Page 1 Prestige 2602R Series ADSL VoIP IAD User’s Guide Version 3.40 2/2005...
Page 2: Copyright
Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patent rights of others.
Page 3: Federal Communications Commission (Fcc) Interference Statement
Certifications Go to www.zyxel.com 1 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 2 Select the certification you wish to view from this page Federal Communications Commission (FCC) Interference Statement...
Page 4: Safety Warnings
Prestige 2602R Series User’s Guide Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. • To reduce the risk of fire, use only No. 26 AWG (American Wire Gauge) or larger telecommunication line cord.
Page 5: Zyxel Limited Warranty
Any replacement will consist of a new or re-manufactured functionally equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty shall not apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions.
Page 6: Customer Support
Prestige 2602R Series User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty Information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.
Page 7 Prestige 2602R Series User’s Guide Customer Support...
Page 8: Table Of Contents
Prestige 2602R Series User’s Guide Table of Contents Copyright ........................2 Federal Communications Commission (FCC) Interference Statement ....3 Safety Warnings ....................... 4 ZyXEL Limited Warranty..................5 Customer Support....................6 Table of Contents ..................... 8 List of Figures ......................20 List of Tables ......................
Page 9 Prestige 2602R Series User’s Guide Chapter 3 Password Setup ..................... 48 3.1 Password Overview ...................48 3.1.1 Configuring Password ................48 Chapter 4 LAN Setup....................... 50 4.1 LAN Overview ....................50 4.1.1 LANs, WANs and the Prestige ..............50 4.2 DNS Server Address ..................50 4.3 DNS Server Address Assignment ..............51...
Page 10 Prestige 2602R Series User’s Guide 5.4 Traffic Shaping ....................63 5.5 Zero Configuration Internet Access ..............64 5.6 Configuring WAN Setup ..................64 5.7 Traffic Redirect ....................70 5.8 Configuring WAN Backup ...................71 Chapter 6 Network Address Translation (NAT) Screens ............74 6.1 NAT Overview ....................74 6.1.1 NAT Definitions ..................74...
Page 11 Prestige 2602R Series User’s Guide 7.6 PSTN Call Setup Signaling ................91 Chapter 8 Voice Screens ......................92 8.1 Voice Screens Introduction ................92 8.2 SIP Settings Configuration .................92 8.3 Advanced Voice Settings Configuration .............93 8.4 Quality of Service (QoS) ..................95 8.4.1 Type Of Service (ToS) ................95 8.4.2 DiffServ .....................96...
Page 12 Prestige 2602R Series User’s Guide 11.4 Web ........................112 11.5 Configuring Remote Management ..............112 Chapter 12 Universal Plug-and-Play (UPnP) ................. 114 12.1 Introducing Universal Plug and Play ..............114 12.1.1 How do I know if I'm using UPnP? ............114 12.1.2 NAT Traversal ..................114 12.1.3 Cautions with UPnP ................114...
Page 13 Prestige 2602R Series User’s Guide Chapter 18 Introducing the SMT .................... 144 18.1 Introduction to the SMT ..................144 18.1.1 Procedure for SMT Configuration via Telnet .........144 18.1.2 Entering Password ................144 18.1.3 Prestige SMT Menu Overview ..............144 18.2 Navigating the SMT Interface .................146 18.2.1 System Management Terminal Interface Summary ......148...
Page 14 Prestige 2602R Series User’s Guide 23.2.2 Encapsulation and Multiplexing Scenarios ...........167 23.2.2.1 Scenario 1: One VC, Multiple Protocols ........167 23.2.2.2 Scenario 2: One VC, One Protocol (IP) ........167 23.2.2.3 Scenario 3: Multiple VCs .............167 23.2.3 Outgoing Authentication Protocol ............169 23.3 Remote Node Network Layer Options ............170 23.3.1 My WAN Addr Sample IP Addresses ...........171...
Page 15 Prestige 2602R Series User’s Guide Chapter 27 Filter Configuration ....................200 27.1 About Filtering ....................200 27.1.1 The Filter Structure of the Prestige ............201 27.2 Configuring a Filter Set for the Prestige ............202 27.3 Filter Rules Summary Menus .................203 27.4 Configuring a Filter Rule ................204 27.4.1 TCP/IP Filter Rule .................205...
Page 16 Prestige 2602R Series User’s Guide 30.2.5 TFTP and FTP over WAN Management Limitations ......231 30.2.6 Backup Configuration Using TFTP ............232 30.2.7 TFTP Command Example ..............232 30.2.8 GUI-based TFTP Clients ..............232 30.2.9 Backup Via Console Port ..............233 30.3 Restore Configuration ..................234 30.3.1 Restore Using FTP ................234...
Page 17 35.6.2 JavaScripts ...................272 35.6.3 Java Permissions ..................274 Appendix A Hardware Specifications ..................278 Ethernet Cable Pin Assignments ................278 Prestige 2602R Series Power Adaptor Specifications ........... 279 Appendix B Setting up Your Computer’s IP Address............280 Windows 95/98/Me....................280 Configuring ...................... 282 Verifying Settings .....................
Page 18 Prestige 2602R Series User’s Guide IP Addressing......................292 IP Classes ......................292 Subnet Masks ......................293 Subnetting ......................294 Example: Two Subnets ..................294 Example: Four Subnets..................296 Example Eight Subnets ..................297 Subnetting With Class A and Class B Networks............ 298 Appendix D PPPoE ........................
Page 19 Prestige 2602R Series User’s Guide Table of Contents...
Page 20: List Of Figures
Prestige 2602R Series User’s Guide List of Figures Figure 1 Prestige Internet Access Application ..............40 Figure 2 Internet Telephone Service Provider Application ..........41 Figure 3 IP-PBX Application ....................42 Figure 4 Prestige LAN-to-LAN Application ................42 Figure 5 Password Screen ....................44 Figure 6 Change Password at Login ...................
Page 21 Prestige 2602R Series User’s Guide Figure 39 Time and Date ..................... 107 Figure 40 Telnet Configuration on a TCP/IP Network ............111 Figure 41 Remote Management ..................112 Figure 42 Configuring UPnP ....................115 Figure 43 Add/Remove Programs: Windows Setup: Communication ......... 116 Figure 44 Add/Remove Programs: Windows Setup: Communication: Components ..
Page 22 Prestige 2602R Series User’s Guide Figure 82 IP Alias Network Example ................... 161 Figure 83 Menu 3.2 TCP/IP and DHCP Setup ..............161 Figure 84 Menu 3.2.1 IP Alias Setup .................. 162 Figure 85 Menu 1 General Setup ..................163 Figure 86 Menu 4 Internet Access Setup ................
Page 23 Prestige 2602R Series User’s Guide Figure 125 Example 4: Menu 15.1.1 Address Mapping Rules ..........198 Figure 126 Outgoing Packet Filtering Process ..............200 Figure 127 Filter Rule Process .................... 201 Figure 128 Menu 21 Filter Set Configuration ..............202 Figure 129 NetBIOS_WAN Filter Rules Summary .............
Page 24 Prestige 2602R Series User’s Guide Figure 168 Menu 24.7.1 As Seen Using the Console Port ..........240 Figure 169 Example Xmodem Upload ................241 Figure 170 Menu 24.7.2 As Seen Using the Console Port ..........241 Figure 171 Example Xmodem Upload ................242 Figure 172 Command Mode in Menu 24 ................
Page 25 Prestige 2602R Series User’s Guide Figure 211 Macintosh OS X: Apple Menu ................290 Figure 212 Macintosh OS X: Network ................. 290 Figure 213 Single-Computer per Router Hardware Configuration ........301 Figure 214 Prestige as a PPPoE Client ................301 Figure 215 Configuration Text File Format: Column Descriptions ........
Page 26: List Of Tables
Prestige 2602R Series User’s Guide List of Tables Table 1 ADSL Standards ....................34 Table 2 Password ....................... 48 Table 3 LAN Setup ......................57 Table 4 LAN: Static DHCP ....................59 Table 5 WAN Setup ......................68 Table 6 WAN Backup ......................72 Table 7 NAT Definitions ......................
Page 27 Prestige 2602R Series User’s Guide Table 39 Menu 1 General Setup ..................151 Table 40 Menu 1.1 Configure Dynamic DNS ..............152 Table 41 Menu 2 WAN Backup Setup ................154 Table 42 Menu 2.1Traffic Redirect Setup ................155 Table 43 DHCP Ethernet Setup ..................157 Table 44 TCP/IP Ethernet Setup ..................
Page 28 Prestige 2602R Series User’s Guide Table 82 Troubleshooting Voice Calls ................269 Table 83 Prestige 2602R Series Power Adaptor Specifications ......... 279 Table 84 Classes of IP Addresses ..................292 Table 85 Allowed IP Address Range By Class ..............293 Table 86 “Natural”...
Page 29 Prestige 2602R Series User’s Guide List of Tables...
Page 30: Preface
Congratulations on your purchase of the Prestige 2602R Series ADSL VoIP IAD. Models in the series ending in “1”, for example Prestige 2602R-61, denote a device that works over the analog telephone system, POTS (Plain Old Telephone Service). Models ending in “3” denote a device that works over ISDN (Integrated Services Digital Network).
Page 31 • For brevity’s sake, we will use “e.g.,” as a shorthand for “for instance”, and “i.e.,” for “that is” or “in other words” throughout this manual. • The Prestige 2602R series may be referred to as the Prestige in this user’s guide. This refers to both models (ADSL over POTS and ADSL over ISDN) unless specifically identified.
Page 32: Introduction To Dsl
Prestige 2602R Series User’s Guide Introduction to DSL DSL (Digital Subscriber Line) technology enhances the data capacity of the existing twisted- pair wire that runs between the local telephone company switching offices and most homes and offices. While the wire itself can handle higher frequencies, the telephone switching...
Page 33 Prestige 2602R Series User’s Guide Introduction to DSL...
Page 34: Getting To Know Your Prestige
Prestige 2602R Series User’s Guide H A P T E R Getting To Know Your Prestige Prestige. This chapter describes the key features and applications of your Introducing the Prestige The Prestige P2602R ADSL VoIP IAD (Integrated Access Device) combines high-speed ADSL Internet access and Voice over IP (VoIP) communication capabilities.
Page 35: Features Of The Prestige
Prestige 2602R Series User’s Guide 1.2 Features of the Prestige The following sections describe the features of the Prestige. A Ringer Equivalence Number is used to determine the number of devices that may be connected to the telephone line. The Prestige can support three devices per telephone port.
Page 36 Prestige supports Type of Service (ToS) and Differentiated Services (DiffServ). This allows the Prestige to tag voice frames so they can be prioritized over the network. SIP ALG The Prestige 2602R is a SIP Application Layer Gateway (ALG). It allows VoIP calls to pass through NAT. Auto-provisioning Auto-provisioning automatically updates your Prestige’s configurable settings via a TFTP...
Page 37 Prestige 2602R Series User’s Guide Universal Plug and Play (UPnP) Using the standard TCP/IP protocol, the Prestige and other UPnP enabled devices can dynamically join a network, obtain an IP address and convey its capabilities to other devices on the network.
Page 38 Prestige 2602R Series User’s Guide • Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.lite (G992.2)). • TCP/IP (Transmission Control Protocol/Internet Protocol) network layer protocol. • ATM Forum UNI 3.1/4.0 PVC. • Supports up to 8 PVCs (UBR, CBR, VBR).
Page 39 Prestige 2602R Series User’s Guide Networking Compatibility Your Prestige is compatible with the major ADSL DSLAM (Digital Subscriber Line Access Multiplexer) providers, making configuration as simple as possible for you. Multiplexing The Prestige supports VC-based and LLC-based multiplexing. Encapsulation The Prestige supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483 encapsulation over ATM, MAC encapsulated routing (ENET encapsulation) as well as PPP over Ethernet (RFC 2516).
Page 40: Applications For The Prestige
Prestige 2602R Series User’s Guide Packet Filters The Prestige's packet filtering functions allows added network security and management. Ease of Installation Your Prestige is designed for quick, intuitive and easy installation. Housing Your Prestige's compact and ventilated housing minimizes space requirements making it easy to position anywhere in your busy office.
Page 41: Making Calls Via Ip-Pbx
Prestige 2602R Series User’s Guide The following figure shows a basic example of how you would make a VoIP call through an ITSP. You use your analog phone (A in the figure) and the Prestige (B) changes the call into VoIP.
Page 42: Lan To Lan Application
Prestige 2602R Series User’s Guide Figure 3 IP-PBX Application 1.3.4 LAN to LAN Application You can use the Prestige to connect two geogr ly dispersed networks over the ADSL line. aphical A typical LAN-to-LAN application for your Prestige is shown as follows.
Page 43 Prestige 2602R Series User’s Guide Chapter 1 Getting To Know Your Prestige...
Page 44: Introducing The Web Configurator
Prestige 2602R Series User’s Guide H A P T E R Introducing the Web Configurator This chapter describes how to access and navigate the web configurator. 2.1 Web Configurator Overview The embedded web configurator allows you to manage the Prestige from anywhere through a browser such as Microsoft Internet Explorer or Netscape Navigator.
Page 45: Resetting The Prestige
2.1.3 Navigating the Prestige Web Configurator The following summarizes how to navigate the web configurator from the SITE MAP screen. We use the Prestige 2602R-61 web screens in this guide as an example. Screens vary slightly for different Prestige models.
Page 46: Wizard Setup
Prestige 2602R Series User’s Guide Figure 7 Web Configurator SITE MAP Screen Click the icon (located in the top right corner of most screens) to view embedded help. 2.2 Wizard Setup Please see the Quick Start Guide for information on the Wizard Setup screens for Internet access and VoIP in the web configurator.
