Summary of Contents for Smeg DRY8WSA
- Page 1 DRY8WSA DRY8SSA Dryer Asciugatrice...
-
Page 2: Explanation Of Symbols
Read this manual prior to initial operation of the product! Dear Customer, We hope that your product, which has been manufactured in modern facilities and passed through a strict quality control procedure, will give you very good results. We advise you to read through this manual carefully before using your product and keep it for future reference. This User Manual will •... -
Page 3: Important Safety Information
Important safety information This section includes safety information that will help • Do not dry items cleaned with industrial chemicals in the dryer. protection from risks of personal injuries or materialistic • Do not dry unwashed items in the dryer. damages. -
Page 4: Package Information
Compliance with the WEEE Directive and • Never attempt to repair the machine yourself, otherwise, you will be putting your life and others’ Disposing of the Waste Product: lives in danger. This product complies with EU WEEE • For malfunctions that cannot be solved by following Directive (2012/19/EU). -
Page 5: Appropriate Installation Location
Installation Refer to the nearest Authorised Service Agent for installation of your product. Preparation of location and electrical installation for the product is under customer’s responsibility. Installation and electrical connections must be carried out by a qualified personnel. Prior to installation, visually check if the product has any defects on it. -
Page 6: Electrical Connection
Electrical connection Connect the machine to a grounded outlet protected by a fuse of suitable capacity as stated in the technical specifications table. Our company shall not be liable for any damages that will arise when the machine is used on a circuit without grounding. -
Page 7: Technical Specification
Technical specification Height (adjustable) 84.6 cm Width 59.5 cm Depth 59.8 cm Capacity (max.) 8 kg Weight (net) 40 kg Voltage Rated power input See type label Model code Type label is located behind the loading door. 7 EN... -
Page 8: Initial Preparations For Drying
Initial preparations for drying Things to be done for energy saving: A B C • Make sure that you operate the product at its full capacity but pay attention to not exceeding it. • Spin your laundry at the highest speed possible when washing them. -
Page 9: Preparing Laundry For Drying
• Garments or pillows bolstered with rubber foam Following weights are given as examples. (latex foam), shower bonnets, water resistant textiles, Approximate Home articles materials with rubber reinforcement and rubber foam weights (g) pads should not be dried in the dryer. Cotton quit covers (double) 1500 •... -
Page 10: Loading The Laundry
Loading the laundry 1. Open the loading door. 2. Place the laundry in the machine without compressing. 3. Push the loading door to close. Ensure that no items are caught in the door. 10 EN... -
Page 11: Control Panel
Selecting a Programme and Operating Your Machine Control panel 1. Washing machine spin speed*/ Timer programme 6. Anti-creasing selection Prevents the laundry from creasing after the machine Spin speed used to spin the laundry in the washing completes its programme. macthine / Indicates the time for timer programs. -
Page 12: Preparing The Machine
Preparing the machine •Quick 35 min You can use this programme to dry your cotton laundry 1. Plug in your machine. that you have spun at high speeds in your washing 2. Place the laundry in the machine. machine.This program dries 2 kg cotton laundry (2 Shirts 3. -
Page 13: Time Display
•Refresh Only ventilation is performed for 10 Tminutes without blowing hot air. You can air your clothes that have been kept at closed environments for a long time and deodourise unpleasant odours thanks to this programme. •Timer programs You can select one of the 10 min., 20 min., 30 min., 40 min., 50 min., 60 min., 80 min., 100 min., 120 min., 140 min. - Page 14 Programme selection and consumption table Programme table Approximate Spin speed in washing Drying time Programs Capacity (kg) amount of remaining machine (rpm) (minutes) humidity Cottons / Coloreds Extra dry 1000 % 60 Cupboard dry 1000 % 60 Iron dry 1000 % 60 Quick 35 min 1200...
-
Page 15: Auxiliary Function
Auxiliary function When the contrast is changed at the end of 3 seconds, all Audio Warning symbols on the display will become visible for 3 seconds in order to indicate that the process is complete. Perform the same procedure to revert back to the previous contrast setting. - Page 16 Progress of programme Dryer door open symbol lights up. Anti- Drying Wardrobe creasing (Extra) Iron Ventilation The progress of a running programme is shown through a Time delay number of symbols on the screen. With the “Time delay” function you can delay the At the beginning of each programme step, the relevant programme start up to 24 hours.
-
Page 17: Childproof Lock
Adding/removing laundry in standby new programme information is displayed Ending the programme through canceling mode A new program can be selected and started after In order to add or take out laundry after the start-up of “Program cancel” is activated in order to change the the programme;... -
Page 18: Filter Cartridge / Door Inner Surface
Maintenance and cleaning Filter Cartridge / Door Inner Surface Lint and fibres released from the laundry to the air during the drying cycle are collected in the “Filter Cartridge”. Sensor Such fibre and lint are generally formed during wearing and washing. Always clean the filter and the inner surfaces of the cover after each drying process. -
Page 19: For The Condenser
*To drain the water tank: 3. Pull out the condenser. 1-Pull the drawer and remove the water tank carefully. 4. Clean the condenser by applying pressurized water 2-Drain the water in the tank with a shower armature and wait until the water drains. -
Page 20: Suggested Solutions For Problems
Suggested solutions for problems Drying process takes too much time • Meshes of the filter may be clogged. Wash with water. Laundry comes out wet at the end of drying. • Meshes of the filter may be clogged. Wash with water. •...
