READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YXR70FY/YXR70FDUY/YXR70FSEPY
YXR70FHY/YXR70FSEY
5B4-F8199-71

Advertisement

Table of Contents
loading

Related Manuals for Yamaha RHINO FUEL INJECTION 700 FI 2008

Summary of Contents for Yamaha RHINO FUEL INJECTION 700 FI 2008

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YXR70FY/YXR70FDUY/YXR70FSEPY YXR70FHY/YXR70FSEY 5B4-F8199-71...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold.
  • Page 3 YXR70FHY/YXR70FSEY. It represents the result of many years of Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EVU00021 IMPORTANT MANUAL INFORMATION FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SE- RIOUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5 This vehicle complies with almost all provinces off-highway noise level and spark ar- rester laws and regulations. YXR70FY/YXR70FDUY/YXR70FSEPY/ YXR70FHY/YXR70FSEY OWNER’S MANUAL ©2008 by Yamaha Motor Co., Ltd. 1st edition, April 2008 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.

  • Page 6: Table Of Contents

    EVU00050 Glove compartment .......4-18 CONTENTS Cup holders........4-18 Cargo bed ........4-19 LOCATION OF THE WARNING Front and rear shock absorber AND SPECIFICATION LABELS..1-1 adjustment (YXR70FY/ YXR70FDUY/YXR70FHY/ SAFETY INFORMATION....2-1 YXR70FSEY).......4-21 Adjusting the front shock absorber DESCRIPTION ......... 3-1 assemblies (YXR70FSEPY)..4-23 Adjusting the rear shock absorber INSTRUMENT AND CONTROL assemblies (YXR70FSEPY)..4-29...
  • Page 7 Accelerator pedal ......5-8 Passenger requirements ....7-4 Seat belts ........5-8 Occupant protection system.... 7-4 Steering........... 5-8 Protective structure......7-6 Fittings and fasteners...... 5-8 Seat belts......... 7-6 Lights..........5-9 Doors ..........7-9 Switches.......... 5-9 Passenger handholds...... 7-9 Control cables ......... 5-9 Seat and hip restraints ....
  • Page 8 Operation on different surfaces Differential gear oil ......8-19 and terrains........7-18 Coolant...........8-21 Hills ..........7-19 Axle boots ........8-23 Uphill..........7-20 Spark plug inspection ....8-24 Downhill ......... 7-21 Cleaning the air filter element ..8-26 Rough terrain......... 7-22 Drive select lever box check Pavement ........
  • Page 9 Brake pedal and accelerator CONSUMER INFORMATION ..11-1 pedal lubrication ......8-41 Identification number records..11-1 Rear knuckle upper and lower YAMAHA SIDE BY SIDE pivot lubrication ......8-41 OFF-ROAD VEHICLE Steering shaft lubrication ....8-43 WARRANTY POLICY ....11-4 Wheel removal ......

  • Page 10: Location Of The Warning And Specification Labels

    EVU00060 L OCATION OF THE WARNING AND SPECIFICATION LABELS H I J...
  • Page 11 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a re- placement label is available from your Yamaha dealer. WARNING WARNING...
  • Page 14 9 YXR70FSEPY 0 YXR70FSEPY...
  • Page 17 MAX 7.3 INCH (185MM) YAMAHA 5UG-F151J-00...
  • Page 19 1-10...

  • Page 20: Safety Information

    EVU00070 SAFETY INFORMATION Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Rhino. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 7 before operating the Rhino. Also use these two chapters and the labels on the vehicle to instruct new operators and passengers.
  • Page 21 Before you operate the Rhino Prepare yourself and your passenger: • This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li- cense. DRIVER UNDER • This vehicle is designed to carry the driver and one passenger. Never carry passengers in the cargo bed.
  • Page 22 Prepare your vehicle Perform the pre-operation checks each time you use the vehicle to make sure it is in safe operat- ing condition. Failure to inspect or maintain the vehicle properly increases the possibility of an ac- cident or equipment damage. See pages 5-1–5-2 for a list of pre-operation checks. Prepare your load or trailer Carrying loads, towing a trailer, or pulling objects can affect handling, stability, and risk of overturn or other accidents.
  • Page 23 While using the Rhino Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel. Be sure passenger is seated, belted, and holding onto the handholds. Close doors be- fore driving. Any part of your body (arms, legs, and head) outside the vehicle can be struck by objects your vehicle is passing or crushed by the vehicle cage/frame in a rollover accident.
  • Page 24 Avoid rollovers: • Use care when turning: • Turning the steering wheel too far or too fast can result in a rollover. • Avoid sideways sliding, skidding, or fishtailing, and never do donuts. • Slow down before entering a turn and avoid hard braking in a turn. •...
  • Page 25 • Drive straight up and down inclines, not across them. If crossing a hill is unavoidable, drive slowly and turn downhill immediately if you feel the vehicle may tip. • Avoid paved surfaces. Turn gradually and go slowly if you must drive on pavement. This ve- hicle is designed for off-road use only.
  • Page 26 When loaded with cargo or towing a trailer: • Reduce speed, operate in low gear only, and allow more room to stop. • Avoid hills and rough terrain. Use extreme caution when towing or carrying a load on in- clines. •...
  • Page 27 Avoid carbon monoxide poisoning All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon monoxide can cause headaches, dizziness, drowsiness, nausea, confusion, and eventually death. Carbon monoxide is a colorless, odorless, tasteless gas which may be present even if you do not see or smell any engine exhaust.
  • Page 28 Many companies with no connection to Yamaha manufacture parts and accessories or offer other modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these af- termarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
  • Page 29 Aftermarket tires and rims The tires and rims that came with your Rhino were designed to match the performance capabili- ties and to provide the best combination of handling, braking, and comfort. Other tires, rims, sizes, and combinations may not be appropriate. Refer to pages 8-43–8-46 for tire specifications and more information on replacing your tires.

  • Page 30: Description

    EVU00080 D ESCRIPTION I J K 1. Headlights 14. Spark arrester 2. Front shock absorber assembly 15. Passenger seat belt 3. Brake fluid reservoir 16. Passenger seat 4. Air filter element 17. Passenger handhold 5. V-belt case 18. Engine oil dipstick 6.
  • Page 31 The vehicle you have purchased may differ slightly from those shown in the figures of this manual. 25. Light switch 26. Steering wheel 27. Main switch 28. On-Command four-wheel-drive and differential gear lock switches 29. Multi-function meter unit 30. Helmet/Seat belt indicator light 31.

