READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YXR7FD
YXR7FSPD
YXR700FAD
1RB-F8199-7A

Advertisement

Table of Contents
loading

Related Manuals for Yamaha YXR7FD

Summary of Contents for Yamaha YXR7FD

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YXR7FD YXR7FSPD YXR700FAD 1RB-F8199-7A...
  • Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold. EC Declaration of Conformity conforming to Directive 2006/42/EC We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product YXR700F (YXR7F) (5Y4AM17W0C0503701–) (YXR7FSP) (5Y4AM22W0C0500901–)
  • Page 3 Congratulations on your purchase of the Yamaha YXR7FD / YXR7FSPD / YXR700FAD. It repre- sents the result of many years of Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EVU00021 IMPORTANT MANUAL INFORMATION FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SE- RIOUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5 Check the laws and regulations in force before choosing where to operate this vehicle. ● It is illegal to operate this vehicle on public lands where vehicles its size are prohibited. YXR7FD / YXR7FSPD / YXR700FAD OWNER’S MANUAL ©2012 by Yamaha Motor Co., Ltd.

  • Page 6: Table Of Contents

    LOCATION OF THE WARNING Cargo bed ........4-21 AND SPECIFICATION LABELS..1-1 Adjusting the front and rear shock absorber assemblies SAFETY INFORMATION....2-1 (YXR7FD/YXR700FAD) ....4-23 Adjusting the front shock absorber DESCRIPTION ......... 3-1 assemblies (YXR7FSPD) ....4-25 Adjusting the rear shock absorber INSTRUMENT AND CONTROL assemblies (YXR7FSPD) ....4-30...
  • Page 7 Accelerator pedal ......5-7 Occupant protection system.... 7-4 Seat belts ........5-7 Protective structure......7-6 Steering........... 5-8 Seat belts......... 7-6 Fittings and fasteners...... 5-8 Doors ..........7-9 Instruments, lights and switches..5-8 Passenger handholds....7-10 Control cables ......... 5-8 Seat and hip restraints ....7-11 Tires ..........
  • Page 8 Hills ..........7-20 Axle boots ........8-23 Uphill..........7-21 Spark plug inspection ....8-24 Downhill ......... 7-22 Cleaning the air filter element ..8-27 Rough terrain......... 7-23 Drive select lever box check Pavement ........7-23 hose ..........8-32 Water ..........7-23 V-belt cooling duct check hose..8-32 Loose terrain/slippery terrain..
  • Page 9 Rear knuckle upper and lower CONSUMER INFORMATION ..11-1 pivot lubrication (left and right)..8-42 Identification number records..11-1 Steering shaft lubrication ....8-43 Wheel removal ......8-44 Tire replacement ......8-44 Wheel installation ......8-45 Battery ........... 8-47 Jump-starting ........ 8-51 Fuse replacement ......

  • Page 10: Location Of The Warning And Specification Labels

    EVU00060 L OCATION OF THE WARNING AND SPECIFICATION LABELS 32 1...
  • Page 11 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a re- placement label is available from your Yamaha dealer. 1YXR7FSPD 2For Europe...
  • Page 12 5YXR7FD 6For Europe ARNING YXR700F 2012 30.0 kW YAMAHA MOTOR CO.,LTD. 540 kg 2500 SHINGAI,IWATA,JAPAN 1RB-F155A-10 ny part of your body (arms, legs, or head) outside of the vehicle can be crushed by the cage/frame. If you think or feel...
  • Page 13 9For Europe 0For Europe 8For Europe...
  • Page 14 ARNING ny part of your body (arms, legs, or head) outside of the vehicle can be crushed by the cage/frame. If you think or feel that the vehicle may tip or roll, brace your feet on the floorboards, and keep your hands on the handholds.
  • Page 15 CFor Europe...
  • Page 16 EFor Europe MAX 7.3 INCH (185MM) YAMAHA 5UG-F151J-00...
  • Page 17 GFor Europe...
  • Page 18 IFor Europe...
  • Page 19 LFor Europe 1-10...

  • Page 20: Safety Information

    EVU00070 SAFETY INFORMATION Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Rhino. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 7 before operating the Rhino.
  • Page 21 Before you operate the Rhino ● Prepare yourself and your passenger: • This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li- cense. Check country laws for minimum age requirements. DRIVER UNDER •...
  • Page 22 Prepare your vehicle Perform the pre-operation checks each time you use the vehicle to make sure it is in safe operat- ing condition. Failure to inspect or maintain the vehicle properly increases the possibility of an ac- cident or equipment damage. See pages 5-1–5-2 for a list of pre-operation checks. Prepare your load or trailer Carrying loads, towing a trailer, or pulling objects can affect handling, stability, and cause the risk of overturns or other accidents.
  • Page 23 While using the Rhino Keep your body completely inside the vehicle at all times. Keep both hands on the steering ● wheel. Be sure the passenger is seated, belted, and holding onto the handholds. Close doors before driving. Any part of your body (arms, legs, and head) outside the vehicle can be struck by objects your vehicle is passing or crushed by the vehicle cage/frame in a rollover accident.
  • Page 24 ● Avoid rollovers: • Use care when turning: • Turning the steering wheel too far or too fast can result in a rollover. • Avoid sideways sliding, skidding, or back-wheel sliding, and never do donuts. • Slow down before entering a turn and avoid hard braking in a turn. •...
  • Page 25 ● If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: • Brace yourself by pressing your feet firmly on the floorboards and keep a firm grip on the steering wheel or handholds.
  • Page 26 Avoid carbon monoxide poisoning All engine exhaust contains carbon monoxide, a deadly gas. Breathing carbon monoxide can cause headaches, dizziness, drowsiness, nausea, confusion, and eventually death. Carbon monoxide is a colorless, odorless, tasteless gas which may be present even if you do not see or smell any engine exhaust.
  • Page 27 Many companies with no connection to Yamaha manufacture parts and accessories or offer other modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these af- termarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
  • Page 28 Aftermarket tires and rims The tires and rims that came with your Rhino were designed to match the performance capabili- ties and to provide the best combination of handling, braking, and comfort. Other tires, rims, sizes, and combinations may not be appropriate. Refer to pages 8-44–8-46 for tire specifications and more information on replacing your tires.

