- Page 1 GAS HOBS USER AND INSTALLATION INSTRUCTIONS...
- Page 2 For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….
-
Page 3: Table Of Contents
CONTENTS General Information page 4 Warning and Safety Instructions page 5 Instructions for Use pages 6–7 Instructions for Installation Pages 8–12 Technical Data Pages 12–13 Conditions of Guarantee Back cover... -
Page 4: General Information
The aforegoing does not affect your statutory rights. The Warrantee applies to Great Britain and Northern Ireland only. In the event that you require any After Sales Service or advice, please contact the Baumatic Service Department on telephone number – 0118 933 6911. - Page 5 Corgi registered (all Baumatic Engineers are Corgi registered) and for electrical installations, NICEIC registration is recommended. Baumatic Ltd declines any responsibility for injury or damage to persons or property as a result of improper use or installation of this appliance.
-
Page 6: Instructions For Use
USER INSTRUCTIONS INSTRUCTIONS FOR USE These User Instructions should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance. The following models are covered by these instructions: AS4.1 AS5.1 USING THE HOB The symbols on the Control Panel fascias show which burner the Control Knob operates. -
Page 7: Helpful Hints
USER INSTRUCTIONS HELPFUL HINTS Always use the correct diameter pan, one that is the same or slightly larger than the flame ring. The flame should never exceed the diameter of the pan. The bottom of the pan should be flat and wherever possible, keep the lid on the pan when cooking. -
Page 8: Instructions For Installation
UK Regulations and Safety Standards or their European Norm Replacements: NOTE: UK law stipulates that gas appliances must be installed and repaired by a CORGI Registered Installer (all Baumatic Engineers are CORGI Registered). Gas safety Regulations (Installation & Use) -
Page 9: Installation Notes
INSTALLATION INSTRUCTIONS INSTALLATION NOTES 1. Cut the aperture to the dimensions shown below or use the template if printed on the packaging. 2. Invert the Hob and apply the sealing agent provided to match the outer perimeter edge. 3. If the sealing agent is a strip type, the protective covering must be removed from both sides. Do not leave a gap in the sealing agent or overlap the thickness. -
Page 10: Ventilation Of Rooms
INSTALLATION INSTRUCTIONS VENTILATION OF ROOMS The room in which this appliance is installed must be well ventilated by natural or mechanical means, or a combination of both to ensure correct combustion and the removal of spent air. The minimum quantity of air for combustion will depend on the room volume, number of appliances and their total power rating. -
Page 11: Electrical Connection
INSTALLATION INSTRUCTIONS ELECTRICAL CONNECTION Before connecting the appliance, make sure the supply voltage marked on the rating Plate corresponds with the mains supply voltage. WARNING – THIS APPLIANCE MUST BE EARTHED This appliance should be wired into a double pole Switched Fused Spur Outlet having 3 mm contact separation and the fuse rating reduced to 3 Amps. -
Page 12: Technical Data
MAINTENANCE During the guarantee period, in case of need all service intervention should be referred back to the Baumatic Ltd Service department. Please note that intervention or repair by any unauthorised personnel will invalidate such guarantee, Before carrying out any maintenance, disconnect the appliance from the gas and electricity supplies. - Page 13 BURNER TYPES AND POWER INPUTS : kW Model Large Medium Small Fish Total Max / Min Max / Min Max / Min Max / Min Max / Min AS4.1 3.0 / 0.7 1.75 / 0.4 1.0 / 0.35 AS5.1 3.0 / 0.7 1.75 / 0.4 1.0 / 0.35 10.5...
-
Page 14: Conditions Of Guarantee
The conditions of the guarantee, which applies, to your Baumatic appliance are as follows: All ‘Work’ in relation to the Guarantee must be carried out by Baumatic Ltd or an approved service agent of Baumatic Ltd. Any claims made under the terms of the guarantee must be supported by the original invoice / bill of sale issued at the time of purchase.