Page 47 Prestige 2602R Series User’s Guide Chapter 2 Introducing the Web Configurator...
Page 48: Chapter 3 Password Setup
Prestige 2602R Series User’s Guide H A P T E R Password Setup 3.1 Password Overview It is highly recommended that you change the password for accessing the Prestige. 3.1.1 Configuring Password To change your Prestige’s password (recommended), click Password in the Site Map screen.
Page 49 Prestige 2602R Series User’s Guide Chapter 3 Password Setup...
Page 50: Chapter 4 Lan Setup
Prestige 2602R Series User’s Guide H A P T E R LAN Setup 4.1 LAN Overview A Local Area Network (LAN) is a shared communication system to which many computers are attached. A LAN is a computer network limited to the immediate area, usually the same building or floor of a building.
Page 51: Dns Server Address Assignment
Prestige 2602R Series User’s Guide There are two ways that an ISP disseminates the DNS server addresses. The first is for an ISP to tell a customer the DNS server addresses, usually in the form of an information sheet, when s/he signs up.
Page 52: Ip Address And Subnet Mask
Prestige 2602R Series User’s Guide • DHCP server enabled with 32 client IP addresses starting from 192.168.1.33. These parameters should work for the majority of installations. If your ISP gives you explicit DNS server address(es), read the embedded web configurator help regarding what fields need to be configured.
Page 53: Ip Assignment With Rfc 1483 Encapsulation
Prestige 2602R Series User’s Guide 4.5.1.2 IP Assignment with RFC 1483 Encapsulation In this case the IP Address Assignment must be static with the same requirements for the IP Address and ENET ENCAP Gateway fields as stated above. 4.5.1.3 IP Assignment with ENET ENCAP Encapsulation In this case you can have either a static or dynamic IP.
Page 54: Ip Pool Setup
Prestige 2602R Series User’s Guide 4.5.2.1 IP Pool Setup The Prestige is pre-configured with a pool of IP addresses for the DHCP clients (DHCP Pool). See the product specifications in the appendices. Do not assign static IP addresses from the Prestige-assigned DHCP pool to your LAN computers.
Page 55: Any Ip
Prestige 2602R Series User’s Guide The Prestige supports both IGMP version 1 (IGMP-v1) and IGMP version 2 (IGMP-v2). At start up, the Prestige queries all directly connected networks to gather group membership. After that, the Prestige periodically updates this information. IP multicasting can be enabled/ disabled on the Prestige LAN and/or WAN interfaces in the web configurator (LAN;...
Page 56: How Any Ip Works
Prestige 2602R Series User’s Guide Note: You must enable NAT/SUA to use the Any IP feature on the Prestige. 4.6.1 How Any IP Works Address Resolution Protocol (ARP) is a protocol for mapping an Internet Protocol address (IP address) to a physical machine address, also known as a Media Access Control or MAC address, on the local area network.
Page 57: Figure 11 Lan Setup
Prestige 2602R Series User’s Guide Figure 11 LAN Setup The following table describes the fields in this screen. Table 3 LAN Setup LABEL DESCRIPTION DHCP DHCP If set to Server, your Prestige can assign IP addresses, an IP default gateway and DNS servers to Windows 95, Windows NT and other systems that support the DHCP client.
Page 58: Configuring Static Dhcp
Prestige 2602R Series User’s Guide Table 3 LAN Setup (continued) LABEL DESCRIPTION Secondary DNS As above. Server Remote DHCP If Relay is selected in the DHCP field above then enter the IP address of the Server actual remote DHCP server here.
Page 59: Figure 12 Lan: Static Dhcp
Prestige 2602R Series User’s Guide Figure 12 LAN: Static DHCP The following table describes the labels in this screen. Table 4 LAN: Static DHCP LABEL DESCRIPTION This is the index number of the Static IP table entry (row). MAC Address Type the MAC address (with colons) of a computer on your LAN.
Page 60: Chapter 5 Wan Setup
Prestige 2602R Series User’s Guide H A P T E R WAN Setup 5.1 WAN Overview A WAN (Wide Area Network) is an outside connection to another network or the Internet. 5.1.1 Encapsulation Be sure to use the encapsulation method required by your ISP. The Prestige supports the following methods.
Page 61: Rfc 1483
Prestige 2602R Series User’s Guide 5.1.1.4 RFC 1483 RFC 1483 describes two methods for Multiprotocol Encapsulation over ATM Adaptation Layer 5 (AAL5). The first method allows multiplexing of multiple protocols over a single ATM virtual circuit (LLC-based multiplexing) and the second method assumes that each protocol is carried over a separate ATM virtual circuit (VC-based multiplexing).
Page 62: Metric
Prestige 2602R Series User’s Guide 5.2 Metric The metric represents the "cost of transmission". A router determines the best route for transmission by choosing a path with the lowest "cost". RIP routing uses hop count as the measurement of cost, with a minimum of "1" for directly connected networks. The number must be between "1"...
Page 63: Traffic Shaping
Prestige 2602R Series User’s Guide By implementing PPPoE directly on the Prestige (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the Prestige does that part of the task. Furthermore, with NAT, all of the LANs’ computers will have access.
Page 64: Zero Configuration Internet Access
Prestige 2602R Series User’s Guide Figure 13 Example of Traffic Shaping 5.5 Zero Configuration Internet Access Once you turn on and connect the Prestige to a telephone jack, it automatically detects the Internet connection settings (such as the VCI/VPI numbers and the encapsulation method) from the ISP and makes the necessary configuration changes.
Page 65: Figure 14 Wan (Rfc 1483)
Prestige 2602R Series User’s Guide Figure 14 WAN (RFC 1483) Chapter 5 WAN Setup...
Page 66: Figure 15 Wan (Pppoa)
Prestige 2602R Series User’s Guide Figure 15 WAN (PPPoA) Chapter 5 WAN Setup...
Page 67: Figure 16 Wan (Enet (Encap)
Prestige 2602R Series User’s Guide Figure 16 WAN (ENET (ENCAP) Chapter 5 WAN Setup...
Page 68: Figure 17 Wan Setup (Pppoe)
Prestige 2602R Series User’s Guide Figure 17 WAN Setup (PPPoE) The following table describes the fields in this screen. Table 5 WAN Setup LABEL DESCRIPTION Name Enter the name of your Internet Service Provider, e.g., MyISP. This information is for identification purposes only.
Page 69 Prestige 2602R Series User’s Guide Table 5 WAN Setup (continued) LABEL DESCRIPTION Encapsulation Select the method of encapsulation used by your ISP from the drop-down list box. Choices vary depending on the mode you select in the Mode field. If you select Bridge in the Mode field, select either PPPoA or RFC 1483.
Page 70: Traffic Redirect
Prestige 2602R Series User’s Guide Table 5 WAN Setup (continued) LABEL DESCRIPTION Connect on Demand Select Connect on Demand when you don't want the connection up all the time and specify an idle time-out in the Max Idle Timeout field.
Page 71: Configuring Wan Backup
Prestige 2602R Series User’s Guide Figure 18 Traffic Redirect Example The following network topology allows you to avoid triangle route security issues when the backup gateway is connected to the LAN. Use IP alias to configure the LAN into two or three logical networks with the Prestige itself as the gateway for each LAN network.
Page 72: Figure 20 Wan Backup
Prestige 2602R Series User’s Guide Figure 20 WAN Backup The following table describes the fields in this screen. Table 6 WAN Backup LABEL DESCRIPTION Backup Type Select the method that the Prestige uses to check the DSL connection. Select DSL Link to have the Prestige check if the connection to the DSLAM is up.
Page 73 Prestige 2602R Series User’s Guide Table 6 WAN Backup (continued) LABEL DESCRIPTION Timeout Type the number of seconds (3 recommended) for your Prestige to wait for a ping response from one of the IP addresses in the Check WAN IP Address field before timing out the request.
Page 74: Network Address Translation (Nat) Screens
Prestige 2602R Series User’s Guide H A P T E R Network Address Translation (NAT) Screens 6.1 NAT Overview NAT (Network Address Translation - NAT, RFC 1631) is the translation of the IP address of a host in a packet, for example, the source address of an outgoing packet, used within one network to a different IP address known within another network.
Page 75: What Nat Does
Prestige 2602R Series User’s Guide 6.1.2 What NAT Does In the simplest form, NAT changes the source IP address in a packet received from a subscriber (the inside local address) to another (the inside global address) before forwarding the packet to the WAN side. When the response comes back, NAT translates the destination address (the inside global address) back to the inside local address before forwarding it to the original inside host.
Page 76: Nat Application
Prestige 2602R Series User’s Guide Figure 21 How NAT Works 6.1.4 NAT Application The following figure illustrates a possible NAT application, where three inside LANs (logical LANs using IP Alias) behind the Prestige can communicate with three distinct WAN networks. More examples follow at the end of this chapter.
Page 77: Sua (Single User Account) Versus Nat
• Many to One: In Many-to-One mode, the Prestige maps multiple local IP addresses to one global IP address. This is equivalent to SUA (for instance, PAT, port address translation), ZyXEL’s Single User Account feature that previous ZyXEL routers supported (the SUA Only option in today’s routers).
Page 78: Sua Server
Prestige 2602R Series User’s Guide 6.3 SUA Server A SUA server set is a list of inside (behind NAT on the LAN) servers, for example, web or FTP, that you can make visible to the outside world even though SUA makes your whole inside network appear as a single computer to the outside world.
Page 79: Configuring Servers Behind Sua (Example)
Prestige 2602R Series User’s Guide 6.3.3 Configuring Servers Behind SUA (Example) Let's say you want to assign ports 21-25 to one FTP, Telnet and SMTP server (A in the example), port 80 to another (B in the example) and assign a default server IP address of 192.168.1.35 to a third (C in the example).
Page 80: Configuring Sua Server
Prestige 2602R Series User’s Guide Table 10 NAT Mode (continued) LABEL DESCRIPTION Full Feature Select this radio button if you have multiple public WAN IP addresses for your Prestige. Edit Details Click this link to go to the NAT - Address Mapping Rules screen.
Page 81: Figure 25 Edit Sua/Nat Server Set
Prestige 2602R Series User’s Guide Figure 25 Edit SUA/NAT Server Set The following table describes the fields in this screen. Table 11 Edit SUA/NAT Server Set LABEL DESCRIPTION Start Port No. Enter a port number in this field. To forward only one port, enter the port number again in the End Port No. field.
Page 82: Configuring Address Mapping
Prestige 2602R Series User’s Guide 6.6 Configuring Address Mapping Ordering your rules is important because the Prestige applies the rules in the order that you specify. When a rule matches the current packet, the Prestige takes the corresponding action and the remaining rules are ignored. If there are any empty rules before your new configured rule, your configured rule will be pushed up by that number of empty rules.
Page 83: Editing An Address Mapping Rule
One-to-one NAT mapping type. M-1: Many-to-One mode maps multiple local IP addresses to one global IP address. This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only.
Page 84: Table 13 Address Mapping Rule Edit
• Many-to-One: Many-to-One mode maps multiple local IP addresses to one global IP address. This is equivalent to SUA (i.e., PAT, port address translation), ZyXEL's Single User Account feature that previous ZyXEL routers supported only. • Many-to-Many Overload: Many-to-Many Overload mode maps multiple local IP addresses to shared global IP addresses.
Page 85 Prestige 2602R Series User’s Guide Chapter 6 Network Address Translation (NAT) Screens...
Page 86: Introduction To Voip
Prestige 2602R Series User’s Guide H A P T E R Introduction to VoIP This chapter provides background information on VoIP and SIP. 7.1 Introduction to VoIP VoIP is the sending of voice signals over the Internet Protocol. This allows you to make phone calls and send faxes over the Internet at a fraction of the cost of using the traditional circuit- switched telephone network.
Page 87: Sip Service Domain
Prestige 2602R Series User’s Guide 7.2.1.2 SIP Service Domain A SIP service domain is the domain name that comes after the @ symbol in a SIP URI. For example, if 1122334455@VoIP-provider.com was your SIP URI, “VoIP-provider.com” is the SIP service domain.
Page 88: Sip User Agent
Prestige 2602R Series User’s Guide 7.2.3.1 SIP User Agent A SIP user agent server can make and receive VoIP telephone calls. This means that SIP can be used for peer-to-peer communications even though it is a client-server protocol. In the following figure, either A or B can act as a SIP user agent client to initiate a call.
Page 89: Sip Redirect Server
Prestige 2602R Series User’s Guide Figure 29 SIP Proxy Server 7.2.3.3 SIP Redirect Server A SIP redirect server accepts SIP requests, translates the destination address to an IP address and sends the translated IP address back to the device that sent the request. Then the client device that originally sent the request can send requests to the IP address that it received back from the redirect server.
Page 90: Sip Register Server
When a VoIP device behind the Prestige registers with the SIP register server, the Prestige translates the device’s private IP address inside the SIP data stream to a public IP address. You do not need to use STUN with a VoIP device that is behind the Prestige 2602R. 7.4 Pulse Code Modulation Pulse Code Modulation (PCM) measures analog signal amplitudes at regular time intervals and converts them into bits.
Page 91: Voice Coding
Prestige 2602R Series User’s Guide 7.5 Voice Coding A codec (coder/decoder) codes analog voice signals into digital signals and decodes the digital signals back into voice signals. The Prestige supports the following codecs. 7.5.1 G.711 G.711 is a Pulse Code Modulation (PCM) waveform codec. G.711 provides very good sound quality but requires 64kbps of bandwidth.
