Main Menu

The BIOS Setup is accessed by pressing the F2 button after the Power-On Self-Test
(POST) memory test begins and before the operating system boot begins. Once you
enter the BIOS Setup Utility, the Main Menu will appear on the screen. The Main
Menu provides System Overview information and allows you to set the System Time
and Date. Use the "<" and ">" cursor keys to navigate between menu screens.
M a i n A d v a n c e d
System Date
System Time
> Primary IDE Master
> Primary IDE Slave
> Secondary IDE Master
> System Information
Below table is described for Primary IDE Master, Primary IDE Slave, and Secondary
IDE Master setting.
M a i n A d v a n c e d
Primary Master
Device
LBA/ Large Mode
DMA Mode
S.M.A.R.T
ViewSonic VOT120

Table 2 BIOS Main Menu

BIOS SETUP UTILITY
B o o t
[Mon 04/03/2009]
:[Not Detected]
:[Not Detected]
:[Not Detected]
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.

Table 3 IDE Device Setting Menu

BIOS SETUP UTILITY
B o o t
:Not Detected
[Auto]
[Auto]
[Auto]
V02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
C h i p s e t P o w e r
[10:18:15]
C h i p s e t P o w e r
S e c u r i t y E x i t
Use [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Time.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
S e c u r i t y E x i t
Disable: Disables LBA Mode.
Auto: Enables LBA Mode if the
device supports it and the
device is not already formatted
with LBA Mode disabled.
<> Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
