Page 1: Electric Hobs
ELECTRIC HOBS USER AND INSTALLATION INSTRUCTIONS... - Page 2 For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….
-
Page 3: Table Of Contents
CONTENTS General Information page 4 Warning and Safety Instructions page 5 Instructions for Use pages 6 – 7 Instructions for Installation Pages 8 – 10 Technical Data Page 11 Conditions of Guarantee Back cover... -
Page 4: General Information
The aforegoing does not affect your statutory rights. The Warrantee applies to Great Britain and Northern Ireland only. In the event that you require any After Sales Service or advice, please contact the Baumatic Service Department on telephone number – 0118 933 6911. - Page 5 (all Baumatic Engineers are Corgi registered) and for electrical installations, NICEIC registration is recommended. Baumatic Ltd declines any responsibility for injury or damage to persons or property as a result of improper use or installation of this appliance. Heat, steam and moisture will be created during use, take care to avoid injury and ensure that the room is adequately ventilated.
-
Page 6: Instructions For Use
USER INSTRUCTIONS INSTRUCTIONS FOR USE These User Instructions should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance. The following models are covered by these instructions: AS6.1 USING THE HOB The symbols on the Control Panel fascias show which hotplate the control system operates. A pilot light indicates when a hotplate is switched on. -
Page 7: Helpful Hints
USER INSTRUCTIONS NOTE: • If two or more cooking zone pads are touched simultaneously the command will be ignored or if a zone is already in use, it may shut down. Continuing to touch zones for more than 10 seconds will cause the hob to shut down. •... -
Page 8: Instructions For Installation
The surface of any adjacent unit must be capable of withstanding a minimum temperature rise of 85°C. PRE-COMMISSIONING THE APPLIANCE When unpacked, check that the following parts are included with the appliance: • Baumatic Ltd Instruction and Installation Book • Baumatic Ltd extended warranty Card • Adhesive sealing agent and fixing clamps & screws... -
Page 9: Installation Notes
INSTALLATION INSTRUCTIONS INSTALLATION NOTES Cut the aperture to the dimensions shown in the table below or use the template provided on the packaging. Invert the hob and apply the sealing agent provided to match the outer perimeter edge. If the sealing agent is a strip type, the protective covering must be removed from both sides. Do not leave a gap in the sealing agent or overlap the thickness. -
Page 10: Installation Instructions
The appliance must not be connected to the mains supply by means of a 13A plug and socket. MAINTENANCE During the guarantee period, in case of need all service intervention should be referred back to the Baumatic Ltd Service department. Please note that intervention or repair by any unauthorised personnel will invalidate such guarantee. -
Page 11: Technical Data
TECHNICAL DATA ELECTRICAL DETAILS Rated Voltage: 230V ac 50Hz Supply Connection: Switched Double-pole Isolator with 3mm contact separation POWER INPUTS AND PROTECTION RATING Model Total Min Fuse Amps Protection Rating AS6.1 26.1 26.1 B13 + B10 25.2 26.1 27.8 28.7 3 x 2.5mm2 Type H05 RR-F <HAR>... -
Page 12: Conditions Of Guarantee
The conditions of the guarantee, which applies, to your Baumatic appliance are as follows: All ‘Work’ in relation to the Guarantee must be carried out by Baumatic Ltd or an approved service agent of Baumatic Ltd. Any claims made under the terms of the guarantee must be supported by the original invoice / bill of sale issued at the time of purchase.
