Sharp FO-1470 Service Manual

Service manual
Hide thumbs Also See for FO-1470:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
Illustration: UX-510UA
open
LCR
www.OpenLCR.com
[1] Specifications ............................................ 1-1
[2] Operation panel ......................................... 1-2
[3] Transmittable documents .......................... 1-3
[4] Installation ................................................. 1-4
[5] Quick reference guide ............................... 1-9
[1] Adjustments .............................................. 2-1
[3] Troubleshooting ...................................... 2-19
[4] Error code table ....................................... 2-20
[1] General description ................................... 3-1
procedures ....................................... 3-4
[1] Block diagram ............................................4-1
[2] Wiring diagram .......................................... 4-2
[3] Point-to-point diagram ............................... 4-3
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
SERVICE MANUAL
CONTENTS
SHARP CORPORATION
No. 00ZUX510UASME
FACSIMILE
MODEL
SELECTION CODE
U
[1] Circuit description ..................................... 5-1
power supply PWB ............................5-11
[1] Control PWB circuit ................................... 6-1
[2] TEL/LIU PWB circuit .................................. 6-9
[3] Power supply PWB circuit ...................... 6-13
[4] CCD PWB circuit ..................................... 6-15
[5] Operation panel PWB circuit ................... 6-16
[1] Protocol ..................................................... 7-1
[2] Power on sequence ................................... 7-2
[1] Service tools ............................................. 8-1
[2] IC signal name .......................................... 8-4
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
UX-510UA
FO-1470U
UX-510A
FO-1470
DESTINATION
U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Sharp FO-1470

Summary of Contents for Sharp FO-1470

  • Page 1: Table Of Contents

    UX-510UA FO-1470U SERVICE MANUAL No. 00ZUX510UASME FACSIMILE UX-510A FO-1470 MODEL SELECTION CODE DESTINATION Illustration: UX-510UA U.S.A. open www.OpenLCR.com CONTENTS CHAPTER 1. GENERAL DESCRIPTION CHAPTER 5. CIRCUIT DESCRIPTION [1] Specifications ..........1-1 [1] Circuit description ........5-1 [2] Operation panel ......... 1-2 [2] Circuit description of control PWB ....