  • Page 29: Description

    EVU00080 D ESCRIPTION J K L 1. Headlights 14. Spark arrester 2. Front shock absorber assembly 15. Passenger seat belt 3. Brake fluid reservoir 16. Sun top (YXR7FSPD) 4. Air filter element 17. Passenger seat 5. V-belt case 18. Passenger handholds 6.
  • Page 30 The vehicle you have purchased may differ slightly from those shown in the figures of this manual. 26. Light switch 27. Steering wheel 28. Main switch 29. On-Command four-wheel-drive and differential gear lock switches 30. Multi-function meter unit 31. Helmet/Seat belt indicator light 32.

  • Page 31: Instrument And Control Functions

    EVU00130 I NSTRUMENT AND CONTROL Functions of the respective switch positions FUNCTIONS are as follows: EVU00140 All electrical circuits are supplied with Main switch power. The helmet/seat belt indicator light comes on and stays on while the key is turned to “ON”. OFF: All electrical circuits are switched off.

  • Page 32: Indicator Lights And Warning Lights

    EVU00150 EVU01140 Indicator lights and warning lights Low-range indicator light “L” This indicator light comes on when the drive select lever is in the “L” position. EVU01150 High-range indicator light “H” This indicator light comes on when the drive select lever is in the “H” position. 1.
  • Page 33 EVU00170 EBU29621 Neutral indicator light “N” On-Command four-wheel-drive indicator This indicator light comes on when the drive “ ”, On-Command differential gear lock select lever is in the “N” position. indicator “ ” and indicator light “DIFF. DIFF. LOCK LOCK” The On-Command four-wheel-drive indicator 5B410001 Reverse indicator light “R”...
  • Page 34 “ON”, or if the warning light not completely locked or unlocked. In this remains on, have a Yamaha dealer check the case, start moving to allow time for the electrical circuit.
  • Page 35 “ON”. If the warning light does not come on initially when the key is turned to “ON”, or if the warning light remains on, have a Yamaha dealer check the electrical circuit.

  • Page 36: Multi-Function Meter Unit

    The indicator light stays on even when the following: the seat belt is properly latched. a speedometer ● If the indicator light does not come on when an odometer ● the key is turned to “ON”, have a Yamaha dealer check the electrical circuit.
  • Page 37 two tripmeters (which show the distance Odometer and tripmeter modes ● traveled since they were last set to zero) ● a clock an hour meter (which shows the total time ● the engine has been running) a voltage display (which shows the battery ●...
  • Page 38 To reset a tripmeter, select it by pushing the Clock, hour meter and voltage display “TRIP/ODO” button, and then hold the “TRIP/ modes ODO” button for at least three seconds. The tripmeters can be used to estimate the dis- tance that can be traveled with a full tank of fu- el.
  • Page 39 To set the clock Voltage display mode 1. Set the display to the clock. 2. Push the “ ” button until the clock starts flashing. 3. Set the hours by pushing the “H” button. 4. Set the minutes by pushing the “M” but- ton.
  • Page 40 If the voltage display indicates “LO” or “HI”, there may be trouble with the battery charging circuit or the battery may be faulty. If this occurs, have a Yamaha dealer check or repair the vehicle. 1. Fuel level warning indicator 2.
  • Page 41 If a problem is detected in an elec- trical circuit, all the display segments and fuel level warning indicator start flashing. If this oc- curs, have a Yamaha dealer check the electri- cal circuit. 1. Engine trouble warning light “...
  • Page 42 EVU00240 Light switch “OFF/ ” NOTICE If the multi-function display indicates an error code, the vehicle should be checked as soon as possible in order to avoid en- gine damage. 1. Light switch “OFF/ ” Set the switch to “ ”...
  • Page 43 EVU01183 On-Command four-wheel-drive and differ- NOTICE ential gear lock switches Do not use the headlights with the engine turned off for an extended period of time. The battery may discharge to the point that the starter motor will not operate properly.

  • Page 44: Horn Switch

    EVU01280 “4WD” (four-wheel drive): Power is sup- Horn switch “ ” ● plied to the rear and front wheels. Press the switch to sound the horn. ● “LOCK” (four-wheel drive with the differen- tial gear locked): Power is supplied to the rear and front wheels with the differential gear locked.

  • Page 45: Accelerator Pedal

    EVU00260 EVU00270 Accelerator pedal Brake pedal Press the accelerator pedal down to increase Press the brake pedal to slow or stop the ve- engine speed. Spring tension returns the ped- hicle. al to the rest position when released. Always check that the accelerator pedal returns nor- mally before starting the engine.

  • Page 46: Parking Brake Lever

    EVU00280 EVU00290 Parking brake lever Drive select lever The parking brake lever is located at the right The drive select lever is used to shift the vehi- side of the driver’s seat. Setting the parking cle into the low, high, neutral, and reverse po- brake lever will help keep the vehicle from sitions.

  • Page 47: Fuel Tank Cap

    EVU00300 Fuel tank cap Doors To open a door, pull the latch outward. To close a door, push or pull the door inward until it is securely latched. Be sure the door is SE- CURELY LATCHED AFTER CLOSING IT. 1. Fuel tank cap To open Remove the fuel tank cap by turning it coun- terclockwise.

  • Page 48: Seats

    EVU00330 Seats To install a seat, insert the projections on the To remove a seat, pull its seat lock lever up- rear of the seat into the seat holders and push ward, lift the front of the seat, and then slide down on the seat at the front.

  • Page 49: Seat Belts

    EVU00340 EVU01191 Seat belts Glove compartment This vehicle is equipped with three-point seat NOTICE belts for both the operator and the passenger. To protect from damage, do not put metal Always wear the seat belts properly while items, like tools, or sharply edged items riding in the vehicle.

  • Page 50: Cup Holders

    5B410005 Cup holders Be sure to tightly close the cap of any plastic bottle before placing it in a cup holder. Some plastic bottles may not fit into the cup holders depending on their size and shape. WARNING Never ride with any open or glass con- ●...

  • Page 51: Cargo Bed

    EVU00351 Cargo bed Opening and closing the tailgate WARNING Do not exceed the specified maximum load limits. Heavier cargo could cause loss of control because of improper weight balance. 1. Tailgate 2. Latch (× 2) To open Unhook the latches, and then lower the tail- gate.
  • Page 52 Lifting and lowering the cargo bed NOTICE The tailgate is not designed to hold heavy loads when open. The tailgate could col- lapse if you put heavy cargo or sit on it. 1. Cargo bed release lever To lift Push down the cargo bed release lever on the left or right side of the vehicle, and then slowly lift up the cargo bed until it stops.

