U-Line Origins 15R Supplementary Manual

¼" CUSTOM PANEL SIZES
BI·95
BI·98
75 Series
75 Stainless Series
29 Series
15 Series
15 Stainless Series
Zero clearance on black and white models with a flush/flat
door panel.
Door will accept a raised panel. Allow proper clearance, on
hinge side when installing a raised panel. Amount of clearance
will depend on raised panel thickness.
The maximum panel thickness when inserted into the door reveal
(channel) is ¼" thick.
For raised panels, on black and white models, the depth of the
reveal is ¼" on both sides and bottom and ½" on top.
For raised panels, on stainless steel models, the depth of the
reveal is ¼" on both sides, top and bottom.
Allow 9/16" clearance on hinge side for all stainless steel models
with flush/flat panel. Additional clearance maybe needed, on hinge
side when installing a raised panel. Amount of clearance will depend
on raised panel thickness.
Panel not to exceed 20 pounds.
Conversion information: 1 inch = 2.54 cm
ORIGINS
13 15/32" H x 12 15/16" H
15 15/16" x 13 15/16" W
28 5/32" H x 22 15/16" W
29 13/32" H x 22 15/16" W
21 13/32" H x 19 13/16" W
28 5/32" H x 13 15/16" W
29 13/32" H x 13 15/16" W
