Chapter 1: Product Introduction

Product Introduction
1.1

Before you proceed

Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
1.2

Motherboard overview

Place this
side towards
the rear of the
chassis
Unplug the power cord before installing or removing the motherboard. Failure to do so can
cause you physical injury and damage motherboard components.
The pin definitions in this chapter are for reference only. The pin names depend on the
location of the header/jumper/connector.
ASUS PRIME H610M-C/PS D4
5
KBMS
ATX_12V
HDMI
COM1
DP VGA
BATTERY
LAN_U32G1_12
2280 2260
AUDIO
Ethernet
3
PCIEX1(G3)_1
Super
I/O
PCIEX1(G3)_2
COM_DEBUG
Audio
Codec
COM2
AAFP
LPT
13 12 14
6 1 4
22cm(8.7in)
CPU_FAN
DIGI
+VRM
LGA1700
M.2(SOCKET3)
PCIE
SATA
3.0 X4 X
2242
PCIEX16_1
ASM
1083
PCI
USB_914
USB_78
CLRTC
SATA6G_1 SATA6G_2 SATA6G_3
11 9
1
2
5
4
8
7
Intel ®
H610
16
128Mb
BIOS
TPM 10
CHASSIS
15
SPEAKER
F_PANEL
7 17
9