  • Page 53: Adjusting The Front And Rear Shock Absorber Assemblies (Yxr7Fd/Yxr700Fad)

    Adjusting the front and rear shock With hands and fingers clear of pinch points, absorber assemblies lower the cargo bed slowly to its original posi- (YXR7FD/YXR700FAD) tion and be sure it is locked into place. WARNING WARNING! Keep hands, body, and other...
  • Page 54 The rear wheels need to be removed to adjust A special wrench can be obtained at a the rear shock absorber assemblies. (See Yamaha dealer to make this adjustment. pages 8-44–8-46 for wheel removal and in- stallation procedures.) Adjust the spring preload as follows:...

  • Page 55: Adjusting The Front Shock Absorber Assemblies (Yxr7Fspd)

    Do not dispose of a damaged or worn assemblies (YXR7FSPD) out shock absorber assembly your- self. Take the shock absorber assem- WARNING bly to a Yamaha dealer for any These shock absorber assemblies contain service. highly pressurized nitrogen gas. Read and The spring preload, rebound damping and...
  • Page 56 Spring preload ● A special wrench can be obtained at a 1. Loosen the locknut. Yamaha dealer to make this adjustment. 2. Turn the spring preload adjusting nut in direction a to increase the spring pre- ● The spring preload setting is determined...
  • Page 57 Rebound damping force Spring preload setting: Turn the rebound damping force adjusting Minimum (soft): screw in direction a to increase the rebound Distance A = 62 mm (2.44 in) damping force and thereby harden the damp- Standard: ing, and in direction b to decrease the re- Distance A = 67 mm (2.64 in) bound damping force and thereby soften the Maximum (hard):...
  • Page 58 Compression damping force Rebound damping setting: Turn the compression damping force adjust- Minimum (soft): ing screw in direction a to increase the com- 12 click(s) in direction b* pression damping force and thereby harden Standard: the damping, and in direction b to decrease 10 click(s) in direction b* the compression damping force and thereby Maximum (hard):...
  • Page 59 Compression damping setting: Although the total number of clicks of a damp- Minimum (soft): ing force adjusting mechanism may not exact- 12 click(s) in direction b* ly match the above specifications due to small Standard: differences in production, the actual number 10 click(s) in direction b* of clicks always represents the entire adjust- Maximum (hard):...

  • Page 60: Adjusting The Rear Shock Absorber Assemblies (Yxr7Fspd)

    5UG1B002 Adjusting the rear shock absorber WARNING assemblies (YXR7FSPD) Suspension components become hot ● during operation. Never touch the WARNING compression damping force adjusting These shock absorber assemblies contain screw, the rebound damping force ad- highly pressurized nitrogen gas. Read and justing screw or the oil reservoir with understand the following information be- your bare hand or skin until suspen-...
  • Page 61 Take the shock absorber assem- bly to a Yamaha dealer for any preload and thereby soften the suspen- service. sion.
  • Page 62 Spring preload setting: ● A special wrench can be obtained at a Minimum (soft): Yamaha dealer to make this adjustment. Distance A = 63.5 mm (2.50 in) ● The spring preload setting is determined Standard: by measuring distance A, shown in the il- Distance A = 63.5 mm (2.50 in)
  • Page 63 Rebound damping force Rebound damping setting: Turn the rebound damping force adjusting Minimum (soft): screw in direction a to increase the rebound 20 click(s) in direction b* damping force and thereby harden the damp- Standard: ing, and in direction b to decrease the re- 12 click(s) in direction b* bound damping force and thereby soften the Maximum (hard):...
  • Page 64 Compression damping force Compression damping setting: Turn the compression damping force adjust- Minimum (soft): ing screw in direction a to increase the com- 12 click(s) in direction b* pression damping force and thereby harden Standard: the damping, and in direction b to decrease 7 click(s) in direction b* the compression damping force and thereby Maximum (hard):...
  • Page 65 WARNING Although the total number of clicks of a damp- Suspension components become hot ● ing force adjusting mechanism may not exact- during operation. Never touch the ly match the above specifications due to small compression damping force adjusting differences in production, the actual number screw, the rebound damping force ad- of clicks always represents the entire adjust- justing screw or the oil reservoir with...

  • Page 66: Trailer Hitch Bracket And Receiver

    The auxiliary DC jack dard trailer hitch. Trailer towing equipment can be used for suitable work lights, radios, can be obtained at a Yamaha dealer. (See etc. The auxiliary DC jack should only be used pages 6-9–6-11 for precaution information.) when the engine is running and the headlights are turned off.
  • Page 67 EVU00380 4. Open the auxiliary DC jack cap, and then NOTICE insert the accessory power plug into the Do not use accessories requiring ● jack. more than the maximum capacity stat- ed above. This may overload the cir- cuit and cause the fuse to blow. ●...

  • Page 68: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspect- ed by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 69 ITEM ROUTINE PAGE Final gear oil/ • Check for leakage. 5-7, 8-15–8-21 Differential gear oil Accelerator pedal • Check for proper accelerator pedal operation. Seat belts • Check for proper operation and belt wear. 5-7–5-8 Steering • Check for proper operation. Fittings and fasteners •...

  • Page 70: Front And Rear Brakes

    Check that there is no free play in the brake ply the brakes firmly for one minute. If there is pedal. If there is free play, have a Yamaha any leakage, have the vehicle inspected by a dealer check the brake system. (See page Yamaha dealer.

  • Page 71: Fuel

    Never refuel while smoking, or while in the vicinity of sparks, open flames, or oth- Your Yamaha engine has been designed to er sources of ignition such as the pilot use regular unleaded gasoline with a re-...
  • Page 72 Portable fuel containers Recommended fuel: If you carry a portable fuel container in the bed UNLEADED GASOLINE ONLY of the Rhino, be sure to secure it with the cap For Europe: Regular unleaded gasoline tightened before driving the vehicle. only with a research octane number of 95 Always place a portable fuel container on the or higher ground before filling it.

  • Page 73: Engine Oil

    EVU00410 EVU00420 Engine oil Coolant Make sure the engine oil is at the specified Check the coolant level in the coolant reser- level. Add oil as necessary. (See pages 8-10– voir when the engine is cold (the coolant level 8-15.) will vary with engine temperature).

