Page 1 Event Data Recorders This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 2 EDR data with the type of confidential. Some diagnostic and maintenance information is personally identifying data routinely acquired during a crash uploaded to Honda upon vehicle start up. investigation. To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed.
Page 3 NOTICE damage to your vehicle, other property, or the environment. identified by the CMBS activated Honda may obtain and use the recorded data for the purpose of technical diagnosis and research and development of Honda vehicles. The CMBS does not record images or audio inside the vehicle.
Page 4 Canada: www.honda.ca/privacy/vehicledata frequently due to internet outages, retries, direct user action, WAP push from the server or a change in query policy on the Honda Honda collects, uses and stores your personal data for the reasons servers). This application periodically transmits to our servers a set out below: ●...
Page 5 End User License Agreement. You may opt out within 30 days of your initial use of the Software by sending a signed, written notice to HONDA at American Honda Motor Co., Inc., Honda Automobile Customer Service, Mail Stop CHI-5, 1919 Torrance Blvd., Torrance, CA 90501-2746.
Page 6 A Few Words About Safety You will find this important safety information in a variety of forms, including: Your safety, and the safety of others, is very important. And ● Safety Labels - on the vehicle. operating this vehicle safely is an important responsibility. ●...
Page 7: Table Of Contents
Overheating P. 706 If You Cannot Unlock the Fuel Fill Door P. 721 The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. 2 Information P. 725 Specifications P. 726 Identification Numbers P.
Page 8 General Information on the Audio System P. 345 Bluetooth® HandsFreeLink® P. 401, 421 Refuel Recommend P. 440 Features P. 239 When Driving P. 448 Honda Sensing® P. 495 Braking P. 601 Parking Your Vehicle P. 613 Driving P. 441 Fuel Economy and CO Emissions P.
Page 9 Quick Reference Guide Visual Index ❚ Brightness Control (P201, 202) ❚ System Indicators (P90) ❚ Gauges (P112) ❚ Driver Information Interface (P116, 139, 142) ❚ ENGINE START/STOP Button (P186) ❚ Audio System (P240) ❚ Navigation System () See Navigation System Manual ❚...
Page 10 ❚ Headlights/Turn Signals (P189, 190) ❚ Fog Lights (P193) ❚ Paddle Shifter (Shift down) (P461) ❚ Left Selector Wheel (P117) ❚ Horn (Press an area around ❚ Adaptive Cruise Control (ACC) with Low Speed Follow Buttons (P522) ❚ Adaptive Cruise Control (ACC) Buttons (P543) ❚...
Page 11 Visual Index ❚ Power Window Switches (P182) ❚ Master Door Lock Switch (P174) ❚ Door Mirror Controls (P205) ❚ Driver’s Front Airbag (P56) ❚ Rearview Mirror (P204) ❚ HomeLink® Buttons (P399) ❚ Passenger’s Front Airbag (P56) ❚ Wireless Charger (P226) ❚...
Page 12 ❚ Cargo Area Light ❚ Ceiling Light (P215) ❚ Side Curtain Airbags (P67) ❚ Grab Handle ❚ Coat Hook (P221) ❚ Sun Visors ❚ Vanity Mirrors ❚ Map Lights (P216) ❚ Moonroof Switch (P185) ❚ Sunglasses Holder (P221) ❚ Seat Belts (P44) ❚...
Page 13 Visual Index ❚ Maintenance Under the Hood (P645) ❚ Windshield Wipers (P197, 665) ❚ Power Door Mirrors (P205) ❚ Side Turn Signal Lights (P189, 660) ❚ Door Lock/Unlock Control (P163) ❚ Headlights (P190, 660) ❚ Front Turn Signal Lights (P189, 660) ❚...
Page 14 Auto Idle Stop Function To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator (green) comes on. (P467, 473) Continuously variable transmission Engine status Deceleration Automatic Brake Hold Off Automatic Brake Hold On (P606) (P606)
Page 15 Manual transmission Engine status Deceleration 1. Depress the brake pedal. 2. Fully depress the clutch pedal. Stop ● Continue to depress the brake pedal. ● Move the shift lever to ● Release the clutch pedal. Start-up 1. Depress the clutch pedal fully again. 2.
Page 16 Eco Assist® System (P466, 478) Ambient Meter ● With SPORT mode off, the color of the ambient meter changes to green to indicate that the vehicle is being driven in a fuel efficient manner. Ambient Meter ECON Mode Indicator (P103) ECON Button Comes on when the ECON mode is DRIVE MODE Switch...
Page 17 Safe Driving (P39) Airbags (P53) ● Your vehicle is fitted with airbags to help protect you and your passengers during a moderate-to-severe collision. Child Safety (P73) ● All children 12 and younger should be seated in the rear seat. ● Smaller children should be properly restrained in a forward-facing child seat. ●...
Page 18 Instrument Panel (P89) System Indicators /Gauges /Driver Information Interface (P90) (P112) (P116, 139, 142) Models with A-type meter Traffic Sign Recognition System (P114) Outside Temperature (P114) Tachometer (P113) Speedometer (P112) Odometer (P113) Driver Information Interface (P116) Shift Up/Down Indicator (P95) M (7-speed manual shift mode) Indicator/Shift Indicator Fuel Gauge (P113) (P95, 96)
Page 19 Models with B-type meter ● You can change the gauge design. Change gauge design (P156) Traffic Sign Recognition System (P114) Driver Information Interface (Left Side Area) (P139) Driver Information Interface (Right Side Area) (P142) Speedometer (P112) Tachometer (P113) Temperature Gauge (P113) Fuel Gauge (P113) Outside Temperature (P114) Odometer (P113)
Page 20 Controls (P157) Clock Select Set Date or Set Time. Models with 9-in. Color Touchscreen (P158) To adjust date Select Models with 7-in. Color Touchscreen Select Save to set the date or time. The audio system receives signals from GPS satellites, updating the clock automatically. ENGINE START/STOP Button To adjust time...
Page 21 Turn Signals Wipers and Washers Steering Wheel (P189) (P203) ● To adjust, push the adjustment lever (P197) Turn Signal Control Lever down, adjust to the desired position, then lock the lever back in place. Wiper/Washer Control Lever Right Adjustment Ring To lock : Low sensitivity : Lower speed, fewer sweeps...
Page 22 Hatch Power Door Mirrors Power Windows (P176) (P182) ● With the power mode in ON, open and (P205) close the power windows. ● With the power mode in ON, move the ● If the power window lock button is in the selector switch to L or R.
Page 23 Climate Control System (P233) ● Press the AUTO button to activate the climate control system. ● Press the button to turn the system on or off. ● Press the button to defrost the windshield. Models with SYNC button Dashboard Dashboard Floor vents Floor and vents...
Page 24 Models without SYNC button Dashboard Dashboard Floor vents Floor and vents and floor defroster vents vents Temperature Control Dial Fan Control Dial A/C (Air Conditioning) Button AUTO Button (Recirculation) Button (ON/OFF) Button (Windshield Defroster) Button...
Page 25 Features USB flash drive or Bluetooth® Audio: (P239) Press and hold to change a folder/group. ● Left Selector Wheel Audio Remote Controls Roll up or down: To cycle through the audio modes, roll up or down and then (P244) press the left selector wheel: Models with 7-in.
Page 26 ● Left Selector Wheel Models with 9-in. Color Touchscreen Roll up or down: To cycle through the (Seek/Skip) Buttons modes, roll up or down and then press the left selector wheel: Back Left Selector Wheel Phone /VOL (Volume) Switch ● VOL / VOL (Volume) Switch Press to adjust the volume up/down.
Page 27 Audio system (P240) (P248) Models with 7-in. Color Touchscreen Audio/Information Screen Selector Knob VOL/ AUDIO (Volume/Power) Knob (Seek/Track) Button MENU Button (Seek/Track) Button (Back) Button PHONE Button CONNECT Button RADIO Button MEDIA Button...
Page 28 (P273) Models with 9-in. Color Touchscreen () See the Navigation System Manual For navigation system operation Audio/Information Screen (Home) Button (Back) Button VOL/ AUDIO (Volume/Power) Knob (Seek/Track) Button (Seek/Track) Button...
Page 29 Driving (P441) Manual Transmission (P463) Park Continuously Variable Transmission Used when parking or starting the engine. (P456, 457, 459) Reverse ● Shift to Used when reversing. and depress the brake pedal when starting the engine. ● Shifting Neutral Depress the brake pedal Transmission is not locked.
Page 30 7-Speed Manual Shift When the transmission is in Mode (P461) with SPORT mode ● Allows you to manually ● Pulling a paddle shifter changes the mode from shift the transmission up or continuously variable down without removing transmission to 7-speed your hands from the manual shift mode.
Page 31 VSA® On and Off Tire Pressure Monitoring (P482) ● The Vehicle Stability Assist System (TPMS) (VSA®) (P484) system helps stabilize the vehicle during ● Detects a change in tire conditions and cornering, and helps maintain traction overall dimensions due to decrease in tire while accelerating on loose or slippery pressures.
Page 32 Refueling (P626) Fuel recommendation: Unleaded gasoline, pump octane number 87 or higher Fuel tank capacity: 12.39 US gal (46.9 L) Unlock the driver’s door. Press the area indicated by the arrow to release the fuel fill door. You will hear a click. After filling, wait about five seconds before removing the...
Page 33 Honda Sensing® (P495) Collision Mitigation Low Speed Braking Models with Low Speed Braking Control Honda Sensing® is a driver support system Braking System Control (P517) which employs the use of two distinctly different kinds of sensors: the sonar sensors (CMBS...
Page 34 Adaptive Cruise Control Traffic Jam Assist Traffic Sign Recognition (P575) (ACC) System The traffic jam assist system uses a camera (P543) (P592) mounted to the upper portion of the Helps maintain a constant vehicle speed and Reminds you of road sign information, such windshield to detect and monitor left and a set following-interval behind a vehicle as the current speed limit your vehicle has...
Page 35 Maintenance (P631) Under the Hood (P645) ● Check engine oil, engine coolant, and windshield washer fluid. Add Wiper Blades (P665) when necessary. ● Replace blades if they leave streaks ● Check brake/clutch fluid. across the windshield or become ● Check the battery condition monthly. noisy.
Page 36 Handling the Unexpected (P689) Flat Tire Engine Won’t Start Overheating (P691) (P706) ● Park in a safe location. If you do not see ● Park in a safe location and replace the (P698) steam under the hood, open the hood, flat tire with the compact spare tire in the ●...
Page 37 What to Do If The steering wheel may be locked. Manual transmission models ● The power mode does not Move the steering wheel left and right ● change from VEHICLE OFF after pressing the ENGINE START/STOP (LOCK) to ACCESSORY. button. Why? The shift lever should be moved to Continuously variable transmission models...
Page 38 Why do the doors lock If you do not open the doors within 30 seconds, the doors are after I unlocked the doors? relocked automatically for security. Why does the beeper The beeper sounds when: sound when I open the The power mode is in ACCESSORY.
Page 39 U.S. models The Tire Pressure Monitoring System (TPMS) needs attention. If I’m seeing an amber you recently inflated or changed a tire, you have to recalibrate indicator of a tire with an the system. exclamation point. What is (P484) 2 Tire Pressure Monitoring System (TPMS) that? Depressing the accelerator Fasten the driver’s seat belt.
Page 40: Safe Driving
Safe Driving You can find many safety recommendations throughout this chapter, and throughout this manual. For Safe Driving Airbags Child Safety Important Safety Precautions....40 Airbag System Components....53 Protecting Child Passengers ....73 Your Vehicle’s Safety Features.... 42 Types of Airbags ........ 56 Safety of Infants and Small Children ..
Page 41: For Safe Driving
For Safe Driving The following pages explain your vehicle's safety features and how to use them properly. The safety precautions below are ones that we consider to be among the most important. Important Safety Precautions ■ Always wear your seat belt 1Important Safety Precautions A seat belt is your best protection in all types of collisions.
Page 42 uuFor Safe DrivinguImportant Safety Precautions ■ Pay appropriate attention to the task of driving safely Engaging in cell phone conversation or other activities that keep you from paying close attention to the road, other vehicles, and pedestrians could lead to a crash. Remember, situations can change quickly, and only you can decide when it is safe to divert some attention away from driving.
Page 43: Your Vehicle's Safety Features
uuFor Safe DrivinguYour Vehicle’s Safety Features Your Vehicle’s Safety Features 1Your Vehicle’s Safety Features Your vehicle is equipped with many features that work together to help protect you and your passengers during a crash. Some features do not require any action on your part. These include a strong steel framework that forms a safety cage around the passenger compartment, front and rear crush zones, a collapsible steering...
Page 44: Safety Checklist
uuFor Safe DrivinguSafety Checklist Safety Checklist For the safety of you and your passengers, make a habit of checking these items 1Safety Checklist each time before you drive. If the door and/or hatch open message appears on the driver information interface, a door and/or the hatch is not completely closed.
Page 45: Seat Belts
Seat Belts About Your Seat Belts Seat belts are the single most effective safety device because they keep you 1About Your Seat Belts connected to the vehicle so that you can take advantage of many built-in safety WARNING features. They also help keep you from being thrown against the inside of the vehicle, against any passengers, or out of the vehicle.
Page 46 uuSeat BeltsuAbout Your Seat Belts ■ Proper use of seat belts 1About Your Seat Belts Follow these guidelines for proper use: If a front or rear seat passenger moves around and • All occupants should sit upright, well back in the seat, and remain in that position extends the seat belt, the lockable retractor may for the duration of the trip.
Page 47 uuSeat BeltsuAbout Your Seat Belts ■ 1Seat Belt Reminder Seat Belt Reminder The indicator will also come on if a front passenger ■ Front seats does not fasten their seat belt within six seconds after The seat belt system includes an indicator on the power mode is set to ON.
Page 48 uuSeat BeltsuAbout Your Seat Belts ■ Rear seats : Fastened Your vehicle monitors rear seat belt use. A driver information interface notifies you if : Unfastened any of the rear seat belts are not used. The display appears when: • Any of the rear passengers' seat belts are unfastened when the power mode is turned to ON.
Page 49 uuSeat BeltsuAbout Your Seat Belts ■ 1Automatic Seat Belt Tensioners Automatic Seat Belt Tensioners The seat belt tensioners can only operate once. The front seats and the outer rear seats are equipped with automatic seat belt If a tensioner is activated, the SRS indicator will come tensioners to enhance safety.
Page 50: Fastening A Seat Belt
uuSeat BeltsuFastening a Seat Belt Fastening a Seat Belt After adjusting a front seat to the proper position, and while sitting upright and well 1Fastening a Seat Belt back in the seat: No one should sit in a seat with an inoperative seat 2 Seats P.
Page 51 uuSeat BeltsuFastening a Seat Belt 3. Position the lap part of the belt as low as 1Fastening a Seat Belt possible across your hips, then pull up on WARNING the shoulder part of the belt so the lap part Lap belt fits snugly.
Page 52 uuSeat BeltsuFastening a Seat Belt ■ 1Advice for Pregnant Women Advice for Pregnant Women Each time you have a checkup, ask your doctor if it is If you are pregnant, the best way to protect yourself and your unborn child when okay for you to drive.
Page 53: Seat Belt Inspection
uuSeat BeltsuSeat Belt Inspection Seat Belt Inspection Regularly check the condition of your seat belts as follows: 1Seat Belt Inspection WARNING • Pull each belt out fully, and look for frays, cuts, burns, and wear. • Check that the latch plates and buckles work smoothly, and the belts retract Not checking or maintaining seat belts can easily.
Page 54: Airbags
Airbags Airbag System Components Continued...
Page 55 uuAirbagsuAirbag System Components The front, driver's knee, front passenger's Two side curtain airbags, one for each Weight sensors in the front passenger’s knee, side, and side curtain airbags are side of the vehicle. The airbags are stored seat. The sensors are used for occupant deployed according to the direction and in the ceiling, above the side windows.
Page 56 uuAirbagsuAirbag System Components ■ 1Important Facts About Your Airbags Important Facts About Your Airbags Do not attempt to deactivate your airbags. Together, Airbags can pose serious hazards. To do their job, airbags must inflate with airbags and seat belts provide the best protection. tremendous force.
Page 57: Types Of Airbags
uuAirbagsuTypes of Airbags Types of Airbags Your vehicle is equipped with four types of airbags: 1Types of Airbags • Front airbags: Airbags in front of the driver’s and front passenger’s seats. The airbags can inflate whenever the power mode is •...
Page 58 uuAirbagsuFront Airbags (SRS) ■ Operation Front airbags are designed to inflate during moderate-to-severe frontal collisions. When the vehicle decelerates suddenly, the sensors send information to the control unit which signals one or both front airbags to inflate. A frontal collision can be either head-on or angled between two vehicles, or when a vehicle crashes into a stationary object, such as a concrete wall.
Page 59 uuAirbagsuFront Airbags (SRS) ■ When front airbags should not deploy Minor frontal crashes: Front airbags were designed to supplement seat belts and help save lives, not to prevent minor scrapes, or even broken bones that might occur during a less than moderate-to-severe frontal crash. Side impacts: Front airbags can provide protection when a sudden deceleration causes a driver or front passenger to move toward the front of the vehicle.
Page 60 uuAirbagsuFront Airbags (SRS) ■ 1Advanced Airbags Advanced Airbags If there is a problem with the driver’s seat position The airbags have advanced features to help reduce the likelihood of airbag related sensor or the passenger’s seat weight sensors, the injuries to smaller occupants. SRS indicator will come on, and in the event of a The driver’s advanced airbag system includes a crash, the airbag will deploy (regardless of the driver’s...
Page 61 uuAirbagsuFront Airbags (SRS) We advise against allowing a child age 12 or under to ride in the front passenger’s 1Advanced Airbags seat. However, if you do allow a small child or infant to ride in the front passenger’s • There is no child seat or other object pressing seat, the system is designed to automatically deactivate the front passenger’s airbag.
Page 62: Knee Airbags
uuAirbagsuKnee Airbags Knee Airbags The knee SRS airbags inflate in a moderate-to-severe frontal collision to help keep 1Knee Airbags the driver and/or front passenger in the proper position and to help maximize the Do not attach accessories on or near a knee airbag as benefit provided by the vehicle’s other safety features.
Page 63 uuAirbagsuKnee Airbags ■ Operation The driver’s and front passenger’s knee airbag When deploy at the same time as the driver’s and inflated front passenger’s airbag respectively. Knee Airbag When inflated Knee Airbag...
Page 64 uuAirbagsuKnee Airbags ■ When knee airbag deploys with little or no visible damage Because the airbag system senses sudden deceleration, a strong impact to the vehicle framework or suspension might cause one or more of the airbags to deploy. Examples include running into a curb, the edge of a hole, or other low fixed object that causes a sudden deceleration in the vehicle chassis.
Page 65: Side Airbags
uuAirbagsuSide Airbags Side Airbags The side airbags help protect the torso and pelvis of the driver, front passenger, or 1Side Airbags an outer rear seat occupant during a moderate-to-severe side impact. Make sure you and your front seat passenger always sit upright.
Page 66 uuAirbagsuSide Airbags ■ Operation When the sensors detect a moderate-to- When severe side impact, the control unit signals the inflated side airbag on the impact side to immediately inflate. Side Airbag When inflated Side Airbag Continued...
Page 67 uuAirbagsuSide Airbags ■ When a side airbag deploys with little or no visible damage Because the airbag system senses sudden acceleration, a strong impact to the side of the vehicle’s framework can cause a side airbag to deploy. In such cases, there may be little or no damage, but the side impact sensors detected a severe enough impact to deploy the airbag.
Page 68: Side Curtain Airbags
uuAirbagsuSide Curtain Airbags Side Curtain Airbags The side curtain airbags help protect the heads of the driver and passengers in the 1Side Curtain Airbags outer seating positions during a moderate-to-severe side impact. The side curtain To get the best protection from the side curtain airbags equipped in this vehicle are also designed to help reduce the likelihood of airbags, occupants should wear their seat belts properly and sit upright and well back in their seats.
Page 69 uuAirbagsuSide Curtain Airbags ■ When side curtain airbags deploy in a frontal collision One or both side curtain airbags may also inflate in a moderate-to-severe angled frontal collision.
Page 70: Airbag System Indicators
uuAirbagsuAirbag System Indicators Airbag System Indicators If a problem occurs in the airbag system, the SRS indicator will come on and a 1Supplemental Restraint System (SRS) Indicator message appears on the driver information interface. WARNING ■ Supplemental Restraint System (SRS) Indicator Ignoring the SRS indicator can result in ■...
Page 71 uuAirbagsuAirbag System Indicators ■ 1Passenger Airbag Off Indicator Passenger Airbag Off Indicator To ensure the passenger is detected properly, confirm ■ When the passenger airbag off that: U.S. Canada indicator comes on • The occupant is sitting in an upright position, The indicator comes on to alert you that the wearing the seat belt properly and the seat-back is not excessively reclined.
Page 72 uuAirbagsuAirbag System Indicators 1Passenger Airbag Off Indicator The passenger airbag off indicator may come on and go off periodically if the total weight on the seat is near the airbag cutoff threshold. For a small adult, depending on physique and posture, the system may not recognize him/her as an adult and thus deactivate the passenger’s airbag.
Page 73: Airbag Care
If it is necessary to remove or modify a front seat to accommodate a person with disabilities, contact a Honda dealer, or for U.S. vehicles, American Honda Automobile Customer Service at 1-800- 999-1009 and for Canadian vehicles, Honda Canada Customer Relations at 1-888- 9-HONDA-9.
Page 74: Protecting Child Passengers
Child Safety Protecting Child Passengers Each year, many children are injured or killed in vehicle crashes because they are 1Protecting Child Passengers either unrestrained or not properly restrained. In fact, vehicle crashes are the WARNING number one cause of death of children ages 12 and under. Children who are unrestrained or To reduce the number of child deaths and injuries, every state, Canadian province improperly restrained can be seriously...
Page 75 uuChild SafetyuProtecting Child Passengers • Never hold a child on your lap because it is impossible to protect them in the 1Protecting Child Passengers event of a collision. WARNING • Never put a seat belt over yourself and a child. During a crash, the belt would Allowing a child to play with a seat belt or likely press deep into the child and cause serious or fatal injuries.
Page 76: Safety Of Infants And Small Children
uuChild SafetyuSafety of Infants and Small Children Safety of Infants and Small Children ■ 1Protecting Infants Protecting Infants WARNING An infant must be properly restrained in a rear-facing child seat until the infant reaches the seat manufacturer’s weight or height limit for the seat. Placing a rear-facing child seat in the front ■...
Page 77 uuChild SafetyuSafety of Infants and Small Children ■ 1Protecting Smaller Children Protecting Smaller Children WARNING If a child has exceeded the weight and height limitations of a rearward-facing child seat, the child should be properly restrained in a firmly secured forward-facing child Placing a forward-facing child seat in the seat until they exceed the weight and height limitations for the forward-facing child front seat can result in serious injury or...
Page 78 uuChild SafetyuSafety of Infants and Small Children ■ 1Selecting a Child Seat Selecting a Child Seat Installation of a LATCH-compatible child seat is Most child seats are LATCH-compatible (Lower Anchors and Tethers for Children). simple. Some have a rigid-type connector while others have a flexible-type connector. Both are equally easy to use.
Page 79 uuChild SafetyuSafety of Infants and Small Children ■ 1Installing a LATCH-Compatible Child Seat Installing a LATCH-Compatible Child Seat WARNING A LATCH-compatible child seat can be installed in either of the two outer rear seats. A child seat is attached to the lower anchors with either the rigid or flexible type of connectors. Never attach two child seats to the same 1.
Page 80 uuChild SafetyuSafety of Infants and Small Children 4. Retract the cargo area cover. Straight Top Tether Type 1Installing a LATCH-Compatible Child Seat 2 Cargo Area Cover P. 223 WARNING 5. Route the tether strap over the top of the head restraint. Using the outer rear seats' inner anchors to Anchor 6.
Page 81 uuChild SafetyuSafety of Infants and Small Children ■ 1Installing a Child Seat with a Lap/Shoulder Seat Belt Installing a Child Seat with a Lap/Shoulder Seat Belt A child seat that is not properly secured will not A child seat can be installed with a lap/shoulder belt in any rear seat or, if absolutely adequately protect a child in a crash and may cause necessary, the front passenger seat.
Page 82 uuChild SafetyuSafety of Infants and Small Children 5. Grab the shoulder part of the seat belt near 1Installing a Child Seat with a Lap/Shoulder Seat Belt the buckle, and pull up to remove any slack To deactivate a lockable retractor, release the buckle from the lap part of the belt.
Page 83 uuChild SafetyuSafety of Infants and Small Children ■ 1Adding Security with a Tether Adding Security with a Tether Always use a tether for forward-facing child seats A tether anchor point is provided behind each Outer Position when using the seat belt or lower anchors. rear seating position.
Page 84 uuChild SafetyuSafety of Infants and Small Children ■ Using an outer anchor Straight Top Tether Type in Outer Position 1. Retract the cargo area cover. 2 Cargo Area Cover P. 223 2. Locate the appropriate tether anchor point. 3. Route the tether strap over the head Anchor restraint.
Page 85 uuChild SafetyuSafety of Infants and Small Children ■ Using the center anchor Straight Top Tether Type in Center Position 1. Retract the cargo area cover. 2 Cargo Area Cover P. 223 2. Locate the appropriate tether anchor point Anchor and lift the cover. 3.
Page 86: Safety Of Larger Children
uuChild SafetyuSafety of Larger Children Safety of Larger Children ■ 1Safety of Larger Children Protecting Larger Children WARNING The following pages give instructions on how to check proper seat belt fit, what kind of booster seat to use if one is needed, and important precautions for a child who Allowing a child age 12 or under to sit in must sit in front.
Page 87 uuChild SafetyuSafety of Larger Children ■ 1Booster Seats Booster Seats When installing a booster seat, make sure to read the If a lap/shoulder seat belt cannot be used instructions that came with it, and install the seat properly, position the child in a booster seat in accordingly.
