Philips 50PUN6102/61 Service Manual

Hide thumbs Also See for 50PUN6102/61:
Table of Contents

Advertisement

Quick Links

Download this manual
Chassis name
TPS17.3A LA
Published by Amy.ma 1752 Quality
2017
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Platform
MSD91H
Subject to modification
TPS17.3A
Model name
50PUN6102/61
55PUN6102/61
3122 785 20550
2017-Dec-27

Advertisement

Table of Contents
loading

Related Manuals for Philips 50PUN6102/61

Summary of Contents for Philips 50PUN6102/61

  • Page 1 Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 3: Product Information

    1. Product information Connectivity Product information may be subject to change without prior notice. For detailed product information, please go to TV Side • USB www.philips.com/support • HDMI 2 • HDMI 3 Display & Sound TV Bottom • Audio out (L/R) Intrinsic resolution •...

  • Page 4: Connections Overview

    2. Connections Overview SCALER HDMI YPBPR HDMI Optical Audio out (L/R) Antenna （For 715G9070M）...

  • Page 5: Mechanical Instructions

    3. Mechanical Instructions 3.1 Cable Dressing ECN8603 ECN701 CN8603 CN9101 ECN102 MAIN POWER SUPPLY CN102 (1054) CN701 (1053) CN105 CN602 ECN01 ECN105 TO IR & Connector(to KEY) ECN602 Connector ECN602 LOUDSPEAKER LOUDSPEAKER (1184) (1184) IR/LED BOARD Cable dressing (50" 6102 series) (1056) ECN701 CN8601...
  • Page 6 3.2.1 Stand removal 1. Remove the fixation screws [1] that secure the stand 2. Take the stand bracket out from the set. 3.2.2 IR board Control Unit 1. Unplug the connector from the SSB. Caution: be careful, as these are very fragile connectors! 2.
  • Page 7 3.2.3 Keyboard Control Unit Release the connector from the SSB Board. Caution: be careful, the Keyboard is catch on the Back cover, please be careful to avoid damage the fragile connectors! Remove all the fixation screws[1] and connector [2] from the keyboard control panel and take it out from the Back cover When defective, replace the whole unit.
  • Page 8 3.2.4 Small Signal Board (SSB) Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the SSB. 1. Release the clips from the LVDS connector that connect with the SSB[1]. Caution: be careful, as these are very fragile connectors! 2.
  • Page 9 3.2.5 Power Supply Unit (PSU) Caution: it is mandatory to remount all different screws at their original position during re-assembly. Failure to do so may result in damaging the PSU. 1. Gently unplug all connectors from the PSU. 2. Remove all fixation screws from the PSU. 3.

  • Page 10: Service Modes

    4. Service Modes 4.1 Service Modes The Service Mode feature is split into following parts: Factory Mode.  Customer Service Mode (CSM).  Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. Some features are: ...
  • Page 11 How to Exit the Factory mode Select EXIT from the menu and press the “OK” button.  Note: When the TV is switched “off” by a power interrupt, or normal switch to “stand-by” while in the factory mode, the TV will show up in “normal operation mode”...

  • Page 12: Software Upgrading, Error Code And Panel Code

    5. Software Upgrading, Error code and Panel Code 5.1 Software Upgrading Step 1: Ready for F/W Upgrade 1. Rename the file to “TPV91H.bin” 2. Prepare a USB memory. 3. Copy the software to USB flash disk (root directory). 4. Switch off the TV and Insert the USB memory stick that contains the software update files in the TV’s USB port Note the version of this F/W before you change the software file name.

  • Page 13: Circuit Descriptions

    6. Circuit Descriptions 6.1 Introduction The TPS17.3A LA is a new chassis launched in AP in 2017. The whole range is covered by MSD91H platform. The major deltas versus its predecessor support NTSC Digital TV, with Video out. The TPS17.3A LA chassis comes with the following stylings: series xxPUN6102/xx ...
  • Page 14 Always replace a defective fuse with one with the correct specifications! This part is available in the regular market. Consult the Philips Service web portal for the order codes of the boards. Important delta’s with the platform are: •...
  • Page 15 - direct-view LED without 2D-dimming: PSL power panel - direct-view LED with 2D-dimming: PSDL power panel. PSL stands for Power Supply with integrated LED-drivers. PSLS stands for a Power Supply with integrated LED-drivers with added Scanning functionality (added microcontroller). PSDL stands for a Power Supply for Direct-view LED backlight with 2D-dimming. 6.3 DC/DC Converters The on-board DC/DC converters deliver the following voltages(depending on set execution): •...
  • Page 16 6.3.2 Power layout SSB C165 +3.3V_TUN C732 +3.3V_SB L701 +5V_SB L702 +1.15V_VDDC C729 +1.8V_DDR2 Power SSB Top View (For 715G9070M) 6.4 Video and Audio Processing - MSD91H1BN2 The MSD91H1BN2-L-006J S3EPLQFP-156 is the main audio and video processor (or System-on-Chip) for this platform. It has the following features: 1.
  • Page 17 streaming playback. Moreover, MSD91H1BN2 is equipped with a DSP specifically designated for audio application, including digital audio format decoding and advanced sound effects, and a high performance RISC CPU to manipulate all possible routines and house-keeping activities. With extendable USB 2.0 interface, an MSD91H1BN2 based system can turn into a high quality media-center in a simple manner.

