Panasonic HTB4152B/12 Service Manual

Home theater soundbar

Advertisement

Quick Links

Home Theater Soundbar
Copyright 2014 WOOX Innovations Limited.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system
or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of WOOX Innovations. Philips and the Philips'Shield Emblem are
registered trademarks of Koninklijke Philips N.V. and are used by WOOX Innovations Limited
under license from Koninklijke Philips N.V.
Published by Arya & Lynn - WK1420 Subject to modification
Version 1.3
HTB4152B/12 & HTB4150B/12/51/98/93/79
TABLE OF CONTENTS
Location of PC Boards & Versions Variation ........................ 1
Specifi cations ....................................................................... 2
Safety Instruction .................................................................. 3
Software Upgrade Instruction..................................................4
Troubleshooting.................................................................... 5
Disassembly Instructions ..................................................... 6
Set Wiring & Block Diagram ................................................. 7
Circuit Diagram & PCBA Layout........................................... 8
Set Mechanical Exploded View .......................................... 9
Revision List ........................................................................ 10
Page
3143 038 61153

Advertisement

loading

Summary of Contents for Panasonic HTB4152B/12

  • Page 1 Home Theater Soundbar HTB4152B/12 & HTB4150B/12/51/98/93/79 TABLE OF CONTENTS Page Location of PC Boards & Versions Variation ......1 Specifi cations ............... 2 Safety Instruction ..............3 Software Upgrade Instruction..........4 Troubleshooting..............5 Disassembly Instructions ............. 6 Set Wiring & Block Diagram ..........7 Circuit Diagram &...
  • Page 2 PCB Board Locations FRONT CONTROL TOUCH BOARD BOARD USB&MP3 BOARD OK BOARD (FOR /98/51 REGION) NFC BOARD Top side LOADER POWER BOARD AMPLIFIER BOARD MAIN BOARD Bottom side VERSION VARIATIONS Type / Versions HTB4152 HTB4150 Service Policy Board in used B/12 B/12 B/51 B/98 B/93 B/79 MAIN BOARD...
  • Page 3 HTB4150B: Product File formats specifications Audio: .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a, China) Note Video: .avi, .divx, .mp4, .m4v, .mkv, .asf, .wmv, notice. .rmvb, .rm, .rv (Available only in Asia Picture: .jpg, .jpeg, .jpe, .gif, .png Region codes Bluetooth The type plate on the back or bottom of the SoundStage shows which regions it supports.
  • Page 4 1.54 Mbps MPEG 4 SP / ASP 38.4 core Mbps MPEG 912 kbps H.264/AVC upto 25 Mbps HiP@4.2 Upto 320 kbps WMV9 45 Mbps Upto 192 kbps AAC, Upto 192 Audio codec Video codec Bit rate kbps PCM, Dolby DivX 3.11, Digital, MP3, DivX 4.x, DivX 5.x, Mbps...
  • Page 5 Audio codec Video Bit rate codec Audio codec Video codec Bit rate PCM, Dolby Digital, MPEG 1, AAC, COOK RV30, RV40 40 Mbps DTS core, MPEG, MPEG 2 Mbps MP3, WMA, AAC, HE-AAC, Dolby Digital Plus MPEG 4 ASP 38.4 Mbps Total output power: 80W RMS (10% THD) Frequency response: 20 Hz-20 kHz /...
  • Page 6 Remote control batteries MHz (50/100 kHz) Signal-to-noise ratio: FM 50 dB 2 x AAA-R03-1.5 V Frequency response: FM 180 Hz-12.5 kHz / ±3 dB Laser Laser Type (Diode): InGaN/AIGaN (BD), AIGaInP (DVD/CD) Compatibility: Hi-Speed USB (2.0) Wave length: 405 ±7 nm (BD), Class support: USB Mass Storage Class 660 ±10 nm (DVD), 785 ±10 nm (CD) (MSC)
