Cpu Core On/Off Function; Onboard Devices Configuration - Asus M5A97 R2.0 User Manual

3.5.6

CPU Core On/Off Function

CPU Core Activation [Auto]
This item lets user turn off cores except core 1, user can turn off 2nd, 3rd, 4th, 5th, etc core
manually. Configuration options: [Auto] [Manual]
The following items appear only when you set the previous item to [Manual]
3rd & 4th Core [Enabled]
Configuration options: [Enabled] [Disabled]
3.5.7

Onboard Devices Configuration

Asmedia USB 3.0 Controller (Rear) [Enabled]
[Enabled]
[Disabled]
Asmedia USB 3.0 Controller (Front) [Enabled]
[Enabled]
[Disabled]
Asmedia USB 3.0 Battery Charging Support [Disabled]
This item appears only when the Asmedia USB 3.0 Controller (Rear) or Asmedia USB 3.0
Controller (Front) is set to [Enabled].
[Enabled]
[Disabled]
Realtek LAN Controller [Enabled]
[Enabled]
[Disabled]
Realtek PXE OPROM [Disabled]
This item appears only when you set the Realtek LAN Controller item to [Enabled] and allows
you to enable or disable the Rom Help of the Realtek LAN controller.
Configuration options: [Enabled] [Disabled]
Serial Port Configuration
The sub-items in this menu allow you to set the serial port configuration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Configuration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
This item appears only when you set the previous item to [Enabled] and allows you to
select the Serial Port base address.
Configuration options: [IO=3F8h; IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4]
[IO=2E8h; IRQ=3]
3-18
Enables the rear USB 3.0 controller.
Disables the controller.
Enables the front USB 3.0 controller.
Disables the controller.
Enables the Asmedia USB 3.0 battery charging function.
Disables this function
Enables the Realtek LAN controller.
Disables the controller.
Chapter 3: BIOS setup
