3.6.4 CPU Q-Fan Control [Enabled]
[Disabled]
[Enabled]
CPU_FAN Speed Low Limit [600 RPM]
This item appears only when you enable the CPU Q-Fan Control feature and allows you to
disable or set the CPU fan warning speed. Configuration options: [Ignore] [100 RPM] [200
RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
CPU Fan Profile [Standard]
This item appears only when you enable the CPU Q-Fan Control feature and allows
you to set the appropriate performance level of the CPU fan.
[Standard]
[Silent]
[Turbo]
[Manual]
The following four items appear only when you set CPU Fan Profile to [Manual].
3-22
Disables the CPU Q-Fan control feature.
Enables the CPU Q-Fan control feature.
Sets to [Standard] to make the CPU fan automatically adjust
depending on the CPU temperature.
Sets to [Silent] to minimize the fan speed for quiet CPU fan operation.
Sets to [Turbo] to achieve maximum CPU fan speed.
Sets to [Manual] to assign detailed fan speed control parameters.
CPU Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature.
The values range from 20ºC to 75ºC.
CPU Lower Temperature [20]
Displays the lower limit of the CPU temperature.
CPU Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum CPU fan duty cycle. The
values range from 20% to 100%. When the CPU temperature reaches the
upper limit, the CPU fan will operate at the maximum duty cycle.
CPU Fan Min. Duty Cycle(%) [30]
Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The
values range from 0% to 100%. When the CPU temperature is under 40ºC,
the CPU fan will operate at the minimum duty cycle.
