Honeywell HCD484L Specifications

HCD484L/HCD484LX
TRUE DAY/NIGHT HIGH RESOLUTION COLOR CAMERA
The Honeywell HCD484L color camera is ideally suited for use in 24/7
surveillance applications. The HCD484L adapts to varying lighting conditions to
e n s u re the highest quality picture even in very low light. When the light level
d rops too low for accurate video identification in color, the camera automatically
moves the IR cut filter out of the optical path and then switches to black and
white video to capture more detail using the increased sensitivity of the CCD to
IR light. The camera uses internal logic or RS485 communication to control the
switchover from color to black and white. This improves the reliability of the
operation of the camera in difficult installations or lighting conditions.
An on-screen text menu simplifies all setup and adjustment options. Menu
navigation is simple and picture adjustments can be made in a matter of seconds
with easy-to-use pushbuttons on the back of the camera.
The HCD484L includes an automatic electronic shutter for changes in light level,
and three zones of automatic backlight compensation option for viewing backlit
scenes. The HCD484L produces 480 TV lines of resolution for applications
requiring the highest level of sharpness in video quality as well as pro v i d i n g
reliable video quality even in low light conditions down to 0.1 lux.
Market Opportunities
The Honeywell HCD484L is designed for high resolution 24/7 surveillance
applications, including those using infrared illumination. This includes general
indoor surveillance applications in retail, financial, and other commercial markets.
Combined with the HHC12 environmental housing, the HCD484L can be used as
a solution for outdoor applications such as parking lots, building entranceways,
and driveways.
Features
• 1/3" color CCD with DSP
• 480 TV lines of resolution
• True Day/Night lowlight performance
down to 0.1 lux (F1.2)
• Manual Exposure Mode for setting
shutter speed
• Automatic Electronic Shutter (AES)
• 3 Zone Automatic Backlight
Compensation (BLC)
• 12 VDC/24 VAC with line lock,
phase adjustable
• DC, Video and Manual Iris
lens support
• Phase adjustable line lock
• Improved low light sensitivity using
external IR illumination