  • Page 32: Instrument And Control Functions

    EVU00130 I NSTRUMENT AND CONTROL Functions of the respective switch positions FUNCTIONS are as follows: EVU00140 All electrical circuits are supplied with Main switch power, and the helmet/seat belt indi- cator light comes on. The headlights and taillights come on when the light switch is set to “...

  • Page 33: Indicator And Warning Lights

    EVU00150 EVU01131 Indicator and warning lights On-Command differential gear lock indica- tor light “DIFF. LOCK” This indicator light and the On-Command dif- ferential gear lock indicator in the display come on when the On-Command differential gear lock switch is set to the “LOCK” position. km/h When the switch is set to “LOCK”, the On- Command differential gear lock indicator light...
  • Page 34 EVU00170 EVU01161 Neutral indicator light “N” On-Command four-wheel-drive/differential This indicator light comes on when the drive gear lock indicator “ ”/“ ” DIFF. LOCK select lever is in the “N” position. The On-Command four-wheel-drive indicator “ ” comes on when the On-Command four- wheel-drive switch is set to the “4WD”...
  • Page 35 If the light comes defective. When this occurs, have a Yamaha on during operation, stop the engine as soon dealer check the self-diagnosis system. (See as it is safe to do so and allow the engine to pages 4-10–4-11 for an explanation of the...

  • Page 36: Multi-Function Meter Unit

    If the indica- a speedometer (which shows the riding tor light does not come on when the key is speed) turned to “ON”, have a Yamaha dealer check an odometer (which shows the total dis- the electrical circuit. tance traveled)
  • Page 37 two tripmeters (which show the distance Odometer and tripmeter modes traveled since they were last set to zero) a clock an hour meter (which shows the total time the engine has been running) a voltage display (which shows the battery voltage) km/h a fuel meter...
  • Page 38 To reset a tripmeter, select it by pushing the Clock, hour meter and voltage display “TRIP/ODO” button, and then hold the “TRIP/ modes ODO” button for at least three seconds. The tripmeters can be used to estimate the dis- tance that can be traveled with a full tank of fu- el.
  • Page 39 To set the clock Voltage display mode 1. Set the display to the clock. 2. Push the “ ” button until the clock starts flashing. 3. Set the hours by pushing the “H” button. 4. Set the minutes by pushing the “M” but- km/h ton.
  • Page 40 “HI”, there may be trouble with the battery charging circuit or the battery may be faulty. If “LO” or “HI” appears in the dis- play, have a Yamaha dealer check or repair km/h the vehicle. 1. Fuel level warning indicator 2.
  • Page 41 This fuel meter is equipped with a self-diagno- sis system. If the electrical circuit is defective, all the display segments and fuel level warn- ing indicator will start flashing. If this occurs, have a Yamaha dealer check the electrical circuit. 1. Engine trouble warning light “ ”...

  • Page 42: Switches

    EVU00230 Switches NOTICE EVU00240 If the multi-function display indicates an Light switch “OFF/ ” error code, the vehicle should be checked as soon as possible in order to avoid en- gine damage. 1. Light switch “OFF/ ” Set the switch to “ ”...
  • Page 43 EVU01183 On-Command four-wheel-drive and differ- NOTICE ential gear lock switches Do not use the headlights with the engine turned off for an extended period of time. The battery may discharge to the point that the starter motor will not operate properly.

  • Page 44: Accelerator Pedal

    EVU00260 Four-wheel drive (“4WD”): Power is sup- Accelerator pedal plied to the rear and front wheels. Press the accelerator pedal down to increase Four-wheel drive with the differential gear engine speed. Spring pressure returns the locked (“4WD-LOCK”): Power is supplied pedal to the rest position when released.

  • Page 45: Brake Pedal

    EVU00270 EVU00280 Brake pedal Parking brake lever Press the brake pedal to slow or stop the ve- The parking brake lever is located at the right hicle. side of the driver’s seat. It will help keep the vehicle from moving while parked. To set the parking brake, pull the lever up completely.

  • Page 46: Drive Select Lever

    EVU00290 EVU00300 Drive select lever Fuel tank cap The drive select lever is used to shift the vehi- Remove the fuel tank cap by turning it coun- cle into the low, high, neutral, and reverse po- terclockwise. sitions. (Refer to pages 6-4–6-5 for the drive select lever operation.) 1.

  • Page 47: Doors

    EVU00330 Doors Seats To open a door, simply pull the latch outward. To remove a seat, pull its seat lock lever up- To close a door, push or pull the door inward ward, lift the front of the seat, and then slide until it is securely latched.

  • Page 48: Seat Belts

    EVU00340 To install a seat, insert the projections on the Seat belts rear of the seat into the seat holders and push This vehicle is equipped with three-point seat down on the seat at the front. Make sure the belts for both the operator and the passenger. seats are securely latched.

  • Page 49: Glove Compartment

    EVU01191 5B410005 Glove compartment Cup holders Be sure to tightly close the cap of any plastic NOTICE bottle before placing it in a cup holder. To protect from damage, do not put metal Some plastic bottles may not fit into the cup products, like tools or sharply edged prod- holders depending on their size and shape.

  • Page 50: Cargo Bed

    EVU00351 Cargo bed 1. Storage/cup holder (× 1) 2. Cup holder (× 2) 1. Cargo bed 2. Tailgate 3. Cargo hook (× 4) Maximum load limit: 181 kg (400 lb) For additional loading information, see pages 6-9–6-11. 4-19...
  • Page 51 Opening and closing the tailgate Lifting and lowering the cargo bed 1. Tailgate 2. Latch (× 2) 1. Cargo bed release lever To open To lift Unhook the latches, and then lower the tail- Push down the cargo bed release lever on the gate.

  • Page 52: Front And Rear Shock Absorber Adjustment (Yxr70Fy/Yxr70Fduy/Yxr70Fhy/ Yxr70Fsey)

    5B410006 To lower Front and rear shock absorber adjustment With hands and fingers clear of pinch points, (YXR70FY/YXR70FDUY/YXR70FHY/ lower the cargo bed slowly to its original posi- YXR70FSEY) tion and be sure it is locked into place. The spring preload can be adjusted to suit the WARNING! Keep hands, body, and other operating conditions.
  • Page 53 The rear wheels need to be removed to adjust A special wrench can be obtained at a the rear shock absorber assemblies. (See Yamaha dealer to make this adjustment. pages 8-43–8-46 for wheel removal and in- stallation procedures.) Adjust the spring preload as follows:...