Page 88: Exhaust Gas Hazard
Exhaust Gas Hazard Carbon Monoxide Gas The engine exhaust from this vehicle contains carbon monoxide, a colorless, 1Carbon Monoxide Gas odorless, and highly toxic gas. As long as you properly maintain your vehicle, carbon WARNING monoxide gas will not get into the interior. Carbon monoxide gas is toxic.
Page 89: Label Locations
Safety Labels Label Locations These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels carefully. If a label comes off or becomes hard to read (except for the U.S. dashboard label which may be removed by the owner), contact a dealer for a replacement.
Page 90: Instrument Panel
Instrument Panel This chapter describes the buttons, indicators, and gauges that are used while driving. Indicators ..........90 Gauges and Driver Information Interface Gauges..........112 Models with A-type meter Driver Information Interface ..... 116 Models with B-type meter Driver Information Interface (Left Side Area) ..........
Page 91: Indicators
Indicators Indicators come on/blink depending on the condition of the vehicle. Messages may display on the driver information interface at the same time. Please take the appropriate action outlined in the message, such as contacting a dealer. Charging System  P. 98 Low Fuel Indicator ...
Page 92 uuIndicatorsu Low Tire Pressure/ NORMAL Mode Immobilizer System  P. 103  P. 104  P. 100 TPMS Indicator Indicator Indicator Security System Alarm SPORT Mode  P. 104  P. 103 Turn Signal and Indicator Indicator  P. 101 Hazard Warning Indicators Adaptive Cruise Control...
Page 93 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on when the parking brake is ● The beeper sounds and the indicator comes on if applied, and goes off when it is released. you drive with the parking brake applied. Comes on for about 30 seconds when you apply ●...
Page 94 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on if there is a problem with the 1.5 L engine models brake system. Comes on along with the Parking Brake and ● Brake System Indicator (amber) - Immediately stop in a safe place. Contact a dealer for repair. The brake pedal becomes harder to operate.
Page 95 uuIndicatorsu Indicator Name On/Blinking Explanation U.S. ● Comes on if there is a problem with a ● Comes on while driving - Have your vehicle system related to braking other than the checked by a dealer. conventional brake system. With this indicator on, your vehicle still has normal ●...
Page 96 uuIndicatorsu Indicator Name On/Blinking Explanation ● After you have set the power mode to ON, ● Readiness codes are part of the on board the vehicle performs system checks. diagnostics for the emissions control systems. However, if the readiness codes have not 2 Testing of Readiness Codes P.
Page 97 uuIndicatorsu Indicator Name On/Blinking Explanation ● Blinks if the transmission system has a ● Blinks while driving - Avoid sudden starts and problem. acceleration and have your vehicle checked by a dealer immediately. Blinks if the transmission system has a Avoid sudden starts, sudden acceleration and high ●...
Page 98 uuIndicatorsu Indicator Name On/Blinking Explanation ● Blinks and the beeper sounds for a few ● The beeper stops and the indicator goes off when seconds if you are not wearing a seat belt you and the passengers fasten their seat belts. when you set the power mode to ON, then Stays on after you and/or the passengers have ●...
Page 99 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on when the fuel reserve is running ● Comes on - Refuel your vehicle as soon as possible. low (approximately 1.8 U.S. gal/7.0 Liter left). Low Fuel Indicator Blinks if there is a problem with the fuel Blinks - Have your vehicle checked by a dealer.
Page 100 uuIndicatorsu Indicator Name On/Blinking Explanation • Comes on if there is a problem with the • Stays on constantly - Have your vehicle checked EPS system. by a dealer. Electric Power • Do not drive displays on the driver Steering (EPS) information interface - Immediately stop in a System Indicator safe place and contact a dealer.
Page 101 uuIndicatorsu Indicator Name On/Blinking Explanation ● May come on briefly if the power mode is ● Comes on while driving - Stop in a safe place, set to ON and the vehicle is not moved check tire pressures, and inflate the tire(s) if within 45 seconds, to indicate the necessary.
Page 102 uuIndicatorsu Indicator Name On/Blinking Explanation • Blinks when you operate the turn signal • Does not blink or blinks rapidly Turn Signal and lever. 2 Replacing Light Bulbs P. 660, 661 Hazard Warning • Blink along with all turn signals when you Indicators press the hazard warning button.
Page 103 uuIndicatorsu Indicator Name On/Blinking Explanation • Comes on along with a beep when a ● Refer to the Indicators information in this chapter problem is detected. A system message on when a system message appears on the driver the driver information interface appears at information interface.
Page 104 uuIndicatorsu Indicator Name On/Blinking Explanation Models without drive mode switch Comes on when the ECON mode is on. ● ECON Mode 2 ECON Button P. 466 Models with drive mode switch Indicator 2 Drive Mode Switch P. 478 Comes on when you set the drive mode to ●...
Page 105 uuIndicatorsu Indicator Name On/Blinking Explanation • Blinks if the immobilizer system cannot • Blinks - You cannot start the engine. Set the Models with recognize the key information. power mode to VEHICLE OFF, then select the ON A-type meter mode again. Indicator Canadian models Depress and hold the brake pedal before setting...
Page 106 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on when the Auto Idle Stop system Auto Idle Stop OFF has been turned off by the Auto Idle Stop 2 Auto Idle Stop System ON/OFF P. 468 Indicator OFF button. Auto Idle Stop Blinks if there is a problem with the Auto Blinks - Have your vehicle checked by a dealer.
Page 107 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on while Auto Idle Stop is temporarily suspended in the following — situations. Continuously variable transmission models Depress the brake pedal firmly. ● - Brake pedal is not fully pressed Continuously variable transmission models - The transmission is in a position other than - System charging is prioritized 2 Auto Idle Stop P.
Page 108 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on if there is a problem with ACC ● Comes on while driving - Have your vehicle with Low Speed Follow checked by a dealer. Comes on if the ACC with Low Speed Drive a short distance at more than 12 mph (20 km/h).
Page 109 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on if there is a problem with the ● Stays on constantly - Have your vehicle checked LKAS. by a dealer. Lane Keeping Indicator may come on temporarily when Make sure the total load is within the Maximum ●...
Page 110 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on if there is a problem with Road ● Stays on constantly - Have your vehicle checked Departure Mitigation system, CMBS , Low by a dealer. Speed Braking Control or blind spot information system Indicator may come on temporarily when Make sure the total load is within the Maximum ●...
Page 111 uuIndicatorsu Indicator Name On/Blinking Explanation ● Comes on when the Road Departure ● Stays on - The temperature inside the camera is Mitigation system and/or CMBS shuts too high. itself off. Use the climate control system to cool down the camera.
Page 112 uuIndicatorsu Indicator Name On/Blinking Explanation Models with Low Speed Braking Control ● Remove the obstacle in the vicinity of the sonar Comes on when mud, snow, or ice sensor. ● accumulates in the vicinity of the sonar 2 Low Speed Braking Control P.
Page 113: Gauges And Driver Information Interface
Gauges and Driver Information Interface Gauges Gauges include the speedometer, fuel gauge, and other related indicators. They are displayed when the power mode is in ON. ■ 1Speedometer Speedometer You can set the speedometer and the displayed Displays your driving speed in mph or km/h. measurements to read in either km/h and mph.
Page 114: Models With A-Type Meter
uuGauges and Driver Information InterfaceuGauges ■ 1Tachometer Tachometer Models with A-type meter Shows the number of engine revolutions per minute. The tachometer can be turned on and off using the driver information interface. 2 Settings P. 129 Even if you have turned off the tachometer on the driver information interface, if No content is selected on the driver information interface, it will change to a tachometer-only display.
Page 115: Models With B-Type Meter
uuGauges and Driver Information InterfaceuGauges ■ 1Outside Temperature Outside Temperature The temperature sensor is in the front bumper. Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada). Road heat and exhaust from another vehicle can affect the temperature reading when your vehicle ■...
Page 116 uuGauges and Driver Information InterfaceuGauges ■ 1Current Mode for ACC with Low Speed Follow , the LKAS, and Current Mode for ACC with Low Speed Follow , the LKAS, and Traffic Jam Assist Traffic Jam Assist Shows the current mode for ACC with Low Speed Follow , LKAS, and traffic jam Models with B-type meter assist...
Page 117: Driver Information Interface
uuGauges and Driver Information InterfaceuDriver Information Interface Models with A-type meter Driver Information Interface The driver information interface shows information such as the estimated travelable distance and fuel economy of the vehicle. It also displays messages such as warnings and other helpful information. When a warning message displays, please check the message and contact a dealer and have the vehicle inspected if necessary.
Page 118 uuGauges and Driver Information InterfaceuDriver Information Interface Range & fuel Warnings P. 118 P. 128 Speed & time No content P. 120 P. 128 Customize Driver display attention P. 127 P. 122 Seat belts Settings P. 125 P. 129 Left Selector Wheel (home) Button Maintenance...
Page 119 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Range / Fuel / Trip Meter Roll the left selector wheel to switch between trip meter A and trip meter B. Average Fuel Economy Range Trip Meter A Trip Meter B Instant Fuel Economy...
Page 120 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Trip meter Shows the total number of miles or kilometers driven since the last reset. Meters A and B can be used to measure two separate trips. Resetting a trip meter To reset the trip meter, display it, press the left selector wheel and then select Reset. The trip meter is reset to 0.0.
Page 121 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Speed & Time Roll the left selector wheel to switch between trip meter A and trip meter B. Elapsed Time Average Speed Trip Meter A Trip Meter B...
Page 122 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Trip meter 2 Trip meter P. 119 ■ Elapsed time 1Elapsed time Shows the time elapsed since Trip A or Trip B was reset. You can change when to reset the elapsed time. 2 Settings P.
Page 123 uuGauges and Driver Information InterfaceuDriver Information Interface ■ 1Driver Attention Monitor Driver Attention Monitor The Driver Attention Monitor cannot always detect if The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is the driver is tired or inattentive. being driven in a manner consistent with drowsy or inattentive driving.
Page 124 uuGauges and Driver Information InterfaceuDriver Information Interface If two bars light up, the Driver attention level low message will appear. If one bar lights up, the Driver attention level low. Time for a break. message will appear, a beep will sound, and the steering wheel will vibrate.
Page 125 uuGauges and Driver Information InterfaceuDriver Information Interface ■ The Driver Attention Monitor resets when: • The engine is turned off. • The driver unfastens the seat belt and opens the door while the vehicle is stopped. ■ For the Driver Attention Monitor to function: 1For the Driver Attention Monitor to function: •...
Page 126 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Seat Belts Appears when any of the seat belts are latched or unlatched. ■ Maintenance Shows the remaining oil life and Maintenance Minder 2 Maintenance Minder P. 635 ■ 1Safety Support Safety Support If a system is indicated by the color amber, have your Indicates the state of the Road Departure Mitigation system, CMBS , and blind spot...
Page 127 uuGauges and Driver Information InterfaceuDriver Information Interface Area Info for Road CMBS Departure Mitigation System Icon and State Info Area Info for Road Blind spot Departure information Mitigation system Icon System and State Area Info for Info Blind spot information system CMBS Icon...
Page 128 uuGauges and Driver Information InterfaceuDriver Information Interface ■ 1Customize Display Customize Display Icons that are gray cannot be removed from the Change the settings to your liking. home screen. ■ Arrange content Continuously variable transmission models You can choose which icons to display on the home screen. When you customize settings, shift to 1.
Page 129 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Speed/Distance Units Enables you to show another unit on the driver information interface and set the displayed measurements to read in either miles and km, mph and km/h. Press and hold the left selector wheel when you select No content on the driver information interface.
Page 130 uuGauges and Driver Information InterfaceuDriver Information Interface ■ 1Settings Settings To customize other features, roll the left selector Use the driver information interface to customize certain features. wheel. 2 List of customizable options P. 130 ■ How to customize 2 Example of customization settings P. 136 Press the (home) button, then select the Settings screen by rolling the left Continuously variable transmission models...
Page 131 uuGauges and Driver Information InterfaceuDriver Information Interface ■ List of customizable options Setup Group Customizable Features Description Selectable Settings TPMS — Calibrates the TPMS. Cancel/Calibrate calibration Forward collision Changes the distance at which CMBS alerts. Long/Normal /Short warning distance Causes the system to beep when the system detects a ACC forward vehicle vehicle, or when the vehicle goes out of ACC with Low ON/OFF...
Page 132 uuGauges and Driver Information InterfaceuDriver Information Interface Setup Group Customizable Features Description Selectable Settings Traffic sign recognition system Turns the traffic sign recognition system on and off. /OFF display setting Traffic sign recognition system Turns the traffic sign recognition system over speed /OFF exceeding speed warning on and off.
Page 133 uuGauges and Driver Information InterfaceuDriver Information Interface Setup Group Customizable Features Description Selectable Settings English /Français/ Language selection Changes the displayed language. Español -5°F ~ ±0°F ~ +5°F Adjust outside temp. (U.S.) Adjusts the temperature reading by a few degrees. display -3°C ~ ±0°C ~ +3°C...
Page 134 uuGauges and Driver Information InterfaceuDriver Information Interface Setup Group Customizable Features Description Selectable Settings Changes which doors unlock when you grab the driver’s Driver door only /All Door unlock mode door handle. doors Keyless access light Causes some exterior lights to flash when you unlock/ /OFF flash lock the doors.
Page 135 uuGauges and Driver Information InterfaceuDriver Information Interface Setup Group Customizable Features Description Selectable Settings Continuously variable transmission models With vehicle speed /Shift from P/OFF Changes the setting for when the doors Auto door lock automatically lock. Manual transmission models With vehicle speed /OFF Continuously variable transmission models All doors when driver’s door opens...
Page 136 uuGauges and Driver Information InterfaceuDriver Information Interface Setup Group Customizable Features Description Selectable Settings Changes the settings for the lockout Door setup Lockout prevention /OFF protection function. Resets the Maintenance Minder display Maintenance — when you have performed the (Selects Reset Items) reset maintenance service.
Page 137 uuGauges and Driver Information InterfaceuDriver Information Interface ■ Example of customization settings The steps for changing the “Trip A” reset timing setting to When fully refueled are shown below. The default setting for “Trip A” reset timing is Manually reset. 1.
Page 138 uuGauges and Driver Information InterfaceuDriver Information Interface 2. Roll the left selector wheel until Meter setup appears on the display. 3. Press the left selector wheel. Language selection appears first in the display. 4. Roll the left selector wheel until “Trip A” reset timing appears on the display, then press the left selector wheel.
Page 139 uuGauges and Driver Information InterfaceuDriver Information Interface 6. Press the left selector wheel after Back appears on the display. 7. Repeat Step 6 until you return to the normal screen.
Page 140 uuGauges and Driver Information InterfaceuDriver Information Interface (Left Side Area) Models with B-type meter Driver Information Interface (Left Side Area) Shows the current mode for audio and phone information, etc. 2 Audio Remote Controls P. 244 2 Bluetooth® HandsFreeLink® P. 421 ■...
Page 141 uuGauges and Driver Information InterfaceuDriver Information Interface (Left Side Area) ■ 1Customize Display Customize Display ■ Continuously variable transmission models Arrange audio source on the left side area When you customize settings, shift to You can choose which sources to display on the audio source screen. Manual transmission models 1.
Page 142 uuGauges and Driver Information InterfaceuDriver Information Interface (Left Side Area) ■ Turn the displaying on the left side area on and off You can select whether the current audio information and clock appear on the left side area. 1. Roll the left selector wheel, then roll the left selector wheel to scroll to select Customize display and press the left selector wheel.
Page 143 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) Models with B-type meter Driver Information Interface (Right Side Area) The driver information interface shows information such as the estimated travelable distance and fuel economy of the vehicle. It also displays messages such as warnings and other helpful information.
Page 144 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ 1Switching the Display Switching the Display You can add or delete the meter contents. Roll the right selector wheel to view different types of content. 2 Customize Display P. 155 Warning Messages Range / Fuel / Speed &...
Page 145 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Range / Fuel / Trip Meter Press the right selector wheel to switch between trip meter A and trip meter B. Average Fuel Economy Range Trip Meter A Instant Fuel Trip Meter B Economy ■...
Page 146 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Average fuel economy 1Average fuel economy Shows the estimated average fuel economy of each trip meter in mpg or l/100 km. You can change when to reset the average fuel The display is updated at set intervals.
Page 147 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Speed & Time Press the right selector wheel to switch between trip meter A and trip meter B. Elapsed Time Average Speed Trip Meter A Trip Meter B...
Page 148 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Trip meter 2 Trip meter P. 144 ■ Elapsed time 1Elapsed time Shows the time elapsed since Trip A or Trip B was reset. You can change when to reset the elapsed time. 2 Customized Features P.
Page 149 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ 1Driver Attention Monitor Driver Attention Monitor The Driver Attention Monitor cannot always detect if The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is the driver is tired or inattentive. being driven in a manner consistent with drowsy or inattentive driving.
Page 150 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) If two bars light up, the Driver attention level low message will appear. If one bar lights up, the Driver attention level low. Time for a break. message will appear, a beep will sound, and the steering wheel will vibrate.
Page 151 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ The Driver Attention Monitor resets when: • The engine is turned off. • The driver unfastens the seat belt and opens the door while the vehicle is stopped. ■ For the Driver Attention Monitor to function: 1For the Driver Attention Monitor to function: •...
Page 152 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Seat Belts Appears when any of the seat belts are latched or unlatched. ■ Maintenance Shows the remaining oil life and Maintenance Minder 2 Maintenance Minder P. 635 Continued...
Page 153 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ 1Safety Support Safety Support If a system is indicated by the color amber, have your Indicates the state of the Road Departure Mitigation system, CMBS , Low Speed vehicle checked by a dealer immediately. Braking Control and blind spot information system such as On, Off, or Failure, by color and letters.
Page 154 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) Area Info for Road Departure Area Info for Blind Blind spot Road Departure Mitigation System spot information information system Mitigation Icon and State Info system Icon and State Info System Area Info for the Low Speed Braking Area Info for...
Page 155 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ 1Warnings Warnings If there are multiple warnings, you can roll the right You can check if there are any active warning messages. selector wheel to see other warnings. ■ Speed/Distance Units Enables you to show another unit on the driver information interface and set the...
Page 156 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ 1Arrange content on the right side area Customize Display Contents that are gray cannot be removed from the Change the settings to your liking. right side area. ■ Arrange content on the right side area Continuously variable transmission models You can choose which contents to display on the right side area.
Page 157 uuGauges and Driver Information InterfaceuDriver Information Interface (Right Side Area) ■ Change gauge design 1Change gauge design You can change the design, such as speedometer, tachometer and so on. You can select the following design. 1. Press the right selector wheel when you Round: Shows the speedometer and tachometer for select the Customize display on the driver round type.
Page 158: Controls
Controls This chapter explains how to operate the various controls necessary for driving. Clock ..........158 Security System Alarm...... 179 Models with A-type meter Windows ........... 182 Locking and Unlocking the Doors Brightness Control ......201 Moonroof ........185 Models with B-type meter Key ..........
Page 159: Clock
Clock Adjusting the Clock You can adjust the time in the clock display with the power mode in ON. 1Adjusting the Clock The clock is automatically updated through the audio ■ system. Adjusting the Time Models with 7-in. Color Touchscreen Models with 7-in.
Page 160 uuClockuAdjusting the Clock Models with 9-in. Color Touchscreen 1Adjusting the Clock 1. Press the button. Models with 9-in. Color Touchscreen 2. Select General Settings. You can also adjust the clock by touching the clock 3. Select System. displayed on the header area of the audio/ information screen, Clock displayed on the home 4.
Page 161: Locking And Unlocking The Doors
Locking and Unlocking the Doors This vehicle comes with the following keys: 1Key Use the keys to start and stop the engine, and Models without remote engine starter All the keys have an immobilizer system. The to lock and unlock all the doors, hatch, and immobilizer system helps to protect against vehicle theft.
Page 162 uuLocking and Unlocking the DoorsuKey ■ Built-in Key The built-in key can be used to unlock the Built-in Key doors when the keyless remote battery becomes weak and the power door unlock operation is disabled. To remove the built-in key, push the release button and then pull out the key.
Page 163: Low Keyless Remote Signal Strength
uuLocking and Unlocking the DoorsuLow Keyless Remote Signal Strength Low Keyless Remote Signal Strength The vehicle transmits radio waves to locate the keyless remote when locking/ 1Low Keyless Remote Signal Strength unlocking the doors and hatch, fuel fill door or to start the engine. Communication between the keyless remote and the vehicle consumes the keyless remote's battery.
Page 164: Locking/Unlocking The Doors From The Outside
uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside Locking/Unlocking the Doors from the Outside ■ 1Locking/Unlocking the Doors from the Outside Using the Keyless Access System If the interior light switch is in the door activated position, When you carry the keyless remote, you can the interior lights come on when you unlock the doors and lock/unlock the doors, fuel fill door and hatch.
Page 165 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside Lock button...
Page 166 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside ■ Unlocking the doors and hatch 1Using the Keyless Access System Grab the driver’s door handle: • Do not leave the keyless remote in the vehicle The driver’s door and fuel fill door when you get out.
Page 167 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside ■ Locking the doors and hatch (Walk 1Locking the doors and hatch (Walk away auto lock®) away auto lock®) The auto lock function is set to OFF as the factory When you walk away from the vehicle with all default setting.
Page 168 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside To temporarily deactivate the function: 1Locking the doors and hatch (Walk away auto lock®) 1. Set the power mode to OFF. The auto lock function does not operate when any of 2.
Page 169 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside ■ 1Using the Remote Transmitter Using the Remote Transmitter If you do not open a door or the hatch within 30 ■ Locking the doors and hatch seconds of unlocking the vehicle with the remote Press the lock button.
Page 170 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside ■ 1Unlocking the Doors Using a Key Unlocking the Doors Using a Key When unlocking, the driver’s door unlocks first. Turn If the unlock button of the keyless remote does not work, use the built-in key the key a second time within a few seconds to unlock instead.
Page 171 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside ■ 1Locking a Door Without Using a Key Locking a Door Without Using a Key When you lock the driver’s door, all the other doors, If you do not have the key on you, or if for some reason you cannot lock a door using hatch and fuel fill door lock at the same time.
Page 172 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Outside Models with keyless access system 1Locking a Door Without Using a Key ■ Lockout protection function Models with keyless access system If the vehicle cannot detect the keyless You can change the lockout protection operation remote, lockout protection activates.
Page 173: Locking/Unlocking The Doors From The Inside
uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Inside Locking/Unlocking the Doors from the Inside ■ 1Using the Lock Tab Using the Lock Tab When you lock the door using the lock tab on the ■ Locking a door driver’s door, all of the other doors, hatch and fuel fill To lock Push the lock tab forward.
Page 174 uuLocking and Unlocking the DoorsuLocking/Unlocking the Doors from the Inside ■ 1Unlocking Using the Front Door Inner Handle Unlocking Using the Front Door Inner Handle The front door inner handles are designed to allow Pull the front door inner handle. front seat occupants to open the door in one motion.
Page 175: Childproof Door Locks
uuLocking and Unlocking the DoorsuChildproof Door Locks ■ 1Using the Master Door Lock Switch Using the Master Door Lock Switch When you lock/unlock either of the front doors using Press the master door lock switch in as shown the master lock switch, all the other doors, hatch and To unlock to lock or unlock all doors, hatch and fuel fill fuel fill door lock/unlock at the same time.
Page 176: Auto Door Locking/Unlocking
uuLocking and Unlocking the DoorsuAuto Door Locking/Unlocking Auto Door Locking/Unlocking Your vehicle locks or unlocks all doors automatically when a certain condition is met. 1Auto Door Locking/Unlocking You can turn off or change to another auto door ■ locking/unlocking setting using the driver Auto Door Locking information interface or audio/information screen.
Page 177: Hatch
Hatch Precautions for Opening/Closing the Hatch Always make sure individuals and objects are clear of the hatch before opening or 1Precautions for Opening/Closing the Hatch closing it. WARNING • Open the hatch all the way. Anyone caught in the path of a hatch that If it is not fully opened, the hatch may begin to close under its own weight.
Page 178 uuHatchuOpening/Closing the Hatch Opening/Closing the Hatch When all the doors are unlocked or press the 1Opening/Closing the Hatch hatch unlock button on the remote Models with keyless access system transmitter, the hatch is unlocked. Press the • Do not leave the keyless remote in the vehicle when you get out.
Page 179 uuHatchuOpening/Closing the Hatch ■ 1Using the Remote Transmitter Using the Remote Transmitter If you have unlocked and opened the hatch using the Press the hatch unlock button to unlock the remote transmitter, when closing, the hatch locks hatch. automatically. Hatch Unlock Button...
Page 180: Security System
Security System Immobilizer System This system prevents a key that has not been pre-registered from starting the 1Immobilizer System engine. NOTICE Leaving the key in the vehicle can result in theft or Pay attention to the following when pressing the ENGINE START/STOP button: accidental movement of the vehicle.
Page 181 uuSecurity SystemuSecurity System Alarm ■ When the security system alarm activates 1Security System Alarm The horn sounds intermittently, and some exterior lights flash. Do not set the security system alarm when someone is in the vehicle or a window is open. The system can ■...
Page 182 uuSecurity SystemuSecurity System Alarm ■ Panic Mode ■ The panic button on the remote transmitter If you press the panic button for approximately one second, the following will occur for about 30 seconds: • The horn sounds. • Some exterior lights flash. Panic Button ■...
Page 183: Windows
Windows Opening/Closing the Power Windows The power windows can be opened and closed when the power mode is in ON, 1Opening/Closing the Power Windows using the switches on the doors. WARNING The driver’s side switches can be used to open and close all the windows. The power Closing a power window on someone’s window lock button on the driver’s side must be switched off (not pushed in, hands or fingers can cause serious injury.
Page 184 uuWindowsuOpening/Closing the Power Windows ■ 1Opening/Closing the Power Windows Opening/Closing the Windows without Auto-Open/Close Function While driving with any of the windows open, you To open: Push the switch down. may hear a booming, throbbing, or helicopter-type To close: Pull the switch up. noise or pressure.