  • Page 18: Ic Data Sheet

    7. IC Data Sheets 7.1 MSD91H (IC U401)
  • Page 19 7.2 AD87588-LG48NAY (IC U601)
  • Page 20 7.3 Si2151-A10-GMR (IC U101)

  • Page 21: Circuit Diagrams

    8.Circuit Diagrams 8.1 A 715G7374 PSU (For 55” 6102 Series) 8-1-1 AC Input CN9903 F9902 C9913 220PF 250V T5AL/250V F9901 FB9901 SG9901 NR9901 NR9902 500V BEAD FUSE NTCR 3.6W T5AH/250V NTCR 3.6W C9902 BD9901 470NF 275V C9911 TS25P06G-06 22PF 250V CN9902 CN9901 L9901...
  • Page 22 8-1-2 PFC-LD7591T D9801 D9803 C9801 47PF 1KV FB9801 S8KC S8KC FB9805 D9802 FMNS-1106S Vsin BEAD BEAD L9801 FB9804 BEAD C9802 R9804 HV_A 170uH 10NF 1KV 1M 1% 1/4W C9804 C9803 D9804 68uF 450V 68uF 450V R9802 IN4148W RHG 10 OHM 1/4W C9817 R9806 47PF 1KV...
  • Page 23 8-1-3 Standby-SSC3S121 COLD 12VS L9102 HV_A +12V/+16V T9102 FB9101 T9101 X'FMR 300uH C9126 220uF 25V C9147 C9148 D9106 BEAD FME-220B C9101 1000PF C9102 R9105 L9103 C9103 2.2NF 82K 2W +12V_A/+16V_A R9103 ZD9104 620K +-1% 1/4W BZT52-B39 C9127 D9102 D9107 220uF 25V R9104 FME-220B 620K +-1% 1/4W...
  • Page 24 8-1-4 LED-SSC9522S+TPV101A or C R8601 0.1R 1W D8614 MBRF10150CT R8602 1M5 1/4W 1% Q8601 C8601 D8601 TK10A50D VCC_ON VBoot 1000PF IN4148W RHG R8613 C8618 T8601 R8603 1M5 1/4W 1% D8603 UF4007 R8611 10R 1/8W 5% VLED R8612 R8604 10R 1/8W 5% Q8603 1M5 1/4W 1% 47 +-5% 1/8W...
  • Page 25 8.2 A 715G9324 PSU (For 50” 6102 Series) 8-2-1 AC Input F9902 X90G20100080000ABF : 52mm*10mm FUSE X90G201001500000HG : 52mm*20mm NR9902 NTCR 5R For BD9901 C9913 T5AH/250V 220PF 250V F9901 HS9902 HS9901 NC / 5A 250V SG9902 NC / HEAT SINK NC / HEAT SINK DSPL-501N-A21F NR9901...
  • Page 26 8-2-2 PFC with LD7592GS D9802 D9803 C9804 NC / S8KC NC / S8KC 47PF FB9802 FB9801 D9801 BEAD L9802 L9801 127R FMNS-1106S NC / 300uH 10% 300uH Vsin C9801 C9802 Q9801 C9800 D9804 56UF 450V 56UF 450V R9804 R9803 TK13A60D 1UF 450V SS1060FL C9817...
  • Page 27 8-2-3 LLC with SSC3S927 R9103 R9110 R9101 68K 1/8W 1% 1.5Mohm 1/4W +/-1% 2.7M 1% COLD R9102 R9123 C9100 C9102 2Mohm 1/4W +/-1% 1K 1% NC / 1.5NF 2.2nF 50V C9103 C9101 R9124 2.2NF NC / 1NF 1K 1% D9104 IN4148W RHG T9101 Q9101...
  • Page 28 8-2-4 Driver with OZ9902C L8603 NC / BOOST CHOKE D8601 L8602 +VLED +20V FB8601 BEAD L8601 C8622 C8612 C8613 C8614 R8631 33uH R8608 Q8601 220uF 50V 220uF 50V 220uF 50V 220uF 50V TK22A10N1 FCHS30A08 R8610 C8616 10 OHM 1% 1/4W 47PF 16VS Co-Lay...