  • Page 54: Adjusting The Front Shock Absorber Assemblies (Yxr70Fsepy)

    Take the shock absorber assem- bly to a Yamaha dealer for any WARNING service. These shock absorber assemblies contain highly pressurized nitrogen gas. Read and...
  • Page 55 A special wrench can be obtained at a 1. Loosen the locknut. 2. Turn the adjusting ring in direction a to Yamaha dealer to make this adjustment. The spring preload setting is determined increase the spring preload and thereby by measuring distance A, shown in the il-...
  • Page 56 Rebound damping force Spring preload setting: Turn the adjusting screw in direction a to in- Maximum (hard): crease the rebound damping force and there- Distance A = 77 mm (3.03 in) by harden the damping, and in direction b to Standard: decrease the rebound damping force and Distance A = 67 mm (2.64 in)
  • Page 57 Compression damping force Rebound damping setting: Turn the adjusting screw in direction a to in- Minimum (soft): crease the compression damping force and 12 click(s) in direction b* thereby harden the damping, and in direction Standard: b to decrease the compression damping 10 click(s) in direction b* force and thereby soften the damping.
  • Page 58 Compression damping setting: Although the total number of clicks of a damp- Minimum (soft): ing force adjusting mechanism may not exact- 12 click(s) in direction b* ly match the above specifications due to small Standard: differences in production, the actual number 10 click(s) in direction b* of clicks always represents the entire adjust- Maximum (hard):...
  • Page 59 WARNING Suspension components become hot during operation. Never touch the compression damping force adjusting screw, the rebound damping force ad- justing screw or the oil reservoir with your bare hand or skin until suspen- sion components have cooled. Always adjust the shock absorber as- semblies on the left and right side to the same setting.

  • Page 60: Adjusting The Rear Shock Absorber Assemblies (Yxr70Fsepy)

    Take the shock absorber assem- bly to a Yamaha dealer for any WARNING service. These shock absorber assemblies contain highly pressurized nitrogen gas. Read and...
  • Page 61 A special wrench can be obtained at a 1. Loosen the locknut. 2. Turn the adjusting ring in direction a to Yamaha dealer to make this adjustment. The spring preload setting is determined increase the spring preload and thereby by measuring distance A, shown in the il-...
  • Page 62 Rebound damping force Spring preload setting: Turn the adjusting screw in direction a to in- Maximum (hard): crease the rebound damping force and there- Distance A = 78.5 mm (3.09 in) by harden the damping, and in direction b to Standard: decrease the rebound damping force and Distance A = 63.5 mm (2.50 in)
  • Page 63 Compression damping force Rebound damping setting: Turn the adjusting screw in direction a to in- Minimum (soft): crease the compression damping force and 20 click(s) in direction b* thereby harden the damping, and in direction Standard: b to decrease the compression damping 12 click(s) in direction b* force and thereby soften the damping.
  • Page 64 Compression damping setting: Although the total number of clicks of a damp- Minimum (soft): ing force adjusting mechanism may not exact- 12 click(s) in direction b* ly match the above specifications due to small Standard: differences in production, the actual number 7 click(s) in direction b* of clicks always represents the entire adjust- Maximum (hard):...

  • Page 65: Trailer Hitch Bracket And Receiver

    Never touch the dard trailer hitch. Trailer towing equipment compression damping force adjusting can be obtained at a Yamaha dealer. (See screw, the rebound damping force ad- pages 6-9–6-11 for precaution information.) justing screw or the oil reservoir with your bare hand or skin until suspen- sion components have cooled.

  • Page 66: Auxiliary Dc Jack

    EVU00380 Auxiliary DC jack The auxiliary DC jack is located at the right side of the front panel. The auxiliary DC jack can be used for suitable work lights, radios, etc. The auxiliary DC jack should only be used when the engine is running. 1.
  • Page 67 NOTICE Do not use accessories requiring more than the maximum capacity stat- ed above. This may overload the cir- cuit and cause the fuse to blow. If accessories are used without the engine running, the battery will lose its charge and engine starting may be- come difficult.

  • Page 68: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspect- ed by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 69 ITEM ROUTINE PAGE Final gear oil/ • Check for leakage. 5-7, 8-16–8-21 Differential gear oil Accelerator pedal • Check for proper accelerator pedal operation. Seat belts • Check for proper operation and belt wear. Steering • Check for proper operation. Fittings and fasteners •...

  • Page 70: Front And Rear Brakes

    Brake operation firm feeling when the brakes are applied. If Check the operation of the brakes at the start not, have the vehicle inspected by a Yamaha of every ride. Test the brakes at slow speed dealer. after starting out to make sure they are work- ing properly.

  • Page 71: Fuel

    Never refuel while smoking, or while in the vicinity of sparks, open flames, or oth- Your Yamaha engine has been designed to er sources of ignition such as the pilot use regular unleaded gasoline with a pump...
  • Page 72 Always place a portable gas container on the hol containing methanol is not recommended ground before filling it. Before removing the by Yamaha because it may cause fuel system container cap, touch the container with the damage or vehicle performance problems.

  • Page 73: Engine Oil

    EVU00410 Engine oil Make sure the engine oil is at the specified level. Add oil as necessary. (See pages 8-10– 8-15.) NOTICE In order to prevent clutch slippage (since the engine oil also lubricates the clutch), do not mix any chemical additives with oil.

  • Page 74: Coolant

    EVU00420 EVU00430 Coolant Final gear oil Check the coolant level in the coolant reser- Make sure the final gear oil is at the specified voir when the engine is cold (the coolant level level. Add oil as necessary. (See pages 8-16– will vary with engine temperature).

  • Page 75: Accelerator Pedal

    Have a Yamaha dealer repair Always check the tightness of chassis fittings as necessary for proper operation. and fasteners before a ride. Take the vehicle to a Yamaha dealer or refer to the Service Manual for correct tightening torque.

  • Page 76: Lights

    Use the tire pressure gauge to check and ad- Check the operation of all switches. Have a just tire pressures when the tires are cold. Tire Yamaha dealer repair as necessary for proper pressures must be equal on both sides. operation.
  • Page 77 Set tire pressures to the following specifica- tions: ACE-02E Recommended Minimum Maximum pressure 70 kPa 63 kPa 77 kPa Front (0.70 kgf/cm (0.63 kgf/cm (0.77 kgf/cm 10 psi) 9 psi) 11 psi) 98 kPa 91 kPa 105 kPa Rear (0.98 kgf/cm (0.91 kgf/cm (1.05 kgf/cm 14 psi)
  • Page 78 EVU00520 Tire wear limit When the tire groove decreases to 3 mm (0.12 in) due to wear, replace the tire. a. Tire wear limit 5-11...