Page 185 uuWindowsuOpening/Closing the Power Windows ■ 1Opening the Windows with the Key Opening the Windows with the Key Models with moonroof Pull and hold the outer handle. Insert the key If you open the windows with the key, the moonroof into the key cylinder completely from below will open automatically along with them.
Page 186: Moonroof
Moonroof Opening/Closing the Moonroof You can operate the moonroof when the power mode is in ON. Use the switch in 1Opening/Closing the Moonroof the front of the ceiling to open and close the moonroof. WARNING ■ Opening or closing the moonroof on Using the Moonroof Switch someone’s hands or fingers can cause ■...
Page 187: Operating The Switches Around The Steering Wheel
Operating the Switches Around the Steering Wheel ENGINE START/STOP Button ■ 1ENGINE START/STOP Button Changing the Power Mode ENGINE START/STOP Button Operating Range You can start the engine when the keyless remote is Continuously Variable Transmission Manual Transmission inside the vehicle. VEHICLE OFF (LOCK) Operating Range The button is off.
Page 188 uuOperating the Switches Around the Steering WheeluENGINE START/STOP Button ■ 1ENGINE START/STOP Button Automatic Power Off Manual transmission models If you leave the vehicle for 30 to 60 minutes with the transmission in If the power mode does not change from VEHICLE (continuously variable transmission) and the power mode in ACCESSORY, the OFF to ACCESSORY, press the ENGINE START/STOP vehicle automatically goes into the mode similar to VEHICLE OFF (LOCK) to avoid...
Page 189 uuOperating the Switches Around the Steering WheeluENGINE START/STOP Button ■ 1Keyless Remote Reminder Keyless Remote Reminder When the keyless remote is within the system’s When the power mode is set to any mode operational range, and all the doors are closed, the other than OFF and you remove the keyless warning function cancels.
Page 190: Turn Signals
uuOperating the Switches Around the Steering WheeluTurn Signals Turn Signals The turn signals can be used when the power 1Turn Signals mode is in ON. The turn signal indicator on the instrument panel will blink when the external turn signal blinks. ■...
Page 191: Light Switches
uuOperating the Switches Around the Steering WheeluLight Switches Light Switches ■ 1Light Switches Manual Operation If you leave the power mode in VEHICLE OFF while Rotating the light switch turns the lights on High Beams the lights are on, a chime sounds when the driver’s and off, regardless of the power mode door is opened.
Page 192 uuOperating the Switches Around the Steering WheeluLight Switches ■ 1Automatic Operation (automatic lighting control) Automatic Operation (automatic lighting control) We recommend that you turn on the lights manually Automatic lighting control can be used when when driving at night, in a dense fog, or in dark areas the power mode is in ON.
Page 193 uuOperating the Switches Around the Steering WheeluLight Switches ■ 1Automatic Operation (automatic lighting control) Headlight Integration with Wipers U.S. models The headlights automatically come on when the wipers are used several times within You can adjust the auto light sensitivity as follow: a certain number of intervals with the headlight switch in AUTO.
Page 194: Fog Lights
uuOperating the Switches Around the Steering WheeluFog Lights Fog Lights When the low beam headlights are on, turn the fog light switch on to use the fog lights. Fog Light Switch Daytime Running Lights The parking/daytime running lights come on when the following conditions have been met: •...
Page 195: Auto High-Beam
uuOperating the Switches Around the Steering WheeluAuto High-Beam Auto High-Beam The front wide view camera detects the light sources ahead of the vehicle such as 1Auto High-Beam the lights of a preceding or oncoming vehicle, or street lights. When you are driving The auto high-beam system does not always operate at night, the system automatically switches the headlights between low beam and in every situation.
Page 196 uuOperating the Switches Around the Steering WheeluAuto High-Beam ■ Automatic switching between high-beam and low-beam 1How to Use the Auto High-Beam When auto high-beam is active, the headlights switch between high beam and low In the following cases, the auto high-beam system beam based on the following conditions.
Page 197 uuOperating the Switches Around the Steering WheeluAuto High-Beam ■ Manual switching between high-beam and low-beam 1How to Use the Auto High-Beam If you want to manually switch the headlights between high beam and low beam, How to turn off the Auto High-Beam System follow either of the procedures below.
Page 198: Wipers And Washers
uuOperating the Switches Around the Steering WheeluWipers and Washers Wipers and Washers ■ 1Wipers and Washers Windshield Wiper/Washer NOTICE The windshield wipers and washers can be Do not use the wipers when the windshield is dry. used when the power mode is in ON. The windshield will get scratched, or the rubber blades will get damaged.
Page 199 uuOperating the Switches Around the Steering WheeluWipers and Washers ■ 1Automatic Intermittent Wipers Automatic Intermittent Wipers The rainfall sensor is in the location shown below. When you push the lever down to AUTO, the windshield wipers sweep once, and go into Rainfall Sensor the automatic mode.
Page 200 uuOperating the Switches Around the Steering WheeluWipers and Washers ■ Rear Wiper/Washer The rear wiper and washer can be used when the power mode is in ON. ■ Wiper switch (OFF, INT, ON) Change the wiper switch setting according to the amount of rain.
Page 201: Rear Defogger/Heated Door Mirror * Button
uuOperating the Switches Around the Steering WheeluRear Defogger/Heated Door Mirror Button Rear Defogger/Heated Door Mirror Button Press the rear defogger and heated door mirror button to defog the rear window 1Rear Defogger/Heated Door Mirror Button and mirrors when the power mode is in ON. This system consumes a lot of power, so turn it off The rear defogger and heated door mirror when the window has been defogged.
Page 202: Models With A-Type Meter
uuOperating the Switches Around the Steering WheeluBrightness Control Models with A-type meter Brightness Control When the power mode is in ON, you can use 1Brightness Control the brightness control dial to adjust The brightness of the instrument panel will be instrument panel brightness.
Page 203: Models With B-Type Meter
uuOperating the Switches Around the Steering WheeluBrightness Control Models with B-type meter Brightness Control The brightness of the gauge is automatically 1Brightness Control adjusted depending on the ambient Several seconds after you have adjusted the brightness. brightness, you will be returned to the previous •...
Page 204: Adjusting The Steering Wheel
uuOperating the Switches Around the Steering WheeluAdjusting the Steering Wheel Adjusting the Steering Wheel The steering wheel height and distance from your body can be adjusted so that you 1Adjusting the Steering Wheel can comfortably grip the steering wheel in an appropriate driving posture. WARNING 1.
Page 205: Interior Rearview Mirror
Mirrors Interior Rearview Mirror Adjust the angle of the rearview mirror when you are sitting in the correct driving 1Mirrors position. Keep the inside and outside mirrors clean and adjusted for best visibility. ■ Rearview Mirror with Day and Night Positions Adjust the mirrors before you start driving.
Page 206: Power Door Mirrors
uuMirrorsuPower Door Mirrors Power Door Mirrors You can adjust the door mirrors when the power mode is in ON. ■ Mirror position adjustment L/R selector switch: Select the left or right mirror. After adjusting the mirror, return the switch to the center position. Selector Switch Adjustment...
Page 207: Seats
Seats Front Seats Adjust the driver’s seat as far back as possible 1Seats Allow sufficient while allowing you to maintain full control of space. Always make seat adjustments before driving. the vehicle. You should be able to sit upright, well back in the seat and be able to 1Front Seats adequately press the pedals without leaning WARNING...
Page 208 uuSeatsuFront Seats ■ Adjusting the front manual seats 1Adjusting the front manual seats Once a seat is adjusted correctly, rock it back and Height Adjustment forth to make sure it is locked in position. (Driver side only) Pull up or push down the lever to raise or lower the seat.
Page 209 uuSeatsuFront Seats ■ 1Adjusting the Seat-Backs Adjusting the Seat-Backs WARNING Adjust the driver’s seat-back to a comfortable, upright position, leaving ample space Reclining the seat-back too far can result in between your chest and the airbag cover in serious injury or death in a crash. the center of the steering wheel.
Page 210 uuSeatsuRear Seats Rear Seats ■ 1Folding Down the Rear Seats Folding Down the Rear Seats The rear seat-back(s) can be folded down to The rear seats can be folded down separately to allow for additional storage space. accommodate bulkier items in the cargo area. Pull the release lever and fold down the seat- Release Lever back.
Page 211 uuSeatsuRear Seats ■ 1Rear Seat Reminder Rear Seat Reminder When the power mode is set to VEHICLE OFF, the This feature alerts you to the possible presence of passengers or items in the rear reminder comes on briefly, then the function is seats before you exit the vehicle.
Page 212 uuSeatsuMaintain a Proper Sitting Position Maintain a Proper Sitting Position After all occupants have adjusted their seats and head restraints , and put on their 1Maintain a Proper Sitting Position seat belts, it is very important that they continue to sit upright, well back in their WARNING seats, with their feet on the floor, until the vehicle is safely parked and the engine is off.
Page 213 uuSeatsuHead Restraints Head Restraints Your vehicle is equipped with head restraints in all seating positions. ■ 1Adjusting the Front Head Restraints Positions Adjusting the Front Head Restraints Positions WARNING Head restraints are most effective for protection against whiplash and other rear- Improperly positioning head restraints impact crash injuries when the center of the reduces their effectiveness and increases...
Page 214 uuSeatsuHead Restraints ■ 1Removing and Reinstalling the Front Head Restraints Removing and Reinstalling the Front Head Restraints WARNING Head restraints can be removed for cleaning or repair. Failure to reinstall, or correctly reinstall, the To remove a head restraint: head restraints can result in severe injury Pull the restraint up as far as it will go.
Page 215 uuSeatsuArmrest Armrest ■ Using the Front Seat Armrest The console lid can be used as an armrest. ■ Using the Rear Seat Armrest Pull down the armrest in the center backrest. * Not available on all models...
Page 216: Interior Convenience Items
Interior Convenience Items Interior Lights ■ 1Interior Light Switches Interior Light Switches In the door activated position, the interior lights fade ■ Front out and go off about 30 seconds after the doors are The interior lights come on regardless of closed.
Page 217 uuInterior Convenience ItemsuInterior Lights ■ 1Map Light Switches Map Light Switches Models with moonroof The map lights can be turned on and off by When the front interior light switch is in the door pressing the switches. activated position and any door is open, the map light will not go off when you press the switches.
Page 218 uuInterior Convenience ItemsuStorage Items Storage Items ■ 1Glove Box Glove Box WARNING Pull the handle to open the glove box. An open glove box can cause serious injury to your passenger in a crash, even if the passenger is wearing the seat belt. Always keep the glove box closed while driving.
Page 219 uuInterior Convenience ItemsuStorage Items ■ Console Compartment Pull the handle to open the console compartment. Continuously variable transmission models ■ Removable tray The tray in the console compartment is detachable. To remove the tray, simply pull it...
Page 220 uuInterior Convenience ItemsuStorage Items ■ 1Beverage Holders Beverage Holders ■ NOTICE Front seat beverage holders Spilled liquids damage the upholstery, carpeting, and Are located in the console between the front electrical components in the interior. seats. Be careful when you are using the beverage holders. Hot liquid can scald you.
Page 221 uuInterior Convenience ItemsuStorage Items ■ Door beverage holders Front seat Are located on the both of front and rear door side pockets. Rear seat...
Page 222 uuInterior Convenience ItemsuStorage Items ■ 1Coat Hook Coat Hook The coat hook is not designed for large or heavy There is a coat hook on the rear left grab items. handle. ■ 1Sunglasses Holder Sunglasses Holder Keep the holder closed while driving except when To open the sunglasses holder, push and accessing stored items.
Page 223 uuInterior Convenience ItemsuStorage Items ■ 1Cargo Hook Cargo Hook NOTICE The cargo hook in the cargo area can be used Do not hang a large object or an object that weighs to hang a light items. more than 6 lbs (3 kg) on the cargo hook. Hanging heavy or large objects may damage the hook.
Page 224 uuInterior Convenience ItemsuStorage Items ■ 1Cargo Area Cover Cargo Area Cover Do not access parcels in the cargo area while driving. The cargo area cover can be used to cover the This may cause injury if you have to brake hard. Handle cargo space.
Page 225 uuInterior Convenience ItemsuStorage Items ■ To remove: Slide the lever on the cargo area cover case and remove it while pulling it toward you. Lever...
Page 226 uuInterior Convenience ItemsuOther Interior Convenience Items Other Interior Convenience Items ■ 1Accessory Power Socket Accessory Power Socket NOTICE The accessory power socket can be used when the power mode is in ACCESSORY or Do not insert an automotive type cigarette lighter element.
Page 227 uuInterior Convenience ItemsuOther Interior Convenience Items ■ 1Wireless Charger Wireless Charger RF Radiation Exposure Statement: To use the wireless charger, the power mode must be in ACCESSORY or ON. This equipment complies with FCC RF Radiation Charge any devices compatible with Qi wireless charging on the area indicated by exposure limits set forth for an uncontrolled mark as follows: environment.
Page 228 uuInterior Convenience ItemsuOther Interior Convenience Items ■ When charging does not start 1Wireless Charger Perform one of the solutions in the following table. CAUTION Indicator Cause Solution Metal objects between the charge pad and the device to be charged will get There is an obstacle(s) between Remove the hot and can burn you.
Page 229 uuInterior Convenience ItemsuOther Interior Convenience Items 1Wireless Charger The wireless charger can support up to 15 W, but the charging rate varies based on the device and other conditions. NOTICE Do not place any magnetic recording media or precision machines within the charging area while charging.
Page 230 uuInterior Convenience ItemsuOther Interior Convenience Items 1Wireless Charger During the charging phase, it is normal for the charging area and device to heat up. Charging may be briefly interrupted when: • All the doors and the hatch are closed - to avoid interference with the proper functioning of the keyless access system.
Page 231 uuInterior Convenience ItemsuOther Interior Convenience Items Canadian models ■ 1Heated Steering Wheel Heated Steering Wheel Do not use the heated steering wheel continuously The power mode must be in ON to use the when the engine is off. Under such conditions, the heated steering wheel.
Page 232 uuInterior Convenience ItemsuOther Interior Convenience Items ■ 1Front Seat Heaters Front Seat Heaters WARNING The seat heaters can be used when the power mode is in ON. Heat induced burns are possible when using seat heaters. Persons with a diminished ability to sense temperature (e.g., persons with diabetes, lower-limb nerve damage, or paralysis) or with sensitive skin should not use seat...
Page 233 uuInterior Convenience ItemsuOther Interior Convenience Items Canadian models 1Rear Seat Heaters ■ Rear Seat Heaters WARNING The seat heaters can be used when the power Heat induced burns are possible when mode is in ON. using seat heaters. There is no heater in the rear center seating Persons with a diminished ability to sense position.
Page 234: Climate Control System
Climate Control System Using Automatic Climate Control The automatic climate control system maintains the interior temperature you select. 1Using Automatic Climate Control The system also selects the proper mix of heated or cooled air that raises or lowers If any buttons are pressed while using the climate the interior temperature to your preference as quickly as possible.
Page 235 uuClimate Control SystemuUsing Automatic Climate Control 1Using Automatic Climate Control Models without SYNC button Pressing the button switches the climate control system between on and off. When turned on, the system returns to your last selection. Dashboard Dashboard Floor vents Floor and While ECON mode is active, the climate control vents...
Page 236 uuClimate Control SystemuUsing Automatic Climate Control ■ 1Defrosting the Windshield and Windows Defrosting the Windshield and Windows For your safety, make sure you have a clear view Pressing the (windshield defroster) button Models with SYNC button through all the windows before driving. turns the air conditioning system on and automatically switches the system to fresh air Do not set the temperature near the upper or lower...
Page 237 uuClimate Control SystemuUsing Automatic Climate Control ■ To rapidly defrost the windows 1To rapidly defrost the windows 1. Press the button. Models with SYNC button After defrosting the windows, switch over to fresh air 2. Press the button. mode. If you keep the system in recirculation mode, the windows may fog up from humidity.
Page 238 uuClimate Control SystemuUsing Automatic Climate Control ■ 1Synchronization Mode Synchronization Mode When the system is in dual mode, the driver’s side temperature and the passenger’s side temperature can be set separately. When you press the button, the system changes to synchronization mode. Driver’s Side Passenger’s Temperature...
Page 239: Automatic Climate Control Sensors
uuClimate Control SystemuAutomatic Climate Control Sensors Automatic Climate Control Sensors The automatic climate control system is Sensor equipped with sensors. Do not cover or spill any liquid on them. Sensor...
Page 240: Features
Features This chapter describes how to operate technology features. Audio System Refuel Recommend ......440 About Your Audio System....240 USB Port(s)........241 Audio System Theft Protection ..243 Audio Remote Controls....244 Audio System Basic Operation ..248, 273 Audio Error Messages ......
Page 241: Audio System
Audio System About Your Audio System The audio system features AM/FM radio and SiriusXM® Radio service . It can also 1About Your Audio System play USB flash drives, iPod, iPhone and Bluetooth® devices. SiriusXM® Radio is available on a subscription basis only.
Page 242: Usb Port(S)
uuAudio SystemuUSB Port(s) USB Port(s) ■ On the front panel ( 1USB Port(s) On the front panel The USB port (2.5A) is for charging devices, Models with 7-in. Color Touchscreen • Do not leave the iPod or USB flash drive in the playing audio files, and connecting vehicle.
Page 243 uuAudio SystemuUSB Port(s) ■ On the back of the console On the back of the console compartment compartment The USB ports (2.5A) are only for charging devices. You cannot play music even if you have connected music players to them. * Not available on all models...
Page 244: Audio System Theft Protection
uuAudio SystemuAudio System Theft Protection Audio System Theft Protection The audio system is disabled when it is disconnected from the power source, such as when the battery is disconnected or goes dead. In certain conditions, the system may display a code entry screen. If this occurs, reactivate the audio system. ■...
Page 245: Audio Remote Controls
uuAudio SystemuAudio Remote Controls Audio Remote Controls Models with 7-in. Color Touchscreen 1Audio Remote Controls Allow you to operate the audio system while driving. The information is shown on Some modes appear only when an appropriate the driver information interface. device or medium is used.
Page 246 uuAudio SystemuAudio Remote Controls Left Selector Wheel Roll up or down: To cycle through the audio modes, roll up or down and then press the left selector wheel: SiriusXM® Bluetooth® Audio Smartphone Connection (Apple CarPlay/Android Auto) Continued...
Page 247 uuAudio SystemuAudio Remote Controls Models with 9-in. Color Touchscreen Allow you to operate the audio system while driving. The information is shown on the driver information interface. + /VOL - (Volume) Switch (Seek/Skip) Buttons Press Up: To increase the volume. Press Down: To decrease the volume.
Page 248 uuAudio SystemuAudio Remote Controls Left Selector Wheel Roll up or down: To cycle through the modes, roll up or down and then press the left selector wheel: Back Phone SiriusXM® Bluetooth® Audio Apps (Apple CarPlay/Android Auto) Customize display...
Page 249: Audio System Basic Operation
Audio System Basic Operation Models with 7-in. Color Touchscreen 1Audio System Basic Operation To use the audio system, the power mode must be in ACCESSORY or ON. These indications are used to show how to operate Use the selector knob or MENU button to the selector knob.
Page 250 uuAudio System Basic OperationuAdjusting the Sound Adjusting the Sound 1. Select an audio source. 1Adjusting the Sound 2. Press the MENU button. The SVC adjusts the volume level based on the 3. Select Sound Settings. vehicle speed. As you go faster, audio volume increases.
Page 251 uuAudio System Basic OperationuDisplay Setup Display Setup You can set the screen brightness separately for Day and Night modes. ■ 1Changing the Screen Brightness Changing the Screen Brightness You can change the Contrast and Black Level 1. Press the MENU button. settings in the same manner.
Page 252 uuAudio System Basic OperationuPlaying AM/FM Radio Playing AM/FM Radio Audio/Information Screen VOL/ AUDIO (Volume/Power) Knob Selector Knob Press to turn the audio system on and Turn to tune the radio frequency. off. Press, and then turn to select an item. Turn to adjust the volume.
Page 253 uuAudio System Basic OperationuPlaying AM/FM Radio ■ 1Playing AM/FM Radio Radio Data System (RDS) Stereo reproduction in AM is not available. Provides text data information related to your selected RDS capable FM station. You can store 12 AM stations and 12 FM stations into ■...
Page 254 uuAudio System Basic OperationuPlaying an iPod Playing an iPod Using your USB connector, connect the iPod to the USB port, then select the USB mode. 2 USB Port(s) P. 241 Audio/Information Screen Album Art USB Indicator Appears when an iPod is connected. VOL/ AUDIO (Volume/Power) Knob Selector Knob...
Page 255 uuAudio System Basic OperationuPlaying an iPod ■ 1Playing an iPod How to Select a Song from the iPod Music List Available operating functions vary on models or 1. Press to display the iPod music list. versions. Some functions may not be available on the vehicle’s audio system.
Page 256 uuAudio System Basic OperationuPlaying an iPod ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select repeat and shuffle modes when playing a song. Shuffle ■ Shuffle/Repeat Shuffle off: Shuffle mode to off. Select shuffle or repeat icon repeatedly until a Shuffle All Songs: Plays all available songs in desired mode.
Page 257 uuAudio System Basic OperationuPlaying a USB Flash Drive Playing a USB Flash Drive Your audio system reads and plays sound files on a USB flash drive in either MP3, WMA, AAC , FLAC, or WAV format. Connect your USB flash drive to the USB port, then press the MEDIA button. 2 USB Port(s) P.
Page 258 uuAudio System Basic OperationuPlaying a USB Flash Drive ■ 1Playing a USB Flash Drive How to Select a File from a Folder Use the recommended USB flash drives. 1. Press to display a folder list. 2 General Information on the Audio System P.
Page 259 uuAudio System Basic OperationuPlaying a USB Flash Drive ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select repeat and random modes when playing a file. Random ■ Random/Repeat Random All Tracks: Plays all files in random Select random or repeat icon.
Page 260 This function is available when the phone is paired and connected to the vehicle’s audio capabilities are compatible with the system. For a list of compatible phones: Bluetooth® HandsFreeLink® (HFL) system. • U.S.: Visit automobiles.honda.com/handsfreelink/, 2 Phone Setup P. 406 or call 1-888-528-7876. • Canada: For more information on smartphone...
Page 261 uuAudio System Basic OperationuPlaying Bluetooth® Audio ■ 1To Play Bluetooth® Audio Files To Play Bluetooth® Audio Files To play the audio files, you may need to operate your 1. Make sure that your phone is paired and phone. If so, follow the phone maker's operating connected to HFL.
Page 262 uuAudio System Basic OperationuPlaying Bluetooth® Audio ■ 1How to Select a Song from the Music Search List How to Select a Song from the Music Search List Depending on the Bluetooth® device you connect, 1. Press to display the music search list. some or all of the categories may not be displayed.
Page 263 uuAudio System Basic OperationuPlaying Bluetooth® Audio ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select repeat and shuffle modes when playing a song. Shuffle ■ Shuffle/Repeat Shuffle off: Shuffle mode to off. Select shuffle or repeat icon repeatedly until a Shuffle Albums: Plays all available albums in desired mode.
Page 264 uuAudio System Basic OperationuSiri Eyes Free Siri Eyes Free You can talk to Siri using the (Talk) button on the steering wheel when your 1Siri Eyes Free iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system. Siri is a trademark of Apple Inc. 2 Phone Setup P.
Page 265 uuAudio System Basic OperationuSmartphone Voice Recognition Smartphone Voice Recognition You can use Smartphone Voice Recognition using the (Talk) button on the steering wheel when your Android phone is paired to the Bluetooth® HandsFreeLink® (HFL) system. 2 Phone Setup P. 406 ■...
Page 266 uuAudio System Basic OperationuApple CarPlay Apple CarPlay If you connect an Apple CarPlay-compatible iPhone to the system via the front USB, 1Apple CarPlay you can use the audio/information screen, instead of the iPhone display, to make a Only iPhone 5 or newer versions with iOS 8.4 or later phone call, listen to music, view maps (navigation), and access messages.
Page 267 Apple CarPlay functionality and services. Display Apple Maps and use the navigation function just as you would on your Honda cannot and does not provide any warranty or iPhone. guarantee of future Apple CarPlay performance or functionality.
Page 268 uuAudio System Basic OperationuApple CarPlay ■ 1Setting Up Apple CarPlay Setting Up Apple CarPlay Only initialize Apple CarPlay when you are safely After you have connected your iPhone to the system via the front USB, use the parked. following procedure to set up Apple CarPlay. Use of Apple CarPlay will result in the When Apple CarPlay first detects your iPhone, you transmission of certain user and vehicle information (such as vehicle location, speed, will need to set up your iPhone.
Page 269 uuAudio System Basic OperationuApple CarPlay ■ 1Operating Apple CarPlay with Siri Operating Apple CarPlay with Siri Below are examples of questions and commands for Press the talk button to activate Siri. Siri. • What movies are playing today? • Call dad at work. •...
Page 270 uuAudio System Basic OperationuAndroid Auto Android Auto When you connect an Android phone to the audio system via the USB port, Android 1Android Auto Auto is automatically initiated. When connected via Android Auto, you can use the We recommend that you update Android OS to the audio/information screen to access the Phone, Google Maps (Navigation), and latest version when using Android Auto.
Page 271 Android Auto functionality and services. Go back to the Android CONNECT Button Honda cannot and does not provide any warranty or Auto menu screen Press to display Android Auto screen guarantee of future Android Auto performance or functionality.
Page 272 uuAudio System Basic OperationuAndroid Auto • You can check Android notifications. • (Android Auto Home) Display useful information organized by Android Auto into simple cards that appear just when they’re needed. ■ Auto Pairing Connection When you connect an Android phone to the unit via the USB port, Android Auto is automatically initiated.