  • Page 7 HTB4152B: Product File formats specifications Audio: .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a, China) Note Video: .avi, .divx, .mp4, .m4v, .mkv, .asf, .wmv, notice. .rmvb, .rm, .rv (Available only in Asia Picture: .jpg, .jpeg, .jpe, .gif, .png Region codes Bluetooth The type plate on the back or bottom of the SoundStage shows which regions it supports.
  • Page 8 1.54 Mbps MPEG 4 SP / ASP 38.4 core Mbps MPEG 912 kbps H.264/AVC upto 25 Mbps HiP@4.2 Upto 320 kbps WMV9 45 Mbps Upto 192 kbps AAC, Upto 192 Audio codec Video codec Bit rate kbps PCM, Dolby DivX 3.11, Digital, MP3, DivX 4.x, DivX 5.x, Mbps...
  • Page 9 Audio codec Video Bit rate codec PCM, Dolby Digital, MPEG 1, Audio codec Video codec Bit rate DTS core, MPEG, MPEG 2 Mbps AAC, COOK RV30, RV40 40 Mbps MP3, WMA, AAC, HE-AAC, Dolby Digital Plus MPEG 4 ASP 38.4 Mbps H.264/AVC Total output power: 80W RMS (10% THD)
  • Page 10 Remote control batteries MHz (50/100 kHz) Signal-to-noise ratio: FM 50 dB 2 x AAA-R03-1.5 V Frequency response: FM 180 Hz-12.5 kHz / ±3 dB Laser Laser Type (Diode): InGaN/AIGaN (BD), AIGaInP (DVD/CD) Compatibility: Hi-Speed USB (2.0) Wave length: 405 ±7 nm (BD), Class support: USB Mass Storage Class 660 ±10 nm (DVD), 785 ±10 nm (CD) (MSC)
  • Page 11 Solder Joint...
  • Page 12 Software Upgrade for HTB4150B 1. There are 2 ways to software upgrade: First:  Upgrade from USB:  New a folder in root directory of USB and name it ‘UPG’. Copy the upgrade file HTB4150.BIN to the UPG directory then press the HOME  key on RC into HOME screen .Select ‘Setup’‐>’Advanced’‐>’Software  update’‐>’USB’ in order and then press OK key .  When upgrade file detected, select "Start" to upgrade, select "Cancel"...
  • Page 13 Software Upgrade for HTB4152B 1. There are 2 ways to software upgrade: First:  Upgrade from USB:  New a folder in root directory of USB and name it ‘UPG’. Copy the upgrade file HTB4152.BIN to the UPG directory then press the HOME  key on RC into HOME screen .Select ‘Setup’‐>’Advanced’‐>’Software  update’‐>’USB’ in order and then press OK key .  When upgrade file detected, select "Start" to upgrade, select "Cancel"...
  • Page 14 Trouble shooting Chart LED No display on Front Control Board LED No display on Front Control Board Check every supply voltage on AM Board whether normal or not. Refer to CON503 on Power Board (XS1 PIN1&PIN2&PIN3: +18V) Check voltage +5V on main Board at XP6 Check whether U6 and U7 work good PIN5&PIN6: +5V or not? And fix it or replace the AM...
  • Page 15 Trouble shooting Chart keys do not work keys do not work Check voltage 3.3V on Front Board R189 Fix the connection XP9 to XP9 on Main Board Check Front Control Board signals at XP9 Pin20:LED_SCL, Pin21:LED_SDA Replace U8 on Main Board, or replace Main Board Replace Touchkey Board...
  • Page 16 Trouble shooting Chart Remote control does not work Remote control does not work Check battery of remote control whether exhausted or not. Replace the battery for remote control Check power supply of IR601 on Front Check the +3.3V net on Front Control Board whether normal or not Control Board to Main Board XP9 XP9 Pin19:+3.3V...
  • Page 17 Trouble shooting Chart No audio output No audio output Check voltage +18V for whether normal or Refer to CON503 on Power Board not at on Amplifier Board Check the 24Pin FFC connection XP13 on Main Board and XP4 on Amplifier Board Replace the connection cable whether right or not between Main Board and Amplifier Board...