  • Page 79: Operation

    If there is a zero and 20 hours. control or function you do not understand, ask your Yamaha dealer. For this reason, we ask that you read the fol- lowing material carefully. Because the engine...

  • Page 80: Starting The Engine

    The coolant temperature warning light and build-up of heat. If any abnormality is noticed engine trouble warning light should come during this period, consult a Yamaha dealer. on, then go off. If a warning light does not go off, see page 0–10 hours:...
  • Page 81 The engine can be started in any gear For maximum engine life, never accelerate if the brake is applied. However, it is hard when the engine is cold! recommended to shift into neutral be- fore starting the engine. 4. With your foot off the accelerator pedal, start the engine by turning the key to “START”.

  • Page 82: Drive Select Lever Operation And Reverse Driving

    Drive select lever operation and reverse 2. Apply the brake pedal, then shift by mov- driving ing the drive select lever along the shift guide. Make sure that the drive select le- NOTICE ver is completely shifted into position. Do not shift without coming to a complete stop and waiting for the engine to return to normal idle speed.
  • Page 83 Due to the synchro- backing. nizing mechanism in the engine, the light may not come on until the vehicle starts moving. If the light does not come on, ask a Yamaha dealer to inspect the reverse indicator light electrical circuit.

  • Page 84: On-Command Four-Wheel-Drive Switch And Differential Gear Lock Switch

    5B410009 On-Command four-wheel-drive switch and “2WD”/“4WD” differential gear lock switch To change from 2WD to 4WD, stop the vehi- You may notice that the vehicle handles dif- cle, and then set the switch to “4WD”. When ferently in 2WD, 4WD, and 4WD-LOCK the vehicle is in 4WD, the four-wheel-drive in- (“DIFF.
  • Page 85 On-Command differential gear lock switch To lock the differential gear in 4WD, stop the “4WD”/“LOCK” vehicle, make sure the On-Command four- wheel-drive switch is set to “4WD”, move the differential gear lock lever to position b, and then set the switch to “LOCK”. When the dif- ferential gear is locked, the differential gear lock indicator light (“DIFF.

  • Page 86: Parking

    EVU01210 Driving before the differential gear lock is Parking properly engaged (e.g., when the indicator When parking, stop the engine and shift the and indicator light are flashing) will cause drive select lever into the neutral position. Ap- the engine speed to be limited until en- ply the parking brake to help prevent the vehi- gagement is complete.

  • Page 87: Loading

    EVU00630 Loading Do not exceed the maximum tongue Take extra precautions when driving with a weight. load or trailer. Follow these instructions and Make sure the load does not interfere always use common sense and good judg- with your control or ability to see ment when carrying cargo or towing a trailer.
  • Page 88 Use the hooks equipped on the cargo bed to MAXIMUM LOADING LIMIT tie down loads. Vehicle loading limit (total weight of cargo, operator, passenger and Choose a trailer hitch drawbar designed for accessories and tongue weight): use with a 5 cm (2 in) receiver. (See page 367 kg (809 lb) (YXR70FY/ 4-34 for more information.) YXR70FDUY/YXR70FHY/YXR70FSEY)
  • Page 89 Operating when loaded with cargo or tow- Pulling something other than a trailer ing a trailer Yamaha recommends that loads be transport- Drive more slowly than you would without a ed in the bed or in a trailer. If you need to load.

  • Page 90: Basic Guide For Safe Use

    5B470010 BASIC GUIDE FOR SAFE KNOW YOUR VEHICLE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, golf- As a Rhino owner you are responsible for the cars and grounds-keeping vehicles. The safe and proper operation of this vehicle. Rhino has higher ground clearance and other Read this chapter and review the safety in- features to handle rugged terrain, and, as a...
  • Page 91 Doing things with a Rhino that some people do for thrills in other vehicles (such as side- ways sliding, skidding, fishtailing, or donuts) have led to side rollovers. These rollovers can result in crushed limbs and other serious inju- ries or death to drivers or passengers. As the owner/operator, it is your responsibility to protect yourself and your passenger from accidents, including rollovers.

  • Page 92: Driver Requirements

    Driver requirements Parents: This vehicle is intended for use only by an Many provinces have implemented new mo- operator 16 or older with a valid motor vehi- tor vehicle licensing requirements for young cle license. drivers. These requirements are in response to the disproportionately high rate of crashes involving youthful drivers.

  • Page 93: Passenger Requirements

    Passenger requirements Occupant protection system This vehicle is designed for the operator and one passenger. Carrying passengers improp- erly can lead to serious injury or death. As the operator, you are responsible for your pas- senger. Your passenger must be able to place both feet on the floorboard while seated upright with his/her back against the seat back.
  • Page 94 WARNING Do not make changes to the occupant pro- tection system. If you install aftermarket products or have your vehicle modified, you may put yourself and others at greater risk of serious injury or death. You are re- sponsible for any such changes to the ve- hicle.

  • Page 95: Protective Structure

    Protective structure Seat belts The vehicle cage/frame provides a protective Seat belts should be worn by both driver and structure that helps limit intrusions by branch- passenger. Driver must be sure that the pas- es or other objects and may reduce your risk senger is belted before driving.
  • Page 96 An unbelted occupant may strike the interior of the vehicle, the protective structure, or oth- er objects in an accident or during operation. You may also fall completely out or be partial- ly ejected from the vehicle, which may lead to being crushed between the ground and the vehicle.
  • Page 97 2. If the latch plate is not positioned in the 4. Put the lap portion of the belt low on your correct location along the seat belt, hips. Pull up on the shoulder part so the squeeze the latch plate ends together belt is snug across your hips.

  • Page 98: Doors

    Doors Passenger handholds The doors are designed to reduce the likeli- Handholds are provided to grip during opera- hood that you will stick your leg out to stop the tion to maintain proper position and balance. vehicle from tipping over or for any other rea- Holding onto the handholds helps to reduce son in a rollover.

  • Page 99: Seat And Hip Restraints

    Seat and hip restraints The seat and hip restraints are designed to help keep you in the vehicle. Do not hold onto hip restraint bar when the vehicle is moving. Your hand or arm may be struck by objects or crushed against outside objects or the ground during a rollover.

  • Page 100: Floorboard

    Floorboard Steering wheel The floorboard allows you to brace your feet, Keep both hands on the steering wheel. Do which helps you keep your body in the vehicle not hold the steering wheel with your thumbs in the event of an accident or rollover. Keep inside the rim.