Page 273 (talk) button to operate Android Auto with your voice. voice recognition: • Reply to text. • Call my wife. • Navigate to Honda. • Play my music. • Send a text message to my wife. • Call flower shop. For more information, please refer to the Android Auto homepage.
Page 274 Audio System Basic Operation Models with 9-in. Color Touchscreen To use the audio system function, the power mode must be in ACCESSORY or ON. (Home) button: Press to go to the home (Back) Button screen. (Home) Button 2 Using the audio/information screen P.
Page 275 1. Make sure your phone is in search or discoverable mode. 2. Select Honda CIVIC from your phone. If you want to pair a phone from this 9-in. Color Touchscreen, select Search for Devices, and then select your phone...
Page 276 uuAudio System Basic OperationuAudio/Information Screen Audio/Information Screen Displays the audio status and wallpaper. From this display, you can go to various setup options. ■ Switching the Display ■ Using the audio/information screen 1Using the audio/information screen Touchscreen operation Home Screen Button •...
Page 277 uuAudio System Basic OperationuAudio/Information Screen ■ General Settings Enters the customizing menu screen. 2 Customized Features P. 374 ■ Navigation Displays the navigation screen. 2 Refer to the Navigation System Manual ■ HondaLink® Displays the HondaLink screen. 2 HondaLink® P. 321 ■...
Page 278 uuAudio System Basic OperationuAudio/Information Screen ■ Trip Computer Displays the trip computer information. • Current Drive tab: Displays the current trip information. • Trip A/Trip B tab: Displays information for the current and three previous drives. The information is stored every time you reset Trip A/B. To reset the Trip A/B, select Settings, then select Delete Trip History.
Page 279 uuAudio System Basic OperationuAudio/Information Screen ■ 1Wallpaper Setup Wallpaper Setup The wallpaper you set up on Clock Faces cannot be You can change, store, and delete the wallpaper on the audio/information screen. displayed on the driver information interface. • When importing wallpaper files, the image must be ■...
Page 280 uuAudio System Basic OperationuAudio/Information Screen ■ Select wallpaper 1Wallpaper Setup 1. Press the button. You cannot delete the initial imported wallpapers. 2. Select Clock. 3. Select Settings. 4. Select Clock Faces. 5. Select a desired picture to set. The preview is displayed on the screen. 6.
Page 281 uuAudio System Basic OperationuAudio/Information Screen ■ 1Home Screen Home Screen The home screen has 3 pages. You can add up to 6 ■ To move to the next screen pages. Press the button to go directly back to the first page of the home screen from any page.
Page 282 uuAudio System Basic OperationuAudio/Information Screen ■ To add app icons on the home screen 1To add app icons on the home screen App icons can be added on the home screen. Pre-installed apps may not start up normally. If this 1.
Page 283 uuAudio System Basic OperationuAudio/Information Screen ■ To move icons on the home screen 1To move icons on the home screen You can change location on the home screen. Select Tips to show tips. To hide them, select it again. 1. Press the button.
Page 284 uuAudio System Basic OperationuAudio/Information Screen ■ To remove icons on the home screen 1To remove icons on the home screen You can delete the icons on the home screen. You cannot delete the All Apps icon. 1. Press the button. 2.
Page 285 uuAudio System Basic OperationuAudio/Information Screen ■ To shortcut icons on the home screen 1To shortcut icons on the home screen You can store up to six icons on the bottom of the home screen. Select Tips to show tips. To hide them, select it again. 1.
Page 286 uuAudio System Basic OperationuAudio/Information Screen ■ Status Area 1. Select the system status icon. The status area appears. 2. Select an item to see the details. 3. Press the button or select the system status icon to close the area. System Status Icon Status Area...
Page 287 uuAudio System Basic OperationuSystem Updates System Updates The audio system’s firmware can be updated with a Wi-Fi connection, or with a USB device. ■ 1How to Update How to Update You can update the system via Wi-Fi, but cannot use When the audio system update is available, the notification is shown on the status the captive portal that require login or agreement the area.
Page 288 uuAudio System Basic OperationuSystem Updates ■ System Updates Settings The following settings can be set. • Auto Download • Version Status • Connection Setup • Automatic Update • Update History ■ Automatic download settings Use the following procedure to change to the automatic download setting. 1.
Page 289 uuAudio System Basic OperationuSystem Updates ■ Connection setup Use the following procedure to connect to the Internet via a Wi-Fi network. 1. Press the button. 2. Select System Updates. If System Updates is not displayed on the home screen, select All Apps.
Page 290 uuAudio System Basic OperationuSystem Updates ■ How to Update Wirelessly ■ Wireless connection mode setup 1. Press the button. 2. Select System Updates. If System Updates is not displayed on the home screen, select All Apps. 3. Select Settings. 4. Select Connection Setup. 5.
Page 291 6. Remove the USB device from the USB port. 7. Connect the USB device into your computer, and then download the update files. Follow the link to download the required software update files. Refer to https://usb.honda.com for instructions. ■ Update the audio system 1.
Page 292 uuAudio System Basic OperationuAdjusting the Sound Adjusting the Sound 1. Press the button. 1Adjusting the Sound 2. Select an audio source icon. The Bose Dynamic Speed Compensation adjusts 3. Select Sound. the volume level based on the vehicle speed. As you go faster, audio volume increases.
Page 293 uuAudio System Basic OperationuDisplay Setup Display Setup You can set the screen brightness. 1Display Setup You can adjust the screen brightness by sliding or ■ Switching Display Mode Manually tapping on the brightness bar. Select Display Mode. You can also change the screen brightness on the The brightness bar is displayed for a few following procedures.
Page 294 uuAudio System Basic OperationuDisplay Setup ■ Selecting an Audio Source Select Audio Source Source Select Screen Source List Icons Select Audio Source on the header area, then select an icon on the source list to switch the audio source. ■ Limitations for Manual Operation Certain manual functions are disabled or inoperable while the vehicle is in motion.
Page 295 uuAudio System Basic OperationuVoice Control Operation Voice Control Operation Your vehicle has a voice control system that allows hands-free operation. 1Voice Control Operation The voice control system uses the (Talk) button on the steering wheel and a When you press the button, a helpful prompt asks microphone near the map lights on the ceiling.
Page 296 uuAudio System Basic OperationuVoice Control Operation ■ ■ You can change the mode on the General Phone Commands Voice Portal Screen Settings screen. • Call <name> 2 Voice Control P. 385 • Call <number> The system recognizes an only contact The system only recognizes the commands name in the stored phonebook of your on the following pages, at certain screens.
Page 297 uuAudio System Basic OperationuVoice Control Operation ■ ■ iPod Commands Navigation Commands • List Album <name> The screen changes to the navigation • List Artist <name> screen. • List Genre <name> 2 Refer to the Navigation System Manual • List Playlist <name> •...
Page 298 uuAudio System Basic OperationuPlaying AM/FM Radio Playing AM/FM Radio Audio/Information Screen Settings Icon Select whether to tune to HD (Back) Button Radio automatically. Press to go back to the previous display. Preset Icons Tune the radio frequency for preset memory. VOL/ AUDIO (Volume/Power) Knob Select and hold the preset icon to...
Page 299 uuAudio System Basic OperationuPlaying AM/FM Radio ■ 1Preset Memory Preset Memory The ST indicator appears on the display indicating To store a station: stereo FM broadcasts. 1. Tune to the selected station. Stereo reproduction in AM is not available. 2. Select and hold the preset icon to store that station. Selecting Press &...
Page 300 uuAudio System Basic OperationuPlaying AM/FM Radio ■ Scan Samples each of the strongest stations on the selected band for 10 seconds. To turn off scan, select Stop or press the button. ■ HD Subchannel Displays the subchannel list when an HD Radio station is selected while listening to an FM station.
Page 301 uuAudio System Basic OperationuPlaying AM/FM Radio ■ AM/FM Settings Change the AM/FM settings. 1. Select Settings. 2. Select an option. • HD Radio: Automatically choose a digital or an analog channel, or listen to analog only. • Artwork: Turns the artwork display on and off.
Page 302 uuAudio System Basic OperationuPlaying SiriusXM® Radio Playing SiriusXM® Radio Album Art Audio/Information Screen Settings Icon Select settings to display and (Back) Button customize SiriusXM® settings. Press to go back to the previous display. Preset Icons Tune the radio frequency for preset memory.
Page 303 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Playing SiriusXM® Radio To Change the Tune Mode In the channel mode, all available channels are 1. Select Settings. selectable. In the category mode, you can select a 2. Select Tune Mode. channel within a category (Jazz, Rock, Classical, etc.). 3.
Page 304 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Playing SiriusXM® Radio Preset Memory You can store 12 SiriusXM® channels into the preset To store a channel: memory. 1. Tune to the selected channel. 2. Select and hold the preset icon to store that channel. Selecting Press &...
Page 305 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Listening to Featured Channels Listening to Featured Channels Up to 10 featured channels by SiriusXM® can be Suggested channel listing received from SiriusXM® can be displayed and selected. displayed. 1. Select More. 2. Select Category List. To switch the sorting method, select Number or 3.
Page 306 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Replay Function Replay Function The system starts storing broadcast in memory when The system can record up to the last 60 minutes of your currently tuned channel’s the power mode is turned ON. You can go back to broadcast, as well as the last 30 minutes of your preset channel’s broadcast, starting the program from that point.
Page 307 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Live Sports Alert Live Sports Alert The Pop-up appears and notifies you of a sports alert While listening to other channels, you can receive sports alerts such as scores from function. the games of your favorite teams. ■...
Page 308 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Traffic and Weather Information Traffic and Weather Information When traffic and weather information is received, a You can receive traffic and weather information. notification is displayed in the header area. 2 Status Area P. 285 ■...
Page 309 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Channel Schedule Channel Schedule Select Keypad to use the on-screen keyboard for You can view a channel schedule or receive an alert when your favorite program is entering the channel number directly. about to start. ■...
Page 310 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ Manage Program Alert You can change settings for the alert function. ■ To enable the alert function 1. Select Settings. 2. Select Manage Program Alerts. 3. Select Notifications. 4. Select ON or OFF. ■...
Page 311 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ 1Scan Scan The “Scan Songs in Presets” function is based on Sample each channel on the selected mode for 10 seconds. TuneScan technology of SiriusXM®. 1. Select More. 2. Select Scan. The “Featured Channels” function is based on Featured Favorites technology of SiriusXM®.
Page 312 uuAudio System Basic OperationuPlaying SiriusXM® Radio ■ SiriusXM® Settings Change the SiriusXM® settings. 1. Select Settings. 2. Select an option. • TuneMix: Turns multiple channel mix preset on and off. • Tune Mode: Choose whether to group by category or channel number when changing channels.
Page 313 uuAudio System Basic OperationuPlaying an iPod Playing an iPod Using your USB connector, connect the iPod to the USB port, then select the USB mode. 2 USB Port(s) P. 241 Cover Art Audio/Information Screen (Back) Button Press to go back to the previous display. Shuffle Icon Select to play all files in the current VOL/...
Page 314 uuAudio System Basic OperationuPlaying an iPod ■ 1Playing an iPod How to Select a Song from the Music Search List Available operating functions vary on models or 1. Select Browse. versions. Some functions may not be available on the 2. Select a search category (e.g., Artists, vehicle’s audio system.
Page 315 uuAudio System Basic OperationuPlaying an iPod ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select shuffle and repeat modes when playing a file. Shuffle ■ Shuffle/Repeat Shuffle off: Shuffle mode to off. Select shuffle or repeat icon repeatedly until a Shuffle All Songs: Plays all available songs in a selected list (playlists, artists, albums, songs, genres,...
Page 316 uuAudio System Basic OperationuPlaying a USB Flash Drive Playing a USB Flash Drive Your audio system reads and plays sound files on a USB flash drive in either MP3, WMA, AAC , FLAC, or WAV format. Connect your USB flash drive to the USB port, then select the USB mode. 2 USB Port(s) P.
Page 317 uuAudio System Basic OperationuPlaying a USB Flash Drive ■ 1Playing a USB Flash Drive How to Select a File from the Music Search List Use the recommended USB flash drives. 1. Select Browse. 2 General Information on the Audio System 2.
Page 318 uuAudio System Basic OperationuPlaying a USB Flash Drive ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select repeat, and random modes when playing a file. Random ■ Random/Repeat Random off: Random mode to off. Select random or repeat icon repeatedly until Random All Tracks: Plays all files in random order.
Page 319 This function is available when the phone is paired and connected to the vehicle’s For a list of compatible phones: Bluetooth® HandsFreeLink® (HFL) system. • U.S.: Visit automobiles.honda.com/handsfreelink/, 2 Phone Setup P. 426 or call 1-888-528-7876. • Canada: For more information on smartphone compatibility, call 1-855-490-7351.
Page 320 uuAudio System Basic OperationuPlaying Bluetooth® Audio ■ 1To Play Bluetooth® Audio Files To Play Bluetooth® Audio Files To play the audio files, you may need to operate your 1. Make sure that your phone is paired and phone. If so, follow the phone maker’s operating connected to the system.
Page 321 uuAudio System Basic OperationuPlaying Bluetooth® Audio ■ 1How to Select a Play Mode How to Select a Play Mode Play Mode Menu Items You can select shuffle and repeat modes when playing a file. Shuffle ■ Shuffle/Repeat Shuffle off: Shuffle mode to off. Select shuffle or repeat icon repeatedly until a Shuffle All Songs: Plays all available songs in a selected list in random order.
Page 322 System Basic OperationuHondaLink® HondaLink® HondaLink® connects you to the latest information from Honda. You can connect 1HondaLink® your phone wirelessly through Wi-Fi or Bluetooth®. The HondaLink® connect app is compatible with most 2 Wi-Fi Connection P. 328 iPhone and Android phones.
Page 323 uuAudio System Basic OperationuHondaLink® ■ To Set Up to Connect HondaLink® Service Use the following procedure to connect to HondaLink® service. ■ To enable the HondaLink® service 1. Press the button. 2. Select General Settings. 3. Select System. 4. Select Data Sharing Setting. 5.
Page 324 System Basic OperationuHondaLink® ■ Vehicle Information and Message from Honda Tips You can check the messages that are received quickly in the shortcut operation. 1. A notification appears and notifies you of a new message on the header area.
Page 325 uuAudio System Basic OperationuHondaLink® 3. Select the system status icon to see the messages. 4. Select a new message to open.
Page 326 uuAudio System Basic OperationuSmart Shortcuts Smart Shortcuts By observing and learning driver behaviors, patterns, and preferences, the system 1Smart Shortcuts anticipates driver actions and presents on-screen suggestions to help perform The app also supports different profiles for each user, desired actions quicker and with fewer steps. with customized learning for each profile.
Page 327 uuAudio System Basic OperationuSmart Shortcuts ■ 1How to Use How to Use You can change the profile by selecting on the 1. Press the button. top of the Smart Shortcuts screen. 2. Select Smart Shortcuts. 3. Select a shortcut to take the action You can customize the following items by selecting suggested.
Page 328 uuAudio System Basic OperationuSmart Shortcuts • Radio Suggestions: When selected, the corresponding radio app (FM, AM, or SiriusXM®) will open and it will start playing the station. From radio apps you can receive: - FM, AM, SiriusXM®: Most frequently listened stations you may like to play next.
Page 329 uuAudio System Basic OperationuWi-Fi Connection Wi-Fi Connection This vehicle is equipped with Wi-Fi connectivity. You can connect to an external 1Wi-Fi Connection Wi-Fi hotspot or communication device. Wi-Fi and Wi-Fi Direct are registered trademarks of Wi-Fi Alliance®. ■ 1Connect the vehicle to a Wi-Fi hotspot Connect the vehicle to a Wi-Fi hotspot You cannot go through the setting procedure while 1.
Page 330 uuAudio System Basic OperationuWi-Fi Connection If you want to turn off the Wi-Fi mode, select OFF. 8. Select the access point you want to connect to the system. To add a new network or select the saved networks, select Options. If Options is selected, Add Network and Saved Networks can be registered.
Page 331 uuAudio System Basic OperationuApple CarPlay Apple CarPlay If you connect an Apple CarPlay-compatible iPhone to the system via the 2.5A USB 1Apple CarPlay port or wirelessly, you can use the audio/information screen, instead of the iPhone We recommend that you update iOS to the latest display, to make a phone call, listen to music, view maps (navigation), and access version when using Apple CarPlay.
Page 332 Apple CarPlay functionality and services. Display Apple Maps and use the navigation function just as you would on your Honda cannot and does not provide any warranty or iPhone. guarantee of future Apple CarPlay performance or functionality.
Page 333 uuAudio System Basic OperationuApple CarPlay ■ 1Setting Up Apple CarPlay Setting Up Apple CarPlay Only initialize Apple CarPlay when you are safely After you have connected your iPhone to the system via the 2.5A USB port or parked. wirelessly, use the following procedure to set up Apple CarPlay. Use of Apple When Apple CarPlay first detects your iPhone, you CarPlay will result in the transmission of certain user and vehicle information (such will need to set up your iPhone.
Page 334 uuAudio System Basic OperationuApple CarPlay ■ Connect Apple CarPlay Wirelessly ■ Connect Apple CarPlay wirelessly on the home screen 1. Press the button. 2. Select Smartphone Connection. 3. Select + Connect New Device. 4. Pair the iPhone to the vehicle’s Bluetooth® HandsFreeLink® (HFL) system. 2 Phone Setup P.
Page 335 uuAudio System Basic OperationuApple CarPlay ■ Connect Apple CarPlay wirelessly on the Bluetooth® device list 1. Press the button. 2. Select General Settings. 3. Select Connections. 4. Select Bluetooth. 5. Select + Connect New Device. 6. Pair the iPhone to the vehicle’s Bluetooth® HandsFreeLink® (HFL) system. 2 Phone Setup P.
Page 336 uuAudio System Basic OperationuApple CarPlay ■ Connect Apple CarPlay wirelessly at start-up (when there is no phone paired to the system) 1. Set the power mode to ACCESSORY or ON. 2. Select OK. If there is no registered device, the Bluetooth® pairing screen will be displayed. If you check the box with Do not show this again, this screen will not be displayed.
Page 337 uuAudio System Basic OperationuApple CarPlay ■ 1Operating Apple CarPlay with Siri Operating Apple CarPlay with Siri Below are examples of questions and commands for Press and hold the talk button to activate Siri. Siri. • What movies are playing today? •...
Page 338 uuAudio System Basic OperationuAndroid Auto Android Auto When you connect an Android phone to the audio system via the USB port or 1Android Auto wirelessly, Android Auto is automatically initiated. When connected via Android We recommend that you update Android OS to the Auto, you can use the audio/information screen to access the Phone, Google Maps latest version when using Android Auto.
Page 339 Android Auto is automatically initiated. cessation of Android Auto functionality and services. Honda cannot and does not provide any warranty or guarantee of future Android Auto performance or functionality. It is possible to use 3rd party apps if they are compatible with Android Auto.
Page 340 uuAudio System Basic OperationuAndroid Auto ■ 1Connecting Android Auto Using the USB Cable to the USB Port Connecting Android Auto Using the USB Cable to the USB Port Only initialize Android Auto when you are safely 1. Connect the Android phone to the USB port using the USB cable. parked.
Page 341 uuAudio System Basic OperationuAndroid Auto ■ Connect Android Auto wirelessly on the Android Auto device list 1. Press the button. 2. Select General Settings. 3. Select Smartphone Connection. 4. Select Android Auto. 5. Select + Connect New Device. 6. Pair the Android phone to the vehicle’s Bluetooth® HandsFreeLink® (HFL) system. 2 Phone Setup P.
Page 342 uuAudio System Basic OperationuAndroid Auto ■ Connect Android Auto wirelessly with the steering wheel 1. Press and hold the (talk) button on the steering wheel. 2. Pair the Android phone to the vehicle’s Bluetooth® HandsFreeLink® (HFL) system. 2 Phone Setup P. 426 3.
Page 343 (talk) button to operate Android Auto with your voice. voice recognition: • Reply to text. • Call my wife. • Navigate to Honda. • Play my music. • Send a text message to my wife. • Call flower shop. For more information, please refer to the Android Auto homepage.
Page 344: Audio Error Messages
Audio Error Messages iPod/USB Flash Drive If an error occurs while playing an iPod or USB flash drive, you may see the following error messages. If you cannot clear the error message, contact a dealer. Error Message Solution Appears when an incompatible device is connected. Disconnect the device. Then, turn Bad USB Device the audio system off and turn it on again.
Page 345 uuAudio Error MessagesuiPod/USB Flash Drive Error Message Solution Appears when the system does not communicate with a connected device. If it appears Device No Response *1, *2 when a device is connected, contact your place of device purchase. Appears when only a HUB is connected. If it appears, connect a USB flash drive to the USB hub not supported *1, *2 HUB.
Page 346: General Information On The Audio System
General Information on the Audio System SiriusXM® Radio Service ■ 1Subscribing to SiriusXM® Radio Subscribing to SiriusXM® Radio Contact Information for SiriusXM® Radio: 1. You need your radio ID ready before registering for subscription. To see the ID on • U.S.: SiriusXM®...
Page 347 uuGeneral Information on the Audio SystemuCompatible iPod, iPhone, and USB Flash Drives Compatible iPod, iPhone, and USB Flash Drives ■ 1iPod and iPhone Model Compatibility iPod and iPhone Model Compatibility This system may not work with all software versions Models with 7-in. Color Touchscreen of these devices.
Page 348 1. SOFTWARE. This AGREEMENT grants you a non-exclusive, limited, and revocable license to use the SOFTWARE and SERVICES solely (a) as installed on your VEHICLE by HONDA, (b) as updated on your Vehicle by HONDA, you (but only as and when directed by HONDA), or a DEALER and (c) as permitted under the terms of this AGREEMENT.
Page 349 To the extent such software is provided under terms that differ from the applicable free or open-source licenses, those terms are offered by HONDA alone.
Page 350 SOFTWARE or SERVICES or any of the content or other material within the SOFTWARE or SERVICES, including without limitation, HONDA or PROVIDER names, logos, or any other trademarks of HONDA or PROVIDERS or used in association with the SOFTWARE or any SERVICES, except as required to use the SOFTWARE or SERVICES in accordance with this AGREEMENT, any applicable PROVIDER TERMS, and the DOCUMENTATION;...
Page 351 C. SOFTWARE Operation 1. HONDA reserves the right to suspend or terminate your access to and use of the SOFTWARE or SERVICES if you are found to be in violation of this AGREEMENT or as reasonably deemed necessary by HONDA.
Page 352 6. SOFTWARE Updates. The SOFTWARE and SERVICES may be updated when your VEHICLE is serviced by a DEALER or remotely, over-the- air, by HONDA from time to time; such updates may occur with or without further notice or your future consent. The SOFTWARE may be updated at HONDA’s discretion and for any purpose including, without limitation, to patch or otherwise improve the SOFTWARE or...
Page 353 It is your responsibility to monitor any speech recognition functions included in the system and address any errors. Neither HONDA nor PROVIDERS will be liable for any damages arising out of errors in the speech recognition process.
Page 354 (c) You understand that the inputting or uploading of information to your VEHICLE’s multimedia system or the SOFTWARE or SERVICES is at your own risk and that HONDA is not responsible for unauthorized access to or use of any personal or other information. All information uploaded to the SOFTWARE and SERVICES may be stored on your VEHICLES’s multimedia system and you understand that the security and...
Page 355 Any decision or action taken by you on the basis of information or content provided via the application is at your sole discretion and risk. HONDA and PROVIDERS are not responsible or liable for any such decision, or for the accuracy, completeness, usefulness, or availability of any content or information displayed, transmitted, or otherwise made available via the SOFTWARE or SERVICES.
Page 356 If HONDA or PROVIDERS are found liable to you for any reason, you agree that the aggregate liability of all these parties to you for any claim is limited to ten U.S.
Page 357 Vehicle, required for data transmission or receipt. HONDA does not guarantee that the SOFTWARE, SERVICES, or any portion thereof will be available at all times or in all areas. You acknowledge and agree that HONDA is not responsible for performance degradation, interruption or delays.
Page 358 SOFTWARE or SERVICES (or any portion thereof), with or without notice to you, and you agree that HONDA shall not be liable to you or to any third party for any modification, suspension or discontinuance of the SOFTWARE or SERVICES.
Page 359 If unenforceability allows arbitration as a class action, then this provision is entirely unenforceable. YOU may opt out within 30 days of your initial use of the Software by sending a signed, written notice to HONDA at Honda Financial Services, P.O.
Page 360 uuGeneral Information on the Audio SystemuLegal Information on Apple CarPlay/Android Auto Legal Information on Apple CarPlay/Android Auto ■ OWNER’S MANUAL LICENSE/LIABILITY STATEMENTS USE OF APPLE CARPLAY IS SUBJECT TO YOUR AGREEMENT TO THE CARPLAY TERMS OF USE, WHICH ARE INCLUDED AS PART OF THE APPLE iOS TERMS OF USE.
Page 361 TECHNOLOGY OR GOVERNMENT REGULATION MAY RENDER THE SERVICES AND/OR APPLICATIONS OBSOLETE AND/OR UNUSABLE. TO THE EXTENT NOT PROHIBITED BY LAW, IN NO EVENT SHALL HONDA OR ITS AFFILIATES BE LIABLE FOR PERSONAL INJURY, OR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING, WITHOUT LIMITATION, DAMAGES FOR...
Page 362 uuGeneral Information on the Audio SystemuAbout Open Source Licenses About Open Source Licenses To see the open source license information, follow these steps. 1About Open Source Licenses Models with 7-in. Color Touchscreen Models with 7-in. Color Touchscreen LICENSE: Copyright © 2001 Bob Trower, Trantor 1.
Page 363 uuGeneral Information on the Audio SystemuLicense Information License Information ■ Bluetooth The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by PANASONIC CORPORATION is under license. Other trademarks and trade names are those of their respective owners. The Bluetooth®...
Page 364 uuGeneral Information on the Audio SystemuLicense Information ■ Apple “Made for iPod,” and “Made for iPhone,” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.
