Cisco 5508 - Wireless Controller - Network Management Device Datasheet page 4

Item
Management
Management Interfaces
Interfaces and Indicators
Physical and Environmental
Regulatory Compliance
© 2012 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.
Specifications
● RFC 3580 IEEE 802.1X RADIUS Guidelines
● RFC 3748 Extensible Authentication Protocol
● Web-based authentication
● TACACS support for management users
● SNMP v1, v2c, v3
● RFC 854 Telnet
● RFC 1155 Management Information for TCP/IP-Based Internets
● RFC 1156 MIB
● RFC 1157 SNMP
● RFC 1213 SNMP MIB II
● RFC 1350 TFTP
● RFC 1643 Ethernet MIB
● RFC 2030 SNTP
● RFC 2616 HTTP
● RFC 2665 Ethernet-Like Interface types MIB
● RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and
Virtual Extensions
● RFC 2819 RMON MIB
● RFC 2863 Interfaces Group MIB
● RFC 3164 Syslog
● RFC 3414 User-Based Security Model (USM) for SNMPv3
● RFC 3418 MIB for SNMP
● RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs
● Cisco private MIBs
● Web-based: HTTP/HTTPS
● Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port
● Cisco Wireless Control System (WCS)
● Uplink: 8 (5508) 1000BaseT, 1000Base-SX and 1000Base-LH transceiver slots
● Small Form-Factor Pluggable (SFP) options (only Cisco SFPs supported): GLC-T, GLC-SX-MM, GLC-
LH-SM
● LED indicators: link
● Service Port: 10/100/1000 Mbps Ethernet (RJ45).
● Service Port: 10/100/1000 Mbps Ethernet (RJ45) For High Availability for future use
● LED indicators: link,
● Utility Port: 10/100/1000 Mbps Ethernet (RJ45)
● LED indicators: link
● Expansion Slots: 1 (5508)
● Console Port: RS232 (DB-9 male/RJ-45 connector included), mini-USB
● Other Indicators: Sys, ACT, Power Supply 1, Power Supply 2
● Dimensions (WxDxH): 17.30 x 21.20 x 1.75 in. (440 x 539 x 44.5 mm)
● Weight: 20 lbs (9.1 kg) with 2 power supplies
● Temperature: Operating temperature: 32 to 104°F (0 to 40°C); Storage temperature: –13 to 158°F (–25
to 70°C)
● Humidity: Operating humidity: 10 95%, noncondensing. Storage humidity: up to 95%
● Input power: 100 to 240 VAC; 50/60 Hz; 1.05 A at 110 VAC, 115 W Maximum; 0.523 A at 220 VAC, 115
W Maximum; Test Conditions: Redundant Power Supplies, 40C, Full Traffic.
● Heat Dissipation: 392 BTU/hour at 110/220 VAC Maximum
CE Mark
Safety:
● UL 60950-1:2003
● EN 60950:2000
● EMI and susceptibility (Class A):
● U.S.: FCC Part 15.107 and 15.109
● Canada: ICES-003
● Japan: VCCI
● Europe: EN 55022, EN 55024
Page 4 of 8