Page 92: Chapter 8 Voice Screens
Prestige 2602R Series User’s Guide H A P T E R Voice Screens This chapter describes how to configure advanced VoIP, QoS, phone and phone book settings. 8.1 Voice Screens Introduction This chapter covers the configuration of the VoIP screens.
Page 93: Advanced Voice Settings Configuration
Prestige 2602R Series User’s Guide Table 15 SIP Settings LABEL DESCRIPTION SIP Account You can configure the Prestige to use multiple SIP accounts. Select one to configure its settings on the Prestige. Active SIP Select this check box to have the Prestige use this SIP account. Clear the check box to have the Prestige not use this SIP account.
Page 94: Figure 32 Voice Advanced Setup
Prestige 2602R Series User’s Guide Figure 32 Voice Advanced Setup The following table describes the labels in this screen. Table 16 Voice Advanced Setup LABEL DESCRIPTION Advanced VoIP This read-only field displays the number of the SIP account that you are Settings configuring.
Page 95: Quality Of Service (Qos)
Prestige 2602R Series User’s Guide Table 16 Voice Advanced Setup (continued) LABEL DESCRIPTION Min-SE When two SIP devices negotiate a SIP session, they must negotiate a common expiration time for idle SIP sessions. This field sets the shortest expiration time that the Prestige will accept.
Page 96: Diffserv
Prestige 2602R Series User’s Guide 8.4.2 DiffServ DiffServ is a class of service (CoS) model that marks packets so that they receive specific per- hop treatment at DiffServ-compliant network devices along the route based on the application types and traffic flow. Packets are marked with DiffServ Code Points (DSCPs) indicating the level of service desired.
Page 97: Phone
Prestige 2602R Series User’s Guide Figure 34 QoS The following table describes the labels in this screen. Table 17 QoS LABEL DESCRIPTION SIP TOS Priority Type a priority for voice transmissions. The Prestige applies Type of Service priority tags with this priority to voice traffic that it transmits. Priorities 6 and 7 are reserved for network control traffic.
Page 98: Voice Activity Detection/Silence Suppression
Prestige 2602R Series User’s Guide 8.6.1 Voice Activity Detection/Silence Suppression Voice Activity Detection (VAD) detects whether or not speech is present. This lets the Prestige reduce the bandwidth that a call uses by not transmitting “silent packets” when you are not speaking.
Page 99: Speed Dial
SIP INVITE requests to the peer VoIP device when you use the speed dial entry. You do not need to configure a SIP account on the Prestige 2602R in order to make a peer-to- peer VoIP call. You must still configure a SIP account on the Prestige 2602RL in order to make a peer-to-peer VoIP call.
Page 100: Speed Dial Configuration
Prestige 2602R Series User’s Guide 8.9 Speed Dial Configuration Click Voice in the navigation panel and then Speed Dial to display the following screen. Figure 36 Speed Dial The following table describes the labels in this screen. Table 19 Speed Dial...
Page 101: Lifeline (Prestige 2602Rl)
Prestige 2602R Series User’s Guide Table 19 Speed Dial (continued) LABEL DESCRIPTION Speed Dial Phone This section of the screen displays the currently saved speed dial entries. You can Book configure up to 10 entries and use them to make calls.
Page 102: Figure 37 Lifeline
Prestige 2602R Series User’s Guide Figure 37 Lifeline The following table describes the labels in this screen. Table 20 Lifeline LABEL DESCRIPTION PSTN Pre-fix Specify the prefix number for dialing regular calls when the VoIP service is Number available. Relay to PSTN Use these fields to specify phone numbers to which the Prestige will always send calls through the regular phone service without the need of dialing a prefix number.
Page 103 Prestige 2602R Series User’s Guide Chapter 8 Voice Screens...
Page 104: Chapter 9 Dynamic Dns Setup
Prestige 2602R Series User’s Guide H A P T E R Dynamic DNS Setup 9.1 Dynamic DNS Dynamic DNS allows you to update your current dynamic IP address with one or many dynamic DNS services so that anyone can contact you (in NetMeeting, CU-SeeMe, etc.). You can also access your FTP server or Web site on your own computer using a domain name (for instance myhost.dhs.org, where myhost is a name of your choice) that will never change...
Page 105: Figure 38 Dynamic Dns
Prestige 2602R Series User’s Guide Figure 38 Dynamic DNS The following table describes the fields in this screen. Table 21 Dynamic DNS LABEL DESCRIPTION Active Select this check box to use dynamic DNS. Service Provider This is the name of your Dynamic DNS service provider.
Page 106: Chapter 10 Time And Date
Prestige 2602R Series User’s Guide H A P T E R Time and Date 10.1 Pre-defined NTP Time Servers List The Prestige uses the following pre-defined list of NTP time servers if you do not specify a time server or it cannot synchronize with the time server you specified.
Page 107: Figure 39 Time And Date
Prestige 2602R Series User’s Guide Figure 39 Time and Date The following table describes the fields in this screen. Table 23 Time and Date LABEL DESCRIPTION Time Server Use Protocol when Select the time service protocol that your time server sends when you turn on the Bootup Prestige.
Page 108 Prestige 2602R Series User’s Guide Table 23 Time and Date (continued) LABEL DESCRIPTION Start Date Enter the month and day that your daylight-savings time starts on if you selected Daylight Savings. End Date Enter the month and day that your daylight-savings time ends on if you selected Daylight Savings.
Page 109 Prestige 2602R Series User’s Guide Chapter 10 Time and Date...
Page 110: Remote Management Configuration
Prestige 2602R Series User’s Guide H A P T E R Remote Management Configuration 11.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers. When you configure remote management to allow management from the WAN, you still need to configure a firewall rule to allow access.
Page 111: Remote Management And Nat
Prestige 2602R Series User’s Guide • You have disabled that service in one of the remote management screens. • The IP address in the Secured Client IP field does not match the client IP address. If it does not match, the Prestige will disconnect the session immediately.
Page 112: Web
Prestige 2602R Series User’s Guide 11.4 Web You can use the Prestige’s embedded web configurator for configuration and file management. See the online help for details. 11.5 Configuring Remote Management Click Remote Management to open the following screen. Figure 41 Remote Management The following table describes the fields in this screen.
Page 113 Prestige 2602R Series User’s Guide Chapter 11 Remote Management Configuration...
Page 114: Universal Plug-And-Play (Upnp)
Prestige 2602R Series User’s Guide H A P T E R Universal Plug-and-Play (UPnP) 12.1 Introducing Universal Plug and Play Universal Plug and Play (UPnP) is a distributed, open networking standard that uses TCP/IP for simple peer-to-peer network connectivity between devices. A UPnP device can dynamically join a network, obtain an IP address, convey its capabilities and learn about other devices on the network.
Page 115: Upnp And Zyxel
Prestige 2602R Series User’s Guide 12.2 UPnP and ZyXEL ZyXEL has achieved UPnP certification from the Universal Plug and Play Forum Creates UPnP™ Implementers Corp. (UIC). ZyXEL's UPnP implementation supports IGD 1.0 (Internet Gateway Device). At the time of writing ZyXEL's UPnP implementation supports Windows Messenger 4.6 and 4.7 while Windows Messenger 5.0 and Xbox are still being...
Page 116: Installing Upnp In Windows Example
Prestige 2602R Series User’s Guide 12.3 Installing UPnP in Windows Example This section shows how to install UPnP in Windows Me and Windows XP. Installing UPnP in Windows Me Follow the steps below to install the UPnP in Windows Me.
Page 117: Figure 44 Add/Remove Programs: Windows Setup: Communication: Components
Prestige 2602R Series User’s Guide Figure 44 Add/Remove Programs: Windows Setup: Communication: Components 4 Click OK to go back to the Add/Remove Programs Properties window and click Next. 5 Restart the computer when prompted. Installing UPnP in Windows XP Follow the steps below to install the UPnP in Windows XP.
Page 118: Figure 46 Windows Optional Networking Components Wizard
Prestige 2602R Series User’s Guide Figure 46 Windows Optional Networking Components Wizard 5 In the Networking Services window, select the Universal Plug and Play check box. Chapter 12 Universal Plug-and-Play (UPnP)
Page 119: Using Upnp In Windows Xp Example
Prestige 2602R Series User’s Guide Figure 47 Networking Services 6 Click OK to go back to the Windows Optional Networking Component Wizard window and click Next. 12.4 Using UPnP in Windows XP Example This section shows you how to use the UPnP feature in Windows XP. You must already have UPnP installed in Windows XP and UPnP activated on the Prestige.
Page 120: Figure 48 Network Connections
Prestige 2602R Series User’s Guide Figure 48 Network Connections 3 In the Internet Connection Properties window, click Settings to see the port mappings there were automatically created. Chapter 12 Universal Plug-and-Play (UPnP)
Page 121: Figure 49 Internet Connection Properties
Prestige 2602R Series User’s Guide Figure 49 Internet Connection Properties 4 You may edit or delete the port mappings or click Add to manually add port mappings. Chapter 12 Universal Plug-and-Play (UPnP)
Page 122: Figure 50 Internet Connection Properties: Advanced Settings
Prestige 2602R Series User’s Guide Figure 50 Internet Connection Properties: Advanced Settings Figure 51 Internet Connection Properties: Advanced Settings: Add 5 When the UPnP-enabled device is disconnected from your computer, all port mappings will be deleted automatically. 6 Select Show icon in notification area when connected option and click OK. An icon displays in the system tray.
Page 123: Figure 52 System Tray Icon
Prestige 2602R Series User’s Guide Figure 52 System Tray Icon 7 Double-click on the icon to display your current Internet connection status. Figure 53 Internet Connection Status Web Configurator Easy Access With UPnP, you can access the web-based configurator on the Prestige without finding out the IP address of the Prestige first.
Page 124: Figure 54 Network Connections
Prestige 2602R Series User’s Guide Figure 54 Network Connections 4 An icon with the description for each UPnP-enabled device displays under Local Network. 5 Right-click on the icon for your Prestige and select Invoke. The web configurator login screen displays.
Page 125: Figure 55 Network Connections: My Network Places
Prestige 2602R Series User’s Guide Figure 55 Network Connections: My Network Places 6 Right-click on the icon for your Prestige and select Properties. A properties window displays with basic information about the Prestige. Figure 56 Network Connections: My Network Places: Properties: Example...
Page 126: Chapter 13 Logs Screens
Prestige 2602R Series User’s Guide H A P T E R Logs Screens 13.1 Logs Overview The web configurator allows you to choose which categories of events and/or alerts to have the Prestige log and then display the logs or have the Prestige send them to an administrator (as e-mail) or to a syslog server.
Page 127: Figure 57 Log Settings
Prestige 2602R Series User’s Guide Figure 57 Log Settings The following table describes the fields in this screen. Table 26 Log Settings LABEL DESCRIPTION Address Info Mail Server Enter the server name or the IP address of the mail server for the e-mail addresses specified below.
Page 128: Displaying The Logs
Prestige 2602R Series User’s Guide Table 26 Log Settings (continued) LABEL DESCRIPTION Send alerts to Alerts are sent to the e-mail address specified in this field. If this field is left blank, alerts will not be sent via e-mail. UNIX Syslog Syslog logging sends a log to an external syslog server used to store logs.
Page 129: Smtp Error Messages
Prestige 2602R Series User’s Guide Figure 58 View Logs The following table describes the fields in this screen. Table 27 View Logs LABEL DESCRIPTION Display The categories that you select in the Log Settings screen (see section ) display in the drop-down list box.
Page 130: Example E-Mail Log
Prestige 2602R Series User’s Guide Table 28 SMTP Error Messages (continued) -6 means RCPT TO fail -7 means DATA fail -8 means mail data send fail 13.4.1 Example E-mail Log An "End of Log" message displays for each mail in which a complete log has been sent. The following is an example of a log sent by e-mail.
Page 131 Prestige 2602R Series User’s Guide Chapter 13 Logs Screens...
Page 132: Chapter 14 System Status Screen
Prestige 2602R Series User’s Guide H A P T E R System Status Screen Click System Status to open the following screen, where you can use to monitor your Prestige. Note that these fields are READ-ONLY and only for diagnostic purposes.
Page 133: Figure 60 System Status
Prestige 2602R Series User’s Guide Figure 60 System Status Chapter 14 System Status Screen...
Page 134: Table 29 System Status
System Status System Name This is the name of your Prestige. It is for identification purposes. ZyNOS Firmware This is the ZyNOS firmware version and the date created. ZyNOS is ZyXEL's Version proprietary Network Operating System design. DSL FW Version This is the DSL firmware version associated with your Prestige.
Page 135: System Statistics
Prestige 2602R Series User’s Guide 14.0.1 System Statistics Click Show Statistics in the System Status screen to open the following screen. Read-only information here includes port status and packet specific statistics. Also provided are "system up time" and "poll interval(s)". The Poll Interval(s) field is configurable.
Page 136 Prestige 2602R Series User’s Guide Table 30 System Status: Show Statistics (continued) LABEL DESCRIPTION TxPkts This field displays the number of packets transmitted on this port. RxPkts This field displays the number of packets received on this port. Errors This field displays the number of error packets on this port.
Page 137 Prestige 2602R Series User’s Guide Chapter 14 System Status Screen...
Page 138: Chapter 15 Dhcp Table & Any Ip
Prestige 2602R Series User’s Guide H A P T E R DHCP Table & Any IP 15.1 Introduction DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual clients to obtain TCP/IP configuration at start-up from a server. You can configure the Prestige as a DHCP server or disable it.
