Russound CAM6.6 Specifications

CAM6.6T and CAM6.6X Receivers
UNO Home Theater
12VDC Trigger IN
Keypad Ports
RS232
Interface
RNET Link
IN and OUT
SRC2
Remote
Source
Included
Inputs
Source 1 IN
Tuner OUT Routed IR
Common IR
Outputs
Specifications
CAM6.6T AM/FM Tuner
Antenna impedance AM: 300 ohm balanced
Impedance FM: 75 ohm unbalanced
Sensitivity @ S/N AM: 20 dB 55dBu
FM: 30 dB 6dB max. 12dBu
Image rejection AM: 33 dB
FM: 80 dB
S/N ratio AM: 45 dB
FM: 60 dB
CAM6.6X Satellite Tuner
XM band 2332.5 - 2345 MHz
XM antenna 50 ohm SMB connection
Amplifier
Frequency response 20 Hz-20 kHz +/- 0.5 dB
Watts per channel 20 watts RMS x 12 into 8 ohms
Total harmonic distortion 0.05%
Signal to noise ratio 88 dB
Audio source inputs 6 (including internal tuner)
Audio zone outputs 6 speaker level
(2 line level)
Max source audio input 5V peak to peak, 10k ohms
Zone variable line
Audio output 5.6V peak to peak, 4 ohms @ 1 kHz
Zone fixed line
Audio output 5.6V peak to peak, 4 ohms @ 1 kHz
Trigger outputs 1 common, 12VDC 100mA each
Trigger inputs 1 home theater
Frequency range AM 530 - 1710 kHz
FM 87.7 - 107.9 MHz
Since 1967, innovation, quality and reliability have been the core of the Russound product tradition. Today, Russound
offers everything for enjoying multi-room audio/video in your home. All audio/video distributed solutions are built to
high standards and designed with the unique consideration of making products that are easy to enjoy and live with.
www.russound.com
©2004 Russound. All rights reserved. All trademarks are the property of their respective owners. Specifications are subject to change without notice.
LR1600-0002. 01/06.
CAM6.6T
Built-In
AM/FM Tuner
Mute 12VDC
Trigger IN
CAM6.6X
Built-In XM
Mute 12VDC
Satellite Radio
12VDC
Trigger OUT
Trigger OUT
IR Learning
Window
Fixed/Variable Fuse Holder
Speaker Outputs
Switch Line with Removable
Outputs
Snap Connectors
Audio
Line
Outputs
Physical
Dimensions 17"W x 12"D x 3.5"H (43 x 30.5 x 9 cm)
Weight 18 lbs (8.1 kg)
Power Supply 110 or 240 VAC
Fuse Rating 110V input; F3A H 250V
US and Canada
240V input; T1.25A H 250V Europe
UNO-S1 Smart Keypad
Dimensions 1.875"W x 1.125"D x 4.3"H
(4.8 x 10.9 x 2.8 cm)
Single gang UL/CSA
approved junction box
Weight 5 oz (141 g)
Power requirements 12 VDC 150mA
CAT-5 connection 110 punchdown
UNO-S2 Smart Keypad
Dimensions 3.65"W x 1.125"D x 4.3"H
(9.2 x 10.9 x 2.8 cm)
Double gang UL/CSA
approved junction box
Weight 6 oz (170 g)
Power requirements 12 VDC 180mA
CAT-5 connection 110 punchdown
*RNET is a proprietary platform
that allows Russound components to
communicate with each other.
603 659 5170 5 Forbes Road
Newmarket, New Hampshire 03857 USA
AC 240V
AC 110V Switch
Six-Zone AM/FM or XM Receivers
Detachable
Line Cord
All you need to know is Russound
CAM6.6T and CAM6.6X
Music throughout your universe
At the touch of a button
Surprisingly affordable
