Model #: B114-004-R, B114-002-R
NOTE: Follow these installation and operating procedures to
ensure correct performance and to prevent damage to this unit
Introduction
The Video Splitter is a signal booster and splitter that takes video input from a single source and directs it to
multiple video outputs for monitors using analog signals. It extends the distance a signal is sent to about 210 ft.
Features:
• One video input to multiple video outputs
• Transmission distance of up to 210 feet
• Suitable for SVGA, VGA, and Multisync monitors
• Daisy-chain multiple units to increase the number of outputs
• Supports 350MHz bandwidth
IMPORTANT NOTE: This unit is not designed for CGA, EGA or MONOCHROME type monitors or
any monitor using a digital video signal.

Specifications

Power Supply
Maximum Cable Length
Signal Type
Installation
Stand-Alone Installation:
1. Connect the PC's video output port to the Video Splitter's "Video In" port using an HDDB15 Male/Female
Monitor Extension Cable (Tripp Lite # P500-006, P510-006, P510-010 or P510-015).
2. Connect the Video Splitter's "Video Out" ports to the input of your monitors either by using the existing
cable on the monitor or by using an HDDB15 Male/Male Monitor Cable (Tripp Lite # P502-006, P512-006
or P512-010).
3. Connect the provided power supply to the Video Splitter and turn on the unit. Your Video Splitter is ready
to go.
Use ONLY the 9V DC adapter that is supplied with this unit.
Copyright © 2005 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.
User's Manual
Video Splitter
(4- & 2-Port)
or to its connected devices.
DC 9V, 1A (max)
210 feet
VGA, SVGA, Multisync Monitor
WARNING!
Technical specifications are subject to change without notice.
Tripp Lite World Headquarters
1111 W. 35th Street,
Chicago, IL 60609 USA
(773) 869-1234, www.tripplite.com