Page 139: Figure 63 Any Ip Table
Prestige 2602R Series User’s Guide Figure 63 Any IP Table The following table describes the labels in this screen. Table 32 Any IP Table LABEL DESCRIPTION This field displays the index number. This field displays the IP address of the network device.
Page 140: Chapter 16 Diagnostic Screens
Prestige 2602R Series User’s Guide H A P T E R Diagnostic Screens These read-only screens display information to help you identify problems with the Prestige. 16.0.1 Diagnostic General Screen Click Diagnostic and then General to open the screen shown next.
Page 141: Diagnostic Dsl Line Screen
Prestige 2602R Series User’s Guide 16.0.2 Diagnostic DSL Line Screen Click Diagnostic and then DSL Line to open the screen shown next. Figure 65 Diagnostic: DSL Line The following table describes the fields in this screen. Table 34 Diagnostic: DSL Line...
Page 142: Chapter 17 Firmware Screen
Firmware Screen 17.1 Introduction Find firmware at www.zyxel.com in a file that (usually) uses the system model name with a "*.bin" extension, e.g., "Prestige.bin". The upload process uses HTTP (Hypertext Transfer Protocol) and may take up to two minutes. After a successful upload, the system will reboot.
Page 143: Figure 67 Network Temporarily Disconnected
Prestige 2602R Series User’s Guide Table 35 Firmware Upgrade (continued) LABEL DESCRIPTION Upload Click Upload to begin the upload process. This process may take up to two minutes. Reset Click this button to clear all user-entered configuration information and return the Prestige to its factory defaults.
Page 144: Chapter 18 Introducing The Smt
Prestige 2602R Series User’s Guide H A P T E R Introducing the SMT 18.1 Introduction to the SMT The Prestige’s SMT (System Management Terminal) is a menu-driven interface that you can access over a telnet connection. This chapter shows you how to access the SMT menus via console port, how to navigate the SMT and how to configure SMT menus.
Page 145: Figure 70 Getting Started Smt Menus
Prestige 2602R Series User’s Guide Figure 70 Getting Started SMT Menus Figure 71 Advanced Applications SMT Menus Chapter 18 Introducing the SMT...
Page 146: Navigating The Smt Interface
Prestige 2602R Series User’s Guide Figure 72 Advanced Management SMT Menus 21 to 23 Figure 73 Advanced Management SMT Menus 24 to 26 18.2 Navigating the SMT Interface The SMT (System Management Terminal) is the interface that you use to configure your Prestige.
Page 147: Table 36 Navigating The Smt Interface
[ENTER] to exit the SMT interface. After you enter the password, the SMT displays the main menu, as shown next. Table 37 SMT Main Menu Copyright (c) 1994 - 2004 ZyXEL Communications Corp. Prestige 2602R-61 Main Menu Getting Started Advanced Management 1.
Page 148: System Management Terminal Interface Summary
Prestige 2602R Series User’s Guide 18.2.1 System Management Terminal Interface Summary Table 38 Main Menu Summary MENU TITLE DESCRIPTION General Setup Use this menu to set up your general information. WAN Backup Setup Use this menu to setup traffic redirect and dial-back up.
Page 149 Prestige 2602R Series User’s Guide 5 Re-type your new system password in the Retype to confirm field for confirmation and press [ENTER]. Note: Note that as you type a password, the screen displays an “ ” for each character you type.
Page 150: Chapter 19 Menu 1 General Setup
Prestige 2602R Series User’s Guide H A P T E R Menu 1 General Setup 19.1 General Setup Menu 1 — General Setup contains administrative and system-related information (shown next). The System Name field is for identification purposes. However, because some ISPs check this name you should enter your computer's "Computer Name".
Page 151: Procedure To Configure Dynamic Dns
Prestige 2602R Series User’s Guide Figure 75 Menu 1 General Setup Menu 1 General Setup System Name= ? Location= Contact Person's Name= Domain Name= Edit Dynamic DNS= No Route IP= Yes Bridge= No Press ENTER to Confirm or ESC to Cancel: Fill in the required fields.
Page 152: Figure 76 Menu 1.1 Configure Dynamic Dns
Prestige 2602R Series User’s Guide Figure 76 Menu 1.1 Configure Dynamic DNS Menu 1.1 - Configure Dynamic DNS Service Provider= WWW.DynDNS.ORG Active= No Host= EMAIL= USER= Password= ******** Enable Wildcard= No Press ENTER to Confirm or ESC to Cancel: Follow the instructions in the next table to configure dynamic DNS parameters.
Page 153 Prestige 2602R Series User’s Guide Chapter 19 Menu 1 General Setup...
Page 154: Chapter 20 Menu 2 Wan Backup Setup
Prestige 2602R Series User’s Guide H A P T E R Menu 2 WAN Backup Setup 20.1 Introduction to WAN Backup Setup This chapter explains how to configure the Prestige for traffic redirect connections. 20.2 Configuring WAN Backup in Menu 2 From the main menu, enter 2 to open menu 2.
Page 155: Traffic Redirect Setup
Prestige 2602R Series User’s Guide Table 41 Menu 2 WAN Backup Setup (continued) FIELD DESCRIPTION Recovery Interval(sec) When the Prestige is using a lower priority connection (usually a WAN backup connection), it periodically checks to whether or not it can use a higher priority connection.
Page 156: Chapter 21 Menu 3 Lan Setup
Prestige 2602R Series User’s Guide H A P T E R Menu 3 LAN Setup 21.1 LAN Setup This section describes how to configure the Ethernet using Menu 3 — LAN Setup. From the main menu, enter 3 to display menu 3.
Page 157: Tcp/Ip Ethernet Setup And Dhcp
Prestige 2602R Series User’s Guide • For bridging Ethernet setup refer to Chapter 25 on page 180. 21.3 TCP/IP Ethernet Setup and DHCP Use menu 3.2 to configure your Prestige for TCP/IP. To edit menu 3.2, enter 3 from the main menu to display Menu 3 — LAN Setup. When menu 3 appears, press 2 and press [ENTER] to display Menu 3.2 —...
Page 158: Table 44 Tcp/Ip Ethernet Setup
Prestige 2602R Series User’s Guide Table 43 DHCP Ethernet Setup (continued) FIELD DESCRIPTION Primary DNS Server Enter the IP addresses of the DNS servers. The DNS servers are passed to the DHCP clients along with the IP address and the subnet mask.
Page 159 Prestige 2602R Series User’s Guide Chapter 21 Menu 3 LAN Setup...
Page 160: Chapter 22 Internet Access
Prestige 2602R Series User’s Guide H A P T E R Internet Access 22.1 Internet Access Overview Refer to the chapters on the web configurator’s wizard, LAN and WAN screens for more background information on fields in the SMT screens covered in this chapter.
Page 161: Ip Alias Setup
Prestige 2602R Series User’s Guide Figure 82 IP Alias Network Example Use menu 3.2.1 to configure IP Alias on your Prestige. 22.4 IP Alias Setup Use menu 3.2 to configure the first network. Move the cursor to Edit IP Alias field and press [SPACEBAR] to choose Yes and press [ENTER] to configure the second and third network.
Page 162: Route Ip Setup
Prestige 2602R Series User’s Guide Figure 84 Menu 3.2.1 IP Alias Setup Menu 3.2.1 - IP Alias Setup IP Alias 1= No IP Address= N/A IP Subnet Mask= N/A RIP Direction= N/A Version= N/A Incoming protocol filters= N/A Outgoing protocol filters= N/A...
Page 163: Internet Access Configuration
Prestige 2602R Series User’s Guide Figure 85 Menu 1 General Setup Menu 1 - General Setup System Name= ? Location= location Contact Person's Name= Domain Name= Edit Dynamic DNS= No Route IP= Yes Bridge= No Press ENTER to Confirm or ESC to Cancel: 22.6 Internet Access Configuration...
Page 164: Table 46 Menu 4 Internet Access Setup
Prestige 2602R Series User’s Guide Table 46 Menu 4 Internet Access Setup FIELD DESCRIPTION ISP’s Name Enter the name of your Internet Service Provider (ISP). This information is for identification purposes only. SPACE BAR Encapsulation Press [ ] to select the method of encapsulation used by your ISP.
Page 165 Prestige 2602R Series User’s Guide Chapter 22 Internet Access...
Page 166: Remote Node Configuration
Prestige 2602R Series User’s Guide H A P T E R Remote Node Configuration 23.1 Remote Node Setup Overview This section describes the protocol-independent parameters for a remote node. A remote node is required for placing calls to a remote gateway. A remote node represents both the remote gateway and the network behind it across a WAN connection.
Page 167: Encapsulation And Multiplexing Scenarios
Prestige 2602R Series User’s Guide Figure 87 Menu 11 Remote Node Setup Menu 11 - Remote Node Setup 1. MyISP (ISP, SUA) 2. ________ 3. ________ 4. ________ 5. ________ 6. ________ 7. ________ 8. ________ Enter Node # to Edit: 23.2.2 Encapsulation and Multiplexing Scenarios...
Page 168: Figure 88 Menu 11.1 Remote Node Profile
Prestige 2602R Series User’s Guide Figure 88 Menu 11.1 Remote Node Profile Menu 11.1 - Remote Node Profile Rem Node Name= MyISP Route= IP Active= Yes Bridge= No Encapsulation= RFC 1483 Edit IP/Bridge= No Multiplexing= LLC-based Edit ATM Options= No...
Page 169: Outgoing Authentication Protocol
Prestige 2602R Series User’s Guide Table 47 Menu 11.1 Remote Node Profile (continued) FIELD DESCRIPTION PAP – accept PAP (Password Authentication Protocol) only. Route This field determines the protocol used in routing. Options are IP and None. Bridge When bridging is enabled, your Prestige will forward any packet that it does not route to this remote node;...
Page 170: Remote Node Network Layer Options
Prestige 2602R Series User’s Guide 23.3 Remote Node Network Layer Options For the TCP/IP parameters, perform the following steps to edit Menu 11.3 – Remote Node Network Layer Options as shown next. 1 In menu 11.1, make sure IP is among the protocols in the Route field.
Page 171: My Wan Addr Sample Ip Addresses
Prestige 2602R Series User’s Guide Table 48 Menu 11.3 Remote Node Network Layer Options (continued) FIELD DESCRIPTION Address When Full Feature is selected in the NAT field, configure address mapping sets in Mapping Set menu 15.1. Select one of the NAT server sets (2-10) in menu 15.2 (see...
Page 172: Remote Node Filter
Prestige 2602R Series User’s Guide Figure 90 Sample IP Addresses for a TCP/IP LAN-to-LAN Connection 23.4 Remote Node Filter Move the cursor to the Edit Filter Sets field in menu 11.1, then press [SPACE BAR] to select Yes. Press [ENTER] to display Menu 11.5 – Remote Node Filter.
Page 173: Editing Atm Layer Options
Prestige 2602R Series User’s Guide Figure 91 Menu 11.5 Remote Node Filter (RFC 1483 or ENET Encapsulation) Menu 11.5 - Remote Node Filter Input Filter Sets: protocol filters= device filters= Output Filter Sets: protocol filters= device filters= Enter here to CONFIRM or ESC to CANCEL: Figure 92 Menu 11.5 Remote Node Filter (PPPoA or PPPoE Encapsulation)
Page 174: Llc-Based Multiplexing Or Ppp Encapsulation
Prestige 2602R Series User’s Guide Figure 93 Menu 11.6 for VC-based Multiplexing Menu 11.6 - Remote Node ATM Layer Options VPI/VCI (VC-Multiplexing) VC Options for IP: VC Options for Bridge: VPI #= 8 VPI #= 1 VCI #= 35 VCI #= 36...
Page 175: Figure 95 Menu 11.1 Remote Node Profile
Prestige 2602R Series User’s Guide Figure 95 Menu 11.1 Remote Node Profile Menu 11.1 - Remote Node Profile Rem Node Name= MyISP Route= IP Active= Yes Bridge= No Encapsulation= PPPoE Edit IP/Bridge= No Multiplexing= LLC-based Edit ATM Options= No Service Name=...
Page 176: Chapter 24 Static Route Setup
Prestige 2602R Series User’s Guide H A P T E R Static Route Setup 24.1 IP Static Route Overview Static routes tell the Prestige routing information that it cannot learn automatically through other means. This can arise in cases where RIP is disabled on the LAN or a remote network is beyond the one that is directly connected to a remote node.
Page 177: Figure 98 Menu 12 Static Route Setup
Prestige 2602R Series User’s Guide Figure 98 Menu 12 Static Route Setup Menu 12 - Static Route Setup 1. IP Static Route 3. Bridge Static Route Please enter selection: From menu 12, select 1 to open Menu 12.1 — IP Static Route Setup (shown next).
Page 178: Table 50 Menu12.1.1 Edit Ip Static Route
Prestige 2602R Series User’s Guide Table 50 Menu12.1.1 Edit IP Static Route FIELD DESCRIPTION Route # This is the index number of the static route that you chose in menu 12.1. Route Name Type a descriptive name for this route. This is for identification purpose only.
Page 179 Prestige 2602R Series User’s Guide Chapter 24 Static Route Setup...
Page 180: Chapter 25 Bridging Setup
Prestige 2602R Series User’s Guide H A P T E R Bridging Setup 25.1 Bridging in General Bridging bases the forwarding decision on the MAC (Media Access Control), or hardware address, while routing does it on the network layer (IP) address. Bridging allows the Prestige to transport packets of network layer protocols that it does not route, for example, SNA, from one network to another.
Page 181: Figure 101 Menu 11.1 Remote Node Profile
Prestige 2602R Series User’s Guide Figure 101 Menu 11.1 Remote Node Profile Menu 11.1 - Remote Node Profile Rem Node Name= ? Route= IP Active= Yes Bridge= Yes Encapsulation= ENET ENCAP Edit IP/Bridge= No Multiplexing= VC-based Edit ATM Options= No...
