Grizzly T33679 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T33679 produces 3600 lumens and is
designed with three articulating joints and a swivel
base to provide an extensive range of movement.
It can be mounted to nearly any flat surface using
the L-bracket or clamping bracket.
Figure 1. Model T33679.
To reduce risk of serious
injury, read this entire
manual
LED
understand instructions/
safety warnings provided
by manufacturer for any
machine or tool you plan to
use with this light.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
BEFORE using
light. Read
COPYRIGHT © MARCH, 2023 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 03/23) #MN22628 PRINTED IN CHINA
***Keep for Future Reference***
ARTICULATING
Inventory
Contents (Figure 2)
A. LED Light Assembly ................................... 1
—Base........................................................ 1
—Arm ......................................................... 1
—LED Light ................................................ 1
B. Clamping Bracket ....................................... 1
C. L-Bracket .................................................... 1
D. Crown Washers 8mm ................................. 4
E. Button Hd Cap Screws M8-1.25 x 50 ......... 2
F. Cap Screws M5-.8 x 16 .............................. 4
G. Fender Washers 8 x 30 x 0.6mm ............... 6
H. Flat Washers 5mm ..................................... 4
I. Lock Nuts M8-1.25 ..................................... 2
J. Hex Wrench 4mm ....................................... 1
K. Hex Wrench 5mm ....................................... 1
L. Open-End Wrench 13mm ........................... 1
and
MODEL T33679
LED LIGHT
INSTRUCTIONS
A
B C
E
G
Figure 2. Inventory.
Qty
D
F
H I
J K L
V1.03.23