  • Page 74: Final Gear Oil

    It must operate smoothly and 8-18 for details.) spring back to the idle position fully when re- leased. Have a Yamaha dealer repair as nec- Recommended oil: essary for proper operation. SAE 80 API GL-4 Hypoid gear oil...

  • Page 75: Steering

    Yamaha dealer repair as necessary for proper operation. EVU00470 Fittings and fasteners Always check the tightness of chassis fittings and fasteners before a ride. Take the vehicle to a Yamaha dealer or refer to the Service Manual for correct tightening torque.

  • Page 76: Tires

    EVU00500 Tires Set tire pressures to the following specifica- Check tire pressure regularly to make sure it tions: is at the recommended specifications. Also ACE-02E Recommended pressure Minimum check for wear and damage. 70 kPa 63 kPa Front EVU00510 (0.70 kgf/cm , 10 psi) (0.63 kgf/cm , 9 psi)
  • Page 77 EVU00520 Tire wear limit When the tire groove decreases to 3 mm (0.12 in) due to wear, replace the tire. 1. Tire pressure gauge a. Tire wear limit 5-10...

  • Page 78: Operation

    If there is a and 20 hours. control or function you do not understand, ask your Yamaha dealer. For this reason, we ask that you read the fol- lowing material carefully. Because the engine WARNING...

  • Page 79: Starting The Engine

    The coolant temperature warning light and build-up of heat. If any abnormality is noticed engine trouble warning light should come during this period, consult a Yamaha dealer. on, then go off. If a warning light does not go off, see pag- 0–10 hours:...
  • Page 80 ● The engine can be started in any gear For maximum engine life, never accelerate if the brake pedal is applied. However, hard when the engine is cold! it is recommended to shift into neutral before starting the engine. 4. With your foot off the accelerator pedal, start the engine by turning the key to “START”.

  • Page 81: Drive Select Lever Operation And Reverse Driving

    Drive select lever operation and reverse 2. Apply the brake pedal, then shift by mov- driving ing the drive select lever along the shift guide. Make sure that the drive select le- NOTICE ver is completely shifted into position. Do not shift without coming to a complete stop and waiting for the engine to return to normal idle speed.
  • Page 82 ● If the light does not come on, ask a Yamaha dealer to inspect the reverse indicator light electrical circuit.

  • Page 83: On-Command Four-Wheel-Drive Switch And Differential Gear Lock Switch

    5B410009 On-Command four-wheel-drive switch and “2WD”/“4WD” differential gear lock switch To change from “2WD” to “4WD”, stop the ve- You may notice that the vehicle handles dif- hicle, and then set the switch to “4WD”. When ferently in “2WD”, “4WD”, and “LOCK”. For the vehicle is in four-wheel drive, the four- example, you should expect that the vehicle wheel-drive indicator “...
  • Page 84 On-Command differential gear lock switch To lock the differential gear in four-wheel “4WD”/“LOCK” drive, stop the vehicle, make sure the On- Command four-wheel-drive switch is set to “4WD”, move the differential gear lock lever to position a, and then set the switch to “LOCK”.

  • Page 85: Parking

    EVU01210 ● Driving before the differential gear is prop- Parking erly engaged or disengaged (e.g., when the When parking, stop the engine and shift the indicator and indicator light are flashing) will drive select lever into the neutral position. Ap- cause the engine speed to be limited until ply the parking brake to help prevent the vehi- the differential gear is completely engaged...

  • Page 86: Loading

    EVU00630 Loading ● Do not exceed the maximum tongue Take extra precautions when driving with a weight. load or trailer. Follow these instructions and ● Make sure the load does not interfere always use common sense and good judg- with your control or ability to see ment when carrying cargo or towing a trailer.
  • Page 87 Carrying loads or towing a trailer can in- accessories and tongue weight): crease the risk of loss of control, an over- YXR7FD 367.0 kg (809 lb) turn, or other accident. To reduce the risk YXR7FSPD 359.0 kg (791 lb) of an accident: YXR700FAD 367.0 kg (809 lb)
  • Page 88 Pulling something other than a trailer Yamaha recommends that loads be transport- ed in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.

  • Page 89: Basic Guide For Safe Use

    5B470010 BASIC GUIDE FOR SAFE KNOW YOUR VEHICLE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, golf- As a Rhino owner you are responsible for the cars and grounds-keeping vehicles. The safe and proper operation of this vehicle. Rhino has higher ground clearance and other Read this chapter and review the safety in- features to handle rugged terrain, and, as a...
  • Page 90 Doing things with a Rhino that some people do for thrills in other vehicles (such as side- ways sliding, skidding, back-wheel sliding, or donuts) have led to side rollovers. These roll- overs can result in crushed limbs and other serious injuries or death to drivers or passen- gers.

  • Page 91: Driver Requirements

    Driver requirements Parents: ● This vehicle is intended for use only by an Many countries have implemented new motor operator 16 or older with a valid motor vehi- vehicle licensing requirements for young driv- cle license. Check country laws for mini- ers.

  • Page 92: Passenger Requirements

    Passenger requirements Occupant protection system This vehicle is designed for the operator and WARNING one passenger. Allowing passengers to ride Do not make changes to the occupant pro- improperly can lead to serious injury or death. tection system. If you install aftermarket As the operator, you are responsible for your products or have your vehicle modified, passenger.
  • Page 93 The Rhino comes with a variety of features to help reduce the risk of driver and passenger injury. These features work together, and when properly used, these features will help protect the occupants in the event of an acci- dent. If these features are not used properly, they can cause injury.

  • Page 94: Protective Structure

    Protective structure Seat belts The vehicle cage/frame provides a protective Seat belts should be worn by both driver and structure that helps limit intrusions by branch- passenger. Driver must be sure that the pas- es or other objects and may reduce your risk senger is belted before driving.
  • Page 95 An unbelted occupant may strike the interior of the vehicle, the protective structure, or oth- er objects in an accident or during operation. You may also fall completely out or be partial- ly ejected from the vehicle, which may lead to being crushed between the ground and the vehicle.
  • Page 96 2. If the latch plate is not positioned in the correct location along the seat belt, squeeze the latch plate ends together along its long edges in order to more eas- ily adjust its location up or down along the length of the belt.

  • Page 97: Doors

    6. Check if the seat belt shoulder position Doors suits the size of the driver and passen- The doors are designed to reduce the likeli- ger. hood that you will stick your leg out to stop the To lower the belt, insert the belt into the vehicle from tipping over or for any other rea- seat belt height adjuster slot as shown.