Page 182: Bridge Static Route Setup
Prestige 2602R Series User’s Guide 25.2.2 Bridge Static Route Setup Similar to network layer static routes, a bridging static route tells the Prestige the route to a node before a connection is established. You configure bridge static routes in menu 12.3.1 (go to menu 12, choose option 3, then choose a static route to edit) as shown next.
Page 183 Prestige 2602R Series User’s Guide Chapter 25 Bridging Setup...
Page 184: Network Address Translation (Nat)
Prestige 2602R Series User’s Guide H A P T E R Network Address Translation (NAT) 26.1 Using NAT You must create a firewall rule in addition to setting up SUA/NAT, to allow traffic from the WAN to be forwarded through the Prestige.
Page 185: Figure 104 Menu 4 Applying Nat For Internet Access
Prestige 2602R Series User’s Guide Figure 104 Menu 4 Applying NAT for Internet Access Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 ATM QoS Type= UBR Peak Cell Rate (PCR)= 0...
Page 186: Nat Setup
Prestige 2602R Series User’s Guide Table 53 Applying NAT in Menus 4 & 11.3 FIELD DESCRIPTION Press [SPACE BAR] and then [ENTER] to select Full Feature if you have multiple public WAN IP addresses for your Prestige. The SMT uses the address mapping set that you...
Page 187: Sua Address Mapping Set
Prestige 2602R Series User’s Guide Figure 107 Menu 15.1 Address Mapping Sets Menu 15.1 - Address Mapping Sets 255. SUA (read only) Enter Menu Selection Number: 26.3.1.1 SUA Address Mapping Set Enter 255 to display the next screen (see also section 27.1.1). The fields in this menu cannot be changed.
Page 188: User-Defined Address Mapping Sets
Prestige 2602R Series User’s Guide Table 54 SUA Address Mapping Rules (continued) FIELD DESCRIPTION Global Start IP This is the starting global IP address (IGA). If you have a dynamic IP, enter 0.0.0.0 as the Global Start IP. Global End IP This is the ending global IP address (IGA).
Page 189: Ordering Your Rules
Prestige 2602R Series User’s Guide 26.3.1.3 Ordering Your Rules Ordering your rules is important because the Prestige applies the rules in the order that you specify. When a rule matches the current packet, the Prestige takes the corresponding action and the remaining rules are ignored. If there are any empty rules before your new configured rule, your configured rule will be pushed up by that number of empty rules.
Page 190: Configuring A Server Behind Nat
Prestige 2602R Series User’s Guide Figure 110 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= = N/A Global IP: Start= = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: The following table explains the fields in this menu.
Page 191: Figure 111 Menu 15.2 Nat Server Setup
Prestige 2602R Series User’s Guide Figure 111 Menu 15.2 NAT Server Setup Menu 15.2 - NAT Server Sets 1. Server Set 1 (Used for SUA Only) 2. Server Set 2 3. Server Set 3 4. Server Set 4 5. Server Set 5 6.
Page 192: General Nat Examples
Prestige 2602R Series User’s Guide Figure 113 Multiple Servers Behind NAT Example 26.5 General NAT Examples The following are some examples of NAT configuration. 26.5.1 Example 1: Internet Access Only In the following Internet access example, you only need one rule where your ILAs (Inside Local addresses) all map to one dynamic IGA (Inside Global Address) assigned by your ISP.
Page 193: Example 2: Internet Access With An Inside Server
Prestige 2602R Series User’s Guide Figure 115 Menu 4 Internet Access & NAT Example Menu 4 - Internet Access Setup ISP's Name= MyISP Encapsulation= RFC 1483 Multiplexing= LLC-based VPI #= 8 VCI #= 35 ATM QoS Type= UBR Peak Cell Rate (PCR)= 0...
Page 194: Example 3: Multiple Public Ip Addresses With Inside Servers
Prestige 2602R Series User’s Guide Figure 117 Menu 15.2.1 Specifying an Inside Server Menu 15.2.1 - NAT Server Setup (Used for SUA Only) Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 192.168.1.10 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0...
Page 195: Figure 118 Nat Example 3
Prestige 2602R Series User’s Guide Figure 118 NAT Example 3 In this case you need to configure Address Mapping Set 1 from Menu 15.1 - Address Mapping Sets. Therefore you must choose the Full Feature option from the Network Address Translation field (in menu 4 or menu 11.3) in Figure 119 on page 195.
Page 196: Figure 120 Example 3: Menu 15.1.1.1
Prestige 2602R Series User’s Guide Figure 120 Example 3: Menu 15.1.1.1 Menu 15.1.1.1 Address Mapping Rule Type= One-to-One Local IP: Start= 192.168.1.10 = N/A Global IP: Start= 10.132.50.1 = N/A Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: Figure 121 Example 3: Final Menu 15.1.1...
Page 197: Example 4: Nat Unfriendly Application Programs
Prestige 2602R Series User’s Guide Figure 122 Example 3: Menu 15.2.1 Menu 15.2.1 - NAT Server Setup Rule Start Port No. End Port No. IP Address --------------------------------------------------- Default Default 0.0.0.0 192.168.1.21 192.168.1.20 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0 0.0.0.0...
Page 198: Figure 124 Example 4: Menu 15.1.1.1 Address Mapping Rule
Prestige 2602R Series User’s Guide Figure 124 Example 4: Menu 15.1.1.1 Address Mapping Rule Menu 15.1.1.1 Address Mapping Rule Type= Many-to-Many No Overload Local IP: Start= 192.168.1.10 = 192.168.1.12 Global IP: Start= 10.132.50.1 = 10.132.50.3 Server Mapping Set= N/A Press ENTER to Confirm or ESC to Cancel: After you’ve configured your rule, you should be able to check the settings in menu 15.1.1 as...
Page 199 Prestige 2602R Series User’s Guide Chapter 26 Network Address Translation (NAT)
Page 200: Chapter 27 Filter Configuration
Prestige 2602R Series User’s Guide H A P T E R Filter Configuration 27.1 About Filtering Your Prestige uses filters to decide whether or not to allow passage of a data packet and/or to make a call. There are two types of filter applications: data filtering and call filtering. Filters are subdivided into device and protocol filters, which are discussed later.
Page 201: The Filter Structure Of The Prestige
Prestige 2602R Series User’s Guide Figure 127 Filter Rule Process Start Packet intoFilter Fetch First Filter Set Filter Set Fetch Next Fetch First Filter Set Filter Rule Fetch Next Filter Rule Next filter Next Filter Set Rule Active? Available? Available?
Page 202: Configuring A Filter Set For The Prestige
Prestige 2602R Series User’s Guide 27.2 Configuring a Filter Set for the Prestige To configure a filter set, follow the steps shown next. 1 Enter 21 in the main menu to display Menu 21 – Filter Setup. Figure 128 Menu 21 Filter Set Configuration...
Page 203: Filter Rules Summary Menus
Prestige 2602R Series User’s Guide Figure 130 NetBIOS_LAN Filter Rules Summary Menu 21.3 - Filter Rules Summary # A Type Filter Rules M m n - - ---- --------------------------------------------------------------- - 1 Y IP Pr=17, SA=0.0.0.0, SP=137, DA=0.0.0.0, DP=53 N D F...
Page 204: Configuring A Filter Rule
Prestige 2602R Series User’s Guide Table 57 Abbreviations Used in the Filter Rules Summary Menu (continued) FIELD DESCRIPTION Action Matched. “F” means to forward the packet immediately and skip checking the remaining rules. “D” means to drop the packet. “N“ means to check the next rule.
Page 205: Tcp/Ip Filter Rule
Prestige 2602R Series User’s Guide 27.4.1 TCP/IP Filter Rule This section shows you how to configure a TCP/IP filter rule. TCP/IP rules allow you to base the rule on the fields in the IP and the upper layer protocol, for example, UDP and TCP headers.
Page 206 Prestige 2602R Series User’s Guide Table 59 TCP/IP Filter Rule (continued) FIELD DESCRIPTION Port # Type the destination port of the packets you want to filter. The field range is 0 to 65535. A 0 field is ignored. Port # Comp Select the comparison to apply to the destination port in the packet against the value given in Destination: Port #.
Page 207: Generic Filter Rule
Prestige 2602R Series User’s Guide Figure 133 Executing an IP Filter Packet into IP Filter Filter Active? Apply SrcAddrMask to Src Addr Check Src Not Matched IP Addr Matched Apply DestAddrMask to Dest Addr Check Dest Not Matched IP Addr...
Page 208: Figure 134 Generic Filter Rule
Prestige 2602R Series User’s Guide To configure a generic rule select an empty filter set in menu 21, for example 5. Select Generic Filter Rule in the Filter Type field and press [ENTER] to open the Generic Filter Rule menu, as shown in the following figure.
Page 209: Filter Types And Nat
Prestige 2602R Series User’s Guide Table 60 Generic Filter Rule (continued) FIELD DESCRIPTION Action Not Select the action for a packet not matching the rule. Choices are Check Next Rule, Matched Forward or Drop. When you have completed this menu, press [ENTER] at the prompt “...
Page 210: Figure 136 Sample Telnet Filter
Prestige 2602R Series User’s Guide Figure 136 Sample Telnet Filter 1 Enter 1 in the menu 21 to display the Filter Set Configuration menu. 2 Enter the index number of the filter set you want to configure (in this case 6) 3 Type a descriptive name or comment in the Edit Comments field (for example, TELNET_WAN) and press [ENTER].
Page 211: Applying Filters And Factory Defaults
Prestige 2602R Series User’s Guide 2 Go to the Edit Filter Sets field, press [SPACE BAR] to choose Yes and press [ENTER]. This brings you to menu 11.5. Apply the example filter set (for example, filter set 3) in this menu as shown in the next section.
Page 212: Ethernet Traffic
Prestige 2602R Series User’s Guide 27.7.1 Ethernet Traffic You seldom need to filter Ethernet traffic; however, the filter sets may be useful to block certain packets, reduce traffic and prevent security breaches. Go to menu 3.1 (shown next) and type the number(s) of the filter set(s) that you want to apply as appropriate. You can choose up to four filter sets (from twelve) by typing their numbers separated by commas, for example, 3, 4, 6, 11.
Page 213: System Password
Prestige 2602R Series User’s Guide 27.8 System Password For information on changing the Prestige password, please see Section 18.3 on page 148. Chapter 27 Filter Configuration...
Page 214: Chapter 28 Snmp Configuration
Prestige 2602R Series User’s Guide H A P T E R SNMP Configuration 28.1 About SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite. Your Prestige supports SNMP agent functionality, which allows a manager station to manage and monitor the Prestige through the network.
Page 215: Supported Mibs
• Trap - Used by the agent to inform the manager of some events. 28.2 Supported MIBs The Prestige supports RFC-1215 and MIB II as defined in RFC-1213 as well as ZyXEL private MIBs. The focus of the MIBs is to let administrators collect statistic data and monitor status and performance.
Page 216: Snmp Traps
Prestige 2602R Series User’s Guide Figure 142 Menu 22 SNMP Configuration Menu 22 - SNMP Configuration SNMP: Get Community= public Set Community= public Trusted Host= 0.0.0.0 Trap: Community= public Destination= 0.0.0.0 Press ENTER to Confirm or ESC to Cancel: The following table describes the SNMP configuration parameters.
Page 217: Table 64 Ports And Permanent Virtual Circuits
A trap is sent to the manager when receiving any RFC-1215) SNMP gets or sets requirements with wrong community (password). whyReboot (defined in ZYXEL-MIB) A trap is sent with the reason of restart before rebooting when the system is going to restart (warm start). For intentional reboot : A trap is sent with the message "System reboot by...
Page 218: System Information And Diagnosis
Prestige 2602R Series User’s Guide H A P T E R System Information and Diagnosis 29.1 Overview These tools include updates on system status, port status, log and trace capabilities and upgrades for the system software. This chapter describes how to use these tools in detail.
Page 219: Figure 144 Menu 24.1 System Maintenance : Status
Prestige 2602R Series User’s Guide The following table describes the fields present in Menu 24.1 — System Maintenance — Status which are read-only and meant for diagnostic purposes. Figure 144 Menu 24.1 System Maintenance : Status Menu 24.1 - System Maintenance - Status 00:36:37 Sat.
Page 220: System Information
Prestige 2602R Series User’s Guide Table 65 Menu 24.1 System Maintenance: Status (continued) FIELD DESCRIPTION Line Status This shows the current status of the xDSL line, which can be Up or Down. Upstream This shows the upstream transfer rate in kbps.
Page 221: Console Port Speed
Menu 1 – General Setup. Routing Refers to the routing protocol used. ZyNOS F/W Version Refers to the ZyNOS (ZyXEL Network Operating System) system firmware version. ZyNOS is a registered trademark of ZyXEL Communications Corporation. ADSL Chipset Displays the vendor of the ADSL chipset and DSL version.
Page 222: Log And Trace
Prestige 2602R Series User’s Guide Figure 147 Menu 24.2.2 System Maintenance : Change Console Port Speed Menu 24.2.2 – System Maintenance – Change Console Port Speed Console Port Speed: 9600 Press ENTER to Confirm or ESC to Cancel: Once you change the Prestige console port speed, you must also set the speed parameter for the communication software you are using to connect to the Prestige.
