Add A Boot Option; Edit Boot Entry; Delete Boot Options - HP Rx2620-2 - Integrity - 0 MB RAM Service Manual

Where:
• NO VOLUME LABEL: A hard drive. When you format a hard drive, the EFI tools provide an
option to LABEL the disk. In this example, the volume is not labelled.
• CD_FORMAT: The label created for the disk currently inside the DVD drive.
• Removable Media Boot: Allows you to boot from a removable media drive (CD/DVD
drive). This option does not support booting from a specific file on a specific CD.
• Load Files: The EFI Shell and the LAN.

Add a Boot Option

Use this option to add items to the EFI boot menu.
This option displays the file systems that are on your system and lets you browse these file
systems for applications or drivers that are executable. Executable files end with the .efi
extension. You can also select remote boot (LAN) options that have been configured on your
network. The option you have selected is added to the EFI boot menu.
If you add a new drive to your system, you must manually add its boot options list if you want
to make it a bootable device.
When adding a boot option that already exists in the Boot Manager list of boot options, you can
choose whether to create a new option or modify the existing one. If you:
• To modify an existing option, change the boot option name or add boot option arguments
to the existing option.
NOTE:
If you create a new boot option for an already existing option, multiple instances of the
same boot option exist.
For example:
Add a Boot Option. Select a Volume
NO VOLUME LABEL [Acpi(HWP0002,0)/Pci(2|0)/Ata(Primary,Master)/CDROM
Removable Media Boot [Acpi(HWP0002,0)/Pci(2|0)/Ata(Secondary,Master)
Load File [EFI Shell [Built-in]]
Load File [Acpi(HWP0002,0)/Pci(3|0)/Mac(00306E4C4F1A)]
Exit
Where:
• NO VOLUME LABEL: A hard drive. You can search through the disk for bootable
applications to add to the Boot Manager list of Boot options.
• Removable Media Boot: Treats the removable media as a bootable device.
• Load File EFI Shell: Adds a new instance to the EFI Shell.
• Load File with the MAC address: Adds a network boot option.

Edit Boot Entry

Use this option to edit the boot options on the EFI boot menu.
NOTE:
This action does not delete any files, applications or drivers from your server.
This option displays a list of boot options that are configured on your server. The names will
match the options on the main Boot Manager menu.
If you remove a drive from your server, you must manually delete it from the boot options list.
• To delete an item from the list, use the arrow keys to highlight the item and press Enter.
• To remove all of the entries from the EFI boot menu, select Delete All Boot Options. This
setting can be used as a security device on servers that are accessed remotely.

Delete Boot Options

Use this option to remove boot options from the EFI boot menu.
168 Utilities
