Chapter 2 Creating Provisioning Scripts
Using Provisioning Parameters
If all alternatives have conditional expressions, and none evaluates to true (or if the whole profile rule
is empty), then the entire Profile_Rule* parameter is skipped, and the next profile rule parameter in the
sequence is evaluated.
The following are some examples of valid programming for a single Profile_Rule* parameter.
The following example resyncs unconditionally to the profile at the specified URL, performing an http
GET request to the remote provisioning server.
http://remote.server.com/Linksys/$MA.cfg
In the following example, the SPA resyncs to two different URLs, depending on the registration state of
Line 1. In case of lost registration, the SPA performs an HTTP POST to a CGI script, transmitting the
contents of the macro expanded GPP_A (which may provide additional information on the state of the
SPA).
($REGTMR1 eq 0)? http://p.tel.com/has-reg.cfg
| [--post a] http://p.tel.com/lost-reg?
In the following example, the SPA resyncs to the same server, but provides additional information if a
certificate is not installed in the unit (for legacy pre-2.0 units).
("$CCERT" eq "Installed")? https://p.tel.com/config?
| https://p.tel.com/config?Linksys$MAU
In the following example, Line 1 is disabled until GPP_A is set equal to Provisioned through the first
URL. Afterwards, it resyncs to the second URL.
("$A" ne "Provisioned")? (Line_Enable_1_ = "No";)! https://p.tel.com/init-prov
| https://p.tel.com/configs
In the following example, the profile returned by the server is assumed to contain XML element tags that
need to be remapped to proper SPA parameter names by the aliases map stored in GPP_B.
[--alias b] https://p.tel.com/account/spa$MA.xml
A resync is typically considered unsuccessful if a requested profile is not received from the server. This
default behavior can be overridden by the parameter Resync_Fails_On_FNF. If Resync_Fails_On_FNF
is set to No, then the SPA accepts a file-not-found response from the server as a successful resync. The
default value for Resync_Fails_On_FNF is Yes.

Report Rule

The SPA provides a mechanism for reporting its current internal configuration to the provisioning server.
This is useful for development and debugging. The report syntax is similar to the XML profile. All
provisionable parameters are included, except for the values of passwords, keys, and the GPP_SA to
GPP_SD parameters, which are not shown.
The Report_Rule parameter is evaluated like a profile rule parameter. In other words, it accepts a URL,
optionally qualified with a bracketed expression. The URL specifies the target destination for the report
and an encryption key can be included as an option.
The URL scheme can be TFTP, HTTP, or HTTPS. When using TFTP, the operation performed is TFTP
PUT. In the case of HTTP and HTTPS, the operation performed is HTTP POST.
If an encryption key is specified, the report is encrypted using 256-bit AES in CBC mode. The encrypted
report can be decrypted with the following OpenSSL (or equivalent) command:
openssl enc –d –aes-256-cbc –k secretphrase –in rep.xml.enc –out rep.xml