Page 223: Syslog And Accounting
Prestige 2602R Series User’s Guide Figure 149 Sample Error and Information Messages 53 Sat Jan 01 00:00:03 2000 PP01 -WARN SNMP TRAP 0: cold start 54 Sat Jan 01 00:00:03 2000 PP01 INFO main: init completed 55 Sat Jan 01 00:00:03 2000 PP01...
Page 224: Figure 151 Syslog Example
L02 Call Terminated C02 Call Terminated Jul 19 11:19:27 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C01 Outgoing Call dev=2 ch=0 40002 Jul 19 11:19:32 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C02 OutCall Connected 64000 40002 Jul 19 11:20:06 192.168.102.2 ZYXEL: board 0 line 0 channel 0, call 1, C02 Call...
Page 225: Diagnostic
Figure 151 Syslog Example (continued) prot: Protocol (“TCP”, ”UDP”, ”ICMP”) spo: Source port dpo: Destination port Jul 19 14:43:55 192.168.102.2 ZYXEL: IP [Src=202.132.154.123 Dst=255.255.255.255 UDP spo=0208 dpo=0208]} S03>R01mF Jul 19 14:44:00 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP spo=05d4 dpo=0035]} S03>R01mF Jul 19 14:44:04 192.168.102.2 ZYXEL: IP [Src=192.168.102.20 Dst=202.132.154.1 UDP...
Page 226: Table 68 Menu 24.4 System Maintenance Menu: Diagnostic
Prestige 2602R Series User’s Guide The following table describes the diagnostic tests available in menu 24.4 for and the connections. Table 68 Menu 24.4 System Maintenance Menu: Diagnostic FIELD DESCRIPTION Reset xDSL Re-initialize the xDSL link to the telephone company.
Page 227 Prestige 2602R Series User’s Guide Chapter 29 System Information and Diagnosis...
Page 228: Firmware And Configuration File Maintenance
The configuration file (often called the romfile or rom-0) contains the factory default settings in the menus such as password, DHCP Setup, TCP/IP Setup, etc. It arrives from ZyXEL with a “rom” filename extension. Once you have customized the Prestige's settings, they can be saved back to your computer under a filename of your choosing.
Page 229: Backup Configuration
Prestige 2602R Series User’s Guide The following table is a summary. Please note that the internal filename refers to the filename on the Prestige and the external filename refers to the filename not on the Prestige, that is, on your computer, local network or FTP site and so the name (but not the extension) may vary.
Page 230: Using The Ftp Command From The Command Line
Prestige 2602R Series User’s Guide Figure 153 Telnet in Menu 24.5 Menu 24.5 - System Maintenance - Backup Configuration To transfer the configuration file to your workstation, follow the procedure below: 1. Launch the FTP client on your workstation. 2. Type "open" and the IP address of your Prestige. Then type "root" and SMT password as requested.
Page 231: Gui-Based Ftp Clients
Prestige 2602R Series User’s Guide Figure 154 FTP Session Example 331 Enter PASS command Password: 230 Logged in ftp> bin 200 Type I OK ftp> get rom-0 zyxel.rom 200 Port command okay 150 Opening data connection for STOR ras 226 File received OK ftp: 16384 bytes sent in 1.10Seconds 297.89Kbytes/sec.
Page 232: Backup Configuration Using Tftp
Prestige 2602R Series User’s Guide 30.2.6 Backup Configuration Using TFTP The Prestige supports the up/downloading of the firmware and the configuration file using TFTP (Trivial File Transfer Protocol) over LAN. Although TFTP should work over WAN as well, it is not recommended.
Page 233: Backup Via Console Port
Prestige 2602R Series User’s Guide Table 71 General Commands for GUI-based TFTP Clients COMMAND DESCRIPTION Host Enter the IP address of the Prestige. 192.168.1.1 is the Prestige’s default IP address when shipped. Send/Fetch Use “Send” to upload the file to the Prestige and “Fetch” to back up the file on your computer.
Page 234: Restore Configuration
Prestige 2602R Series User’s Guide Figure 157 Backup Configuration Example Type a location for storing the configuration file or click Browse to look for one. Choose the Xmodem protocol. Then click Receive. 4 After a successful backup you will see the following screen. Press any key to return to the SMT menu.
Page 235: Restore Using Ftp Session Example
Prestige 2602R Series User’s Guide Figure 159 Telnet into Menu 24.6 Menu 24.6 -- System Maintenance - Restore Configuration To transfer the firmware and configuration file to your workstation, follow the procedure below: 1. Launch the FTP client on your workstation.
Page 236: Restore Via Console Port
Prestige 2602R Series User’s Guide 30.3.3 Restore Via Console Port Note: The console port is internal and reserved for technician use only. Restore configuration via console port by following the HyperTerminal procedure shown next. Procedures using other serial communications programs should be similar.
Page 237: Uploading Firmware And Configuration Files
Prestige 2602R Series User’s Guide Figure 164 Successful Restoration Confirmation Screen Save to ROM Hit any key to start system reboot. 30.4 Uploading Firmware and Configuration Files This section shows you how to upload firmware and configuration files. You can upload configuration files by following the procedure in Section 30.2 on page...
Page 238: Ftp File Upload Command From The Dos Prompt Example
Prestige 2602R Series User’s Guide Figure 166 Telnet Into Menu 24.7.2 System Maintenance Menu 24.7.2 - System Maintenance - Upload System Configuration File To upload the system configuration file, follow the procedure below: 1. Launch the FTP client on your workstation.
Page 239: Ftp Session Example Of Firmware File Upload
Prestige 2602R Series User’s Guide 30.4.4 FTP Session Example of Firmware File Upload Figure 167 FTP Session Example of Firmware File Upload 331 Enter PASS command Password: 230 Logged in ftp> bin 200 Type I OK ftp> put firmware.bin ras...
Page 240: Tftp Upload Command Example
Prestige 2602R Series User’s Guide 30.4.6 TFTP Upload Command Example The following is an example TFTP command: tftp [-i] host put firmware.bin ras where “ ” specifies binary image transfer mode (use this mode when transferring binary files), “ ” is the Prestige’s IP address and “...
Page 241: Example Xmodem Firmware Upload Using Hyperterminal
Prestige 2602R Series User’s Guide 30.4.7.2 Example Xmodem Firmware Upload Using HyperTerminal Click Transfer, then Send File to display the following screen. Figure 169 Example Xmodem Upload After the firmware upload process has completed, the Prestige will automatically restart. 30.4.7.3 Uploading Configuration File Via Console Port 1 Select 2 from Menu 24.7 –...
Page 242: Example Xmodem Configuration Upload Using Hyperterminal
Prestige 2602R Series User’s Guide 3 Enter “atgo” to restart the Prestige. 30.4.7.4 Example Xmodem Configuration Upload Using HyperTerminal Click Transfer, then Send File to display the following screen. Figure 171 Example Xmodem Upload After the configuration upload process has completed, restart the Prestige by entering “atgo”.
Page 243 Prestige 2602R Series User’s Guide Chapter 30 Firmware and Configuration File Maintenance...
Page 244: Chapter 31 System Maintenance
Enter the CI from the SMT by selecting menu 24.8. See the included disk or the zyxel.com web site for more detailed information on CI commands. Enter 8 from Menu 24 — System Maintenance. A list of valid commands can be found by typing help or ? at the command prompt.
Page 245: Call Control Support
Prestige 2602R Series User’s Guide 31.2 Call Control Support Call Control Support is only applicable when Encapsulation is set to PPPoE in menu 4 or menu 11.1. The budget management function allows you to set a limit on the total outgoing call time of the Prestige within certain times.
Page 246: Time And Date Setting
Prestige 2602R Series User’s Guide The total budget is the time limit on the accumulated time for outgoing calls to a remote node. When this limit is reached, the call will be dropped and further outgoing calls to that remote node will be blocked.
Page 247: Resetting The Time
Prestige 2602R Series User’s Guide Figure 177 Menu 24.10 System Maintenance: Time and Date Setting Menu 24.10 - System Maintenance - Time and Date Setting Use Time Server when Bootup= None Time Server Address= N/A Current Time: 00 : 51 : 24...
Page 248 Prestige 2602R Series User’s Guide • 24-hour intervals after starting. Chapter 31 System Maintenance...
Page 249 Prestige 2602R Series User’s Guide Chapter 31 System Maintenance...
Page 250: Chapter 32 Remote Management
Prestige 2602R Series User’s Guide H A P T E R Remote Management 32.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which Prestige interface (if any) from which computers. When you configure remote management to allow management from the WAN, you still need to configure a firewall rule to allow access.
Page 251: Remote Management Limitations
Prestige 2602R Series User’s Guide Figure 178 Menu 24.11 Remote Management Control Menu 24.11 - Remote Management Control TELNET Server: Server Port = 23 Server Access = LAN only Secured Client IP = 0.0.0.0 FTP Server: Server Port = 21 Server Access = LAN only Secured Client IP = 0.0.0.0...
Page 252: Remote Management And Nat
Prestige 2602R Series User’s Guide 32.3 Remote Management and NAT When NAT is enabled: • Use the Prestige’s WAN IP address when configuring from the WAN. • Use the Prestige’s LAN IP address when configuring from the LAN. 32.4 System Timeout There is a default system management idle timeout of five minutes (three hundred seconds).
Page 253 Prestige 2602R Series User’s Guide Chapter 32 Remote Management...
Page 254: Chapter 33 Ip Policy Routing
Prestige 2602R Series User’s Guide H A P T E R IP Policy Routing 33.1 IP Policy Routing Overview Traditionally, routing is based on the destination address only and the IAD takes the shortest path to forward a packet. IP Routing Policy (IPPR) provides a mechanism to override the default routing behavior and alter the packet forwarding based on the policy defined by the network administrator.
Page 255: Ip Routing Policy Setup
Prestige 2602R Series User’s Guide IPPR follows the existing packet filtering facility of RAS in style and in implementation. The policies are divided into sets, where related policies are grouped together. A user defines the policies before applying them to an interface or a remote node, in the same fashion as the filters.
Page 256: Figure 180 Menu 25.1 Ip Routing Policy Setup
Prestige 2602R Series User’s Guide Figure 180 Menu 25.1 IP Routing Policy Setup Menu 25.1 - IP Routing Policy Setup Criteria/Action - - -------------------------------------------------------------------------- 1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5 SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0 2 N __________________________________________________________________________ __________________________________________________________________________ 3 N __________________________________________________________________________ __________________________________________________________________________ 4 N __________________________________________________________________________...
Page 257: Figure 181 Menu 25.1.1 Ip Routing Policy
Prestige 2602R Series User’s Guide Figure 181 Menu 25.1.1 IP Routing Policy Menu 25.1.1 - IP Routing Policy Policy Set Name= test Active= No Criteria: IP Protocol Type of Service= Don't Care Packet length= 0 Precedence = Don't Care Len Comp= N/A Source: addr start= 0.0.0.0...
Page 258: Applying An Ip Policy
Prestige 2602R Series User’s Guide Table 76 Menu 25.1.1 IP Routing Policy (continued) FIELD DESCRIPTION Gateway addr Defines the outgoing gateway address. The gateway must be on the same subnet as the Prestige if it is on the LAN, otherwise, the gateway must be the IP address of a remote node.
Page 259: Ip Policy Routing Example
Prestige 2602R Series User’s Guide Figure 182 Menu 3.2 TCP/IP and DHCP Ethernet Setup Menu 3.2 - TCP/IP and DHCP Setup DHCP Setup DHCP= Server Client IP Pool Starting Address= 192.168.1.33 Size of Client IP Pool= 32 Primary DNS Server= 0.0.0.0 Secondary DNS Server= 0.0.0.0...
Page 260: Figure 184 Example Of Ip Policy Routing
Prestige 2602R Series User’s Guide Figure 184 Example of IP Policy Routing To force packets coming from clients with IP addresses of 192.168.1.33 to 192.168.1.64 to be routed to the Internet via the WAN port of the Prestige, follow the steps as shown next.
Page 261: Figure 186 Ip Routing Policy Example
Prestige 2602R Series User’s Guide 3 Create a rule in menu 25.1 for this set to route packets from any host ( IP=0.0.0.0 means any host) with protocol TCP and port FTP access through another gateway (192.168.1.100). Figure 186 IP Routing Policy Example Menu 25.1.1 - IP Routing Policy...
Page 262: Chapter 34 Call Scheduling
Prestige 2602R Series User’s Guide H A P T E R Call Scheduling 34.1 Introduction The call scheduling feature allows the Prestige to manage a remote node and dictate when a remote node should be called and for how long. This feature is similar to the scheduler in a videocassette recorder (you can specify a time period for the VCR to record).
Page 263: Figure 189 Menu 26.1 Schedule Set Setup
Prestige 2602R Series User’s Guide Figure 189 Menu 26.1 Schedule Set Setup Menu 26.1 Schedule Set Setup Active= Yes Start Date(yyyy-mm-dd)= 2000 - 01 - 01 How Often= Once Once: Date(yyyy-mm-dd)= 2000 - 01 - 01 Weekdays: Sunday= N/A Monday= N/A...
Page 264: Figure 190 Applying Schedule Set(S) To A Remote Node (Pppoe)
Prestige 2602R Series User’s Guide Table 77 Menu 26.1 Schedule Set Setup (continued) FIELD DESCRIPTION Action Forced On means that the connection is maintained whether or not there is a demand call on the line and will persist for the time period specified in the Duration field.
Page 265 Prestige 2602R Series User’s Guide Chapter 34 Call Scheduling...
Page 266: Chapter 35 Troubleshooting
Prestige 2602R Series User’s Guide H A P T E R Troubleshooting This chapter covers potential problems and the corresponding remedies. 35.1 Problems Starting Up the Prestige Table 78 Troubleshooting Starting Up Your Prestige PROBLEM CORRECTIVE ACTION None of the Make sure that the Prestige’s power adaptor is connected to the Prestige and plugged...