  • Page 18 Trouble shooting Chart No video output No video output Check L452, R616 whether right on Main Add L452, R616 Board Check the video signal whether right at U1: PIN B18 or R615 Replace Main IC or Main Board...
  • Page 19 Trouble shooting Chart Can’t read disc or can’t open the disk door Can’t read disc or can’t open the disk door Check loader work normally or not Check XP7 on Main Board Check 45Pin, 8Pin, 4Pin cable from Main Board to Loader connect right or Fix 45Pin, 8Pin, 4Pin cable Replace Loader 、...
  • Page 20 Trouble shooting Chart Tuner FM does not work Tuner FM does not work Check voltage at U17 PIN1 (+5V) on Check whether U6 and U7 work good Main Board whether normal or not or not? And fix it or replace the AM board.
  • Page 21 Trouble shooting Chart AUX in does not work AUX in does not work Check voltage at U18 PIN16 (6V),check 12V on Main Board whether normal or not Refer to Power Board CON503 Check Main Board U18 Pin4, Pin11 signal input whether right or not Check AUX IN connector Check 74HC4052...
  • Page 22 Trouble shooting Chart MP3 Link does not work MP3 Link does not work Check signal PIN28:MP3_R PIN26:MP3_L ON front board whether normal Refer to Main Board XP9 or not Check Main Board U18 74HC4052 PIN2, Check Main Board C361, C352, R352, PIN15 L/R signal input right or not R458 Check voltage at U18 PIN16 (6V), check...
  • Page 23 5-10 Trouble shooting Chart COAX in does not work COAX in does not work Check voltage at U27 PIN6/PIN23:3.3V on Main Board whether normal or not Check power supply circuit. Check Main Board U27 CS8416 PIN3 input signal whether normal or not Check Main Board C360, L11 Check U27 CS8416 whether broken.
  • Page 24 5-11 Trouble shooting Chart Karaoke in does not work Karaoke in does not work Check signal at XP9 PIN30:MIC_in signal from front board normal or not Refer to Main Board XP9 Check Main Board U18 74HC4052 PIN5, PIN14 L/R signal input right or not Check the cable between XP9 and XP9 Check U18 74HC4052 whether broken Check Main Board U26...
  • Page 25 5-12 Trouble shooting Chart Network in does not work Network in does not work P3 Pin1, Pin2, Pin3, Pin6 from Check netting twine normal or not netting twine link Check normal or Replace P3...
  • Page 26 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 1:Open the front panel.Open the cloth network directly first, then remove 12 shock absorption cushions and 12 screws on the front cover.Open the front panel.(Figure 1) (Figure 1)
  • Page 27 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 2:Dismantle the NFC board and Touch board.Dismantle these two boards directly.(Figure 2) (Figure 2) Step 3:Dismantle the Front Control board.Remove 4 screws on the board,then disconnect connectors (XS1,XS2,XP9).(Figure 3) (Figure 3) Step 4:Dismantle the USB &...
  • Page 28 Mechanical and Dismantling Instructions Dismantling Instruction Detailed information please refer to the model set. The following guidelines show how to dismantle the player. Step 6:Dismantle the Loader.Rive off 4 rubber pads on the plastic feet and then remove 16 screws on the two matel bottom covers.Open the cover on right side.Disconnect connectors(XP7,J11,J12).
  • Page 29 Wiring and Block Diagram for HTB4150B/HTB4152B TUNER SPK L/R 74HC4052 ARC(OPTI) BD BOARD I/O*3 AK5358 SDIN ASCLK ALRCLK MT8560 SPK HL/HR STA339BWS CS8416 AOSDATA0 AOLRCK AOSDATA1 AOSDATA2 AOBCK AOMCLK RESET AMP_SCL SPK SUB AMP_SDA AMP_MUTE MOTOR AMP_RST 3.3V DRIVER RESET MUTE 3.3V MUTE...
