- Page 1 ViewSonic ® ViewBook Pro - User Guide - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Pyководство пользователя - Οδηγός χρηστών - 使用手冊(繁中) Model No. : VS13060...
- Page 2 ETSI EN 300 328 EN 301 489-01 EN 301 489-17 Notified Countries: Germany, UK, Netherlands, Belgum, Sweden, Denmark, Fnland, France, Italy, Span, Austra, Ireland, Portugal, Greece, Luxembourg, Estona, Latva, Lthuana, Czech Republc, Slovaka, Slovena, Hungary, Poland and Malta. ViewSonic VNB131...
- Page 3 Power Adapter comples wth the ratng. Only use accessores specified by the manufacturer. Check the connectons between the man unt and attachments before turnng on the notebook PC. DO NOT use the notebook PC whle eatng food, avod drtyng the notebook PC. ViewSonic VNB131...
- Page 4 Only use Battery Packs approved by the manufacturer or else damage may occur. The notebook PC has apertures to dsperse heat. DO NOT place the notebook PC on soft objects (e.g.: bed, sofa, your lap), or else the notebook PC may become hot and the system may halt. ViewSonic VNB131...
- Page 5 4. Lead as an allottng element n steel contanng up to 0.35% lead by weght, alumnum contanng up to 0.4% lead by weght and as a cooper alloy contanng up to 4% lead by weght. ViewSonic VNB131...
- Page 6 For Your Records Product Name: VNB131 VewSonc NoteBook Model Number: VS13060 Document Number: VNB131-1_UG_ENG Rev. 1B 12-14-09 Serial Number: Purchase Date: Product disposal at end of product life VewSonc s concerned about the preservaton of our envronment. Please ® dspose of ths product properly at the end of ts useful lfe. For the recyclng nformaton, please refer to our webste: 1.
-
Page 7: Table Of Contents
2.5.5 Exit Settings ..................21 Chapter 3 System Recovery ..............22 How to restore the previously backed up system in Windows ........22 Restore the backed up system under DOS mode ............25 Rescue the data under DOS mode ................28 Troubleshooting ..................31 ViewSonic VNB131... -
Page 8: Chapter 1 Introduction
Thank you for choosing ViewSonic ViewBook Pro. Please check if the packaging or any of the below listed accessories are damaged or missing, in which case please contact with ViewSonic local representative office. • ViewBook Pro notebook computer • Power Cord •... -
Page 9: Specifications
- 6 cells Li-Ion battery pack, 10.8V/47.52Wh, supports an Battery additional 3-cell Li Ion Battery Pack (Optional) - 322 x 239 x 17~25 mm Dimensions - 12.68 x 9.41 x 0.67~1 inch Weight - Less than 1.5 kg/3.30 lbs (including 3 cell Li-Ion battery pack) ViewSonic VNB131... -
Page 10: Knowing The Parts
1.3 Knowing the Parts After having checked the package and installed your ViewBook Pro, let’s get familiar with its parts. Top view ViewSonic VNB131... - Page 11 The left and right buttons function like the left and right mouse buttons. and right) Light-Emitting Diodes (LEDs) that light up to show the status of the Status indicators computer’s functions and components. Palmrest Comfortable support area for your hands when you use the computer. ViewSonic VNB131...
-
Page 12: Base View
Base view ViewSonic VNB131... - Page 13 The spring battery lock keeps the battery pack secured. When the battery pack Battery Lock - is inserted, the spring battery lock will automatically lock. When removing the Spring battery pack, this spring lock must be retained in the unlocked position. ViewSonic VNB131...
-
Page 14: Left View
Plays and records CD or DVD discs. (Optional). USB 2.0 ports Connects to USB 2.0 devices. (e.g., USB mouse, USB camera). Microphone-in jack Accepts input from external microphones. Headphones / speaker / Connects to audio line-out devices. (e.g., speakers, headphones). line-out jack ViewSonic VNB131... -
Page 15: Notebook Usage
The battery charging normally starts once the battery charge drops below 98%. First the master battery is charged. Once it is full, the secondary (optional) battery is charged. The discharge process is opposite – the secondary battery is used first and once it is empty the master battery takes over. ViewSonic VNB131... -
Page 16: Removing The Battery
3. Push the DC power connector of the power adapter into the power jack in your ViewBook Pro. ViewBook Pro is supplied with DC power of +19V @ 65W and the power adapter can accept AC 110~240V, 50~60HZ outputting +19V, 3.42A. ViewSonic VNB131... -
Page 17: Startup
ViewBook Pro turns off (cold power off). Please note that this should be used only when your OS is not responding and there is no other way to shutdown or restart, as doing the cold power off may result in a data loss. ViewSonic VNB131... -
Page 18: Indicators
When ViewBook Pro is in Sleep mode the DC socket LED would be pulsating in white color. Caps Lock Once Caps Lock is on, the LED on the Caps Lock button would be glowing. ViewSonic VNB131... -
Page 19: Touchpad
When using the touchpad, keep it — and your fingers — dry and clean. The touchpad is sensitive to finger movement, hence, the lighter the touch, the better the response. Tapping harder will not increase the touchpad’s responsiveness. ViewSonic VNB131... -
Page 20: Multi-Finger Touchpad
Multi-Finger Touchpad Start the whole new experience Scroll ViewSonic VNB131... - Page 21 Zoom Rotate Flick Press ViewSonic VNB131...