  • Page 101: Learning To Operate Your Vehicle

    LEARNING TO OPERATE YOUR VEHICLE CORRECT GRIP EXAMPLE Personal protective equipment INCORRECT GRIP EXAMPLE 1. Approved motorcycle helmet 2. Eye protection 3. Long-sleeved shirt or jacket 4. Gloves 5. Long pants 6. Over-the-ankle boots 7-12...

  • Page 102: Practice For New Rhino Users

    Both driver and passenger should wear the Wear eye protection when operating or riding following to reduce risk of injury in an acci- the vehicle to reduce the risk of a serious ac- dent: cident or injury. Eye protection, such as a face Approved motorcycle helmet that fits prop- shield or goggles, may reduce the risk of for- erly...

  • Page 103: Getting Ready To Ride

    Getting ready to ride Perform the Pre-Operation Checks on pages 5-1–5-11. Follow the instructions starting on page 6-2 to start the engine. Become familiar with the way the vehicle feels in low and high ranges, first in two-wheel drive (2WD) and then in four-wheel drive (4WD) and four-wheel drive with the differential locked (DIFF.

  • Page 104: Turning

    Turning If you think or feel that the vehicle may tip or Use care in turns – turning the steering wheel roll, keep your body completely inside the pro- too far or too fast can result in loss of control tective structure of the vehicle: or a rollover.

  • Page 105: Accelerating

    Accelerating Braking With the engine idling in neutral and your foot When slowing down or stopping, take your on the brake, shift the drive select lever into foot off the accelerator pedal and press the low or high. NOTICE: Do not shift from low brake pedal smoothly.

  • Page 106: Leaving The Vehicle

    Leaving the vehicle Parking on a flat area Do not get out of the vehicle while the engine When parking on a flat area, stop the engine is running and the drive select lever is in any and shift the drive select lever into the neutral gear.

  • Page 107: Loading

    4. With the brake pedal applied, set the Operation on different surfaces and parking brake. terrains 5. Block the front and rear wheels with Go slowly and proceed with caution when op- rocks or other objects. erating on an unfamiliar surface or terrain. This vehicle may handle differently in certain Loading types of terrains or on certain surfaces.

  • Page 108: Hills

    Hills Choose carefully which hills you attempt to climb or descend. Avoid hills with slippery sur- faces or those where you will not be able to see far enough ahead of you. Use common sense and remember that some hills are too steep for you to climb or descend.

  • Page 109: Uphill

    Uphill Slow down when you reach the crest of the hill Do not attempt to climb hills until you have if you cannot see clearly what is on the other mastered basic maneuvers on flat ground. side – there could be another person, an ob- Drive straight up hills, and avoid crossing the stacle, or a sharp drop-off.

  • Page 110: Downhill

    Downhill If you are sliding or skidding, try to steer in the Check the terrain carefully before going direction the vehicle is sliding, to regain con- downhill. When possible, choose a path that trol. For example, if you feel the back of the lets you drive your vehicle straight downhill.

  • Page 111: Rough Terrain

    Rough terrain Water Operation over rough terrain should be done If you must cross shallow, slow-moving water with caution. up to the depth of the vehicle’s floorboards, Look for and avoid obstacles that could choose your path carefully to avoid sharp cause damage to the vehicle or could lead drop-offs, large rocks, or slippery surfaces to a rollover or accident.

  • Page 112: Loose Terrain/Slippery Terrain

    Loose terrain/slippery terrain NOTICE When driving on slippery terrain, including After driving your vehicle in water, be sure wet, muddy, or icy conditions, as well as loose to drain the trapped water by removing the gravel, be aware that you could begin skid- check hose at the bottom of the air filter ding or sliding.

  • Page 113: Brush Or Wooded Areas

    Brush or wooded areas Encountering obstacles When operating in areas with brush or trees, If you cannot go around an obstacle, such as watch carefully on both sides and above the a fallen tree or a ditch, stop the vehicle where vehicle for obstacles such as branches that it is safe to do so.

  • Page 114: Periodic Maintenance And Adjustment

    If you are not familiar with vehicle service, have a Yamaha dealer perform service.

  • Page 115: Owner's Manual And Tool Kit

    EVU00660 Owner’s manual and tool kit You are recommended to put this owner’s manual in the vinyl bag and always carry it un- derneath the driver seat as shown. Put the owner’s tool kit and tire pressure gauge in the space beside the battery.
  • Page 116 If you do not have a torque wrench available during a service operation requiring one, take your vehicle to a Yamaha dealer to check the torque settings and adjust them as necessary.

  • Page 117: Periodic Maintenance Chart For The Emission Control System

    However, keep in mind that if the vehicle isn’t used for a long period of time, the month maintenance intervals should be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require spe- cial tools, data and technical skills.

  • Page 118: General Maintenance And Lubrication Chart

    EVU01650 General maintenance and lubrication chart INITIAL EVERY month Whichever ITEM ROUTINE comes first 1,200 2,400 2,400 4,800 (mi) (200) (750) (1,500) (1,500) (3,000) hours • Check coolant leakage. Cooling system • Repair if necessary. • Replace coolant every 24 months. •...
  • Page 119 INITIAL EVERY month Whichever ITEM ROUTINE comes first 1,200 2,400 2,400 4,800 (mi) (200) (750) (1,500) (1,500) (3,000) hours Drive shaft universal joint* • Lubricate with lithium-soap-based grease. • Check for cracks or damage. Engine mount* • Check bolt tightness. •...

  • Page 120: Hood

    EVU00680 Hood To open Unhook the hood latches, and then slowly tilt the hood up until it stops. 1. Hood 1. Latch (× 2)
  • Page 121 To close NOTICE Lower the hood slowly to its original position, Make sure that all cables and wires and then hook the hood latches. Secure pro- are in place when closing the hood. jections 1 on the rear of the hood into slots 2 Do not drive the vehicle with the hood on the back of the instrument panel.

  • Page 122: Console

    5B410011 Console To install 1. Place the console in its original position. To remove 2. Install the parking brake lever boot. 1. Remove the seats. (See pages 4-16– 3. Install the seats. 4-17 for seat removal and installation NOTICE procedures.) Be sure to position the seat belt buck- 2.