Page 365 uuGeneral Information on the Audio SystemuLicense Information ■ MPEG Mpeg4 Visual THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUALA STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO...
Page 366 uuGeneral Information on the Audio SystemuLicense Information AVC/H.264 THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO.
Page 367: Customized Features
Customized Features Models with 7-in. Color Touchscreen 1Customized Features Use the audio/information screen to customize certain features. When you customize settings: • Make sure that the vehicle is at a complete stop. ■ How to Customize the Settings Continuously variable transmission models •...
Page 368 uuCustomized Featuresu ■ Customization Flow Press the MENU button. Bass / Treble Sound Settings Balance / Fader Speed Volume Compensation Bluetooth Settings Connect New Device Change Device Priority Device Disconnect All Device Delete Device Clock Settings Automatic Time Daylight Saving Time Set Time Time Zone Smartphone Settings...
Page 369 uuCustomized Featuresu RDS Settings RDS Information Display Adjustment Brightness Contrast Black Level Night Display OFF Touch Panel Sensitivity Rear Camera Setting Fixed Guideline Dynamic Guideline Language License Factory Data Reset...
Page 370 uuCustomized Featuresu Press the PHONE button and select Settings. Bluetooth Settings Connect New Device Change Device Priority Device Disconnect All Device Delete Device Ringtone Phone Vehicle Auto Phone Call Transfer Hands-Free System Clear Continued...
Page 371 uuCustomized Featuresu ■ List of customizable options Press the MENU button. Customizable Features Description Selectable Settings Bass / Treble Adjusts the settings of the audio speakers’ Balance / Fader Sound Settings — sound. Speed Volume 2 Adjusting the Sound P. 249 Compensation Pairs a new phone to HFL.
Page 372 uuCustomized Featuresu Customizable Features Description Selectable Settings Changes the brightness of the audio/ Brightness information screen. Changes the contrast of the audio/ Contrast information screen. Display Adjustment Changes the black level of the audio/ — Black Level information screen. Changes between the daytime mode, Night nighttime mode and display off mode.
Page 373 uuCustomized Featuresu Press the PHONE button and select Settings. Customizable Features Description Selectable Settings Pairs a new phone to HFL. Connect New Device — 2 Phone Setup P. 406 Connects a paired phone. Change Device — 2 Phone Setup P. 406 Bluetooth Settings Priority Device Sets a device as the priority device.
Page 374 uuCustomized FeaturesuDefaulting All the Settings Defaulting All the Settings Reset all the menu and customized settings as the factory defaults. 1Defaulting All the Settings 1. Press the MENU button. When you transfer the vehicle to a third party, reset 2. Select Factory Data Reset. all settings to default and delete all personal data.
Page 375 Customized Features Models with 9-in. Color Touchscreen 1Customized Features Use the audio/information screen to customize certain features. When you customize settings: • Make sure that the vehicle is at a complete stop. ■ How to Customize the General Settings Continuously variable transmission models •...
Page 376 uuCustomized Featuresu ■ Customization flow Press the button. Automatic Date & Time Set Date & Time Date & Time Set Date Select General Settings. Set Time Time Zone Automatic Time Zone (Select time zone) Auto Daylight Saving Time Date Format Time Format System Language...
Page 377 uuCustomized Featuresu Data Sharing Setting Refuel Recommend About Status Legal Information Model Number Android Version Kernel Version Build Number Factory Data Reset Detail Information App Manager...
Page 378 uuCustomized Featuresu Apple CarPlay + Connect New Device Smartphone (Saved Devices) Connection Android Auto + Connect New Device (Saved Devices) Wi-Fi Change Mode (Available Networks/ Connected Devices) Connections Options Add Network Saved Networks Bluetooth Options Bluetooth Priority Device + Connect New Device (Saved Devices) Brightness Display...
Page 379 uuCustomized Featuresu Bass / Treble Treble Midrange Bass Audio Zones & Balance / Sound Fader Bose Centerpoint Bose Dynamic Speed Compensation Rear Camera Fixed Guideline Dynamic Guideline Camera Cross Traffic Monitor Voice Control Voice Control Mode...
Page 380 uuCustomized Featuresu ■ System Customizable Features Description Selectable Settings Automatic Selects ON to have the GPS automatically adjust the /OFF Date & Time clock. Select OFF to cancel this function. Adjusts date. Date & Set Date Day/Month/Year 2 Adjusting the Clock P. 158 Time Hour/Minute Adjusts time.
Page 381 uuCustomized Featuresu Customizable Features Description Selectable Settings Changes the driver information interface and audio/ English /Español/ Language information screen language separately. Français Touch Panel Sets the sensitivity of the touch panel screen. High/Normal Sensitivity System Sounds Sets the system sound volume level. —...
Page 382 uuCustomized Featuresu Customizable Features Description Selectable Settings Status Legal Information Model Number About Displays the Android setting items. — Android Version Kernel Version Build Number Factory Data Resets all the settings to their factory default. Continue/Cancel Reset 2 Defaulting All the Settings P. 397 Detail Displays the Android system memory and apps App Manager...
Page 383 uuCustomized Featuresu ■ Smartphone Connection Customizable Features Description Selectable Settings Pairs a new phone to Apple CarPlay. + Connect New Device — 2 Phone Setup P. 426 Apple CarPlay Connects, disconnects, or deletes a paired phone. (Saved Devices) — 2 Phone Setup P. 426 Pairs a new phone to Android Auto.
Page 384 uuCustomized Featuresu ■ Connections Customizable Features Description Selectable Settings Network Change Mode Changes the Wi-Fi mode. Smartphone /OFF (Available Networks/Connected Displays the available network(s) or current connected — Devices) device(s). Add Network Adds a new network to connect Wi-Fi. — Options Saved Networks Saves the connected network.
Page 385 uuCustomized Featuresu ■ Display Customizable Features Description Selectable Settings Brightness Changes the brightness of the audio/information screen. — Contrast Changes the contrast of the audio/information screen. — Black Level Changes the black level of the audio/information screen. — Resets all customized settings for the brightness, Default —...
Page 386 uuCustomized Featuresu ■ Camera Customizable Features Description Selectable Settings Shows the guideline that does not move with the Fixed Guideline /OFF steering wheel. 2 Multi-View Rear Camera P. 624 Rear Camera Shows the guideline that moves with the steering Dynamic Guideline /OFF wheel.
Page 387 uuCustomized Featuresu ■ How to Customize the Vehicle Settings With the power mode in ON, press the button, and then select Vehicle Settings and select a setting item. Audio/Information Screen...
Page 388 uuCustomized Featuresu ■ Customization flow Press the button. Select Vehicle Settings. TPMS Calibration Driver Assist System Setup Forward Collision Warning Distance ACC Forward Vehicle Detect Beep Road Departure Mitigation Setting Lane Keeping Assist Suspend Beep Blind Spot Info Traffic Sign Recognition System Display Setting Traffic Sign Recognition System Speed Limit Warning Speed Limit Warning Threshold Setting Driver Attention Monitor...
Page 389 uuCustomized Featuresu Meter Setup Adjust Outside Temp. Display “Trip A” Reset Timing “Trip B” Reset Timing Adjust Alarm Volume Fuel Efficiency Backlight Turn By Turn Auto Display Speed/Distance Units Rear Seat Reminder Keyless Access Setup Door Unlock Mode Smart Entry Light Flash Smart Entry Beep Remote Start System ON/OFF Lockout Protection...
Page 390 uuCustomized Featuresu Lighting Setup Auto High Beam Interior Light Dimming Time Headlight Auto OFF Timer Auto Light Sensitivity Auto Headlight On with Wiper On Door/Window Setup Auto Door Lock Auto Door Unlock Key And Remote Unlock Mode Walk Away Auto Lock Keyless Lock Answer Back Remote Window Control Maintenance Info.
Page 391 uuCustomized Featuresu ■ TPMS Calibration Customizable Features Description Selectable Settings Cancels/Calibrates the tire pressure monitoring system (TPMS). TPMS Calibration Calibrate/Cancel 2 Tire Pressure Monitoring System (TPMS) P. 484 ■ Driver Assist System Setup Customizable Features Description Selectable Settings Selects distance for Forward Collision Warning audible and visual Forward Collision Warning Long/Normal /Short...
Page 392 uuCustomized Featuresu Customizable Features Description Selectable Settings Audible And Visual Alert Selects On/Off the blind spot information system audible alert. Blind Spot Info Visual Alert 2 Blind Spot Information System P. 491 Traffic Sign Recognition Displays the traffic sign recognition system on the instrument panel. Display /None System Display Setting...
Page 393 uuCustomized Featuresu ■ Meter Setup Customizable Features Description Selectable Settings Adjust Outside Temp. -5°F ~ ±0°F ~ +5°F (U.S.) Selects to adjust outside temperature reading by a few degrees. 2 Outside Temperature P. 114 Display -3°C ~ ±0°C ~ +3°C (Canada) Selects the timing to reset Trip A.
Page 394 uuCustomized Featuresu ■ Keyless Access Setup Customizable Features Description Selectable Settings Changes which doors unlock when you grab the driver’s door Driver Door Only /All Door Unlock Mode handle. Doors Causes some exterior lights to flash when you unlock/lock the Smart Entry Light Flash /OFF doors.
Page 395 uuCustomized Featuresu ■ Lighting Setup Customizable Features Description Selectable Settings Auto High Beam Turns on/off auto high beam function. /OFF Selects the length of time the interior lights stay on after doors are Interior Light Dimming Time closed. 60sec/30sec /15sec 2 Interior Lights P.
Page 396 uuCustomized Featuresu ■ Door/Window Setup Customizable Features Description Selectable Settings Continuously variable transmission models OFF/With Vehicle Speed /Shift From P Auto Door Lock Changes the setting for the automatic locking feature. Manual transmission models OFF/With Vehicle Speed Continuously variable transmission models OFF/All Doors When Driver’s Door Opens /All Doors When Shifted to...
Page 397 uuCustomized Featuresu ■ Maintenance Info. Customizable Features Description Selectable Settings Resets the maintenance information. Maintenance Info. Select Reset Items 2 Maintenance Minder P. 635...
Page 398 uuCustomized FeaturesuDefaulting All the Settings Defaulting All the Settings Reset all the menu and customized settings as the factory defaults. 1Defaulting All the Settings When you transfer the vehicle to a third party, reset ■ all settings to default and delete all personal data. Defaulting General Settings 1.
Page 399: Homelink® Universal Transceiver
HomeLink® Universal Transceiver The HomeLink® Universal Transceiver can be programmed to operate up to three 1HomeLink® Universal Transceiver remote controlled devices around your home, such as garage doors, lighting, or Before programming HomeLink to operate a garage home security systems. door opener, confirm that the opener has an external entrapment protection system, such as an “electronic ■...
Page 400 uuHomeLink® Universal Transceiver uTraining HomeLink Training HomeLink If it is necessary to erase a previously entered learned code: • Press and hold the I and III HomeLink buttons for about 10 seconds, until the green indicator blinks. Release the buttons, and proceed to step 1.
Page 401 uuHomeLink® Universal Transceiver uTraining HomeLink ■ 1Training HomeLink Programming a Button Reprogramming a Button 1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the If you want to retrain a programmed button for a HomeLink®...
Page 402: Bluetooth® Handsfreelink
To use HFL, you need a Bluetooth-compatible cell phone. For a list of compatible phones, pairing Using HFL procedures, and special feature capabilities: • U.S.: Visit automobiles.honda.com/handsfreelink/, ■ HFL Buttons or call 1-888-528-7876. • Canada: For more information on smartphone compatibility, call 1-855-490-7351.
Page 403 Bluetooth SIG, Inc., and any 2 Receiving a Call P. 419 use of such marks by Honda Motor Co., Ltd., is under PHONE button: Press to go directly to the Phone screen. license. Other trademarks and trade names are those...
Page 404 uuBluetooth® HandsFreeLink®uUsing HFL ■ 1HFL Status Display HFL Status Display The information that appears on the audio/ The audio/information screen notifies you when there is an incoming call. information screen varies between phone models. Battery Level Status Bluetooth Indicator Signal Strength Appears when your phone is connected to HFL.
Page 405 uuBluetooth® HandsFreeLink®uHFL Menus HFL Menus The power mode must be in ACCESSORY or ON to use the system. 1HFL Menus To use HFL, you must first pair your Bluetooth- compatible cell phone to the system while the vehicle is parked. Some functions are limited while driving.
Page 406 uuBluetooth® HandsFreeLink®uHFL Menus Select the ring tone stored in the connected cell phone. Ringtone Phone Vehicle Select the ring tone stored in HFL. Auto Phone Call Set calls to automatically transfer from your phone to HFL when you Transfer enter the vehicle. Hands-Free Clear the phone settings, paired phones, all favorite contacts entries, all System Clear...
Page 407 If your phone is not ready to be paired or is not paired within three minutes, the system will time 4. Select Honda Civic from your phone. out and return to the Bluetooth Settings screen. If you want to pair a phone from this...
Page 408 uuBluetooth® HandsFreeLink®uHFL Menus ■ To pair a cell phone (when a phone has already been paired to the system) 1. Press the PHONE button. If a prompt appears asking to connect to a phone, select No and proceed with step 2. 2.
Page 409 HandsFreeLink®uHFL Menus 5. Make sure your phone is in search or discoverable mode. 6. Select Honda Civic from your phone. If you want to pair a phone from this audio system, select Search from car and follow the prompts.
Page 410 uuBluetooth® HandsFreeLink®uHFL Menus ■ To change the currently paired phone 1. Press the PHONE button. 2. Select Settings. 3. Select Bluetooth Settings. 4. Select Change Device. The screen changes to a device list. 5. Select a desired device name. 6. Select Both, Audio, or Phone. When another device is connected to Android Auto and you select Both or Phone, a confirmation message appears.
Page 411 uuBluetooth® HandsFreeLink®uHFL Menus ■ To delete a paired phone 1. Press the PHONE button. 2. Select Settings. 3. Select Bluetooth Settings. 4. Select Delete Device. The screen changes to a device list. 5. Select a phone you want to delete. 6.
Page 412 uuBluetooth® HandsFreeLink®uHFL Menus ■ Automatic Transferring If paring between your phone and the system is executed while you are on the phone, the call can be automatically transferred to HFL. 1. Press the PHONE button. 2. Select Settings. 3. Select Auto Phone Call Transfer. 4.
Page 413 uuBluetooth® HandsFreeLink®uHFL Menus ■ To Clear the System Phone settings, paired phones, all favorite contacts entries, all call history data, and all imported phonebook data are erased. 1. Press the PHONE button. 2. Select Settings. 3. Select Hands-Free System Clear. 4.
Page 414 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Automatic Import of Cellular Phonebook and Call History Automatic Import of Cellular Phonebook and Call History When you select a person from the list in the cellular When your phone is paired, the contents of its phonebook and call history are phonebook, you can see up to five category icons.
Page 415 uuBluetooth® HandsFreeLink®uHFL Menus ■ Favorite Contacts ■ To add a favorite contacts Recent Calls Screen 1. Press the PHONE button. 2. Select Recent Calls, Contacts, or Keypad. On the Recent Calls or Contacts screen 3. Select the star icon. Star Icon Contacts Screen Star Icon Keypad Screen...
Page 416 uuBluetooth® HandsFreeLink®uHFL Menus ■ To delete a favorite contact 1. Press the PHONE button. 2. Select Favorite Contacts. 3. Select the star icon. 4. A confirmation message appears on the screen. Select Yes. Star Icon Continued...
Page 417 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Making a Call Making a Call Once a call is connected, you can hear the voice of You can make calls by inputting any phone number, or by using the imported the person you are calling through the audio Recent Calls, Favorite Contacts, and Contacts entries.
Page 418 uuBluetooth® HandsFreeLink®uHFL Menus ■ To make a call using a phone number 1. Press the PHONE button. 2. Select Keypad. 3. Select a number. 4. Select Call. Dialing starts automatically. ■ To make a call using the call history 1To make a call using the call history Call history is stored by All, Dialed, Missed, The call history appears only when a phone is or Received.
Page 419 uuBluetooth® HandsFreeLink®uHFL Menus ■ To make a call using a favorite contact 1. Press the PHONE button. 2. Select Favorite Contacts. 3. Select a number. Dialing starts automatically.
Page 420 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Receiving a Call Receiving a Call Call Waiting When there is an incoming call, an audible HFL Mode Select Answer using the left selector wheel to put notification sounds and the Incoming Call... the current call on hold to answer the incoming call. screen appears.
Page 421 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Options During a Call Options During a Call Keypad: Available on some phones. The following options are available during a call. Swap Calls: Put the current call on hold to answer the incoming call. Mute: Mute your voice. Use Handheld: Transfer a call from HFL to your phone.
Page 422 To use HFL, you need a Bluetooth-compatible cell phone. For a list of compatible phones, pairing Using HFL procedures, and special feature capabilities: • U.S.: Visit automobiles.honda.com/handsfreelink/, ■ or call 1-888-528-7876. HFL Buttons • Canada: For more information on smartphone compatibility, call 1-855-490-7351.
Page 423 Bluetooth SIG, Inc., and any While receiving a call, the incoming call screen is displayed on the driver information use of such marks by Honda Motor Co., Ltd., is under interface. You can pick up the call using the left selector wheel.
Page 424 uuBluetooth® HandsFreeLink®uUsing HFL ■ 1HFL Status Display HFL Status Display The information that appears on the audio/ The audio/information screen notifies you when there is an incoming call. information screen varies between phone models. Signal Strength Battery Level Status Bluetooth Indicator Appears when your phone is connected to HFL Mode...
Page 425 uuBluetooth® HandsFreeLink®uHFL Menus HFL Menus The power mode must be in ACCESSORY or ON to use the system. 1HFL Menus To use HFL, you must first pair your Bluetooth- ■ Phone settings screen compatible cell phone to the system while the vehicle is parked.
Page 426 uuBluetooth® HandsFreeLink®uHFL Menus ■ Phone menu screen 1. Press the button. 2. Select Phone. Display the last outgoing, incoming and missed calls. Recent Calls Dialed Display the last outgoing calls. Missed Display the last missed calls. Received Display the last incoming calls. Favorite Contacts (Existing entry list) Dial the selected number in the favorite contacts list.
Page 427 : The phone is compatible with Bluetooth® Audio. discoverable mode. : The phone can be used with HFL. 4. Select Honda CIVIC from your phone. : The phone is compatible with Apple CarPlay. If you want to pair a phone from this : The phone is compatible with Android Auto.
Page 428 uuBluetooth® HandsFreeLink®uHFL Menus 7. A notification appears on the screen if pairing is successful. 8. Select OK. A confirmation message for phone data collection appears. 9. Select ON or OFF. A confirmation message for HondaLink Assist appears. 10. Select Yes or No. Continued...
Page 429 uuBluetooth® HandsFreeLink®uHFL Menus ■ To change the currently paired phone 1To change the currently paired phone 1. Go to the phone settings screen. If no other phones are found or paired when trying to 2 Phone settings screen P. 424 switch to another phone, HFL will inform you that the 2.
Page 430 uuBluetooth® HandsFreeLink®uHFL Menus ■ To delete a paired phone 1. Go to the phone settings screen. 2 Phone settings screen P. 424 2. Select Change Devices. 3. Select a phone you want to delete. 4. Select Options. 5. Select Delete Device. 6.
Page 431 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Ring Tone Ring Tone Vehicle: The fixed ring tone sounds from the You can change the ring tone setting. speakers. 1. Go to the phone settings screen. Phone: Depending on the make and model of the 2 Phone settings screen P.
Page 432 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Automatic Import of Cellular Phonebook and Call History Automatic Import of Cellular Phonebook and Call History When you select a name from the list in the cellular ■ When Automatic Phone Sync is set to phonebook, you can see a category icon. The icons indicate what types of numbers are stored for that When your phone is paired, the contents of its name.
Page 433 uuBluetooth® HandsFreeLink®uHFL Menus ■ Favorite Contacts ■ To add a favorite contacts Recent Calls Screen 1. Select Phone. 2. Select Recent Calls, Contacts, or Keypad. On the Recent Calls or Contacts screen 3. Select the star icon. Star Icon Contacts Screen Star Icon Keypad Screen On the Keypad screen...
Page 434 uuBluetooth® HandsFreeLink®uHFL Menus ■ To edit a favorite contacts 1. Select Phone. 2. Select Favorite Contacts. 3. Select Edit on the favorite contacts entry you want to edit. 4. Select a setting you want. 5. Select Done. ■ To delete a favorite contacts 1.
Page 435 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Making a Call Making a Call Once a call is connected, you can hear the voice of You can make calls by inputting any phone the person you are calling through the audio number, or by using the imported Recent speakers.
Page 436 uuBluetooth® HandsFreeLink®uHFL Menus ■ To make a call using a phone number 1. Select Phone. 2. Select Keypad. 3. Select a number. Use the keyboard on the touch screen for entering numbers. 4. Select Call. Dialing starts automatically. ■ To make a call using the Call History 1To make a call using the Call History Call history is stored by All, Dialed, Missed, The call history displays the last 20 all, dialed, missed,...
Page 437 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Receiving a Call Receiving a Call Call Waiting When there is an incoming call, an audible Select (answer) to put the current call on hold to notification sounds (if activated) and the answer the incoming call. Incoming Call...
Page 438 uuBluetooth® HandsFreeLink®uHFL Menus ■ 1Options During a Call Options During a Call Keypad: Available on some phones. The following options are available during a call. Mute: Mute your voice. You can select the icons on the audio/information Use Handheld: Transfer a call from the system to your phone. screen.
Page 439 If the unit fails to connect to the operator, it repeatedly tries until it succeeds. Honda reserves the right to terminate HondaLink Assist services at any time or for any reason, and in the future may not be able to provide services due to changes in, or obsolescence of, technology integral to the service or changes in governmental regulation.
Page 440 uuBluetooth® HandsFreeLink®uHondaLink® Assist ■ To enable notification 1To enable notification 1. Go to the phone settings screen. Setting options: 2 Phone settings screen P. 424 • Yes: Notification is available. • 2. Select HondaLink Assist. No: Disable the feature. 3. Select Yes or No.
Page 441 Refuel Recommend Models with 9-in. Color Touchscreen 1Refuel Recommend Your vehicle is equipped with a feature that automatically calculates when to refuel. You can turn the Refuel Recommend function on and This feature will notify you when refueling is recommended as well as enable you to off.
Page 442: Driving
Front Wide View Camera....598 Blind Spot Information System ..491 Starting the Engine ......448 Sonar Sensors ........ 600 Honda Sensing® ........ 495 Precautions While Driving....455 Braking Collision Mitigation Braking System Continuously Variable Transmission ... 456 Anti-lock Brake System (ABS) ... 611 (CMBS ) ........
Page 443: Before Driving
Before Driving Driving Preparation Check the following items before you start driving. ■ 1Exterior Checks Exterior Checks NOTICE • Make sure there are no obstructions on the windows, door mirrors, exterior When doors are frozen shut, use warm water around lights, or other parts of the vehicle.
Page 444 uuBefore DrivinguDriving Preparation ■ 1Interior Checks Interior Checks The headlight aim is set by the factory, and does not • Store or secure all items on board properly. need to be adjusted. However, if you regularly carry Carrying too much cargo, or improperly storing it, can affect your vehicle’s heavy items in the cargo area, have the aiming handling, stability, stopping distance, and tires, and make it unsafe.
Page 445 uuBefore DrivinguDriving Preparation • Be sure items placed on the floor behind the front seats cannot roll under the seats. They can interfere with the driver's ability to operate the pedals, the operation of the seats, or the operation of the sensors under the seats. •...
Page 446 uuBefore DrivinguMaximum Load Limit Maximum Load Limit The maximum load for your vehicle is 850 lbs (385 kg). See the 1Maximum Load Limit Tire and Loading Information label attached to the driver’s WARNING doorjamb. Overloading or improper loading can affect handling and stability Label Example and cause a crash in which you can be hurt or killed.
Page 447 uuBefore DrivinguMaximum Load Limit (5) Determine the combined weight of luggage and cargo being 1Maximum Load Limit loaded on the vehicle. That weight may not safely exceed the Towing a Trailer: available cargo and luggage load capacity calculated in step 4. See Towing a Trailer to determine whether your (6) If your vehicle will be towing a trailer, load from your trailer will vehicle is designed to tow a trailer.
Page 448: Towing A Trailer
Towing a Trailer Your vehicle is not designed to tow a trailer. Attempting to do so can void your warranties. Towing Behind a Motorhome Your vehicle is not designed to be towed behind a motor home. If your vehicle needs to be towed in an emergency, refer to the emergency towing information.
Page 449: When Driving
When Driving Starting the Engine 1. Make sure the parking brake is applied. 1Starting the Engine The parking brake and brake system Keep your foot firmly on the brake pedal when starting the engine. indicator (red) comes on for 30 seconds when you pull up the electric parking The engine is harder to start in cold weather and in thinner brake switch.
Page 450 uuWhen DrivinguStarting the Engine All models 1Starting the Engine 3. Press the ENGINE START/STOP button The immobilizer system protects your vehicle from theft. If an improperly coded device is used, the without depressing the accelerator pedal. engine’s fuel system is disabled. 2 Immobilizer System P.
Page 451 uuWhen DrivinguStarting the Engine ■ 1Remote Engine Start Remote Engine Start WARNING You can remotely start the engine using the keyless remote. Carbon monoxide gas is toxic and can ■ To start the engine rapidly accumulate in closed or even partly Press the button, then press and hold LED: Blinks when any...
Page 452 uuWhen DrivinguStarting the Engine When started remotely, the engine automatically shuts off after 10 minutes of idling 1Remote Engine Start and/or the brake pedal and ENGINE START/STOP button have not been pressed The engine may not start by the remote engine start simultaneously.
Page 453 uuWhen DrivinguStarting the Engine ■ To stop the engine 1Remote Engine Start Press and hold the button for one The engine may stop while it is running if: second. • You do not start the vehicle within 10 minutes of starting the engine with the keyless remote.