  • Page 30 OK Board Circuit Diagram: REFM REFM R646 R646 +12V_D_A R609 R609 2.2K 2.2K 12VA REFM + CE608 + CE608 CE609 + CE609 C772 C772 220uF/16V 220uF/16V 0.1uF/16V/Y5V 0.1uF/16V/Y5V 47uF/16V 47uF/16V R610 R610 C611 C611 47pF/50V/NP0 47pF/50V/NP0 R643 R643 R642 R642 110K 110K 100K...
  • Page 31 USB & MP3 Board Circuit Diagram: 600/200mA 600/200mA MP3_R MP3_L 3PIN/2.0mm 3PIN/2.0mm DET2 600/200mA 600/200mA coax 7PIN/PJ-3523 7PIN/PJ-3523 USB INPUT USB-A/WT USB-A/WT USB_DM USB_DP USB_DM USB_DP 4PIN/2.0mm 4PIN/2.0mm PRTR5V0U2X PRTR5V0U2X ESD3 ESD3 NC/0 NC/0 NC/0 NC/0 NC/0 NC/0...
  • Page 32 Touch Board Circuit Diagram: 3.3V_STBY R669 R669 C627 C627 C637 C637 VOLUME- PAD601 PAD601 SOURCE PAD602 PAD602 PAD603 PAD603 STANDBY PAD604 PAD604 OPEN/CLOSE GNDA PAD605 PAD605 VOLUME+ SI[5] OUT2 SI[6] OUT3 SI[7] OUT4 C630 C630 C631 C631 C632 C632 C633 C633 C634 C634...
  • Page 33 Front Control Board Circuit Diagram:VFD C251 C251 C252 C252 NC/10pF/50V/NP0 NC/10pF/50V/NP0 NFC_FD NC/10pF/50V/NP0 NC/10pF/50V/NP0 R194 R194 R193 R193 NFC_FD SCL_MCU SDA_MCU R190 R190 PIO13 R191 R191 PIO11 R192 R192 PIO9 BT_ADUIO_EN BT_STATUS MIC_Detect LED_CON USB_VCC VCC_D DIG1 DIG1 R189 R189 DIG2 3.3V_STBY DIG2...
  • Page 34 Front Control Board Circuit Diagram:Bluetooth Bluetooth TP32 TP32 NC/0 NC/0 NC/0 NC/0 500/500mA 500/500mA R938 R938 100K 100K BT_ADUIO_EN R195 R195 BT_ADUIO_EN 3.3V_STBY BT_3V3 BT_STATUS BT_STATUS BT_3V3 NC/PNP_3CG3906M NC/PNP_3CG3906M R945 R945 BT_BM160 BT_BM160 R946 R946 9.1K 9.1K C775 C775 R937 R937 R319 R319...
  • Page 35 Front Control Board Circuit Diagram:NFC TP38 TP38 NTAG203F NTAG203F 39pF/50V/NP0 39pF/50V/NP0 0.1uF/16V/Y5V 0.1uF/16V/Y5V 2PIN/1.25mm 2PIN/1.25mm TP39 TP39...
  • Page 36 Power Board Circuit Diagram: TR501 TR501 FB502 FB502 FB90@100MHz FB90@100MHz T5311 T5311 EE25 EE25 CY503 CY503 NTC/3ohm/5A NTC/3ohm/5A R502A R502A R502C R502C LIF4-22-15 LIF4-22-15 LIF4-22-15 LIF4-22-15 220pF/250VAC 220pF/250VAC LIF501 LIF501 +18V KBP306 KBP306 LIF502 LIF502 CY501 CY501 220pF/250VAC 220pF/250VAC CN501 CN501 CE502 CE502...
  • Page 37 Amplifier Board Circuit Diagram:Power 6PIN/2.5mm/120mm 6PIN/2.5mm/120mm POWER_18V POWER_18V FB11 FB11 120/2A 120/2A 10uF/50V 10uF/50V 6.8uH/2.4A 6.8uH/2.4A 0.01uF/50V/X7R 0.01uF/50V/X7R 220K 220K 49.9K/1% 49.9K/1% C121 C121 R137 R137 EUP3482A EUP3482A 10K/1% 10K/1% C127 C127 C120 C120 3300pF/50V/X7R 3300pF/50V/X7R 0.1uF/25V/Y5V 0.1uF/25V/Y5V 1K/1% 1K/1% 7.5K 7.5K AMP_VCC...
  • Page 38 Amplifier Board Circuit Diagram:AMP +3.3V 24PIN/0.5mm 24PIN/0.5mm NC/4.7K NC/4.7K 4.7K 4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K NC/4.7K FAULT AMP_RST 1/2power-control AUDIO_MUTE +3.3V AMP_SDA AMP_SCL 500/800mA 500/800mA AD_MCLK +3.3V +3.3VD AD_BCLK RESET I2S_DOUT2 FB13 FB13 500/200mA 500/200mA DSP_MUTE I2S_DOUT1 TP19...
  • Page 39 8-10 8-10 OK Board Print-layout (bottom side)
  • Page 40 8-11 8-11 USB & MP3 Board Print-layout (bottom and top side)
  • Page 41 8-12 8-12 Touch Board Print-layout (bottom and top side)
  • Page 42 8-13 8-13 Front Control Board Print-layout (bottom and top side)
  • Page 43 8-14 8-14 Power Board Print-layout (bottom side)
  • Page 44 8-15 8-15 Amplifier Board Print-layout (bottom side)
  • Page 45 8-16 8-16 Amplifier Board Print-layout (top side)
  • Page 46 Exploded View for HTB4150B: Partlist refer to a separated excel file on FYP...
  • Page 47 Exploded View for HTB4152B: Partlist refer to a separated excel file on FYP...