  • Page 123: Engine Oil And Oil Filter Cartridge

    5B410012 Engine oil and oil filter cartridge Check engine oil level before each operation. In addition, change the oil and the oil filter car- tridge at the intervals specified in the periodic maintenance and lubrication chart. To check the engine oil level 1.
  • Page 124 5. Insert the dipstick completely into the oil 7. Insert the dipstick completely into the oil filler hole, and then remove it again to filler hole. check the oil level. The engine oil should 8. Reinstall the console. be between the minimum and maximum level marks.
  • Page 125 To change the engine oil (with or without oil filter cartridge replacement) 1. Park the vehicle on a level surface. 2. Remove the console. (See page 8-9 for console removal and installation proce- dures.) 3. Start the engine, warm it up for several minutes, and then turn it off.
  • Page 126 7. Remove the oil filter cartridge with an oil filter wrench. An oil filter wrench is avail- able from a Yamaha dealer. Make sure that the O-ring is removed together with the oil filter cartridge. If the O-ring re- mains attached to the crankcase, oil leak- age may occur.
  • Page 127 12. Refill with the specified amount of recom- mended engine oil, and then insert the dipstick completely into the oil filler hole. NOTICE: Be sure to wipe off spilled oil on any parts after the engine and ex- haust system have cooled down. Recommended engine oil: See page 10-3.
  • Page 128 NOTICE In order to prevent clutch slippage (since the engine oil also lubricates the clutch), do not mix any chemical additives with oil. Do not use oils with a diesel specification of “CD” or oils of a higher quality than specified. In addition, do not use oils labeled “EN- ERGY CONSERVING II”...

  • Page 129: Final Gear Oil

    5B410013 Final gear oil 3. If the oil is below the brim of the filler hole, add sufficient oil of the recommended Checking the final gear oil level type to raise it to the correct level. 1. Park the vehicle on a level surface. NOTICE: Be sure no foreign material 2.
  • Page 130 Changing the final gear oil 3. Place a container under the final gear 1. Park the vehicle on a level surface. case to collect the used oil. 2. Remove the final gear case guard by re- 4. Remove the oil filler bolt and the drain moving the bolts and the collars.
  • Page 131 6. Refill with the recommended final gear oil 9. Install the final gear case guard by install- up to the brim of the filler hole. NOTICE: ing the bolts and the collars, and then Be sure no foreign material enters the tightening the bolts to the specified final gear case.

  • Page 132: Differential Gear Oil

    5B410014 Differential gear oil 3. Reinstall the differential gear oil filler bolt, and then tighten it to the specified torque. Checking the differential gear oil level Tightening torque: 1. Park the vehicle on a level surface. Differential gear oil filler bolt: 2.
  • Page 133 3. Place a container under the differential 6. Refill the differential gear case with the gear case to collect the used oil. recommended oil. NOTICE: Be sure no 4. Remove the differential gear oil filler bolt foreign material enters the differential and differential gear oil drain bolt to drain gear case.

  • Page 134: Coolant

    5B410015 9. Install the differential gear case guard by Coolant installing the bolts and the collars, and The coolant level should be checked before then tightening the bolts to the specified each ride. torque. Checking the coolant level Tightening torque: 1.
  • Page 135 3. If the coolant is at or below the minimum Changing the coolant level mark, remove the reservoir cap, The coolant must be changed by a Yamaha add coolant to the maximum level mark, dealer at the intervals specified in the periodic reinstall the reservoir cap.

  • Page 136: Axle Boots

    EVU00740 Axle boots Check the protective boots for holes or tears. If any damage is found, have them replaced by a Yamaha dealer. 1. Rear axle boot (× 2 each side) 1. Front axle boot (× 2 each side) 8-23...

  • Page 137: Spark Plug Inspection

    EVU00750 Spark plug inspection Removal 1. Remove the console. (See page 8-9 for console removal and installation proce- dures.) 2. Remove the spark plug cap. 1. Spark plug wrench 1. Spark plug cap 3. Use the spark plug wrench in the tool kit to remove the spark plug as shown.
  • Page 138 Inspection Installation The spark plug is an important engine compo- 1. Measure the electrode gap with a wire nent and is easy to inspect. The condition of thickness gauge and, if necessary, adjust the spark plug can indicate the condition of the gap to specification.

  • Page 139: Cleaning The Air Filter Element

    5B410016 3. Install the spark plug and tighten it to the Cleaning the air filter element specified torque. If a torque wrench is not There is a check hose at the bottom of the air available when you are installing the filter case and at the bottom of the air duct un- spark plug, a good estimate of the correct der the case.
  • Page 140 1. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) 2. Remove the air intake duct shroud by re- moving the quick fastener screws. 1. Air filter case check hose 1. Quick fastener screw (× 2) 2. Air intake duct shroud 8-27...
  • Page 141 3. Remove the air filter case cover by un- 4. Remove the air filter element. hooking the holders. 1. Air filter element 1. Air filter case cover holder (× 5) 2. Air filter case cover 8-28...
  • Page 142 5. Remove the sponge material from the air 6. Wash the sponge material gently but filter frame. thoroughly in parts cleaning solvent. WARNING! Using gasoline or other flammable solvents to clean the air fil- ter element can cause a fire or explo- sion, which could lead to serious injury.
  • Page 143 10. Allow the sponge material to dry thor- oughly. Inspect the sponge material and replace it if damaged. 11. Thoroughly apply Yamaha foam air filter oil or other quality liquid foam air filter oil (not spray type) to the sponge material.

  • Page 144: Drive Select Lever Box Check Hose

    2P512001 The air filter element should be cleaned every Drive select lever box check hose 20–40 hours. It should be cleaned and lubri- The drive select lever box check hose is locat- cated more often if the vehicle is operated in ed under the console.

  • Page 145: V-Belt Cooling Duct Check Hose

    V-belt case, remove the drain plug to drain any water from the case. If water drains from the V-belt case after re- moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect other engine parts.

  • Page 146: Cleaning The Spark Arrester

    5B410018 Cleaning the spark arrester 2. Remove the tailpipe by pulling it out of the muffler, and then remove the gasket. WARNING 3. Tap the tailpipe lightly, and then use a Hot exhaust system may cause burns. To wire brush to remove any carbon depos- avoid burns or fires, make sure that the en- its from the spark arrester portion of the gine is stopped and the exhaust system is...

  • Page 147: Valve Clearance

    To check the brake pad wear, check the wear indicator grooves. If a brake pad has worn to the point that the wear indica- tor grooves have almost disappeared, have a Yamaha dealer replace the brake pads as a set. 8-34...

  • Page 148: Checking The Parking Brake Pads

    To check the brake pad wear, check the wear indicator grooves. If a brake pad has worn to the point that a wear indicator groove almost appears, have a Yamaha deal- er replace the brake pads as a set. 1. Brake pad wear indicator groove 1.