Page 454 uuWhen DrivinguStarting the Engine ■ 1Starting to Drive Starting to Drive Manual transmission models Continuously variable transmission models Engine Restart Function When the engine was started using the button on the keyless remote If the engine stalls, fully depress the clutch pedal 1.
Page 455 uuWhen DrivinguStarting the Engine ■ 1Stopping the Engine Stopping the Engine The power mode will automatically turn to VEHICLE You can turn the engine off when the vehicle is completely stopped. OFF about 20 minutes after the following conditions have been met: Continuously variable transmission models •...
Page 456: Precautions While Driving
uuWhen DrivinguPrecautions While Driving Precautions While Driving ■ 1Precautions While Driving In Rain Continuously variable transmission models Avoid driving in deep water and on flooded roads. This can damage the engine or NOTICE driveline, or cause electrical component failure. Do not operate the shift lever while pressing the accelerator pedal.
Page 457: Continuously Variable Transmission
uuWhen DrivinguContinuously Variable Transmission 1Precautions While Driving Avoid hard braking for the first 200 miles (300 km) after purchasing your new vehicle or replacing the brake pads or rotors, to allow for proper break-in. NOTICE The following can damage the under spoiler: •...
Page 458: Shifting
uuWhen DrivinguShifting Continuously variable transmission models without paddle shifter Shifting 1Shifting Change the shift position in accordance with your driving needs. You cannot change the power mode from ON to VEHICLE OFF unless the shift position is in ■ Shift positions The vehicle may move very slightly even in while the engine is cold.
Page 459 uuWhen DrivinguShifting ■ 1Shift Operation Shift Operation NOTICE When you change the shift position from and vice versa, come to a complete stop and keep the brake pedal depressed. Operating the shift lever before the vehicle has come to a complete standstill can damage the transmission. Use the shift position indicator to check the lever position before pulling away.
Page 460 uuWhen DrivinguShifting Continuously variable transmission models with paddle shifter Shifting Change the shift position in accordance with your driving needs. 1Shifting You cannot change the power mode from ON to ■ Shift positions VEHICLE OFF unless the shift position is in The vehicle may move very slightly even in while the engine is cold.
Page 461 uuWhen DrivinguShifting ■ 1Shift Operation Shift Operation NOTICE When you change the shift position from Models with A-type meter Models with B-type meter and vice versa, come to a complete stop and keep the Tachometer’s Red Zone brake pedal depressed. Operating the shift lever before the vehicle has come to a complete standstill can damage the transmission.
Page 462 uuWhen DrivinguShifting ■ 17-Speed Manual Shift Mode 7-Speed Manual Shift Mode In the 7-speed manual shift mode, the transmission Use the paddle shifters to change between 1st and 7th speeds without releasing shifts up or down by operating either paddle shifter your hands from the steering wheel.
Page 463 uuWhen DrivinguShifting ■ 17-Speed Manual Shift Mode Operation 7-Speed Manual Shift Mode Operation Each paddle shift operation makes a single speed change. To change continuously, release the paddle shifter Paddle Shifter Paddle Shifter before pulling it again for the next speed. (Shift down) (Shift up) The shift indicator blinks when you cannot shift up or...
Page 464 uuWhen DrivinguShifting Manual transmission models Shifting ■ 1Shift Lever Operation Shift Lever Operation NOTICE Fully depress the clutch pedal to operate the shift lever and change gears, then Do not shift to before the vehicle comes to a slowly release the pedal. complete stop.
Page 465 uuWhen DrivinguShifting ■ 1Shift Up/Down Indicators Shift Up/Down Indicators This indicator will not prompt you to downshift to Come on to inform you that upshifting or Models with A-type meter increase engine braking. It is up to you to downshift downshifting is necessary to prevent the to increase engine braking when driving downhill.
Page 466 uuWhen DrivinguShifting ■ Reverse Lockout The manual transmission has a lockout mechanism that stops you from accidentally shifting into R from a forward gear while the vehicle is moving above a certain speed. If you cannot shift to R when the vehicle is stopped, do the following: 1.
Page 467: Econ Button
uuWhen DrivinguECON Button ECON Button 1ECON Button Models with A-type meter While in the ECON mode, the climate control system has greater temperature fluctuation. Due to emergency brakes operation or driving conditions, you may not be able to change the mode. ECON Mode Indicator ECON Button Models with B-type meter...
Page 468: Auto Idle Stop
uuWhen DrivinguAuto Idle Stop Continuously variable transmission models Auto Idle Stop To help maximize fuel economy, the engine automatically stops when the vehicle 1Auto Idle Stop comes to a stop, depending on environmental and vehicle operating conditions. The The 12-volt battery installed in this vehicle is indicator (green) comes on at this time.
Page 469 uuWhen DrivinguAuto Idle Stop ■ 1Auto Idle Stop System ON/OFF Auto Idle Stop System ON/OFF If you turn off the Auto Idle Stop system while it is To turn the Auto Idle Stop system off, press activated, the engine will restart. Auto Idle Stop OFF this button.
Page 470 uuWhen DrivinguAuto Idle Stop ■ 1Auto Idle Stop Activates When: Auto Idle Stop Activates When: Do not open the hood while the Auto Idle Stop The vehicle stops with the transmission in D and the brake pedal depressed. function is activated. If the hood is opened, the When you put the transmission into P quickly with depressing the brake pedal, the engine will not restart automatically.
Page 471 uuWhen DrivinguAuto Idle Stop ■ Auto Idle Stop may not activate when: • The vehicle is stopped by braking suddenly. • The steering wheel is operated. • The vehicle is repeatedly accelerated and decelerated at a low speed. • The fan speed is high. •...
Page 472 uuWhen DrivinguAuto Idle Stop ■ 1The Engine Automatically Restarts When: The Engine Automatically Restarts When: If you are using an electronic device during Auto Idle • The brake pedal is released (without the automatic brake hold system activated). Stop, the device may temporarily be turned off when •...
Page 473 uuWhen DrivinguAuto Idle Stop ■ Starting Assist Brake Function Briefly keeps the brake applied after releasing the brake pedal to restart the engine. This can keep your vehicle from unexpectedly moving while on an incline.
Page 474 uuWhen DrivinguAuto Idle Stop Manual transmission models Auto Idle Stop To help maximize fuel economy, the engine automatically stops when the vehicle 1Auto Idle Stop comes to a stop, depending on environmental and vehicle operating conditions. The The 12-volt battery installed in this vehicle is indicator (green) comes on at this time.
Page 475 uuWhen DrivinguAuto Idle Stop ■ 1Auto Idle Stop System ON/OFF Auto Idle Stop System ON/OFF If you turn off the Auto Idle Stop system while it is To turn the Auto Idle Stop system off, press activated, the engine will restart. Auto Idle Stop OFF this button.
Page 476 uuWhen DrivinguAuto Idle Stop ■ 1Auto Idle Stop Activates When: Auto Idle Stop Activates When: Do not open the hood while the Auto Idle Stop After the vehicle moves forward, stopping with the brake, the clutch pedal fully function is activated. If the hood is opened, the depressed, the shift lever in N , and then the clutch pedal is released.
Page 477 uuWhen DrivinguAuto Idle Stop ■ Auto Idle Stop may not activate when: • The steering wheel is operated. • The fan speed is high. • The climate control system is in use, and there is a significant difference between the set temperature and the actual interior temperature. •...
Page 478 uuWhen DrivinguAuto Idle Stop ■ 1The Engine Automatically Restarts When: The Engine Automatically Restarts When: If you are using an electronic device during Auto Idle The clutch pedal is depressed. Stop, the device may temporarily be turned off when the engine restarts. ■...
Page 479: Drive Mode Switch
uuWhen DrivinguDrive Mode Switch Drive Mode Switch Constantly controls your vehicle’s engine, transmission, EPS, brakes and VSA® 1Drive Mode Switch according to the mode you select. The mode may not be able to be changed when: You can choose between three modes, SPORT mode, NORMAL mode and ECON •...
Page 480 uuWhen DrivinguDrive Mode Switch ■ SPORT Mode Enhances heightened throttle response. ■ NORMAL Mode Balances handling and riding in all environments. Continued...
Page 481 uuWhen DrivinguDrive Mode Switch ■ ECON Mode Helps you improve your fuel economy by adjusting the performance of the engine, transmission and climate control system.
Page 482: Vehicle Stability Assist
uuWhen DrivinguVehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System Vehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System VSA® helps stabilize the vehicle during cornering if the vehicle turns more or less 1Vehicle Stability Assist (VSA®), aka Electronic Stability Control than what was intended.
Page 483 uuWhen DrivinguVehicle Stability Assist (VSA®), aka Electronic Stability Control (ESC), System ■ 1Vehicle Stability Assist (VSA®), aka Electronic Stability Control VSA® On and Off (ESC), System This button is on the driver side control panel. In certain unusual conditions when your vehicle gets VSA®...
Page 484: Agile Handling Assist
uuWhen DrivinguAgile Handling Assist Agile Handling Assist Lightly brakes the front wheels, as needed, when you turn the steering wheel, and 1Agile Handling Assist helps support the vehicle’s stability and performance during cornering. The agile handling assist cannot enhance stability in all driving situations.
Page 485: Tire Pressure Monitoring System (Tpms)
uuWhen DrivinguTire Pressure Monitoring System (TPMS) Tire Pressure Monitoring System (TPMS) Instead of directly measuring the pressure in each tire, the TPMS on this vehicle 1Tire Pressure Monitoring System (TPMS) monitors and compares the rolling radius and rotational characteristics of each The system does not monitor the tires when driving wheel and tire while you are driving to determine if one or more tires are at low speed.
Page 486 uuWhen DrivinguTire Pressure Monitoring System (TPMS) 1Tire Pressure Monitoring System (TPMS) The Vehicle Stability Assist (VSA®) system, Vehicle Stability Assist (VSA®) OFF, Adaptive Cruise Control (ACC) , Adaptive Cruise Control (ACC) with Low Speed Follow , low tire pressure/TPMS and safety support indicators may come on in amber along with a message in the gauge when you set the power mode to ON after reconnecting the battery.
Page 487 uuWhen DrivinguTire Pressure Monitoring System (TPMS) Models with 7-in. Color Touchscreen You can calibrate the system from the settings on the driver information interface. 1. Press the (home) button, to select Settings, then press the left selector wheel. Vehicle settings appears on the display. 2.
Page 488 uuWhen DrivinguTire Pressure Monitoring System (TPMS) 3. Press the left selector wheel. The display switches to the customization setup screen, where you can select Cancel or Calibrate. 4. Roll the left selector wheel and select Calibrate, then press the left selector wheel.
Page 489 uuWhen DrivinguTire Pressure Monitoring System (TPMS) Models with 9-in. Color Touchscreen You can calibrate the system from the customized feature on the audio/information screen. 1. Set the power mode to ON. 2. Press the button. 3. Select Vehicle Settings. 4. Select TPMS Calibration. 5.
Page 490: Tire Pressure Monitoring System (Tpms) - Required Federal Explanation
uuWhen DrivinguTire Pressure Monitoring System (TPMS) - Required Federal Explanation Tire Pressure Monitoring System (TPMS) - Required Federal Explanation Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label.
Page 491 uuWhen DrivinguTire Pressure Monitoring System (TPMS) - Required Federal Explanation Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver's responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale.
Page 492: Blind Spot Information System
uuWhen DrivinguBlind Spot Information System Blind Spot Information System When the system detects vehicles approaching from behind in adjacent lanes, the 1Blind Spot Information System appropriate indicator comes on, providing assistance when you change lanes. Important Safety Reminder Like all assistance systems, the blind spot information ■...
Page 493 uuWhen DrivinguBlind Spot Information System ■ When the system detects a vehicle 1Blind Spot Information System Blind spot information system alert indicator: For proper blind spot information system operation: Comes On Located on the outside rearview mirror on • Always keep the rear bumper and area around the both sides.
Page 494 uuWhen DrivinguBlind Spot Information System ■ 1Blind Spot Information System Blind Spot Information System On and Off You can also select safety support content from the When you turn the blind spot information Models with A-type meter driver information interface. system on and off, do the following.
Page 495 uuWhen DrivinguBlind Spot Information System ■ Blind Spot Information System Conditions and Limitations The blind spot information system alert indicator may not come on under the following conditions: • There is a large speed difference between your vehicle and the vehicle in the adjacent lane.
Page 496: Honda Sensing
Models without Low Speed Braking Control Honda Sensing® is a driver support system which employs the use of a front wide view camera mounted to the interior side of the windshield, behind the rearview mirror.
Page 497 Sensing®u Honda Sensing® has following functions. ■ The functions which do not require switch operations to activate • Collision Mitigation Braking System (CMBS 2 P. 499 • Low Speed Braking Control 2 P. 511 • Low Speed Braking Control 2 P.
Page 498 uuHonda Sensing®u ■ Operation Switches for the Adaptive Cruise Control (ACC) with Low Speed Follow Adaptive Cruise Control (ACC) /Lane Keeping Assist System (LKAS)/Traffic Jam Assist ■ Button Button CANCEL Button Press to activate standby mode for ACC with Low Speed Follow /ACC .
Page 499 uuHonda Sensing®u ■ Gauge Content You can see the current state of Adaptive Models with A-type meter Cruise Control (ACC) with Low Speed Follow Adaptive Cruise Control (ACC) , Lane Keeping Assist System (LKAS) and Traffic Jam Assist Indicates that ACC with Low Speed Follow /ACC is ready to be activated.
Page 500: Collision Mitigation Braking System
uuHonda Sensing®uCollision Mitigation Braking System (CMBS Collision Mitigation Braking System (CMBS The system can assist you when it determines there is a possibility of your vehicle 1Collision Mitigation Braking System (CMBS colliding with a vehicle (including motorcycles) ahead from behind, an oncoming Important Safety Reminder vehicle in front, a pedestrian, or someone riding a bicycle (moving bicycle).
Page 501 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ How the system works 1How the system works The camera in the CMBS is also designed to detect When to use pedestrians. A front wide view camera is located However, this pedestrian detection feature may not behind the rearview mirror.
Page 502 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ When the system activates The system provides visual and audible alerts of a possible collision, and stops if the collision is avoided. Take appropriate action to prevent a collision (apply the brakes, change lanes, etc.) Visual Alerts Beep...
Page 503 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ Collision Alert Stages The system has three alert stages for a possible collision. However, depending on circumstances, the CMBS may not go through all of the stages before initiating the last stage. CMBS Distance between vehicles The sensors detect a vehicle Audible &...
Page 504 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ 1Collision Mitigation Braking System (CMBS CMBS On and Off You cannot turn the CMBS off while driving. When you turn the CMBS on and off, do the Models with A-type meter following. The CMBS may automatically shut off, and the 1.
Page 505 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ 1CMBS Conditions and Limitations CMBS Conditions and Limitations Have your vehicle checked by a dealer if you find any The system may automatically shut off and the safety support indicator (amber) will unusual behavior of the system (e.g., the warning come on under certain conditions.
Page 506 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ Vehicle conditions • The vehicle is tilted due to heavy load in the cargo area or rear seats. • Tire chains are installed. • Driving at night or in a dark place (e.g., a tunnel) with the headlights off. •...
Page 507 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ Examples of limitations on the correct detection of the camera due to the condition of 1Collision Mitigation Braking System (CMBS the vehicle ahead of you, oncoming vehicles, pedestrians, or moving bicycles Make sure that all the tires are of the same specified •...
Page 508 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ Examples of other limitations on detection or system operation • When the vehicle ahead of you is a small motorcycle, motorcycle with a sidecar, wheelchair, or other specially shaped vehicle. • When a vehicle is lower in the rear than the front such as trucks that are not carrying a load, or a narrow vehicle.
Page 509 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ Automatic shutoff The CMBS may automatically shut itself off and the safety support indicator (amber) comes and stays on when: • You drive off-road or on a mountain road, or curved and winding road for an extended period.
Page 510 uuHonda Sensing®uCollision Mitigation Braking System (CMBS ■ With Little Chance of a Collision Even if there is little chance of a collision, the CMBS may activate under the following conditions: • Your vehicle approaches or passes another vehicle that is making a left or right turn.
Page 511 uuHonda Sensing®uCollision Mitigation Braking System (CMBS • When passing through a low or narrow gate at a speed well over the speed limit. • When there are traffic signs or structures such as guard rails are beside the road along a curve. •...
Page 512: Low Speed Braking Control
uuHonda Sensing®uLow Speed Braking Control Low Speed Braking Control Continuously variable transmission models with parking sensor system 1Low Speed Braking Control Using sonar sensors located on the front and rear bumpers, and the front grille, this WARNING system detects if there is danger of a potential collision with a wall or other obstacle during normal driving or when the accelerator pedal is depressed with too much The Low Speed Braking Control System force.
Page 513 uuHonda Sensing®uLow Speed Braking Control ■ 1Low Speed Braking Control How the System Works For directions on the proper handling of the sonar ■ Assistive braking sensors, please refer to the following page. Assistive braking provides a visual and audible alert when the vehicle is moving 2 Sonar Sensors P.
Page 514 uuHonda Sensing®uLow Speed Braking Control ■ Assistive driving power suppression When the vehicle is stopped or moving at less than 6 mph (10 km/h) and there is an obstacle such as a wall detected near the front of or back of the vehicle, if the accelerator pedal is depressed more than necessary, the system will inform you with a visual and audible alert.
Page 515 uuHonda Sensing®uLow Speed Braking Control ■ 1System On and Off System On and Off You can also select safety support content from the When you turn the system on and off, do the Right driver information interface. following. Selector 2 Driver Information Interface (Right Side Wheel 1.
Page 516 uuHonda Sensing®uLow Speed Braking Control ■ 1Conditions for Cancellation Conditions for Cancellation After Low Speed Braking Control has activated once, Conditions for assistive driving power suppression. it will not activate again for the same obstacle. • When the accelerator is no longer depressed. They can be activated again after driving for a certain •...
Page 517 uuHonda Sensing®uLow Speed Braking Control ■ Examples of situations where the sonar sensor cannot detect obstacles • The sonar sensor is dirty (covered by snow, water, mud, etc.). • The vehicle is too hot or cold. • The steering wheel is turned sharply when approaching the obstacle at an angle. ■...
Page 518 uuHonda Sensing®uLow Speed Braking Control Low Speed Braking Control Manual transmission models with parking sensor system 1Low Speed Braking Control Using sonar sensors located on the front and rear bumpers, and the front grille, this WARNING system detects if there is danger of a potential collision with a wall or other obstacle during normal driving.
Page 519 uuHonda Sensing®uLow Speed Braking Control ■ 1Low Speed Braking Control How the System Works For directions on the proper handling of the sonar The Low Speed Braking Control provides a visual and audible alert when the vehicle sensors, please refer to the following page. is moving between approximately 1 and 6 mph (2 and 10 km/h) and there is the 2 Sonar Sensors P.
Page 520 uuHonda Sensing®uLow Speed Braking Control ■ 1System On and Off System On and Off You can also select safety support content from the When you turn the system on and off, do the driver information interface. following. 2 Driver Information Interface (Right Side Right 1.
Page 521 uuHonda Sensing®uLow Speed Braking Control ■ 1Conditions for Cancellation Conditions for Cancellation After Low Speed Braking Control has activated once, A certain amount of time has passed since activation. it will not activate again for the same obstacle. They can be activated again after driving for a certain distance after last activation.
Page 522 uuHonda Sensing®uLow Speed Braking Control ■ Examples of situations where the sonar sensor cannot detect obstacles • The sonar sensor is dirty (covered by snow, water, mud, etc.). • The vehicle is too hot or cold. • The steering wheel is turned sharply when approaching the obstacle at an angle. ■...
Page 523: Adaptive Cruise Control (Acc) With Low Speed Follow
uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow Adaptive Cruise Control (ACC) with Low Speed Follow Helps maintain a constant vehicle speed and a set following-interval behind a vehicle 1Adaptive Cruise Control (ACC) with Low Speed Follow detected ahead of yours and, if the detected vehicle comes to a stop, can decelerate WARNING and stop your vehicle, without you having to keep your foot on the brake or the accelerator.
Page 524 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ How to activate the system 1Adaptive Cruise Control (ACC) with Low Speed Follow You can read about handling information for the How to use camera equipped with this system. (white) is on in the gauge 2 Front Wide View Camera P.
Page 525 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ 1To Set the Vehicle Speed To Set the Vehicle Speed The Vehicle Stability Assist (VSA®) system, Vehicle Stability Assist (VSA®) OFF, Adaptive Cruise Control (green) (ACC) with Low Speed Follow, low tire pressure/ RES/+/SET/−...
Page 526 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow When ACC with Low Speed Follow starts Models with A-type meter operating, the vehicle icon, interval bars and Set Vehicle Interval set speed appear on the gauge. When you use ACC with Low Speed Follow, Straight Driving Assist (a feature of the Electric Power Steering system) is activated.
Page 527 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ 1When in Operation When in Operation If the vehicle ahead of you slows down abruptly, or if ■ There is a vehicle ahead another vehicle cuts in front of you, a beeper sounds, ACC with Low Speed Follow monitors if a vehicle ahead of you enters the ACC with a message appears on the driver information Low Speed Follow range.
Page 528 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow When a vehicle whose speed is slower than Models with A-type meter 1When in Operation your set speed is detected in front of you, your Even if the interval between your vehicle and the vehicle starts to slow down.
Page 529 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ There is no vehicle ahead 1When in Operation Your vehicle maintains the set speed without Models with A-type meter • ACC with Low Speed Follow may temporarily having to keep your foot on the brake or control the interval between your vehicle and the accelerator pedal.
Page 530 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ A vehicle detected ahead is within ACC with Low Speed Follow range and 1When in Operation slows to a stop WARNING Your vehicle also stops, automatically. The Models with A-type meter Stopped message appears on the gauge.
Page 531 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow If no vehicle is ahead of you before you Models with A-type meter resume driving, depress the accelerator pedal and ACC with Low Speed Follow will operate again within the prior set speed. (green) Models with B-type meter (green)
Page 532 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ ACC with Low Speed Follow Conditions and Limitations The system may automatically shut off under certain conditions. Some examples of these conditions are listed below. Other conditions may reduce some of the ACC with Low Speed Follow functions.
Page 533 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ Roadway conditions • Driving on curvy, winding, undulating, or sloping roads. • Driving on rutted roads (snowy or unpaved roads, etc.). • Puddles or a film of water is on the road surface. •...
Page 534 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ Examples of conditions under which the camera may not correctly detect the vehicle ahead of you • A vehicle suddenly crosses in front of you. • The interval between your vehicle and the vehicle ahead of you is too short. •...
Page 535 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ Examples of conditions under which the system may not work properly • A vehicle ahead of you stops and the speed difference between your vehicle and the vehicle ahead of you is significantly large. •...
Page 536 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ 1To Adjust the Vehicle Speed To Adjust the Vehicle Speed If a vehicle detected ahead is going at a speed slower Increase or decrease the vehicle speed using the RES/+/SET/− switch on the steering than your increased set speed, ACC with Low Speed wheel.
Page 537 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ To Set or Change Following-interval Press the Interval button to change the ACC with Low Speed Follow following-interval. Each time you press the button, the following- interval (the interval behind a vehicle detected ahead of you) setting cycles through furthest, far, mid, and nearest following-intervals.
Page 538 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow The higher your vehicle’s following-speed is, the longer the nearest, mid, far or furthest following-interval becomes. See the following examples for your reference. When the Set Speed is: Following-interval 50 mph (80 km/h) 65 mph (104 km/h) 87.3 feet 110.6 feet...
Page 539 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ 1To Cancel To Cancel Resuming the prior set speed: After you have To cancel ACC with Low Speed Follow, do any canceled ACC with Low Speed Follow, you can of the following: activate the ACC with Low Speed Follow with the •...
Page 540 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ Automatic cancellation 1To Cancel The beeper sounds and a message appears on the driver information interface when ACC with Low Speed Follow is automatically canceled. Any of these conditions may Models with A-type meter Models with A-type meter cause the ACC with Low Speed Follow to automatically cancel:...
Page 541 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ 1To Switch ACC with Low Speed Follow to Cruise Control To Switch ACC with Low Speed Follow to Cruise Control Always be aware which mode you are in. When you Press and hold the Interval button for one Interval are driving in Cruise mode, the system will not assist...
Page 542 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow ■ To Adjust the Vehicle Speed • Each time you press the RES/+/SET/− switch up or down, the vehicle speed is increased or decreased by about 1 mph or 1 km/h accordingly. •...
Page 543 uuHonda Sensing®uAdaptive Cruise Control (ACC) with Low Speed Follow 1To Cancel Models with A-type meter Prior Set Speed (gray) (white) Models with B-type meter Prior Set Speed (gray) (white) You cannot set or resume in the following situations: • When vehicle speed is less than 25 mph (40 km/h) •...
Page 544: Adaptive Cruise Control (Acc)
uuHonda Sensing®uAdaptive Cruise Control (ACC)* Adaptive Cruise Control (ACC)* Helps maintain a constant vehicle speed and a set following-interval behind a vehicle 1Adaptive Cruise Control (ACC)* detected ahead of yours, without you having to keep your foot on the brake or the WARNING accelerator.
Page 545 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ How to activate the system 1Adaptive Cruise Control (ACC)* You can read about handling information for the How to use camera equipped with this system. (white) is on in the gauge 2 Front Wide View Camera P. 598 ACC is ready to use.
Page 546 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ 1To Set the Vehicle Speed To Set the Vehicle Speed The Vehicle Stability Assist (VSA®) system, Vehicle Stability Assist (VSA®) OFF, Adaptive Cruise Control (green) (ACC), low tire pressure/TPMS and safety support RES/+/SET/− Switch indicators may come on in amber along with a message in the gauge when you set the power mode to ON after reconnecting the battery.