  • Page 98: Passenger Handholds

    Passenger handholds Handholds are provided to grip during opera- tion to maintain proper position and balance. Holding onto the handholds helps to reduce the likelihood that the passenger puts a hand outside the vehicle if the vehicle begins to tip. There are two handholds on the protective structure and two handholds on the passen- ger’s left side, for the right and left hands.

  • Page 99: Seat And Hip Restraints

    Seat and hip restraints Floorboard The seat and hip restraints are designed to The floorboard allows you to brace your feet, help keep you in the vehicle. Do not hold onto which helps you keep your body in the vehicle hip restraint when the vehicle is moving.

  • Page 100: Steering Wheel

    Steering wheel CORRECT GRIP EXAMPLE Keep both hands on the steering wheel. Do not hold the steering wheel with your thumbs inside the rim. Keep your palms on the out- side of the steering wheel. Similar to other off- road vehicles, if the Rhino hits a deep rut or large obstacle, the steering wheel could brief- ly jerk in one direction or back and forth as the tires and vehicle respond to the obstacle.

  • Page 101: Learning To Operate Your Vehicle

    LEARNING TO OPERATE YOUR VEHICLE Both driver and passenger should wear the following to reduce risk of injury in an acci- Personal protective equipment dent: ● Approved motorcycle helmet that fits prop- erly Eye protection (goggles, helmet face ● shield, or protective eyewear) Over-the-ankle boots, gloves, long-sleeved ●...

  • Page 102: Practice For New Rhino Users

    Wear eye protection when operating or riding the vehicle to reduce the risk of a serious ac- cident or injury. Eye protection, such as a face shield or goggles, may reduce the risk of for- eign material getting in your eyes and help prevent loss of vision.

  • Page 103: Getting Ready To Ride

    Getting ready to ride Turning Perform the Pre-Operation Checks on pages Use care in turns – turning the steering wheel 5-1–5-10. Follow the instructions starting on too far or too fast can result in loss of control pages 6-2–6-3 to start the engine. or a rollover.

  • Page 104: Accelerating

    If you think or feel that the vehicle may tip or Accelerating roll, keep your body completely inside the pro- With the engine idling in neutral and your foot tective structure of the vehicle: on the brake, shift the drive select lever into ●...

  • Page 105: Braking

    Braking Engine braking When slowing down or stopping, take your Engine compression braking is designed to foot off the accelerator pedal and press the assist you when operating your Rhino off- brake pedal smoothly. Improper use of the road. With this feature, the engine helps slow brakes can cause the tires to lose traction, re- the vehicle down after you take your foot off ducing control of the vehicle and increasing...

  • Page 106: Leaving The Vehicle

    Leaving the vehicle Parking on a flat area Do not get out of the vehicle while the engine When parking on a flat area, stop the engine is running and the drive select lever is in any and shift the drive select lever into the neutral gear.

  • Page 107: Loading

    4. With the brake pedal applied, set the Operation on different surfaces and parking brake. terrains 5. Block the front and rear wheels with Go slowly and proceed with caution when op- rocks or other objects. erating on an unfamiliar surface or terrain. This vehicle may handle differently in certain Loading types of terrains or on certain surfaces.

  • Page 108: Hills

    Hills Choose carefully which hills you attempt to climb or descend. Avoid hills with slippery sur- faces or those where you will not be able to see far enough ahead of you. Use common sense and remember that some hills are too steep for you to climb or descend.

  • Page 109: Uphill

    Uphill Slow down when you reach the crest of the hill Do not attempt to climb hills until you have if you cannot see clearly what is on the other mastered basic maneuvers on flat ground. side – there could be another person, an ob- Drive straight up hills, and avoid crossing the stacle, or a sharp drop-off.

  • Page 110: Downhill

    Downhill If you are sliding or skidding, try to steer in the Check the terrain carefully before going direction the vehicle is sliding, to regain con- downhill. When possible, choose a path that trol. For example, if you feel the back of the lets you drive your vehicle straight downhill.

  • Page 111: Rough Terrain

    Rough terrain Water Operation over rough terrain should be done If you must cross shallow, slow-moving water with caution. up to the depth of the vehicle’s floorboards, ● Look for and avoid obstacles that could choose your path carefully to avoid sharp cause damage to the vehicle or could lead drop-offs, large rocks, or slippery surfaces to a rollover or accident.

  • Page 112: Loose Terrain/Slippery Terrain

    Loose terrain/slippery terrain NOTICE When driving on slippery terrain, including After driving your vehicle in water, be sure wet, muddy, or icy conditions, as well as loose to drain the trapped water by removing the gravel, be aware that you could begin skid- check hoses at the bottom of the air filter ding or sliding.

  • Page 113: Brush Or Wooded Areas

    Brush or wooded areas Encountering obstacles When operating in areas with brush or trees, If you cannot go around an obstacle, such as watch carefully on both sides and above the a fallen tree or a ditch, stop the vehicle where vehicle for obstacles such as branches that it is safe to do so.

  • Page 114: Periodic Maintenance And Adjustment

    WARNING hicle. If you are not familiar with vehicle Brake discs, calipers, drums, and linings service, have a Yamaha dealer perform can become very hot during use. To avoid service. possible burns, let brake components cool...

  • Page 115: Owner's Manual And Tool Kit

    EVU00660 Owner’s manual and tool kit You are recommended to put this owner’s manual in the vinyl bag and always carry it un- derneath the driver seat as shown. Put the owner’s tool kit and tire pressure gauge in the space beside the battery.
  • Page 116 If you do not have a torque wrench available during a service operation requiring one, take your vehicle to a Yamaha dealer to check the torque settings and adjust them as necessary.

  • Page 117: Periodic Maintenance Chart For The Emission Control System

    However, keep in mind that if the vehicle isn’t used for a long period of time, the month maintenance intervals should be followed. Items marked with an asterisk should be performed by a Yamaha dealer as they require spe- ●...

  • Page 118: General Maintenance And Lubrication Chart

    EVU01650 General maintenance and lubrication chart INITIAL EVERY month Whichever ITEM ROUTINE comes first 1200 2400 2400 4800 (mi) (200) (750) (1500) (1500) (3000) hours • Check coolant leakage. Cooling system* • Repair if necessary. • Replace coolant every 24 months. •...
  • Page 119 INITIAL EVERY month Whichever ITEM ROUTINE comes first 1200 2400 2400 4800 (mi) (200) (750) (1500) (1500) (3000) hours Drive shaft universal joint* • Lubricate with lithium-soap-based grease. • Check for cracks or damage. Engine mount* • Check bolt tightness. •...