  • Page 149: Checking The Brake Fluid Level

    EVU00850 Checking the brake fluid level The brake fluid reservoir is located under the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) Observe these precautions: When checking the fluid level, make sure the top of the brake fluid reservoir is level. Use only the recommended quality brake fluid.

  • Page 150: Brake Fluid Replacement

    Brake fluid may deteriorate painted surfac- Checking the brake pedal es or plastic parts. Always clean up spilled Have a Yamaha dealer check the brakes at fluid immediately. the intervals specified in the periodic mainte- Have a Yamaha dealer inspect the brake nance and lubrication chart.

  • Page 151: Parking Brake Lever Free Play Adjustment

    EVU00870 Parking brake lever free play adjustment Periodically check the parking brake lever free play and adjust it if necessary. 1. Shift the drive select lever into low gear “L”. 2. Remove the seats. (See pages 4-16– 4-17 for seat removal and installation procedures.) 3.

  • Page 152: Brake Light Switch Adjustment

    EVU00880 Brake light switch adjustment The brake light switch, which is activated by the brake pedal, is properly adjusted when the brake light comes on just before braking takes effect. If necessary, adjust the brake light switch as follows. 1. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) 2.

  • Page 153: Cable Inspection And Lubrication

    Cables can also become frayed or kinked. 1. Brake light switch 2. Adjusting nut Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: Lithium-soap-based grease 8-40...

  • Page 154: Brake Pedal And Accelerator Pedal Lubrication

    EVU00900 5B410021 Brake pedal and accelerator pedal Rear knuckle upper and lower pivot lubrication lubrication Lubricate the pivoting parts. 1. Remove the lower arm protector by re- moving the bolts. Recommended lubricant: Lithium-soap-based grease 1. Bolt (× 3) 2. Lower arm protector 8-41...
  • Page 155 2. Lubricate the knuckle upper and lower 3. Install the lower arm protector by install- pivots with a grease gun. ing the bolts and tightening them to the specified torque. Tightening torque: Lower arm protector: 7 Nm (0.7 m·kgf, 5.1 ft·lbf) Recommended lubricant: Lithium-soap-based grease 8-42...

  • Page 156: Steering Shaft Lubrication

    EVU00920 EVU00930 Steering shaft lubrication Wheel removal Lubricate the pivot points. 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable Recommended lubricant: stand under the frame. Lithium-soap-based grease 3. Remove the nuts from the wheel. 4. Remove the wheel. 1.

  • Page 157: Tire Replacement

    Tire replacement The tires listed below have been approved by Always use the same size and type of tires Yamaha Motor Manufacturing Corporation of recommended in this owner’s manual. The America for this model. tires that came with your Rhino were de-...

  • Page 158: Wheel Installation

    EVU00940 Wheel installation 1. Install the wheel and the nuts. The arrow mark on the tire must point toward the rotating direction of the wheel. Tapered nuts are used for both the front and rear wheels. Install the nuts with their tapered side towards the wheel.

  • Page 159: Battery

    EVU00950 Battery Wheel nut torque: This model is equipped with a VRLA (Valve Front: 55 Nm (5.5 m·kgf, 40 ft·lbf) Regulated Lead Acid) battery. There is no Rear: 55 Nm (5.5 m·kgf, 40 ft·lbf) need to check the electrolyte or to add distilled water.
  • Page 160 To remove the battery 1. Turn the key to “OFF”. WARNING 2. Open the hood. (See pages 8-7–8-8 for Avoid battery contact with skin, eyes, or hood opening and closing procedures.) clothing. Shield eyes when working near 3. Remove the quick fastener screws. batteries.
  • Page 161 To charge the battery Have a Yamaha dealer charge the battery as soon as possible if it seems to have dis- charged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.
  • Page 162 Using a conventional battery charger will damage the battery. If you do not have access to a constant-volt- age battery charger, have a Yamaha dealer charge your battery. 1. Positive battery lead (red) 2. Negative battery lead (black)

  • Page 163: Jump-Starting

    5B410022 Jump-starting However, if the vehicle must be jump-started, Jump-starting the vehicle should be avoided. proceed as follows. The battery should be removed and charged 1. Turn the key to “OFF”. instead. 2. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) WARNING 3.
  • Page 164 1. Jumper cable positive lead 1. Jumper cable negative lead 6. Connect the negative lead of the jumper 7. Start the engine. (Refer to “Starting the cable to the negative terminal of the engine” on pages 6-2–6-3.) charged battery and the other end of the 8.

  • Page 165: Fuse Replacement

    5B410023 9. Reinstall the console. Fuse replacement 10. Reinstall the battery compartment cover. The main fuse, the fuel injection system fuse, 11. Close the hood. and the fuse box are located under the hood. If a fuse is blown, turn off the main switch and install a new fuse of the specified amperage.
  • Page 166 3. Remove the quick fastener screws. 4 56 1 2 3 4. Remove the battery compartment cover by lifting it up and pulling it out. 1. Fuel injection system spare fuse 2. Fuel injection system fuse 3. Main fuse 4. Headlight fuse “HEAD” 5.

  • Page 167: Replacing A Headlight Bulb

    6. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. If the fuse blows again immediately, have a Yamaha dealer check the electrical system. 1. Cover at the rear of the headlight 7.
  • Page 168 3. Remove the headlight bulb holder cover 4. Remove the headlight bulb holder by by pulling it off. pushing it in and turning it counterclock- wise. 1. Headlight bulb holder cover 1. Headlight bulb holder 8-55...
  • Page 169 5. Wait for the headlight bulb to cool before 7. Reinstall the bulb holder by pushing it in touching or removing it. Remove the bulb and turning it clockwise. by pulling it out. Reinstall the bulb holder cover and the 6.

  • Page 170: Headlight Beam Adjustment

    Tail/brake light bulb replacement If a tail/brake light bulb burns out, replace it as NOTICE follows: It is advisable to have a Yamaha dealer 1. Remove the quick fastener screws, nuts make this adjustment. and bolts from panel A (if replacing the...
  • Page 171 2. Lift the cargo bed up. (See pages 4-20– 4-21 for cargo bed lifting and lowering procedures.) 3. Remove the panel (panel A or B). 4. Remove the bulb holder (together with the bulb) by turning it counterclockwise. 1. Panel B 1.

  • Page 172: Troubleshooting

    If your vehicle Tightening torque: requires any repair, take it to a Yamaha deal- Panel nut: 7 Nm (0.7 m·kgf, 5.1 ft·lbf) The skilled technicians at a Yamaha dealer- ship have the tools, experience, and know- how to properly service your vehicle.
  • Page 173 WARNING When checking the fuel system, do not smoke and make sure there are no open flames or sparks in the area, including pi- lot lights from water heaters or furnaces. Gasoline or gasoline vapors can ignite or explode, causing severe injury or property damage.