Page 547 uuHonda Sensing®uAdaptive Cruise Control (ACC)* When you use ACC, Straight Driving Assist (a Models with A-type meter feature of the Electric Power Steering system) Set Vehicle Interval is activated. By enabling the steering system to automatically compensate for natural steering pull, Straight Driving Assist makes it easier for you to keep your vehicle in a straight line.
Page 548 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ 1When in Operation When in Operation If the vehicle ahead of you slows down abruptly, or if ■ There is a vehicle ahead another vehicle cuts in front of you, a beeper sounds, ACC monitors if a vehicle ahead of you enters the ACC range. If a vehicle is detected a message appears on the driver information doing so, the ACC system maintains or decelerates your vehicle’s set speed in order interface.
Page 549 uuHonda Sensing®uAdaptive Cruise Control (ACC)* When a vehicle whose speed is slower than Models with A-type meter 1When in Operation your set speed is detected in front of you, your Even if the interval between your vehicle and the vehicle starts to slow down. vehicle detected ahead is short, ACC may start accelerating your vehicle under the following circumstances:...
Page 550 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ There is no vehicle ahead 1When in Operation Your vehicle maintains the set speed without Models with A-type meter • ACC may temporarily control the interval between having to keep your foot on the brake or your vehicle and the vehicle in adjacent lane or accelerator pedal.
Page 551 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ ACC Conditions and Limitations The system may automatically shut off under certain conditions. Some examples of these conditions are listed below. Other conditions may reduce some of the ACC functions. 2 Front Wide View Camera P. 598 ■...
Page 552 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ Roadway conditions • Driving on curvy, winding, undulating, or sloping roads. • Driving on rutted roads (snowy or unpaved roads, etc.). • Puddles or a film of water is on the road surface. • Your vehicle is strongly shaken on uneven road surfaces. ■...
Page 553 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ Examples of conditions under which the camera may not correctly detect the vehicle ahead of you • A vehicle suddenly crosses in front of you. • The interval between your vehicle and the vehicle ahead of you is too short. •...
Page 554 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ Examples of conditions under which the system may not work properly • A vehicle ahead of you stops and the speed difference between your vehicle and the vehicle ahead of you is significantly large. •...
Page 555 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ 1To Adjust the Vehicle Speed To Adjust the Vehicle Speed If a vehicle detected ahead is going at a speed slower Increase or decrease the vehicle speed using the RES/+/SET/− switch on the steering than your increased set speed, ACC may not wheel.
Page 556 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ To Set or Change Following-interval Press the Interval button to change the ACC following-interval. Each time you press the button, the following- interval (the interval behind a vehicle detected ahead of you) setting cycles through furthest, far, mid, and nearest following-intervals.
Page 557 uuHonda Sensing®uAdaptive Cruise Control (ACC)* The higher your vehicle’s following-speed is, the longer the nearest, mid, far or furthest following-interval becomes. See the following examples for your reference. When the Set Speed is: Following-interval 50 mph (80 km/h) 65 mph (104 km/h) 87.3 feet 110.6 feet Nearest...
Page 558 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ 1To Cancel To Cancel Resuming the prior set speed: After you have To cancel ACC, do any of the following: canceled ACC, you can activate the ACC with the • Press the CANCEL button. prior set speed displayed on the gauge (in gray) by indicator (green) on the gauge pressing the RES/+/SET/−...
Page 559 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ Automatic cancellation 1To Cancel The beeper sounds and a message appears on the driver information interface when Models with A-type meter ACC is automatically canceled. Any of these conditions may cause the ACC to Prior Set Speed (gray) automatically cancel: •...
Page 560 uuHonda Sensing®uAdaptive Cruise Control (ACC)* • The engine speed goes into the tachometer’s red zone. • The engine speed goes to below 1,000 rpm. • You shift into neutral temporarily when shifting into a higher or lower gear. • When the transmission is put into N without depressing the clutch pedal.
Page 561 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ 1To Switch ACC to Cruise Control To Switch ACC to Cruise Control Always be aware which mode you are in. When you Press and hold the Interval button for one Interval are driving in Cruise mode, the system will not assist Button second.
Page 562 uuHonda Sensing®uAdaptive Cruise Control (ACC)* ■ To Adjust the Vehicle Speed • Each time you press the RES/+/SET/− switch up or down, the vehicle speed is increased or decreased by about 1 mph or 1 km/h accordingly. • If you keep the RES/+/SET/− switch pressed up or down, the vehicle speed increases or decreases by about 5 mph or 5 km/h accordingly.
Page 563 uuHonda Sensing®uAdaptive Cruise Control (ACC)* 1To Cancel Models with A-type meter Prior Set Speed (gray) (white) Models with B-type meter Prior Set Speed (gray) (white) The set speed cannot be set or resumed when ACC has been turned off using the button.
Page 564: Lane Keeping Assist System (Lkas)
uuHonda Sensing®uLane Keeping Assist System (LKAS) Lane Keeping Assist System (LKAS) Provides steering input to help keep the vehicle in the middle of a detected lane and 1Lane Keeping Assist System (LKAS) provides tactile and visual alerts if the vehicle is detected drifting out of its lane. Important Safety Reminders The LKAS is for your convenience only.
Page 565 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ 1Lane Keeping Assist System (LKAS) Lane Keep Support Function When it fails to detect lanes, the system will Provides assistance to keep the vehicle in the center of the lane. When the vehicle temporarily be canceled.
Page 566 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ Lane Departure Warning Function When the vehicle enters the warning area, the LKAS alerts you with slight steering wheel vibration as well as a warning display. LKAS indicator (green) Amber line Warning Area Warning Area *1: Models with A-type meter *2: Models with B-type meter...
Page 567 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ 1When the System can be Used When the System can be Used If the vehicle drifts toward either left or right lane line The system can be used when the following conditions are met. due to the system applying torque, turn off the LKAS •...
Page 568 uuHonda Sensing®uLane Keeping Assist System (LKAS) 2. Keep your vehicle near the center of the Models with A-type meter lane while driving. Green lines The LKAS indicator changes from white to green, and white lines change to green once the system starts operating after detecting the left and right lane markings.
Page 569 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ To Cancel Press the LKAS button. The LKAS is turned off every time you stop the engine, even if you turned it on the last time you drove the vehicle. LKAS Button...
Page 570 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ The system operation is suspended if Models with A-type meter 1To Cancel you: You can change the setting for the LKAS. White lines • Decrease the vehicle speed to about 40 mph LKAS suspended beep on and off can be selected. (64 km/h) or less.
Page 571 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ The LKAS may be automatically suspended when: • The system fails to detect lane lines. • The steering wheel is turned quickly. • You fail to steer the vehicle. • Driving through a sharp curve. •...
Page 572 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ LKAS Conditions and Limitations The system may not detect lane markings and therefore may not keep the vehicle in the middle of the lane under certain conditions, including the following: ■ Environmental conditions •...
Page 573 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ Roadway conditions • Driving on a road with temporary lane markings. • Faint, multiple, or varied lane markings are visible on the roadway due to road repairs or old lane markings. Faded lines Duplicate lines Tire tracks •...
Page 574 uuHonda Sensing®uLane Keeping Assist System (LKAS) • When objects on the road (curb, guard rail, pylons, etc.) are recognized as white (or yellow) lines. • Driving on rough or unpaved roads, or over bumpy surfaces. • Driving on roads with double lane lines. •...
Page 575 uuHonda Sensing®uLane Keeping Assist System (LKAS) ■ Vehicle conditions • When lighting is weak due to dirt covering the headlight lenses, or there is poor visibility in a dark place due to the headlights being improperly adjusted. • The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals, accessories, stickers, or film on the windshield.
Page 576: Traffic Jam Assist
uuHonda Sensing®uTraffic Jam Assist Traffic Jam Assist The traffic jam assist system uses a camera mounted to the upper portion of the 1Traffic Jam Assist windshield to detect and monitor left and right white (or yellow) traffic lane lines. Important Safety Reminders Based on inputs from the camera, the system can apply steering torque to keep your Traffic Jam Assist is for your convenience only.
Page 577 uuHonda Sensing®uTraffic Jam Assist ■ Lane Departure Warning Function When the vehicle enters the warning area, Traffic Jam Assist alerts you with slight steering wheel vibration or an audible alert as well as a warning display. LKAS indicator (green) Amber line Warning Area Warning Area *1: Models with A-type meter...
Page 578 uuHonda Sensing®uTraffic Jam Assist ■ 1Traffic Jam Assist Activation Traffic Jam Assist Activation Refer to the following page for proper handling of Traffic Jam Assist is activated when all of the following conditions exist: the LKAS: • LKAS is activated. 2 Lane Keeping Assist System (LKAS) P.
Page 579 (or yellow) traffic lane lines while Traffic while driving. Green lines Jam Assist is active, deactivate Traffic Jam Assist and have your vehicle inspected by an authorized Honda The LKAS indicator changes from white dealer. to green, and white lines change to...
Page 580 uuHonda Sensing®uTraffic Jam Assist ■ Canceling Traffic Jam Assist Press the Lane Keeping Assist System (LKAS) button to cancel Traffic Jam Assist. ■ Traffic Jam Assist may be automatically suspended when: 1Traffic Jam Assist may be automatically suspended when: The system is automatically temporarily canceled under the following circumstances. You are traveling over 45mph (72km/h).
Page 581 uuHonda Sensing®uTraffic Jam Assist ■ Traffic Jam Assist Conditions and Limitations The system may not detect lane markings and therefore may not keep the vehicle in the middle of the lane under certain conditions, including the following: ■ Environmental conditions •...
Page 582 uuHonda Sensing®uTraffic Jam Assist ■ Roadway conditions • Driving on a road with temporary lane markings. • Faint, multiple, or varied lane markings are visible on the roadway due to road repairs or old lane markings. Faded lines Duplicate lines Tire tracks •...
Page 583 uuHonda Sensing®uTraffic Jam Assist • When objects on the road (curb, guard rail, pylons, etc.) are recognized as white (or yellow) lines. • Driving on rough or unpaved roads, or over bumpy surfaces. • Driving on roads with double lane lines. •...
Page 584 uuHonda Sensing®uTraffic Jam Assist ■ Vehicle conditions • When lighting is weak due to dirt covering the headlight lenses, or there is poor visibility in a dark place due to the headlights being improperly adjusted. • The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals, accessories, stickers, or film on the windshield.
Page 585: Road Departure Mitigation System
uuHonda Sensing®uRoad Departure Mitigation System Road Departure Mitigation System Alerts and helps assist you when the system detects a possibility of your vehicle 1Road Departure Mitigation System crossing over detected lane markings, or approaching the outer edge of the Important Safety Reminder pavement (into grass or gravel border) or a detected oncoming vehicle.
Page 586 uuHonda Sensing®uRoad Departure Mitigation System The system cancels assisting operations when you turn the steering wheel to avoid 1Road Departure Mitigation System crossing over detected lane markings or approaching the outer edge of the There are times when you may not notice the Road pavement (into grass or gravel border) or an oncoming vehicle.
Page 587 uuHonda Sensing®uRoad Departure Mitigation System ■ 1How the System Activates How the System Activates The Road Departure Mitigation system may The system activates when all of the following conditions are met: automatically shut off and the safety support • The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h). indicator (amber) comes and stays on.
Page 588 uuHonda Sensing®uRoad Departure Mitigation System ■ 1Road Departure Mitigation system On and Off Road Departure Mitigation system On and Off You can also select safety support content from the When you turn the Road Departure Mitigation Models with A-type meter driver information interface.
Page 589 uuHonda Sensing®uRoad Departure Mitigation System ■ Road Departure Mitigation system Conditions and Limitations The system may not properly detect lane markings (in white or yellow), the outer edge of the pavement (into grass or gravel border) or an oncoming vehicle under certain conditions.
Page 590 uuHonda Sensing®uRoad Departure Mitigation System ■ Roadway conditions • Driving on a road with temporary lane markings. • Faint, multiple, or varied lane markings are visible on the roadway due to road repairs or old lane markings. • The roadway has merging, split, or crossing lines, such as at an intersection or crosswalk.
Page 591 uuHonda Sensing®uRoad Departure Mitigation System ■ Vehicle conditions • When lighting is weak due to dirt covering the headlight lenses, or there is poor visibility in a dark place due to the headlights being improperly adjusted. • The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals, accessories, stickers, or film on the windshield.
Page 592 uuHonda Sensing®uRoad Departure Mitigation System ■ Examples of other limitations on detection or system operation • When the oncoming vehicle is specially-shaped. • When the camera cannot correctly identify the shape of the oncoming vehicle. ■ With Little Chance of a Collision The Road Departure Mitigation system may activate in the below conditions.
Page 593: Traffic Sign Recognition System
Models with A-type meter Models with B-type meter recommend that you replace the windshield with a genuine Honda replacement windshield. Making even minor repairs within the camera’s field of vision or Speed Limit Sign installing an aftermarket replacement windshield may also cause the system to operate abnormally.
Page 594 uuHonda Sensing®uTraffic Sign Recognition System 1Traffic Sign Recognition System To help reduce the likelihood that high interior temperatures will cause the camera’s sensing system to shut off, when parking, find a shady area or face the front of the vehicle away from the sun. If you use a reflective sun shade, do not allow it to cover the camera housing.
Page 595 uuHonda Sensing®uTraffic Sign Recognition System ■ 1Traffic Sign Recognition System Conditions and Limitations Traffic Sign Recognition System Conditions and Limitations When the traffic sign recognition system The traffic sign recognition system may not be able to recognize a traffic sign in the malfunctions, appears on the gauge.
Page 596 uuHonda Sensing®uTraffic Sign Recognition System ■ The position or the condition of the traffic sign • The sign is in a place that makes it hard to find. • The sign is located far away from your vehicle. • The sign is located where it is hard for headlight beams to reach. •...
Page 597 uuHonda Sensing®uTraffic Sign Recognition System The traffic sign recognition system may not operate correctly, such as displaying signs that do not adhere to the actual regulations for the roadway or do not exist at all in the following cases. A speed limit sign may display at a higher or lower speed than the actual speed limit.
Page 598 uuHonda Sensing®uTraffic Sign Recognition System ■ Signs Displayed on the Gauge The speed limit sign icon is displayed on the screen. Models with A-type meter Models with B-type meter Speed Limit Sign Speed Limit Sign Speed Limit Sign...
Page 599: Front Wide View Camera
If this occurs, we recommend that you replace the windshield with a This camera is located behind the rearview Front Wide genuine Honda replacement windshield. Making mirror. View Camera even minor repairs within the camera’s field of vision...
Page 600 uuHonda Sensing®uFront Wide View Camera 1Front Wide View Camera If the Some driver assist systems cannot operate: Camera temperature too high message appears: • Use the climate control system to cool down the interior and, if necessary, also use defroster mode with the airflow directed towards the camera.
Page 601: Sonar Sensors
uuHonda Sensing®uSonar Sensors Sonar Sensors ■ Location and range of sensors 1Sonar Sensors The sonar sensors are situated in the front and rear bumpers, and the front grille. For the sonar sensors to work properly, do not: • Place stickers or other objects on or around the sensors.
Page 602 Braking Brake System ■ 1Parking Brake Parking Brake You may hear the electric parking brake system Use the parking brake to keep the vehicle stationary when parked. When the motor operating from the rear wheel area when you parking brake is applied, you can manually or automatically release it. apply or release the parking brake.
Page 603 uuBrakinguBrake System Continuously variable transmission models 1Parking Brake ■ Automatic parking brake feature operation In the following situations, the parking brake If the automatic parking brake feature has been activated: automatically operates. • • The parking brake is applied automatically when you set the power mode to When the vehicle stops with the automatic brake hold system activated for more than 10 minutes.
Page 604 uuBrakinguBrake System Manual transmission models 1Parking Brake Depress the accelerator pedal while releasing the clutch pedal releases the parking If the parking brake cannot be released brake. automatically, release it manually. Use the accelerator pedal to release the parking brake when you are starting the When the vehicle is traveling uphill, the accelerator vehicle facing uphill, or in a traffic jam.
Page 605 uuBrakinguBrake System Continuously variable transmission models ■ Activating and deactivating the automatic parking brake feature 1Parking Brake With the power mode is in ON, carry out the following steps to either activate or In cold climates, the parking brake may freeze in deactivate the automatic parking brake feature.
Page 606 uuBrakinguBrake System To confirm that the parking brake is applied, check if the parking brake and brake system indicator (red) is on. ■ 1Foot Brake Foot Brake Check the brakes after driving through deep water, Your vehicle is equipped with disc brakes at all four wheels. A vacuum power assist or if there is a buildup of road surface water.
Page 607 uuBrakinguBrake System ■ 1Automatic Brake Hold Automatic Brake Hold WARNING Continuously variable transmission models Keeps the brake applied after releasing the brake pedal until the accelerator pedal is Activating the automatic brake hold system pressed. You can use this system while the vehicle is temporarily stopped, like at on steep hills or slippery roads may still traffic lights and in heavy traffic.
Page 608 uuBrakinguBrake System ■ Canceling the system 1Automatic Brake Hold Depress the accelerator pedal while the While the system is activated, you can turn off the transmission is in a position other than P or engine or park the vehicle through the same N .
Page 609 uuBrakinguBrake System Manual transmission models Keeps the brake applied after releasing the brake pedal until you shift into one of the gears other than N and: • Release the clutch pedal on a level road or when facing downhill. • Release the clutch pedal and depress the accelerator pedal when facing uphill. You can use this system while the vehicle is temporarily stopped, like at traffic lights and in heavy traffic.
Page 610 uuBrakinguBrake System ■ Canceling the system Shift into one of the gears other than N and: Clutch Pedal Release the clutch pedal on a level road or when facing downhill. Release the clutch pedal and depress the Goes accelerator pedal when facing uphill. The system is canceled and the vehicle starts to move.
Page 611 uuBrakinguBrake System ■ Turning off the automatic brake hold system 1Turning off the automatic brake hold system While the system is on, press the automatic Make sure to turn off the automatic brake hold brake hold button again. system before using an automated car wash. The automatic brake hold system Goes indicator goes off.
Page 612: Anti-Lock Brake System (Abs)
uuBrakinguAnti-lock Brake System (ABS) Anti-lock Brake System (ABS) ■ 1Anti-lock Brake System (ABS) NOTICE Helps prevent the wheels from locking up, and helps you retain steering control by The ABS may not function correctly if you use a tire of pumping the brakes rapidly, much faster than you can.
Page 613: Brake Assist System
uuBrakinguBrake Assist System Brake Assist System Designed to assist the driver by generating greater braking force when you depress the brake pedal hard during emergency braking. ■ Brake assist system operation Press the brake pedal firmly for more powerful braking. When brake assist operates, the pedal may wiggle slightly and an operating noise may be heard.
Page 614: Parking Your Vehicle
Parking Your Vehicle When Stopped 1. Depress the brake pedal firmly. 1Parking Your Vehicle 2. With the brake pedal depressed, pull up the electric parking brake switch slowly, Continuously variable transmission models but fully. WARNING Continuously variable transmission models The vehicle can roll away if left unattended 3.
Page 615 uuParking Your VehicleuWhen Stopped Always set the parking brake, in particular if you are parked on an incline. 1When Stopped In extremely cold temperatures, the parking brake may freeze up if applied. If such temperatures are expected, do not apply the parking brake but, if parking on a slope, either turn the front wheels so they will contact the curb if the vehicle rolls down the slope or block the wheels to keep the vehicle from...
Page 616 uuParking Your VehicleuParking Sensor System Parking Sensor System The corner and center sensors monitor obstacles around your vehicle, and the 1Parking Sensor System beeper, driver information interface and audio/information screen let you know the Even when the system is on, always confirm if there is approximate distance between your vehicle and the obstacle.
Page 617 uuParking Your VehicleuParking Sensor System ■ Parking sensor system on and off 1Parking Sensor System With the power mode in ON, press the When you set the power mode to ON, the system will parking sensor system button to turn on or off be in the previously selected condition.
Page 618 uuParking Your VehicleuParking Sensor System ■ Screen Operation 1Screen Operation You can switch between split view off and Split View Off The split screen tab disappears, and the split view split view on by touching the split screen tab. returns to the last camera view mode under the following conditions: •...
Page 619 uuParking Your VehicleuParking Sensor System ■ When the distance between your vehicle and detected obstacles becomes shorter Interval Distance between the Bumper and Obstacle Driver information between Indicator Audio/Information Screen interface Corner Sensors Center Sensors beeps Front: About 35-24 in (90-60 cm) Comes on Moderate...
Page 620 uuParking Your VehicleuParking Sensor System ■ 1Turning off All Rear Sensors Turning off All Rear Sensors When you put the transmission into , the indicator 1. Make sure that the parking sensor system is not activated. Set the power mode to in the parking sensor system button blinks as a VEHICLE OFF.
Page 621 uuParking Your VehicleuCross Traffic Monitor Cross Traffic Monitor Monitors the rear corner areas using the radar sensors when reversing, and alerts 1Cross Traffic Monitor you if a vehicle approaching from a rear corner is detected. CAUTION The system is convenient when you are backing out of a parking space. Cross Traffic Monitor cannot detect all approaching vehicles and may not detect an approaching vehicle at all.
Page 622 uuParking Your VehicleuCross Traffic Monitor ■ 1Cross Traffic Monitor How the System Works Cross Traffic Monitor may not detect or may delay The system activates when: alerting an approaching vehicle, or may alert without • The power mode is in ON. an approaching vehicle under the following •...
Page 623 uuParking Your VehicleuCross Traffic Monitor ■ 1When the System Detects a Vehicle When the System Detects a Vehicle If the on the lower right changes to in amber when the transmission is in , mud, snow or ice, Arrow Icon etc.
Page 624 uuParking Your VehicleuCross Traffic Monitor ■ Cross Traffic Monitor On and Off The system can be turned on and off on the audio/information screen by pressing the Cross Traffic Monitor icon. You can also switch the system on and off from the customized feature on the audio/ information screen.
Page 625: Multi-View Rear Camera
Multi-View Rear Camera About Your Multi-View Rear Camera The audio/information screen can display your vehicle’s rear view. 1About Your Multi-View Rear Camera The display automatically changes to the rear view when the transmission is put into The rear camera view is restricted. You cannot see the corner ends of the bumper or what is underneath the bumper.
Page 626 uuMulti-View Rear CamerauAbout Your Multi-View Rear Camera Wide view mode Normal view mode Top down view mode Bumper Bumper Bumper • If you were last using Wide view mode or Normal view mode, the same view mode will be activated the next time you put the transmission into •...
Page 627: Refueling
Top tier detergent gasoline control, we strongly recommend the use of gasoline Because the level of detergency and additives in gasoline vary in the market, Honda that does NOT contain harmful manganese-based endorses the use of “TOP TIER Detergent Gasoline” where available to help fuel additives such as MMT, if such gasoline is available.
Page 628 uuRefuelinguHow to Refuel How to Refuel Your fuel tank is not equipped with a fuel filler cap. You can insert the filler nozzle 1How to Refuel directly into the filler neck. The tank seals itself again when you pull out the filler WARNING nozzle.
Page 629 uuRefuelinguHow to Refuel 6. Place the end of the filler nozzle on the 1How to Refuel lower part of filler opening, then insert it Use the lock tab or the master door lock switch to slowly and fully. unlock the fuel fill door. The vehicle doors and fuel fill door automatically Make sure that the end of the filler relock if the remote unlock function is used.
Page 630: Fuel Economy And Co Emissions
Fuel Economy and CO Emissions Improving Fuel Economy and Reducing CO Emissions Achieving fuel economy and reducing CO emissions is dependent on several 1Improving Fuel Economy and Reducing CO Emissions factors, including driving conditions, load weight, idling time, driving habits, and Direct calculation is the recommended method to vehicle condition.
Page 631: Turbo Engine Vehicle
Turbo Engine Vehicle Handling Precautions The turbocharger is a high-precision device to obtain greater horsepower by 1Turbo Engine Vehicle delivering a large volume of compressed air into the engine using a turbine driven by The scheduled maintenance intervals for replacing the engine’s exhaust gas pressure.
Page 632: Maintenance
Maintenance This chapter discusses basic maintenance. Before Performing Maintenance Engine Coolant ........ 655 Tire and Wheel Replacement ... 674 Inspection and Maintenance .... 632 Transmission Fluid......657 Tire Rotation........675 Safety When Performing Maintenance ..633 Brake/Clutch Fluid ......658 Winter Tires ........
Page 633: Before Performing Maintenance
• Check the tire pressure monthly. Examine the tread for wear and foreign objects. subscription to the Service Express website at 2 Checking and Maintaining Tires P. 668 www.techinfo.honda.com. • Check the operation of the exterior lights monthly. 2 Authorized Manuals P. 737 2 Replacing Light Bulbs P.
Page 634: Safety When Performing Maintenance
uuBefore Performing MaintenanceuSafety When Performing Maintenance Safety When Performing Maintenance Some of the most important safety precautions are given here. However, we cannot 1Safety When Performing Maintenance warn you of every conceivable hazard that can arise in performing maintenance. WARNING Only you can decide whether you should perform a given task.
Page 635: Parts And Fluids Used In Maintenance Service
Performing MaintenanceuParts and Fluids Used in Maintenance Service Parts and Fluids Used in Maintenance Service The use of Honda genuine parts and fluids is recommended when maintaining and 1Parts and Fluids Used in Maintenance Service servicing your vehicle. Honda genuine parts are manufactured according to the 2.0 L engine models...
Page 636: Maintenance Minder
Maintenance Minder If the engine oil life is less than 15%, you will see the Maintenance Minder messages appear on the driver information interface every time you set the power mode to ON. The messages notify you when to change the engine oil, or when to bring your vehicle to a dealer for indicated maintenance services.
Page 637 uuMaintenance Minder uTo Use Maintenance Minder To Use Maintenance Minder ■ Displaying the Maintenance Minder Information 1Displaying the Maintenance Minder Information Based on the engine operating conditions, the Maintenance items, which should be serviced at the same time that you replace the remaining engine oil life is calculated and displayed engine oil, appear on the driver information interface.