  • Page 120: Hood

    EVU00680 Hood To open Unhook the hood latches, and then slowly tilt the hood up until it stops. 1. Hood 1. Hood latch (× 2)
  • Page 121 To close NOTICE Lower the hood slowly to its original position, Make sure that all cables and wires ● and then hook the hood latches. Secure pro- are in place when closing the hood. jections 1 on the rear of the hood into slots 2 ●...

  • Page 122: Console

    5B410011 Console To install 1. Place the console in its original position. To remove 2. Install the parking brake lever boot. 1. Remove the seats. (See page 4-18 for 3. Install the seats. seat removal and installation proce- NOTICE dures.) Be sure to position the seat belt buck- ●...

  • Page 123: Engine Oil And Oil Filter Cartridge

    5B410012 Engine oil and oil filter cartridge Check engine oil level before each operation. In addition, change the oil and the oil filter car- tridge at the intervals specified in the periodic maintenance and lubrication chart. To check the engine oil level 1.
  • Page 124 5. Insert the dipstick completely into the oil 7. Insert the dipstick completely into the oil filler hole, and then remove it again to filler hole. check the oil level. 8. Install the console. The engine oil should be between the mini- mum and maximum level marks.
  • Page 125 To change the engine oil (with or without oil filter cartridge replacement) 1. Park the vehicle on a level surface. 2. Remove the console. (See page 8-10 for console removal and installation proce- dures.) 3. Start the engine, warm it up for several minutes, and then turn it off.
  • Page 126 If the O-ring remains attached to the crankcase, oil leakage may occur. An oil filter wrench is available from a Yamaha dealer. 1. O-ring 9. Install the new oil filter cartridge with an oil filter wrench, and then tighten it to the specified torque with a torque wrench.
  • Page 127 12. Refill with the specified amount of recom- mended engine oil, and then insert the dipstick completely into the oil filler hole. Recommended engine oil: See pages 10-1–10-2. Oil quantity: Without oil filter cartridge replacement: 2.00 L (2.11 US qt, 1.76 Imp.qt) With oil filter cartridge replacement: 2.10 L (2.22 US qt, 1.85 Imp.qt) 1.

  • Page 128: Final Gear Oil

    5B410013 Final gear oil NOTICE In order to prevent clutch slippage ● Checking the final gear oil level (since the engine oil also lubricates 1. Park the vehicle on a level surface. the clutch), do not mix any chemical 2. Remove the final gear oil filler bolt and its additives with oil.
  • Page 129 3. If the oil is below the brim of the filler hole, Changing the final gear oil add sufficient oil of the recommended 1. Park the vehicle on a level surface. type to raise it to the correct level. 2. Remove the final gear case guard by re- NOTICE: Be sure no foreign material moving the bolts and the collars.
  • Page 130 3. Place an oil pan under the final gear case 6. Refill with the recommended final gear oil to collect the used oil. up to the brim of the filler hole. NOTICE: 4. Remove the final gear oil filler bolt and its Be sure no foreign material enters the O-ring, the final gear oil drain bolt and its final gear case.

  • Page 131: Differential Gear Oil

    5B410014 9. Install the final gear case guard by install- Differential gear oil ing the bolts and the collars, and then tightening the bolts to the specified Checking the differential gear oil level torque. 1. Park the vehicle on a level surface. 2.
  • Page 132 4. Check the gasket for damage, and re- place it if necessary. 5. Install the differential gear oil filler bolt and its gasket, and then tighten the bolt to the specified torque. Tightening torque: Differential gear oil filler bolt: 23 Nm (2.3 m·kgf, 17 ft·lbf) 1.
  • Page 133 Changing the differential gear oil 3. Place an oil pan under the differential 1. Park the vehicle on a level surface. gear case to collect the used oil. 2. Remove the differential gear case guard 4. Remove the differential gear oil filler bolt, by removing the bolts and the collars.
  • Page 134 9. Check for oil leakage. If oil leakage is Tightening torque: found, check for the cause. Differential gear oil drain bolt: 10. Install the differential gear case guard by 9.8 Nm (0.98 m·kgf, 7.1 ft·lbf) installing the bolts and the collars, and then tightening the bolts to the specified 6.

  • Page 135: Coolant

    5B410015 Coolant The coolant level should be checked before each ride. Checking the coolant level 1. Park the vehicle on a level surface. 2. Check the coolant level in the coolant reservoir when the engine is cold as the coolant level varies with engine tempera- ture.

  • Page 136: Axle Boots

    EVU00740 Changing the coolant Axle boots The coolant must be changed by a Yamaha Check the axle boots for holes or tears. dealer at the intervals specified in the periodic If any damage is found, have them replaced maintenance and lubrication chart.

  • Page 137: Spark Plug Inspection

    EVU00750 Spark plug inspection Removal 1. Remove the console. (See page 8-9 for console removal and installation proce- dures.) 2. Remove the spark plug cap. 1. Rear axle boot (× 2 each side) 1. Spark plug cap 3. Use the spark plug wrench in the tool kit to remove the spark plug as shown.
  • Page 138 Inspection The spark plug is an important engine compo- nent and is easy to inspect. The condition of the spark plug can indicate the condition of the engine. The ideal color of the porcelain insulator around the center electrode is a medium-to- light tan for a vehicle that is being ridden nor- mally.
  • Page 139 Measure the spark plug gap with a wire thick- 2. Install the spark plug and tighten it to the ness gauge and, if necessary, adjust the gap specified torque. If a torque wrench is not to specification. available when you are installing the spark plug, a good estimate of the correct torque is one-quarter to one-half turn past finger tight.

