Operating Instructions
Zoom Lens
Commercial Use
ET-C1U100
Model No.
ENGLISH
FRANÇAIS
日本語
Thank you for purchasing this Panasonic product.
■ To ensure correct use of this lens, please read the operating instructions supplied
with the lens and the projector carefully.
■ Before using this product, be sure to read "Read this first!" (
Page 3 to 4).
■ Please save this manual for future use.
DPQX1701ZA/X1
Advertisement
Table of Contents
Related Manuals for Panasonic ET-C1U100
Summary of Contents for Panasonic ET-C1U100
- Page 1 ENGLISH FRANÇAIS 日本語 Thank you for purchasing this Panasonic product. ■ To ensure correct use of this lens, please read the operating instructions supplied with the lens and the projector carefully. ■ Before using this product, be sure to read “Read this first!” ( Page 3 to 4).
-
Page 2: Table Of Contents
█ Contents Read this first! ..................3 Before Use.....................5 Preparation....................6 Before replacing the projection lens ............6 Attaching the Lens................... 6 Image peripheral focus adjustment function..........7 Projection relationships...............8 Lens shift ranges ................10 Specifications ..................11 Dimensions ..................11 Projected image size and Projection distance..Appendix / Annexe / 付録 1 The "Appendix"... -
Page 3: Read This First
Read this first! Always follow these precautions WARNING: Do not look at or place your skin into the light emitted from the lens while the projector is being used. Doing so can cause burns or loss of sight. z Strong light is emitted from the projector’s lens. Do not look at or place your hands directly into this light. - Page 4 Read this fi rst! (continued) ■ Hazard distance (IEC 62471-5:2015) The distance from the projection lens surface, at which the emission reaches the Accessible Emission Limit (AEL) of risk group 2, is known as the hazard distance (HD) or safety distance. The area where the emission exceeds the Accessible Emission Limit of risk group 2 is called the hazard zone (HZ).
-
Page 5: Before Use
This manual omits the alphabets at the end of projector model numbers. z Models other than the above may also be supported. Refer to the operating instructions for your projector or the following website. https://panasonic.net/cns/projector/ ■ Supplied Accessories Make sure that the following has been provided. -
Page 6: Preparation
Preparation Before replacing the projection lens Return the projection lens to the home position before replacing or removing it. For details on how to return the lens to the home position, refer to the operating instructions of the projector. Attention z Make sure that the projector power supply is switched off before attaching or detaching the projection lens. -
Page 7: Image Peripheral Focus Adjustment Function
This shift in focal balance tends to increase proportionally with smaller throw ratios. The ET-C1U100 is equipped with an image peripheral focus adjustment function to correct the shift in focal balance between the center and peripheral areas of the projected image. -
Page 8: Projection Relationships
Projection relationships The dimensional relationship between the screen and the projector is shown below. ■ Dimensional relationship diagram Projected image L (LW/LT) Screen L (LW/LT) Note z This diagram assumes that the size and position of the projected image will be adjusted so that the image fills the entire screen. - Page 9 Projection relationships (continued) ■ Dimensional relationship For details on the projection distance (L), refer to “Projected image size and Projection distance” and “Projection distance formulas” in the Appendix. Note z For details on “Projected image size and Projection distance” for projector models other than PT-REQ12 / PT-REQ10 / PT-REQ80 / PT-REZ12 / PT-REZ10 / PT-REZ80, refer to “Setting up”...
-
Page 10: Lens Shift Ranges
Projection relationships (continued) Only [KEYSTONE] [KEYSTONE] and [CURVED CORRECTION] Only [CURVED used used together CORRECTION] used Projector Vertical Horizontal Vertical Horizontal model keystone keystone keystone keystone Min. value Min. value Min. value Min. value correction correction correction correction of R2/L2 of R3/L3 of R2/L2 of R3/L3... -
Page 11: Specifications
Specifications F number 2.13 Focal Length (f) 5.4 mm (7/32") - 5.8 mm (15/64") Width 130 mm (5-1/8") Dimensions Height 139 mm (5-15/32") Depth 477 mm (18-25/32") Net Weight 4.7 kg (10.36 lb) Dimensions (Unit: mm) 477 (18-25/32") ENGLISH-11... - Page 12 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Importer: Panasonic Connect Europe GmbH English Hagenauer Strasse 43, 65203 Wiesbaden, Germany Authorized Representative in EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Производител: Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Япония...
- Page 13 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japón Importador: Panasonic Connect Europe GmbH Español Hagenauer Strasse 43, 65203 Wiesbaden, Alemania Representante Autorizado para la UE: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburgo, Alemania Fabriqué par : Panasonic Connect Co., Ltd.
- Page 14 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Importeur: Panasonic Connect Europe GmbH Nederlands Hagenauer Strasse 43, 65203 Wiesbaden, Duitsland Bevoegde vertegenwoordiger in de EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Duitsland Produsert av: Panasonic Connect Co., Ltd.
- Page 15 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japonsko Dovozca: Panasonic Connect Europe GmbH Slovenčina Hagenauer Strasse 43, 65203 Wiesbaden, Nemecko Autorizovaný zástupca v EÚ: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Nemecko Proizvaja: Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japonska Uvoznik: Panasonic Connect Europe GmbH Slovenščina...
- Page 16 Manufactured by: Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Importer: Panasonic Connect Europe GmbH Hagenauer Strasse 43, 65203 Wiesbaden, Germany Authorized Representative in EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Importer for UK:...
-
Page 17: Projected Image Size And Projection Distance
Appendix / Annexe / 付録 ■ Projected image size and Projection distance ■ Taille de l'image projetée et distance de projection ■ 投写画面サイズと投写距離 z When the screen aspect ratio is 16:10 z Lorsque le rapport d’aspect de l'écran est 16:10 (Unit / Unités / 単位... - Page 18 Appendix / Annexe / 付録 （continued / suite / つづき） z When the screen aspect ratio is 4:3 z Lorsque le rapport d’aspect de l'écran est 4:3 (Unit / Unités / 単位 : m) z 画面アスペクト比 4：3 のとき Throw ratio / Rapport de projection / スローレシオ : [0.371 - 0.398:1] 2.54 (100") 1.524 2.032...
- Page 19 Appendix / Annexe / 付録 （continued / suite / つづき） z Projection distance formulas z Formules de distance de projection z 投写距離計算式 The dimensions of the following table contain a slight error. Periods are used to represent decimal points in the calculation formulas in the following table. Les dimensions du tableau suivant peuvent présenter un léger écart.
- Page 20 Two Riverfront Plaza, Newark, NJ 07102 TEL: (877) 803 - 8492 Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 TEL: (905) 624 - 5010 パナソニック コネクト株式会社 〒 571-8503 大阪府門真市松葉町２番 15 号 電話 0120-872-601 SS1023AM0 -PS © Panasonic Connect Co., Ltd. 2023 Printed in Japan...