  • Page 29: B 715G9070 Ssb

    8.3 B 715G9070 SSB 8-3-1 AV/YPbPr/SPDIF Change CONN 088G 78G154AYG. 20170216 Nearly Connector Nearly IC AV1_IN R102 C104 47NF 16V CVBS0P CVBS0P 150 OHM 5% 1/16W R103 C139 47NF 16V CVBS_VCOM CVBS_VCOM NEARLY CONN. 180R 1/16W 5% CN101 Y PBPR_R_IN#1 Y _IN#1 COMP_Y HD_RIN...
  • Page 30 8-3-2 Tuner In/Debug IF Interface Filter- Close to Tuner Silicon Tuner +3.3V_TU +3.3V_TU C138 33pF 50V C102 R135 R146 1.2nF 50V IF_FAT_IN+ IF_FAT_P C175 100R 1/16W 1% C159 0R05 1/16W 1.2nF 50V R186 1UF 10V R136 R147 C177 IF_FAT_IN- IF_FAT_N L103 100NF 16V C157...
  • Page 31 8-3-3 HDMI INPUT HDMI0&ARC (HDMI 2.0) HDMI NET CN501 388G340FJ05FAT0001 HDMI0-RX0P HDMI0/5V SHLD0 HDMI0-RX0P HDMI0-RX2P HDMI0-RX0N TMDSD2+ HDMI0-RX0N HDMI0-RX1P HDMI0-RX1P SHLD2 DSHLD0 HDMI0-RX2N HDMI0-RX1N HDMI0/5V HDMI0-RX1N TMDSD2- HDMI0-RX1P HDMI0-RX2P R502 R503 TMDSD1+ HDMI0-RX2P HDMI0-RX2N DSHLD1 HDMI0-RX2N HDMI0-RX1N HDMI0-CLKN HDMI0-CLKN TMDSD1- HDMI0-RX0P HDMI0-CLKP R504...
  • Page 32 8-3-4 MSD91H1BN_Scaler HDMI Interface Core Power 1.15V HDMI0-RX0P Change from X5R to X6S/X7R. HDMI0-RX0P HDMI0-RX0N +1.15V_VDDC HDMI0-RX0N HDMI0-RX1P HDMI0-RX1P HDMI0-RX1N HDMI0-RX1N HDMI0-RX2P HDMI0-RX2P HDMI0-RX2N C402 C403 C404 C405 C406 C407 C408 HDMI0-RX2N HDMI0-CLKN HDMI0-CLKN HDMI0-CLKP 2.2uF 6.3V 100NF 16V 100NF 16V 100NF 16V 100NF 16V 100NF 16V...
  • Page 33 388G352F6B3AXH IR / KEY BOARD CONN. +3.3V_Standby +3.3V_Standby R139 R138 0R05 CN105 30K OHM +-1% 1/16W +3.3V_Standby IR-in Follow Philips AP IR board, modify R141 100R 1/16W 1% R172 IR-in IR_3VSB circuit.(2017/07/13) C152 NC/3.3K 1% Key pad_power_key KEY _PAD0 R140...
  • Page 34 8-3-6 AUDIO AMP/HEADPHONE C617/C623 Separate VCC trace POP NOISE (AC OFF) HS601 Close to CN601 AMP_3V3 +5V_Standby PVDD AMP+HP_PDN +12V_AUD PVDD +12V_AUD R604 Main filter Option D601 PD_MUTE Q601 L601 HEAT SINK LOUT+ R602 LL4148 MMBT3904 C602 AMP_RESET# C601 R603 22uH 100UF 35V C603...
  • Page 35 8-3-7 SYSTEM POWER +12V= 16V for 50" & 55" power board MAIN POWER +12V Connector +5V_Standby +5V_Normal Q702 AO3401A CN701 C701 C703 C702 BL_DIM BL_ON R702 PS_ON 100PF 50V 0.1uF 100UF 25V C704 +5V_Normal / C705 +19 use 330NF 16V ???mA 47K 1/16W 5% 0.1uF...
  • Page 36 8.4 J 715G8623 IR/LED Panel 8-4-1 IR BOARD Light Sensor CN201 R223 R224 R225 R226 R227 R228 R229 I2C ADDR LED_R DVD3V3 DVD3V3 JSA-1130 0x44 RC-IR C222 1uF 10V JSA-1130 0x45 3V3SB LS_SCL R225 0R05 1/16W C221 100N 16V DVD3V3 LS_SDA TSL25715 0x29...
  • Page 37 8.5 E 715G7088 Keyboard control panel 8-5-1 Key BOARD...
  • Page 38 9. Styling Sheets 9.1 6102 series 50" 1053 1184 1050 1057 1056 1054...
  • Page 39 9.2 6102 series 55 1054 1053 1050 1184 1057+63 1056+36...