  • Page 140: Cleaning The Air Filter Element

    5B410016 Cleaning the air filter element There is a check hose at the bottom of the air filter case and at the bottom of the air duct un- der the case. If dust or water collects in a check hose, empty the hose and clean the air filter element and air filter case.
  • Page 141 1. Open the hood. (See pages 8-7–8-8 for 3. Remove the air filter case cover by un- hood opening and closing procedures.) hooking the holders. 2. Remove the air intake duct shroud by re- moving the quick fastener screws. 1. Air filter case cover holder (× 5) 2.
  • Page 142 4. Remove the air filter element. 5. Remove the sponge material from the air filter frame. 1. Air filter element 1. Air filter frame 2. Sponge material 8-29...
  • Page 143 NOTICE: Do not twist replace it if damaged. the sponge material when squeezing 11. Thoroughly apply Yamaha foam air filter oil or other quality liquid foam air filter oil (not spray type) to the sponge material. The sponge material should be wet but not dripping.
  • Page 144 14. Insert the projections on the air filter case The air filter element should be cleaned every cover into the holders on the air filter 20–40 hours. It should be cleaned and lubri- case, and then install the air filter case cated more often if the vehicle is operated in cover by hooking the holders onto the extremely dusty areas.

  • Page 145: Drive Select Lever Box Check Hose

    2P512001 5B410017 Drive select lever box check hose V-belt cooling duct check hose The drive select lever box check hose is locat- The V-belt cooling duct check hose is located ed under the console. (See page 8-9 for con- under the cargo bed. If dust or water collects sole removal and installation procedures.) If in the V-belt cooling duct check hose, remove dust or water collects in the drive select lever...

  • Page 146: V-Belt Case Drain Plug

    If water drains from the V-belt case after re- haust system. moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect 1. Remove the tailpipe bolts.

  • Page 147: Valve Clearance

    To prevent this, the valve clear- ance must be adjusted regularly. This adjust- ment however, should be left to a professional Yamaha service technician. 1. Tailpipe 2. Spark arrester 3. Gasket 4.

  • Page 148: Brakes

    To check the brake pad wear, check the wear indicator grooves. If a brake pad has worn to the point that the wear indica- tor grooves have almost disappeared, have a Yamaha dealer replace the brake pads as a set. 8-35...

  • Page 149: Checking The Parking Brake Pads

    Check the pad has worn to a wear indicator groove, have brake fluid level with the top of the reservoir a Yamaha dealer replace the brake pads as a level. Replenish the brake fluid if necessary. set.

  • Page 150: Brake Fluid Replacement

    Use only the specified brake fluid; oth- ● the brake system for leakage. If the brake fluid erwise, the rubber seals may deterio- level goes down suddenly, have a Yamaha rate, causing leakage. dealer check the cause before further riding. ●...

  • Page 151: Checking The Brake Pedal

    EVU01220 EVU00870 Checking the brake pedal Parking brake lever free play adjustment Have a Yamaha dealer check the brakes at Periodically check the parking brake lever free the intervals specified in the periodic mainte- play and adjust it if necessary.
  • Page 152 a. Parking brake lever free play 1. Rubber cover 2. Locknut 3. Adjusting nut 8. Turn the adjusting nut in direction a to 5. Release the parking brake lever. increase the free play or in direction b to 6. Slide the rubber cover back on the park- ing brake cable.

  • Page 153: Brake Light Switch Adjustment

    EVU00880 Brake light switch adjustment The brake light switch, which is activated by the brake pedal, is properly adjusted when the brake light comes on just before braking takes effect. If necessary, adjust the brake light switch as follows. 1. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) 2.

  • Page 154: Cable Inspection And Lubrication

    Cables can also become frayed or kinked. Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: Lithium-soap-based grease...
  • Page 155 5B410021 Rear knuckle upper and lower pivot 2. Lubricate the knuckle upper and lower lubrication (left and right) pivots with a grease gun. 1. Remove the lower arm protector by re- moving the bolts. Recommended lubricant: 1. Bolt (× 3) 2.

  • Page 156: Steering Shaft Lubrication

    EVU00920 3. Install the lower arm protector by install- Steering shaft lubrication ing the bolts and tightening them to the Lubricate the pivot points. specified torque. Recommended lubricant: Tightening torque: Lithium-soap-based grease Lower arm protector bolt: 7 Nm (0.7 m·kgf, 5.1 ft·lbf) 8-43...

  • Page 157: Wheel Removal

    EVU00930 Wheel removal Tire replacement 1. Loosen the wheel nuts. Always use the same size and type of tires 2. Elevate the vehicle and place a suitable recommended in this owner’s manual. The stand under the frame. tires that came with your Rhino were de- 3.

  • Page 158: Wheel Installation

    EVU00940 The tires listed below have been approved by Wheel installation Yamaha Motor Manufacturing Corporation of 1. Install the wheel and the nuts. America for this model. ● The arrow mark on the tire must point toward the rotating direction of...
  • Page 159 Wheel nut torque: Front: 55 Nm (5.5 m·kgf, 40 ft·lbf) Rear: 55 Nm (5.5 m·kgf, 40 ft·lbf) 1. Arrow mark 1. Tapered nut 8-46...

  • Page 160: Battery

    EVU00950 Battery WARNING The battery is located under the hood. (See Avoid battery contact with skin, eyes, or pages 8-7–8-8 for hood opening and closing clothing. Shield eyes when working near procedures.) batteries. Keep out of reach of children. This model is equipped with a VRLA (Valve You could be poisoned or severely burned Regulated Lead Acid) battery.
  • Page 161 NOTICE Do not try to remove the sealing caps of the battery cells. You may damage the bat- tery. To remove the battery 1. Turn the key to “OFF”. 2. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) 3.
  • Page 162 To charge the battery Have a Yamaha dealer charge the battery as soon as possible if it seems to have dis- charged. Keep in mind that the battery tends to discharge more quickly if the vehicle is equipped with optional electrical accessories.
  • Page 163 NOTICE Always keep the battery charged. Storing a discharged battery can cause permanent battery damage. To install the battery Be sure the battery is fully charged. 1. Place the battery in its compartment. 1. Positive battery lead (red) 2. Connect the positive battery lead first, 2.

  • Page 164: Jump-Starting

    5B410022 Jump-starting However, if the vehicle must be jump-started, Jump-starting the vehicle should be avoided. proceed as follows. The battery should be removed and charged 1. Turn the key to “OFF”. instead. 2. Open the hood. (See pages 8-7–8-8 for hood opening and closing procedures.) WARNING 3.
  • Page 165 1. Jumper cable positive lead 1. Jumper cable negative lead 6. Connect the negative lead of the jumper 7. Start the engine. (Refer to “Starting the cable to the negative terminal of the engine” on pages 6-2–6-3.) charged battery and the other end of the 8.