Page 267: Problems With The Wan
Prestige 2602R Series User’s Guide 35.3 Problems with the WAN Table 80 Troubleshooting the WAN PROBLEM CORRECTIVE ACTION The DSL LED is Check the telephone wire and connections between the Prestige DSL port and the off. wall jack. Make sure that the telephone company has checked your phone line and set it up for DSL service.
Page 268: Problems Accessing The Prestige
Prestige 2602R Series User’s Guide 35.4 Problems Accessing the Prestige Table 81 Troubleshooting Accessing the Prestige PROBLEM CORRECTIVE ACTION I cannot The username is “admin”. The default password is “1234”. The Password and access the Username fields are case-sensitive. Make sure that you enter the correct password Prestige.
Page 269: Problems Making Voice Calls
Prestige 2602R Series User’s Guide 35.5 Problems Making Voice Calls Table 82 Troubleshooting Voice Calls PROBLEM CORRECTIVE ACTION There is no dial Check the telephone connections. tone. You can test the telephone wire by using it to connect a telephone directly to a telephone outlet and checking for a dial tone.
Page 270: Enable Pop-Up Blockers With Exceptions
Prestige 2602R Series User’s Guide Figure 191 Pop-up Blocker You can also check if pop-up blocking is disabled in the Pop-up Blocker section in the Privacy tab. 1 In Internet Explorer, select Tools, Internet Options, Privacy. 2 Clear the Block pop-ups check box in the Pop-up Blocker section of the screen. This disables any web pop-up blockers you may have enabled.
Page 271: Figure 193 Internet Options
Prestige 2602R Series User’s Guide Figure 193 Internet Options 3 Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.1.1. 4 Click Add to move the IP address to the list of Allowed sites.
Page 272: Javascripts
Prestige 2602R Series User’s Guide Figure 194 Pop-up Blocker Settings 5 Click Close to return to the Privacy screen. 6 Click Apply to save this setting. 35.6.2 JavaScripts If pages of the web configurator do not display properly in Internet Explorer, check that JavaScripts are allowed.
Page 273: Figure 195 Internet Options
Prestige 2602R Series User’s Guide Figure 195 Internet Options 2 Click the Custom Level... button. 3 Scroll down to Scripting. 4 Under Active scripting make sure that Enable is selected (the default). 5 Under Scripting of Java applets make sure that Enable is selected (the default).
Page 274: Java Permissions
Prestige 2602R Series User’s Guide Figure 196 Security Settings - Java Scripting 35.6.3 Java Permissions 1 From Internet Explorer, click Tools, Internet Options and then the Security tab. 2 Click the Custom Level... button. 3 Scroll down to Microsoft VM.
Page 275: Figure 197 Security Settings - Java
Prestige 2602R Series User’s Guide Figure 197 Security Settings - Java 35.6.3.0.1 JAVA (Sun) 1 From Internet Explorer, click Tools, Internet Options and then the Advanced tab. 2 make sure that Use Java 2 for <applet> under Java (Sun) is selected.
Page 276: Figure 198 Java (Sun)
Prestige 2602R Series User’s Guide Figure 198 Java (Sun) Chapter 35 Troubleshooting...
Page 277 Prestige 2602R Series User’s Guide Chapter 35 Troubleshooting...
Page 278: Hardware Specifications
Prestige 2602R Series User’s Guide P P E N D I X Hardware Specifications Ethernet Cable Pin Assignments Figure 199 Ethernet Cable Pin Assignments Appendix A Hardware Specifications...
Page 279: Prestige 2602R Series Power Adaptor Specifications
Prestige 2602R Series User’s Guide Prestige 2602R Series Power Adaptor Specifications Table 83 Prestige 2602R Series Power Adaptor Specifications NORTH AMERICAN PLUG STANDARDS AC Power Adapter Model 30-112-122204 Input Power 120VAC/60Hz Output Power 12V AC, 1A Power Consumption Safety Standards...
Page 280: Setting Up Your Computer's Ip Address
Prestige 2602R Series User’s Guide P P E N D I X Setting up Your Computer’s IP Address All computers must have a 10M or 100M Ethernet adapter card and TCP/IP installed. Windows 95/98/Me/NT/2000/XP, Macintosh OS 7 and later operating systems and all versions of UNIX/LINUX include the software components you need to install and use TCP/ IP on your computer.
Page 281: Figure 200 Windows 95/98/Me: Network: Configuration
Prestige 2602R Series User’s Guide Figure 200 WIndows 95/98/Me: Network: Configuration Installing Components The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. If you need the adapter: 1 In the Network window, click Add.
Page 282: Configuring
Prestige 2602R Series User’s Guide 3 Select Microsoft from the list of manufacturers. 4 Select Client for Microsoft Networks from the list of network clients and then click 5 Restart your computer so the changes you made take effect. Configuring...
Page 283: Verifying Settings
Prestige 2602R Series User’s Guide Figure 202 Windows 95/98/Me: TCP/IP Properties: DNS Configuration 4 Click the Gateway tab. • If you do not know your gateway’s IP address, remove previously installed gateways. • If you have a gateway IP address, type it in the New gateway field and click Add.
Page 284: Figure 203 Windows Xp: Start Menu
Prestige 2602R Series User’s Guide Figure 203 Windows XP: Start Menu 2 For Windows XP, click Network Connections. For Windows 2000/NT, click Network and Dial-up Connections. Figure 204 Windows XP: Control Panel 3 Right-click Local Area Connection and then click Properties.
Page 285: Figure 205 Windows Xp: Control Panel: Network Connections: Properties
Prestige 2602R Series User’s Guide Figure 205 Windows XP: Control Panel: Network Connections: Properties 4 Select Internet Protocol (TCP/IP) (under the General tab in Win XP) and click Properties. Figure 206 Windows XP: Local Area Connection Properties 5 The Internet Protocol TCP/IP Properties window opens (the General tab in Windows XP).
Page 286: Figure 207 Windows Xp: Advanced Tcp/Ip Settings
Prestige 2602R Series User’s Guide • If you have a static IP address click Use the following IP Address and fill in the IP address, Subnet mask, and Default gateway fields. Click Advanced. Figure 207 Windows XP: Advanced TCP/IP Settings 6 If you do not know your gateway's IP address, remove any previously installed gateways in the IP Settings tab and click OK.
Page 287: Verifying Settings
Prestige 2602R Series User’s Guide 7 In the Internet Protocol TCP/IP Properties window (the General tab in Windows XP): • Click Obtain DNS server address automatically if you do not know your DNS server IP address(es). • If you know your DNS server IP address(es), click Use the following DNS server addresses, and type them in the Preferred DNS server and Alternate DNS server fields.
Page 288: Macintosh Os 8/9
Prestige 2602R Series User’s Guide Macintosh OS 8/9 1 Click the Apple menu, Control Panel and double-click TCP/IP to open the TCP/IP Control Panel. Figure 209 Macintosh OS 8/9: Apple Menu 2 Select Ethernet built-in from the Connect via list.
Page 289: Verifying Settings
Prestige 2602R Series User’s Guide Figure 210 Macintosh OS 8/9: TCP/IP 3 For dynamically assigned settings, select Using DHCP Server from the Configure: list. 4 For statically assigned settings, do the following: • From the Configure box, select Manually. •...
Page 290: Figure 211 Macintosh Os X: Apple Menu
Prestige 2602R Series User’s Guide Figure 211 Macintosh OS X: Apple Menu 2 Click Network in the icon bar. • Select Automatic from the Location list. • Select Built-in Ethernet from the Show list. • Click the TCP/IP tab. 3 For dynamically assigned settings, select Using DHCP from the Configure list.
Page 291: Verifying Settings
Prestige 2602R Series User’s Guide 5 Click Apply Now and close the window. 6 Turn on your Prestige and restart your computer (if prompted). Verifying Settings Check your TCP/IP properties in the Network window. Appendix B Setting up Your Computer’s IP Address...
Page 292: Appendix Cip Subnetting
Prestige 2602R Series User’s Guide P P E N D I X IP Subnetting IP Addressing Routers “route” based on the network number. The router that delivers the data packet to the correct destination host uses the host ID. IP Classes An IP address is made up of four octets (eight bits), written in dotted decimal notation, for example, 192.168.1.1.
Page 293: Subnet Masks
Prestige 2602R Series User’s Guide Note: Host IDs of all zeros or all ones are not allowed. Therefore: A class “C” network (8 host bits) can have 2 –2 or 254 hosts. A class “B” address (16 host bits) can have 2 –2 or 65534 hosts.
Page 294: Subnetting
Prestige 2602R Series User’s Guide Subnetting With subnetting, the class arrangement of an IP address is ignored. For example, a class C address no longer has to have 24 bits of network number and 8 bits of host ID. With subnetting, some of the host ID bits are converted into network number bits.
Page 295: Table 89 Subnet 1
Prestige 2602R Series User’s Guide The first three octets of the address make up the network number (class “C”). You want to have two separate networks. Divide the network 192.168.1.0 into two separate subnets by converting one of the host ID bits of the IP address to a network number bit.
Page 296: Example: Four Subnets
Prestige 2602R Series User’s Guide 192.168.1.0 with mask 255.255.255.128 is the subnet itself, and 192.168.1.127 with mask 255.255.255.128 is the directed broadcast address for the first subnet. Therefore, the lowest IP address that can be assigned to an actual host for the first subnet is 192.168.1.1 and the highest is 192.168.1.126.
Page 297: Example Eight Subnets
Prestige 2602R Series User’s Guide Table 93 Subnet 3 (continued) LAST OCTET BIT NETWORK NUMBER VALUE Subnet Address: Lowest Host ID: 192.168.1.129 192.168.1.128 Broadcast Address: Highest Host ID: 192.168.1.190 192.168.1.191 Table 94 Subnet 4 NETWORK NUMBER LAST OCTET BIT VALUE IP Address 192.168.1.
Page 298: Subnetting With Class A And Class B Networks
Prestige 2602R Series User’s Guide The following table is a summary for class “C” subnet planning. Table 96 Class C Subnet Planning NO. “BORROWED” HOST NO. HOSTS PER SUBNET MASK NO. SUBNETS BITS SUBNET 255.255.255.128 (/25) 255.255.255.192 (/26) 255.255.255.224 (/27) 255.255.255.240 (/28)
Page 299 Prestige 2602R Series User’s Guide Appendix C IP Subnetting...
Page 300: Appendix Dpppoe
[Document Title] P P E N D I X PPPoE PPPoE in Action An ADSL modem bridges a PPP session over Ethernet (PPP over Ethernet, RFC 2516) from your computer to an ATM PVC (Permanent Virtual Circuit) which connects to a DSL Access Concentrator where the PPP session terminates (see Figure 213 on page 301).
Page 301: How Pppoe Works
[Document Title] Figure 213 Single-Computer per Router Hardware Configuration How PPPoE Works The PPPoE driver makes the Ethernet appear as a serial link to the computer and the computer runs PPP over it, while the modem bridges the Ethernet frames to the Access Concentrator (AC).
Page 302: Appendix E Internal Sptgen
Prestige 2602R Series User’s Guide P P E N D I X Internal SPTGEN This appendix introduces Internal SPTGEN. All menus shown in this appendix are example menus meant to show SPTGEN usage. Actual menus for your product may differ.
Page 303: Internal Sptgen File Modification - Important Points To Remember
Prestige 2602R Series User’s Guide Internal SPTGEN File Modification - Important Points to Remember Each parameter you enter must be preceded by one “=”sign and one space. Some parameters are dependent on others. For example, if you disable the Configured field in...
Page 304: Internal Sptgen Ftp Upload Example
Prestige 2602R Series User’s Guide Figure 218 Internal SPTGEN FTP Download Example c:\ftp 192.168.1.1 220 PPP FTP version 1.0 ready at Sat Jan 1 03:22:12 2000 User (192.168.1.1:(none)): 331 Enter PASS command Password: 230 Logged in ftp>bin 200 Type I OK ftp>...
Page 305: Table 99 Menu 1 General Setup (Smt Menu 1)
Prestige 2602R Series User’s Guide Table 98 Abbreviations Used in the Example Internal SPTGEN Screens Table ABBREVIATION MEANING INPUT An example of what you may enter Applies to the Prestige. The following are Internal SPTGEN screens associated with the SMT screens of your Prestige.
Page 306 Prestige 2602R Series User’s Guide Table 100 Menu 3 (SMT Menu 3 (continued)) / Menu 3.2 TCP/IP and DHCP Ethernet Setup (SMT Menu 3.2) INPUT 30200001 = DHCP <0(None) | 1(Server) | 2(Relay)> 30200002 = Client IP Pool Starting Address 192.168.1.33...
Page 307 Prestige 2602R Series User’s Guide Table 100 Menu 3 (SMT Menu 3 (continued)) 30201008 = IP Alias #1 Incoming protocol filters = 256 Set 3 30201009 = IP Alias #1 Incoming protocol filters = 256 Set 4 30201010 = IP Alias #1 Outgoing protocol filters...
Page 308 Prestige 2602R Series User’s Guide Table 100 Menu 3 (SMT Menu 3 (continued)) 30500004 = RTS Threshold <0 ~ 2432> = 2432 30500005 = FRAG. Threshold <256 ~ 2432> = 2432 30500006 = <0(DISABLE) | 1(64-bit WEP) | 2(128-bit WEP)>...
