00(Start reduced voltage time small)-06(Start reduced voltage time b036 Start reduced voltage large)
Page 15
Explanation of functions (note2) Applicable motor indicates HITACHI three-phase motor. When you use other motor, set so that the motor current doesn’t exceed the rated current of the inverter. (note3) Output voltage will reduce when the power voltage is reduced. (Except when AVR function is selected.) (note4) When you operate motor over 50/60Hz, inquire about the allowable max.revolution time of motor etc.
