Honeywell HCD80484 Specifications

HCD80 SERIES
HIGH AND STANDARD RESOLUTION, TRUE DAY/NIGHT
COLOR BULLET CAMERA
The HCD80 Series offers great functionality and superior picture quality around
the clock when accompanied by external IR illumination. This discreet, bullet-style
camera is perfect for architecturally sensitive applications. Catch all the action
24-hours a day using the True Day/Night camera. When the ambient light drops
below a certain point, a mechanical filter within the camera switches and the
camera changes from color to black and white.
The sleek, futuristic bullet styling is visually appealing, yet impact resistant.
The attractive, polished machined aluminum enclosure comes with a protective
sunhood. The HCD80 Series is designed with a clear flat viewing window to
provide better picture quality.
The HCD80 is more secure than a box camera. It is difficult to knock out of
position with its ball and socket design. Swivel the camera into place, then lock
it down with the tamper resistant screws. This camera also boasts a discreet,
track mount installation using locking security screws and concealed wiring so
the wires cannot be cut or the camera tampered with or disconnected.
For easy installation, indoors or out, the HCD80 Series mounts in minutes to
a wall or ceiling. A metal mounting plate provides ease of installation onto
electrical boxes.
Market Opportunities
The Honeywell HCD80 Series is designed for cost effective, high resolution 24/7
surveillance applications that have changing light conditions through the day.
This includes general indoor and outdoor surveillance applications in banking,
retail, offices, hotels, bars, restaurants, parking garages, playgrounds, commercial
buildings, warehouses, industrial and manufacturing sites, schools, universities,
and day care centers.
Features
• Discreet, bullet-style camera with
switchable IR cut filter
• Impact and tamper resistant
• 4.0 – 9.0 mm Vari-focal Auto Iris
lens built-in
• Easy to install
• Flexible mounting options
• Wall or ceiling mount
• Available in 480 TVL and 350 TVL
versions
• Polished aluminum enclosure with
protective sunhood
• Standard line lock in 24 VAC
operation
• One power connection self-
configures to 12 VDC or 24 VAC
with transient surge protection
www.honeywellvideo.com