Page 309: Table 101 Menu 4 Internet Access Setup (Smt Menu 4)
Prestige 2602R Series User’s Guide Table 101 Menu 4 Internet Access Setup (SMT Menu 4) (continued) 40000002 = Active <0(No) | 1(Yes)> 40000003 = ISP's Name = ChangeMe 40000004 = Encapsulation <2(PPPOE) | 3(RFC 1483)| 4(PPPoA )| 5(ENET ENCAP)> 40000005 = Multiplexing <1(LLC-based)
Page 310: Table 102 Menu 12 (Smt Menu 12)
Prestige 2602R Series User’s Guide Table 101 Menu 4 Internet Access Setup (SMT Menu 4) (continued) 40000032= RIP Version <0(Rip-1) | 1(Rip-2B) |2(Rip-2M)> 40000033= Nailed-up Connection <0(No) |1(Yes)> Table 102 Menu 12 (SMT Menu 12) / Menu 12.1.1 IP Static Route Setup (SMT Menu 12.1.1)
Page 311 Prestige 2602R Series User’s Guide Table 102 Menu 12 (SMT Menu 12) (continued) / Menu 12.1.4 IP Static Route Setup (SMT Menu 12.1.4) INPUT 120104001 = IP Static Route set #4, Name <Str> 120104002 = IP Static Route set #4, Active <0(No) |1(Yes)>...
Page 312 Prestige 2602R Series User’s Guide Table 102 Menu 12 (SMT Menu 12) (continued) 120107006 = IP Static Route set #7, Metric 120107007 = IP Static Route set #7, Private <0(No) |1(Yes)> / Menu 12.1.8 IP Static Route Setup (SMT Menu 12.1.8)
Page 313 Prestige 2602R Series User’s Guide Table 102 Menu 12 (SMT Menu 12) (continued) 120111004 = IP Static Route set #11, Destination IP subnetmask 120111005 = IP Static Route set #11, Gateway = 0.0.0.0 120111006 = IP Static Route set #11, Metric...
Page 314 Prestige 2602R Series User’s Guide Table 102 Menu 12 (SMT Menu 12) (continued) 120115002 = IP Static Route set #15, Active <0(No) |1(Yes)> 120115003 = IP Static Route set #15, Destination = 0.0.0.0 IP address 120115004 = IP Static Route set #15, Destination...
Page 315: Table 103 Menu 15 Sua Server Setup (Smt Menu 15)
Prestige 2602R Series User’s Guide Table 103 Menu 15 SUA Server Setup (SMT Menu 15) (continued) 150000014 = SUA Server #4 Port Start 150000015 = SUA Server #4 Port End 150000016 = SUA Server #4 Local IP address = 0.0.0.0...
Page 316: Table 104 Menu 21.1 Filter Set #1 (Smt Menu 21.1)
Prestige 2602R Series User’s Guide Table 103 Menu 15 SUA Server Setup (SMT Menu 15) (continued) 150000048 = SUA Server #11 Protocol <0(All)|6(TCP)|17(U DP)> 150000049 = SUA Server #11 Port Start 150000050 = SUA Server #11 Port End 150000051 = SUA Server #11 Local IP address = 0.0.0.0...
Page 317 Prestige 2602R Series User’s Guide Table 104 Menu 21.1 Filter Set #1 (SMT Menu 21.1) (continued) / Menu 21.1.1.2 set #1, rule #2 (SMT Menu 21.1.1.2) INPUT 210102001 = IP Filter Set 1,Rule 2 Type <2(TCP/IP)> 210102002 = IP Filter Set 1,Rule 2 Active <0(No)|1(Yes)>...
Page 318 Prestige 2602R Series User’s Guide Table 104 Menu 21.1 Filter Set #1 (SMT Menu 21.1) (continued) 210103013 = IP Filter Set 1,Rule 3 Act Match <1(check next)|2(forward)| 3(drop) 210103014 = IP Filter Set 1,Rule 3 Act Not Match <1(check next)|2(forward)| 3(drop) / Menu 21.1.1.4 set #1, rule #4 (SMT Menu 21.1.1.4)
Page 319: Table 105 Menu 21.1 Filer Set #2, (Smt Menu 21.1)
Prestige 2602R Series User’s Guide Table 104 Menu 21.1 Filter Set #1 (SMT Menu 21.1) (continued) 210105009 = IP Filter Set 1,Rule 5 Src Subnet Mask 210105010 = IP Filter Set 1,Rule 5 Src Port 210105011 = IP Filter Set 1,Rule 5 Src Port Comp <0(none)|1(equal)
Page 320 Prestige 2602R Series User’s Guide Table 105 Menu 21.1 Filer Set #2, (SMT Menu 21.1) (continued) / Menu 21.1.2.1 Filter set #2, rule #1 (SMT Menu 21.1.2.1) INPUT 210201001 = IP Filter Set 2, Rule 1 Type <0(none)|2(TCP/IP)> = 2...
Page 321 Prestige 2602R Series User’s Guide Table 105 Menu 21.1 Filer Set #2, (SMT Menu 21.1) (continued) 210202009 = IP Filter Set 2, Rule 2 Src Subnet Mask 210202010 = IP Filter Set 2,Rule 2 Src Port 210202011 = IP Filter Set 2, Rule 2 Src Port <0(none)|1(equal)|2...
Page 322 Prestige 2602R Series User’s Guide Table 105 Menu 21.1 Filer Set #2, (SMT Menu 21.1) (continued) 210204002 = IP Filter Set 2, Rule 4 Active <0(No)|1(Yes )> = 1 210204003 = IP Filter Set 2, Rule 4 Protocol = 17...
Page 323 Prestige 2602R Series User’s Guide Table 105 Menu 21.1 Filer Set #2, (SMT Menu 21.1) (continued) 210205011 = IP Filter Set 2, Rule 5 Src Port <0(none)|1(equal)|2 Comp (not equal)|3(less)|4(gr eater)> 210205013 = IP Filter Set 2, Rule 5 Act Match <1(check...
Page 324: Table 106 Menu 23 System Menus (Smt Menu 23)
Prestige 2602R Series User’s Guide Table 106 Menu 23 System Menus (SMT Menu 23) */ Menu 23.1 System Password Setup (SMT Menu 23.1) INPUT 230000000 = System Password = 1234 */ Menu 23.2 System security: radius server (SMT Menu 23.2)
Page 325: Command Examples
Prestige 2602R Series User’s Guide Table 106 Menu 23 System Menus (SMT Menu 23) (continued) 230400008 = WPA Mixed Mode <0(Disable) |1(Enable)> 230400009 = Data Privacy for Broadcast/ <0(TKIP) |1(WEP)> Multicast packets 230400010 = WPA Broadcast/Multicast Key Update Timer Table 107 Menu 24.11 Remote Management Control (SMT Menu 24.11) / Menu 24.11 Remote Management Control (SMT Menu 24.11)
Page 326 Prestige 2602R Series User’s Guide Appendix E Internal SPTGEN...
Page 327 Prestige 2602R Series User’s Guide Appendix E Internal SPTGEN...
Page 328: Appendix F Command Interpreter
This appendix describes how to use the command interpreter. Enter 24 in the main menu to bring up the system maintenance menu. Enter 8 to go to Menu 24.8 - Command Interpreter Mode. See the included disk or zyxel.com for more detailed information on these commands. Appendix F Command Interpreter...
Page 329: Command Syntax
Prestige 2602R Series User’s Guide Note: Use of undocumented commands or misconfiguration can damage the unit and possibly render it unusable. Command Syntax • The command keywords are in courier new font. • Enter the command keywords exactly as shown, do not abbreviate.
Page 330: Appendix G Boot Commands
Prestige 2602R Series User’s Guide P P E N D I X Boot Commands The BootModule AT commands execute from within the router’s bootup software, when debug mode is selected before the main router firmware is started. When you start up your Prestige, you are given a choice to go into debug mode by pressing a key at the prompt shown in the following screen.
Page 331: Figure 221 Boot Module Commands
Prestige 2602R Series User’s Guide Figure 221 Boot Module Commands just answer OK ATHE print help ATBAx change baudrate. 1:38.4k, 2:19.2k, 3:9.6k 4:57.6k 5:115.2k ATENx,(y) set BootExtension Debug Flag (y=password) ATSE show the seed of password generator ATTI(h,m,s) change system time to hour:min:sec or show...
Page 332: Appendix H Log Descriptions
Prestige 2602R Series User’s Guide P P E N D I X Log Descriptions This appendix provides descriptions of example log messages. Table 109 System Maintenance Logs LOG MESSAGE DESCRIPTION The router has adjusted its time based on information from the Time calibration is time server.
Page 333: Table 110 System Error Logs
Prestige 2602R Series User’s Guide Table 109 System Maintenance Logs (continued) LOG MESSAGE DESCRIPTION The router is saving configuration changes. Configuration Change: PC = 0x%x, Task ID = 0x%x Someone has logged on to the router’s SSH server. Successful SSH login Someone has failed to log on to the router’s SSH server.
Page 334: Table 112 Tcp Reset Logs
Prestige 2602R Series User’s Guide Table 112 TCP Reset Logs LOG MESSAGE DESCRIPTION The router sent a TCP reset packet when a host was under a SYN Under SYN flood attack, flood attack (the TCP incomplete count is per destination host.)
Page 335: Table 115 Cdr Logs
Prestige 2602R Series User’s Guide Table 114 ICMP Logs (continued) LOG MESSAGE DESCRIPTION The firewall allowed a triangle route session to pass Triangle route packet forwarded: through. ICMP The router blocked a packet that didn’t have a Packet without a NAT table entry corresponding NAT table entry.
Page 336: Table 117 Upnp Logs
Prestige 2602R Series User’s Guide Table 117 UPnP Logs LOG MESSAGE DESCRIPTION UPnP packets can pass through the firewall. UPnP pass through Firewall Table 118 ICMP Notes TYPE CODE DESCRIPTION Echo Reply Echo reply message Destination Unreachable Net unreachable Host unreachable...
Page 337: Table 119 Syslog Logs
Prestige 2602R Series User’s Guide Table 118 ICMP Notes (continued) TYPE CODE DESCRIPTION Information request message Information Reply Information reply message Table 119 Syslog Logs LOG MESSAGE DESCRIPTION "This message is sent by the system ("RAS" displays as the <Facility*8 + Severity>Mon dd system name if you haven’t configured one) when the router...
Page 338: Table 122 Fsm Logs: Caller Side
Prestige 2602R Series User’s Guide Table 122 FSM Logs: Caller Side LOG MESSAGE DESCRIPTION Someone used a phone connected to the listed phone port to VoIP Call Start Ph[Phone initiate a VoIP call to the listed destination. Port Number] <- Outgoing...
Page 339: Log Commands
Prestige is to record. 2 Use sys logs category to view a list of the log categories. Figure 222 Displaying Log Categories Example Copyright (c) 1994 - 2004 ZyXEL Communications Corp. ras> ? Valid commands are: exit...
Page 340: Displaying Logs
Prestige 2602R Series User’s Guide Displaying Logs • Use the sys logs display command to show all of the logs in the Prestige’s log. • Use the sys logs category display command to show the log settings for all of the log categories.
Page 341 Prestige 2602R Series User’s Guide Appendix H Log Descriptions...
Page 342: Index
Prestige 2602R Series User’s Guide Index Numerics 110V AC Backup 230V AC Backup Type 64kbps Basement 8kbps Bridging 169, 180 Ether Address Ethernet Ethernet Addr Timeout Remote Node Static Route Setup Budget Management 245, 246 BYE Request Accessories ACK Message...
Page 343 Prestige 2602R Series User’s Guide Computer Name Domain Name 51, 78 Conditions that prevent TFTP and FTP from working Domain Name System over WAN Downstream Noise Margin Configuration 53, 138 DS Field configuration file DS field Connecting Cables DSCPs Console Port...
Page 344 Prestige 2602R Series User’s Guide Factory LAN Defaults Hidden Menus High Voltage Points Filename Conventions Hop Count 171, 178 filename conventions Host Filter 156, 200 Host IDs Applying Filters HTTP Ethernet Traffic HyperTerminal 241, 242 Ethernet traffic HyperTerminal program 233, 236...
Page 345 Prestige 2602R Series User’s Guide IP policy routing IP Policy Routing (IPPR) 38, 160 Applying an IP Policy MAC address Ethernet IP Policies Main Menu Gateway Maintenance IP Pool Setup management idle timeout period IP Protocol Management Information Base (MIB)
Page 346 Prestige 2602R Series User’s Guide Network Address Translation (NAT) 37, 184 Power Supply, repair Network Management 39, 78 PPP Encapsulation NNTP PPP Log Non-Proxy PPP session over Ethernet (PPP over Ethernet, RFC 2516) North America PPPoA NTP Time Servers PPPoE...
Page 347 Prestige 2602R Series User’s Guide Related Documentation Relay to PSTN Remote DHCP Server Safety Warnings Remote Management Sample IP Addresses Remote Management and NAT Saving SMT Configuration Remote Management Limitations 110, 251 Schedule Sets Remote Management Setup Duration Remote Node...
Page 348 Prestige 2602R Series User’s Guide GetNext Manager Talk Time MIBs TCP/IP 111, 209, 226 Trap Telecommunication Line Cord. Trusted Host Telnet SOHO (Small Office/Home Office) Telnet Configuration Source-Based Routing Test Your Internet Connection Speaking Volume Text File Format Speed Dial...
Page 349 Prestige 2602R Series User’s Guide URL Type Web Configurator 44, 45, 46 Use Proxy Wet Basement Used Port User Name Xmodem File Upload XMODEM protocol 35, 98 VAD Support Variable Bit Rate VBR (Variable Bit Rate) VC-based Multiplexing Zero Configuration...