  • Page 174: Troubleshooting Charts

    No fuel. 2. Compression There is compression. Compression normal. Use the electric starter to see if there is compression. Ask a Yamaha dealer to No compression. inspect. 3. Ignition Wipe clean with dry cloth. Ignition system is Spark is good.
  • Page 175 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. If it is difficult to get the recommended coolant, tap water can be used temporarily, provided that it is changed to the recommended coolant as soon as possible.

  • Page 176: Cleaning And Storage

    EVU01030 C LEANING AND STORAGE 3. Rinse the dirt and degreaser off with a garden hose. Use only enough pressure A. Cleaning to do the job. WARNING! Test the Frequent, thorough cleaning of your vehicle brakes after washing. Apply the will not only enhance its appearance but will brakes several times at slow speeds improve its general performance and extend...

  • Page 177: Storage

    1. Fill the fuel tank with fresh fuel and add 6. Clean the seats with a vinyl upholstery the specified amount of Yamaha Fuel cleaner to keep the covers pliable and Stabilizer and Conditioner or equivalent glossy.
  • Page 178 4. Block up the frame to raise all wheels off nates the need to drain the fuel system. Con- the ground. sult a Yamaha dealer if the fuel system needs 5. Tie a plastic bag over the exhaust pipe to be drained.

  • Page 179: Specifications

    EVU01050 S PECIFICATIONS YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Dimensions: Overall length 2,885 mm (113.6 in) Overall width 1,385 mm (54.5 in) Overall height 1,853 mm (73.0 in) (YXR70FY/YXR70FDUY/ YXR70FHY) 1,901 mm (74.8 in) (YXR70FSEPY/YXR70FSEY) Seat height 818 mm (32.2 in) Wheelbase 1,910 mm (75.2 in) Ground clearance 280 mm (11.0 in) Minimum turning radius...
  • Page 180 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Engine: Engine type Liquid cooled 4-stroke, SOHC Cylinder arrangement Forward-inclined single cylinder Displacement 686.0 cm Bore × stroke 102.0 × 84.0 mm (4.02 × 3.31 in) Compression ratio 9.20:1 Starting system Electric starter Lubrication system Wet sump 10-2...
  • Page 181 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Engine oil: Type: 130 ˚F YAMALUBE 4 20W-50 or SAE 20W-50 YAMALUBE 4 10W-40 or SAE 10W-40 YAMALUBE 4 5W-30 or SAE 5W-30 50 ˚C Recommended engine oil classification API service SG type or higher, JASO standard MA NOTICE In order to prevent clutch slippage (since the en- gine oil also lubricates the clutch), do not mix any...
  • Page 182 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Final gear case oil: Type SAE 80 API GL-4 Hypoid gear oil Quantity 0.25 L (0.26 US qt, 0.22 Imp.qt) Differential gear case oil: Type SAE 80 API GL-4 Hypoid gear oil Quantity 0.18 L (0.19 US qt, 0.16 Imp.qt) Radiator capacity (including all routes): 2.35 L (2.48 US qt, 2.07 Imp.qt) Air filter:...
  • Page 183 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Transmission: Primary reduction system V-belt Secondary reduction system Shaft drive 41/21 × 17/12 × 33/9 (10.142) Secondary reduction ratio Transmission type V-belt automatic Operation Right hand operation 23/14 × 28/23 (2.000) Reverse gear Sub transmission ratio 31/16 (1.938) high 31/21 (1.476) Chassis:...
  • Page 184 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Brakes: System Front and rear unified Type front Dual disc brake rear Dual disc brake Operation Foot operation Suspension: Front suspension Double wishbone Rear suspension Double wishbone Shock absorber: Front shock absorber Coil spring/oil damper (YXR70FY/YXR70FDUY/ YXR70FHY/YXR70FSEY) Coil spring/gas-oil damper (YXR70FSEPY) Rear shock absorber Coil spring/oil damper (YXR70FY/YXR70FDUY/...
  • Page 185 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Electrical: Ignition system TCI (digital) Generator system AC magneto Battery type U1L-11 Battery capacity 12 V 28.0 Ah Headlight type: Krypton bulb Bulb voltage, wattage × quantity: 12 V 30.0 W/30.0 W × 2 Headlight 12 V 5.0 W/21.0 W × 2 Tail/brake light Indicator lights: Neutral indicator light...
  • Page 186 YXR70FY/YXR70FDUY/YXR70FSEPY/ Model YXR70FHY/YXR70FSEY Specified fuses: Main fuse 40.0 A Fuel injection system fuse 10.0 A Headlight fuse 15.0 A Ignition fuse 10.0 A Auxiliary DC jack fuse 10.0 A Four-wheel-drive motor fuse 10.0 A Signaling system fuse 10.0 A Backup fuse 10.0 A Radiator fan fuse 25.0 A...

  • Page 187: Consumer Information

    Record the key identification number, vehicle identification number, and model label infor- mation in the spaces provided for assistance when ordering spare parts from a Yamaha 2. VEHICLE IDENTIFICATION NUMBER: dealer or for reference, in case the vehicle is ACA-02E stolen.
  • Page 188 EVU00100 EVU00110 Key identification number Vehicle identification number The key identification number is stamped on The vehicle identification number is stamped the key, as shown in the following illustration. into the frame. This number can be used for ordering a new key.
  • Page 189 Model label The model label is affixed to the frame under the driver seat. Record the information on this label in the space provided. This information will be needed to order spare parts from your Yamaha dealer. 1. Model label 11-3...

  • Page 190: Yamaha Side By Side Off-Road Vehicle Warranty Policy

    In this warranty, the term ‘OFF-ROAD VEHICLE’ shall The subsequent owner has the responsibility for ensuring CUSTOMER provide records refer to a new side-by-side off-road vehicle manufactured that a change of registration is sent to YAMAHA at the maintenance having been performed YAMAHA...
  • Page 191 This warranty does not extend to: particular purpose on the part of YAMAHA, and any other • Fill with correct fuel as per Owner’s Manual OFF-ROAD VEHICLES which have been modified in obligation or liability on behalf of YAMAHA, and the above...
  • Page 192 YAMAHA MOTOR CO., LTD. PRINTED IN USA 2008.04-0.3×1 CR...

This manual is also suitable for:

Yxr70fy 2008Yxr70fduy 2008Yxr70fsepy 2008Yxr70fhy 2008Yxr70fsey 2008

Table of Contents