  • Page 166: Fuse Replacement

    5B410023 9. Install the console. Fuse replacement 10. Install the battery compartment cover. The main fuse, the fuel injection system fuse, 11. Close the hood. and the fuse box are located under the hood. If a fuse is blown, turn off the main switch and install a new fuse of the specified amperage.
  • Page 167 3. Remove the quick fastener screws. 1 2 3 4 56 4. Remove the battery compartment cover by lifting it up and pulling it out. 1. Fuel injection system spare fuse 2. Fuel injection system fuse 3. Main fuse 4. Headlight fuse “HEAD” 5.

  • Page 168: Replacing A Headlight Bulb

    6. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. If the fuse blows again immediately, have a Yamaha dealer check the electrical system. 1. Cover at the rear of the headlight 7.
  • Page 169 3. Remove the headlight bulb holder cover 4. Remove the headlight bulb holder by by pulling it off. pushing it in and turning it counterclock- wise. 1. Headlight bulb holder cover 1. Headlight bulb holder 8-56...
  • Page 170 5. Wait for the headlight bulb to cool before touching or removing it. Remove the bulb by pulling it out. 6. Insert a new headlight bulb into the bulb holder. NOTICE: Do not touch the glass part of the headlight bulb to keep it free from oil, otherwise the transparency of the glass, the lumi- nosity of the bulb, and the bulb life will...

  • Page 171: Headlight Beam Adjustment

    Tail/brake light bulb replacement If a tail/brake light bulb burns out, replace it as NOTICE follows: It is advisable to have a Yamaha dealer 1. Remove the quick fastener screws, nuts make this adjustment. and bolts from panel A (if replacing the...
  • Page 172 2. Lift the cargo bed up. (See pages 4-22– 4-23 for cargo bed lifting and lowering procedures.) 3. Remove the panel (panel A or B). 4. Remove the tail/brake light bulb holder (together with the bulb) by turning it coun- terclockwise.

  • Page 173: Troubleshooting

    If your vehicle Tightening torque: requires any repair, take it to a Yamaha deal- Panel nut: 7 Nm (0.7 m·kgf, 5.1 ft·lbf) The skilled technicians at a Yamaha dealer- ship have the tools, experience, and know- how to properly service your vehicle.
  • Page 174 WARNING When checking the fuel system, do not smoke and make sure there are no open flames or sparks in the area, including pi- lot lights from water heaters or furnaces. Gasoline or gasoline vapors can ignite or explode, causing severe injury or property damage.

  • Page 175: Troubleshooting Charts

    Engine turns over or replace the spark plug. Battery is good. quickly. Use the electric starter. Check the connections, and ask Engine turns over Ask a Yamaha dealer to a Yamaha dealer to charge the slowly. inspect. battery if necessary. 8-62...
  • Page 176 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. If it is difficult to get the recommended coolant, tap water can be used temporarily, provided that it is changed to the recommended coolant as soon as possible.

  • Page 177: Cleaning And Storage

    EVU01030 C LEANING AND STORAGE 3. Rinse the dirt and degreaser off with a garden hose. Use only enough pressure A. Cleaning to do the job. WARNING! Test the Frequent, thorough cleaning of your vehicle brakes after washing. Apply the will not only enhance its appearance but will brakes several times at slow speeds improve its general performance and extend...

  • Page 178: Storage

    1. Fill the fuel tank with fresh fuel and add 6. Clean the seats with a vinyl upholstery the specified amount of Yamaha Fuel cleaner to keep the covers pliable and Stabilizer and Conditioner or equivalent glossy.
  • Page 179 4. Block up the frame to raise all wheels off nates the need to drain the fuel system. Con- the ground. sult a Yamaha dealer if the fuel system needs 5. Tie a plastic bag over the exhaust pipe to be drained.

  • Page 180: Specifications

    EBU25960 S PECIFICATIONS Dimensions: Vibration on handlebar (EN1032, ISO5008): YXR7FD Will not exceed 2.5 m/s Overall length: YXR7FSPD Will not exceed 2.5 m/s 2885 mm (113.6 in) Engine: Overall width: 1385 mm (54.5 in) Engine type: Overall height: Liquid cooled 4-stroke, SOHC YXR7FD 1853 mm (73.0 in)
  • Page 181 SAE 10W-30 Air filter element: SAE 10W-40 Wet element Fuel: SAE 15W-40 Recommended fuel: SAE 20W-40 YXR7FD Regular unleaded gasoline only SAE 20W-50 YXR7FSPD Regular unleaded gasoline only YXR700FAD Unleaded gasoline only Fuel tank capacity: –20 –10 50 ˚C 30.0 L (7.93 US gal, 6.60 Imp.gal)
  • Page 182 MAXXIS/M952Y Right hand operation Loading: Reverse gear: Maximum loading limit: 23/14 × 28/23 (2.000) YXR7FD 367.0 kg (809 lb) Low range: YXR7FSPD 359.0 kg (791 lb) 31/16 (1.938) YXR700FAD 367.0 kg (809 lb) High range: (Total weight of rider, passenger, cargo, accessories, and 31/21 (1.476)
  • Page 183 Wheel type: Type: YXR7FD Panel wheel Double wishbone YXR7FSPD Cast wheel Spring/shock absorber type: YXR700FAD Panel wheel YXR7FD Coil spring/oil damper Rim size: YXR7FSPD Coil spring/gas-oil damper 12 × 7.5AT YXR700FAD Coil spring/oil damper Front brake: Wheel travel: 185 mm (7.3 in)
  • Page 184 Coolant temperature warning light: Four-wheel-drive motor fuse: 10.0 A Engine trouble warning light: Radiator fan fuse: 25.0 A Parking brake indicator light: For Europe only On-Command four-wheel-drive/differential gear lock indica- The figures quoted are emission levels and are not tor: necessarily safe working levels.
  • Page 185 The vehicle identification number is stamped model label information in the spaces provid- into the frame. ed for assistance when ordering spare parts from a Yamaha dealer or for reference, in case the vehicle is stolen. 1. VEHICLE IDENTIFICATION NUMBER: ACA-02E 2.
  • Page 186 Model label The model label is affixed to the frame under the driver seat. Record the information on this label in the space provided. This information will be needed to order spare parts from your Yamaha dealer. 1. Model label 11-2...
  • Page 188 PRINTED IN USA 2012.04-0.3×1 CR...

This manual is also suitable for:

Rhino 700 fiYxr7fspdYxr700fad

Table of Contents