-
Page 22: Using The Keyboard
Desired access Num Lock on Num Lock off Number keys on embedded keypad Type numbers in a normal manner. Hold <Fn> while typing letters on Type the letters in a normal Main keyboard keys embedded keypad. manner. ViewSonic VNB131... -
Page 23: Windows Keys
<Fn>+<F7> Display toggle the signal to both the display screen and the external display/ projector. <Fn>+<F8> Speaker toggle Turns the speakers on and off. <Fn>+<F9> Volume up Increases the sound volume. <Fn>+<F10> Volume down Decreases the sound volume. ViewSonic VNB131... -
Page 24: Chapter 2 Bios Setup Utility
Loads the Optimal Default settings <F10> Saves the configuration changes and exits setup <PGDN> Goes to a next page <HOME> Goes to the top of the screen <PGUP> Goes to the previous page <END> Goes to the bottom of the screen ViewSonic VNB131... -
Page 25: Boot Device Priority
This item sets the time you specify (usually the current time) in the format of [Hour], [Minute] and [Second]. • System date This item sets the date you specify (usually the current date) in the format of [Month], [Date], and [Year]. • System Memory Displays the auto-detected system memory. ViewSonic VNB131... -
Page 26: Advanced Settings
Save and Ext • Set Supervisor Password Supervisor Password controls access to the setup utility. • Password on boot Enables password entry on boot. • Set Harddisk Password Harddisk Password controls access to the Harddisk and the setup utility. ViewSonic VNB131... -
Page 27: Boot Settings
Excluded from boot order Press <x> to exclude or include the device from the boot list. Use the UP and Down arrows to select a device and the <+> and <-> keys to move the device up or down. ViewSonic VNB131... -
Page 28: Exit Settings
Load Setup Defaults : Loads the default values for all setup items. • Discard Changes : Abandons your changes and reloads the previous configuration as it was before running the setup utility. • Save Changes : Saves Setup Data to CMOS. ViewSonic VNB131... -
Page 29: Chapter 3 System Recovery
If your system has not been damaged completely, you can use Windows mode to restore the system to the previously backed up state. 1. Click on the “Security Center” icon on your Desktop and choose “System Backup and Restoration”. 2. Choose “System Restoration” option in the Security Center control panel. ViewSonic VNB131... - Page 30 “Next” button. 4. As the restore point was created for the C: disk partition, there is a need to reboot to complete the restore process. Click the “Next” button and the OS will auto reboot. ViewSonic VNB131...
- Page 31 5. ViewBook Pro will auto restore the system after reboot, Windows will need few minutes to complete this task. After the system restore is complete, Windows will display the following window. Please click the “Restart” button to finish. ViewSonic VNB131...
-
Page 32: Restore The Backed Up System Under Dos Mode
1. Press the F9 key during boot to enter the Security Center. 2. Press the F9 key to enter into security center interface if you want to restore your system. 3. After pressing the F9 key, you will see the System Restoration and Rescue Data options. ViewSonic VNB131... - Page 33 5. Choose one of restore points to restore your OS and click “Start Rescue” button. All files on drive C: and settings will be deleted. System recovery will format the hard disk and restore the system to its default state. ViewSonic VNB131...
- Page 34 6. An alert will pop up after clicking the “Start Rescue” button, please click “Ok”. 7. After the restore process is complete you will see an information window. Click on the “Restart” button to finish. ViewSonic VNB131...
-
Page 35: Rescue The Data Under Dos Mode
Rescue the data under DOS mode 1. Click “Rescue Data” option in the security center to start the rescue. 2. Choose the files or folders to rescue and then click “Rescue Data”. ViewSonic VNB131... - Page 36 3. Choose the HDD partition where you would like to save the restore point to. 4. After clicking OK, the files will be backed up. ViewSonic VNB131...
- Page 37 5. Please restart your ViewBook Pro after the backup has successfully finished. 6. After the backup has finished and the system was restarted, you can copy the backup file to one of your external storage devices. ViewSonic VNB131...
-
Page 38: Troubleshooting
The power adapter is connected to the computer and to the AC power wall outlet. c) The computer power is on. (Press the power button again for confirmation.) If after following these steps the screen is still blank, please contact ViewSonic customer service. - Page 39 Your ViewBook Pro might have locked when it was entering Sleep mode while performing a communication operation. You can disable the sleep timer, if you are to leave your ViewBook Pro to download/upload files and will not be using it. ViewSonic VNB131...
- Page 40 F= 1-909-468-1202 Sngapore/ Malaysa/ www.ap.vewsonc.com T= 65 6461 6044 servce@sg.vewsonc.com Thaland South Afrca ap.vewsonc.com/za/ Contact your reseller servce@ap.vewsonc.com www.vewsonceurope.com/uk/ servce_gb@ Unted Kngdom www.vewsonceurope.com/uk/ support/call-desk/ vewsonceurope.com T (Toll-Free)= 1-800-688-6688 Unted States www.vewsonc.com T (Toll)= 1-424-233-2530 servce.us@vewsonc.com F= 1-909-468-1202 ViewSonic VNB131...
- Page 41 3. Take or shp the product freght prepad n the orgnal contaner to an authorzed VewSonc servce center or VewSonc. 4. For addtonal nformaton or the name of the nearest VewSonc servce center, contact VewSonc. 4.3: VewSonc Notebook Warranty Page 1 of 2 NB_LW01 Rev. 1a 02-11-09 ViewSonic VNB131...
- Page 42 Mantenance Guarantee Card. For users n Europe and Russa, full detals of warranty provded can be found n www.vewsonceurope. com under Support/Warranty Informaton. 4.3: VewSonc Notebook Warranty Page 2 of 2 NB_LW01 Rev. 1a 02-11-09 ViewSonic VNB131...