Page 638 uuMaintenance Minder uTo Use Maintenance Minder Models with B-type meter 1. Set the power mode to ON. 2. Roll the right selector wheel until the Maintenance Minder screen is displayed. The engine oil life appears on the driver information interface along with maintenance items due soon.
Page 639 uuMaintenance Minder uTo Use Maintenance Minder ■ Maintenance Minder Messages on the Driver Information Interface Maintenance Message Oil Life Display Explanation Information When you select the Maintenance Minder screen, it displays codes for maintenance items due at the next engine oil change, along with the percentage of engine oil life remaining.
Page 640 uuMaintenance Minder uTo Use Maintenance Minder Maintenance Message Oil Life Display Explanation Information Maintenance Due Now The remaining engine oil life The engine oil has almost reached the end of its service is 5 to 1 percent. life, and the maintenance items Models with A-type meter should be inspected and Press the...
Page 641 uuMaintenance Minder uTo Use Maintenance Minder ■ Maintenance Service Items Maintenance Minder Message System Message Indicator Main Item Sub Items *1: Models with A-type meter *2: Models with B-type meter...
Page 642 uuMaintenance Minder uTo Use Maintenance Minder U.S. models 1Maintenance Service Items • Adjust the valves during services A, B, 1, 2, or 3 if they are noisy. CODE Maintenance Main Items CODE Maintenance Sub Items ● Replace engine oil ● Rotate tires Replace engine oil and oil filter...
Page 643 uuMaintenance Minder uTo Use Maintenance Minder Canadian models 1Maintenance Service Items • Adjust the valves during services A, 0, 9, 1, 2, or 3 if they are noisy. CODE Maintenance Main Items CODE Maintenance Sub Items Replace engine oil Rotate tires ●...
Page 644 uuMaintenance Minder uTo Use Maintenance Minder ■ 1Resetting the Display Resetting the Display NOTICE Reset the maintenance minder information display if you have performed the Failure to reset the Maintenance Minder display maintenance service. after a maintenance service results in the system Models with A-type meter showing incorrect maintenance intervals, which can lead to serious mechanical problems.
Page 645 uuMaintenance Minder uTo Use Maintenance Minder Models with B-type meter Right Selector Wheel 1. Set the power mode to ON. 2. Roll the right selector wheel until the Maintenance Minder screen is displayed. 3. Press and hold the right selector wheel for about 10 seconds to enter the reset mode.
Page 646: Maintenance Under The Hood
Maintenance Under the Hood Maintenance Items Under the Hood 1.5 L engine models Brake/Clutch Fluid (Black Cap) Engine Oil Fill Cap Washer Fluid (Blue Cap) Engine Coolant Reserve Tank Battery Engine Oil Dipstick (Orange) Radiator Cap * Not available on all models Continued...
Page 647 uuMaintenance Under the HooduMaintenance Items Under the Hood 2.0 L engine models Engine Oil Dipstick (Orange) Brake/Clutch Engine Oil Fill Cap Fluid (Black Cap) Washer Fluid (Blue Cap) Battery Engine Coolant Reserve Tank Radiator Cap * Not available on all models...
Page 648: Opening The Hood
uuMaintenance Under the HooduOpening the Hood Opening the Hood 1. Park the vehicle on a level surface, and set 1Opening the Hood Hood Release Handle the parking brake. WARNING 2. Pull the hood release handle under the driver’s side lower corner of the dashboard. The hood support rod can become very hot The hood will pop up slightly.
Page 649: Recommended Engine Oil
The following seal indicates the oil is energy Genuine Engine Oil Commercial Engine Oil conserving and that it meets the American Petroleum Honda Genuine Motor Oil Premium-grade 0W-20 detergent oil ● ● Institute’s latest requirements.
Page 650: Oil Check
uuMaintenance Under the HooduOil Check Oil Check We recommend that you check the engine oil level every time you refuel. 1Oil Check Park the vehicle on level ground. If the oil level is near or below the lower mark, slowly Wait approximately three minutes after turning the engine off before you check the add oil, being careful not to overfill.
Page 651 uuMaintenance Under the HooduOil Check 4. Remove the dipstick again, and check the 1Oil Check 1.5 L engine models level. It should be between the upper and NOTICE lower marks. Add oil if necessary. Under certain driving conditions, it is normal for the engine oil level to rise above the upper mark.
Page 652: Adding Engine Oil
uuMaintenance Under the HooduAdding Engine Oil Adding Engine Oil 1. Unscrew and remove the engine oil fill cap. 1Adding Engine Oil 1.5 L engine models 2. Add oil slowly. NOTICE 3. Reinstall the engine oil fill cap, and tighten Do not fill the engine oil above the upper mark. it securely.
Page 653: Changing The Engine Oil And Oil Filter
uuMaintenance Under the HooduChanging the Engine Oil and Oil Filter Changing the Engine Oil and Oil Filter You must change the engine oil and oil filter regularly in order to maintain the 1Changing the Engine Oil and Oil Filter engine’s lubrication. The engine may be damaged if they are not changed regularly. NOTICE You may damage the environment if you do not Change the oil and filter in accordance with the maintenance message on the driver...
Page 654 uuMaintenance Under the HooduChanging the Engine Oil and Oil Filter 4. Remove the drain bolt and washer from 1.5 L engine models the bottom of the engine, and drain the oil into a suitable container. Drain Bolt Washer 2.0 L engine models Drain Bolt Washer Continued...
Page 655 uuMaintenance Under the HooduChanging the Engine Oil and Oil Filter 5. Remove the oil filter and dispose of the 1Changing the Engine Oil and Oil Filter 1.5 L engine models remaining oil. You will need a special wrench to replace the oil 6.
Page 656: Engine Coolant
Reserve Tank NOTICE 1. Make sure the engine and radiator are Reserve Tank Genuine Honda engine coolant is a 50/50 mixture of cool. antifreeze and water that can withstand freezing at 2. Check the amount of coolant in the reserve temperatures as low as about −31°F (−35°C).
Page 657 uuMaintenance Under the HooduEngine Coolant ■ 1Engine Coolant Radiator Do not add rust inhibitors or other additives to your 1. Make sure the engine and radiator are vehicle’s cooling system. They may not be compatible cool. with the coolant or with the engine components. 2.
Page 658: Transmission Fluid
Manual Transmission Fluid NOTICE Specified fluid: Honda MTF If Honda MTF is not available, you may use the API certificated SAE 0W-20 or 5W-20 viscosity motor oil as a Have a dealer check the fluid level and replace if necessary.
Page 659: Brake/Clutch
Under the HooduBrake/Clutch Fluid Brake/Clutch Fluid 1Brake/Clutch Fluid Specified fluid: Honda Heavy Duty Brake Fluid DOT 3 NOTICE ■ Checking the Brake Fluid Brake fluid marked DOT 5 is not compatible with your vehicle’s braking system and can cause extensive The fluid level should be between the MIN damage.
Page 660: Refilling Window Washer Fluid
uuMaintenance Under the HooduRefilling Window Washer Fluid Refilling Window Washer Fluid Check the amount of window washer fluid. 1Refilling Window Washer Fluid If the level is low, fill the washer reservoir. NOTICE Do not use engine antifreeze or a vinegar/water Canadian models solution in the windshield washer reservoir.
Page 661: Replacing Light Bulbs
Fog Lights readjusted at a dealer or by a qualified technician. Fog lights are LED type. Have an authorized Honda dealer inspect and replace the light assembly. Front Turn Signal Lights Front turn signal lights are LED type.
Page 662 Signal Light Bulbs When replacing, use the following bulbs. Brake lights, taillights, and rear side marker lights are Brake Light: LED LED type. Have an authorized Honda dealer inspect Taillight: LED and replace the light assembly. Rear Side Marker Light: LED Rear Turn Signal Light: 21 W (Amber) 1.
Page 663 uuReplacing Light BulbsuBrake Light, Taillight, Rear Side Marker Light, and Rear Turn Signal Light Bulbs 4. Turn the socket counter-clockwise and remove it. 5. Remove the old bulb and insert a new bulb. 6. Align the pins with the body grommets, then push in until they fully seat.
Page 664 2. Turn the socket counter-clockwise and Bulb remove it. 3. Remove the old bulb and insert a new bulb. Socket Rear License Plate Light Rear license plate light is LED type. Have an authorized Honda dealer inspect and replace the light assembly.
Page 665 Light BulbsuHigh-Mount Brake Light High-Mount Brake Light High-mount brake light is LED type. Have an authorized Honda dealer inspect and replace the light assembly.
Page 666: Checking And Maintaining Wiper Blades
Checking and Maintaining Wiper Blades Checking Wiper Blades If the wiper blade rubber has deteriorated, it will leave streaks, become noisy, and the hard surfaces of the blade may scratch the window glass. Changing the Front Wiper Blade 1. Set the power mode to ON, then to 1Changing the Front Wiper Blade VEHICLE OFF.
Page 667 uuChecking and Maintaining Wiper BladesuChanging the Front Wiper Blade 4. Depress the lock tab, then slide the wiper blade off the wiper arm. 5. Slide the new wiper blade onto the wiper arm until it clicks into place. 6. Lower both wiper arms. 7.
Page 668 uuChecking and Maintaining Wiper BladesuChanging the Rear Wiper Blade Changing the Rear Wiper Blade 1. Hold up the wiper arm. 2. Insert a flat-tip screwdriver into the groove of the wiper arm to remove the wiper blade. Wrap the flat-tip screwdriver with a cloth to prevent scratches.
Page 669: Checking Tires
Checking and Maintaining Tires Checking Tires To safely operate your vehicle, your tires must be of the proper type and size, in 1Checking Tires good condition with adequate tread, and properly inflated. WARNING ■ Inflation guidelines Using tires that are excessively worn or Properly inflated tires provide the best combination of handling, tread life, and improperly inflated can cause a crash in comfort.
Page 670: Tire And Loading Information Label
uuChecking and Maintaining TiresuTire and Loading Information Label Tire and Loading Information Label The label attached to the driver’s doorjamb provides necessary tire and loading 1Tire and Loading Information Label information. The tire and loading information label attached to the driver’s doorjamb contains: The number of people your vehicle can carry.
Page 671 uuChecking and Maintaining TiresuTire Labeling ■ 1Tire Identification Number (TIN) Tire Identification Number (TIN) DOT B97R FW6X 2209 The tire identification number (TIN) is a group of numbers and letters that look like DOT: This indicates that the tire meets all the example in the side column.
Page 672: Dot Tire Quality Grading (U.s. Vehicles)
uuChecking and Maintaining TiresuDOT Tire Quality Grading (U.S. Vehicles) DOT Tire Quality Grading (U.S. Vehicles) The tires on your vehicle meet all U.S. Federal Safety Requirements. All tires are also graded for treadwear, traction, and temperature performance according to Department of Transportation (DOT) standards.
Page 673 uuChecking and Maintaining TiresuDOT Tire Quality Grading (U.S. Vehicles) ■ 1Traction Traction Warning: The traction grade The traction grades, from highest to lowest, are AA, A, B, and C. assigned to this tire is based on Those grades represent the tire's ability to stop on wet pavement straight-ahead braking traction tests, as measured under controlled conditions on specified and does not include acceleration,...
Page 674: Wear Indicators
uuChecking and Maintaining TiresuWear Indicators Wear Indicators The groove where the wear indicator is located is about 1/16 inch (about 1.6 mm) Example of a Wear Indicator mark shallower than elsewhere on the tire. If the tread has worn so that the indicator is exposed, replace the tire.
Page 675: Tire And Wheel Replacement
uuChecking and Maintaining TiresuTire and Wheel Replacement Tire and Wheel Replacement Replace your tires with radials of the same size, load range, speed rating, and 1Tire and Wheel Replacement maximum cold tire pressure rating (as shown on the tire’s sidewall). Using tires of a WARNING different size or construction can cause certain vehicle systems such as the ABS and Vehicle Stability Assist...
Page 676: Tire Rotation
uuChecking and Maintaining TiresuTire Rotation Tire Rotation Rotating tires according to the maintenance messages on the driver information 1Tire Rotation interface helps to distribute wear more evenly and increase tire life. Tires with directional tread patterns should only be rotated front to back (not from one side to the other). ■...
Page 677: Winter Tires
uuChecking and Maintaining TiresuWinter Tires Winter Tires If driving on snowy or frozen roads, mount all season marked M+S tires, snow tires, 1Winter Tires or tire chains; reduce speed; and maintain sufficient distance between vehicles when WARNING driving. Using the wrong chains, or not properly Be particularly careful when operating the steering wheel or brakes to prevent installing chains, can damage the brake skidding.
Page 678 uuChecking and Maintaining TiresuWinter Tires For tire chains: 1Winter Tires • Install them on the front tires only. When tire chains are mounted, follow the chain • Because your vehicle has limited tire clearance, we strongly recommend using the manufacturer’s instructions regarding vehicle chains listed below: operational limits.
Page 679: Battery
Battery Checking the Battery The condition of the battery is monitored by a 1Battery sensor located on the negative terminal of the WARNING battery. If there is a problem with this sensor, the driver information interface will display a The battery gives off explosive hydrogen warning message.
Page 680 uuBatteryuCharging the Battery Charging the Battery Disconnect both battery cables to prevent damaging your vehicle’s electrical system. 1Battery Always disconnect the negative (–) cable first, and reconnect it last. When you find corrosion, clean the battery terminals by applying a baking powder and water solution. Clean the terminals with a damp towel.
Page 681: Remote Transmitter Care
Remote Transmitter Care Replacing the Remote Battery If the indicator does not come on when the button is pressed, replace the battery. 1Replacing the Remote Battery Battery type: CR2032 WARNING 1. Remove the built-in key. CHEMICAL BURN HAZARD The battery that powers the remote transmitter can cause severe internal burns and can even lead to death if swallowed.
Page 682: Climate Control System Maintenance
Climate Control System Maintenance Air Conditioning To ensure proper and safe operation, the Society of Automotive Engineers (SAE 1Air Conditioning J2845) recommends that the refrigerant system only be serviced by trained and NOTICE certified technicians. Vented refrigerant is harmful to the environment. To avoid refrigerant from venting, never replace the Never repair or replace the air conditioning evaporator (cooling coil) with one evaporator with one removed from a used or...
Page 683: Interior Care
Cleaning Interior Care Use a damp cloth with a mixture of mild detergent and warm water to remove dirt. 1Interior Care Use a clean cloth to remove detergent residue. Do not spill liquids inside the vehicle. Electrical devices and systems may malfunction if liquids are ■...
Page 684 uuCleaninguInterior Care ■ 1Floor Mats Floor Mats If you use any floor mats that were not originally The driver’s floor mat hooks over floor provided with your vehicle, make sure they are anchors, which keep the mat from sliding designed for your specific vehicle, fit correctly, and forward.
Page 685: Exterior Care
uuCleaninguExterior Care Exterior Care Dust off the vehicle body after you drive. Regularly inspect your vehicle for scratches on painted surfaces. A scratch on a painted surface can result in body rust. If you find a scratch, promptly repair it. ■...
Page 686 uuCleaninguExterior Care ■ 1Applying Wax Applying Wax NOTICE A good coat of automotive body wax helps protect your vehicle’s paint from the Chemical solvents and strong cleaners can damage elements. Wax will wear off over time and expose your vehicle’s paint to the the paint, metal, and plastic on your vehicle.
Page 687 uuCleaninguExterior Care ■ Fogged Exterior Light Lenses The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily if you have driven in the rain, or after the vehicle has been run through a car wash. Dew condensation also may build up inside the lenses when there is a significant enough difference between the ambient and inside lens temperatures (similar to vehicle windows fogging up in rainy conditions).
Page 688: Accessories And Modifications
2 Fuses P. 714 • Before installing any electronic accessory, have the installer contact a dealer for Honda Genuine accessories are recommended to ensure proper operation on your vehicle. assistance. If possible, have a dealer inspect the final installation.
Page 689: Modifications
The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle is intended to be used with automobile system diagnostic devices or with other devices that Honda has approved. Use of any other type of device may adversely affect the vehicle’s electronic systems or allow them to be compromised, possibly resulting in a system malfunction, drained battery, or other unexpected problems.
Page 690: Handling The Unexpected
Handling the Unexpected This chapter explains how to handle unexpected troubles. Tools Overheating If the Electric Power Steering (EPS) System Types of Tools ........690 How to Handle Overheating..... 706 Indicator Comes On ....... 711 If a Tire Goes Flat Indicator, Coming On/Blinking If the Low Tire Pressure/TPMS Indicator Changing a Flat Tire ......
Page 691: Tools
Tools Types of Tools 1Types of Tools The tools are stored in the cargo area. Wheel Nut Wrench/ Jack Jack Handle Jack Handle Bar Funnel Tool Case...
Page 692: If A Tire Goes Flat
If a Tire Goes Flat Changing a Flat Tire If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually 1Changing a Flat Tire to reduce speed. Then, stop in a safe place. Replace the flat tire with a compact Follow compact spare precautions: spare tire.
Page 693 uuIf a Tire Goes FlatuChanging a Flat Tire ■ Getting Ready to Replace the Flat Tire 1. Pull the strap on the floor lid and open the lid. Strap 2. Take the tool case out of the cargo area. 3. Take the jack, wheel nut wrench, and jack Tool Case handle bar out of the tool case.
Page 694 uuIf a Tire Goes FlatuChanging a Flat Tire 6. Place the compact spare tire (wheel side up) under the vehicle body, near the tire that needs to be replaced. 7. Loosen each wheel nut about one turn using the wheel nut wrench. Continued...
Page 695 uuIf a Tire Goes FlatuChanging a Flat Tire ■ 1How to Set Up the Jack How to Set Up the Jack WARNING 1. Place the jack under the jacking point closest to the tire to be changed. The vehicle can easily roll off the jack, seriously injuring anyone underneath.
Page 696 uuIf a Tire Goes FlatuChanging a Flat Tire ■ 1Replacing the Flat Tire Replacing the Flat Tire Do not over tighten the wheel nuts by applying extra 1. Remove the wheel nuts and flat tire. torque using your foot or a pipe. 2.
Page 697 uuIf a Tire Goes FlatuChanging a Flat Tire ■ 1Storing the Flat Tire Storing the Flat Tire WARNING 1. Remove the center cap. Loose items can fly around the interior in a crash and can seriously injure the occupants. Store the wheel, jack, and tools securely Center Cap before driving.
Page 698 uuIf a Tire Goes FlatuChanging a Flat Tire U.S. models ■ TPMS and the Compact Spare Tire If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator comes on while you are driving. After driving for a few miles (kilometers), Tire pressure monitor system problem.
Page 699: Engine Does Not Start
Engine Does Not Start Checking the Engine If the engine does not start, check the starter. 1Checking the Engine If you must start the vehicle immediately, use an assisting vehicle or booster battery to jump start it. 2 If the Battery Is Dead P. 702 Starter condition Checklist Starter doesn’t turn or turns...
Page 700: If The Keyless Remote Battery Is Weak
uuEngine Does Not StartuIf the Keyless Remote Battery is Weak If the Keyless Remote Battery is Weak If the beeper sounds, the To start, touch start button with emblem side of remote message appears on the driver information interface, and the ENGINE START/STOP button flashes, and the engine won’t start, start the engine as follows: 1.
Page 701: Emergency Engine Start
uuEngine Does Not StartuEmergency Engine Start Continuously variable transmission models Emergency Engine Start If the engine does not start using the normal engine starting procedure, you may be 1Emergency Engine Start able to start it using the emergency start procedure below. Refer to the following if you cannot move the shift lever out of the position.
Page 702: Emergency Engine Stop
uuEngine Does Not StartuEmergency Engine Stop Emergency Engine Stop The ENGINE START/STOP button may be used to stop the engine due to an 1Emergency Engine Stop emergency situation even while driving. If you must stop the engine, do either of the Do not press the ENGINE START/STOP button while following operations: driving unless it is absolutely necessary for the engine...
Page 703: If The Battery Is Dead
If the Battery Is Dead Jump Starting Procedure Turn off the power to electric devices, such as audio and lights. Turn off the engine, 1If the Battery Is Dead then open the hood. WARNING 1. Open the cover on the positive + terminal. 1.5 L engine models 2.
Page 704 uuIf the Battery Is DeaduJump Starting Procedure 5. Connect the other end of the second 1If the Battery Is Dead 1.5 L engine models jumper cable to the stud bolt as shown. Do Battery performance degrades in cold conditions and not connect this jumper cable to any other may prevent the engine from starting.
Page 705 uuIf the Battery Is DeaduJump Starting Procedure ■ 1What to Do After the Engine Starts What to Do After the Engine Starts The Vehicle Stability Assist (VSA®) system, Vehicle Once your vehicle’s engine has started, remove the jumper cables in the following Stability Assist (VSA®) OFF, Adaptive Cruise Control order.
Page 706: Shift Lever Does Not Move
Shift Lever Does Not Move Continuously variable transmission models Follow the procedure below if you cannot move the shift lever out of the position. ■ Releasing the Lock 1. Set the parking brake. Cover 2. Remove the built-in key from the keyless remote.
Page 707: Overheating
Overheating How to Handle Overheating Overheating symptoms are as follows: 1How to Handle Overheating Models with B-type meter WARNING • The temperature gauge pointer is at the mark or the engine suddenly loses Steam and spray from an overheated power. engine can seriously scald you.
Page 708 uuOverheatinguHow to Handle Overheating ■ Next thing to do 1How to Handle Overheating 1. Check that the cooling fan is operating and Reserve Tank WARNING stop the engine once the Engine temperature too hot. Do not drive. Removing the radiator cap while the Allow engine to cool.
Page 709: If The Engine Oil Pressure Low Warning
Indicator, Coming On/Blinking If the Engine oil pressure low Warning Appears ■ Reasons for the warning to appear 1If the Engine oil pressure low Warning Appears Appears when the engine oil pressure is low. NOTICE ■ What to do as soon as the warning Running the engine with low oil pressure can cause appears serious mechanical damage almost immediately.
Page 710: If The Malfunction Indicator Lamp Comes On Or Blinks
uuIndicator, Coming On/BlinkinguIf the Charging System Indicator Comes On If the Charging System Indicator Comes On ■ Reasons for the indicator to come on 1If the Charging System Indicator Comes On Comes on when there is a problem with the charging system. If you need to stop temporarily, do not turn off the ■...
Page 711: If The Brake System Indicator (Red) Comes On Or Blinks
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator (Red) Comes On or Blinks If the Brake System Indicator (Red) Comes On or Blinks ■ Reasons for the indicator to come on 1If the Brake System Indicator (Red) Comes On or Blinks U.S.
Page 712: If The Electric Power Steering (Eps) System Indicator Comes On
uuIndicator, Coming On/BlinkinguIf the Electric Power Steering (EPS) System Indicator Comes On If the Electric Power Steering (EPS) System Indicator Comes On ■ Reasons for the indicator to come on Comes on when there is a problem with the EPS system. ■...
Page 713: If The Brake System Indicator (Red) Comes On Or Blinks At The Same Time When The Brake System Indicator (Amber) Comes On
uuIndicator, Coming On/BlinkinguIf the Brake System Indicator (Red) Comes On or Blinks at the Same Time When the Brake System Indicator (Amber) Comes On If the Brake System Indicator (Red) Comes On or Blinks at the Same Time When the Brake System Indicator (Amber) Comes On If the Brake System Indicator (Red) Comes On or Blinks at the Same ■...
Page 714: If The Low Tire Pressure/Tpms Indicator Comes On Or Blinks
uuIndicator, Coming On/BlinkinguIf the Low Tire Pressure/TPMS Indicator Comes On or Blinks U.S. models If the Low Tire Pressure/TPMS Indicator Comes On or Blinks 1If the Low Tire Pressure/TPMS Indicator Comes On or Blinks ■ Reasons for the indicator to come on or blink NOTICE A tire pressure is significantly low, or the TPMS has not been calibrated.
Page 715: Fuse Locations
Fuses Fuse Locations If any electrical devices are not working, set the power mode to VEHICLE OFF and check to see if any applicable fuse is blown. ■ Engine Compartment Fuse Box Located near the battery. Push the tabs to open the box. Fuse locations are shown on the fuse box cover.
Page 716 uuFusesuFuse Locations ■ Circuit protected and fuse rating Circuit Protected Amps Circuit Protected Amps ST MAGNETIC SW 30 A (15 A) Circuit Protected Amps WIPER 30 A LCM L (15 A) BATTERY 125 A 70 A (15 A) 40 A R/M1 30 A STOP...
Page 717 uuFusesuFuse Locations ■ Interior Fuse Box Located under the dashboard. Fuse locations are shown on the label under the steering column. Locate the fuse in question by the fuse number and label number. Fuse Box Sub Fuse Box Fuse Label...
Page 718 uuFusesuFuse Locations ■ Circuit protected and fuse rating Circuit Protected Amps Circuit Protected Amps 10 A AS P/SEAT SLI (20 A) Circuit Protected Amps ACG / D/V / ST CUT RLY 20 A OPTION1 / FUEL LID 10 A P/W DR 20 A OPTION5 10 A...
Page 719: Inspecting And Changing Fuses
uuFusesuInspecting and Changing Fuses Inspecting and Changing Fuses 1. Set the power mode to VEHICLE OFF. Turn 1Inspecting and Changing Fuses headlights and all accessories off. NOTICE Hole 2. Remove the fuse box cover. Replacing a fuse with one that has a higher rating 3.
Page 720 uuFusesuInspecting and Changing Fuses 4. Check the combined fuses in the engine 1Inspecting and Changing Fuses compartment fuse box. There is a fuse puller on the back of the engine Look into the space between the fuses. compartment fuse box cover. If the fuse is blown, have it replaced by a dealer.
Page 721: Emergency Towing
Emergency Towing Call a professional towing service if you need to tow your vehicle. 1Emergency Towing NOTICE ■ Flatbed equipment Trying to lift or tow your vehicle by the bumpers will The operator loads your vehicle on the back of a truck. cause serious damage.
Page 722: If You Cannot Unlock The Fuel Fill Door
If You Cannot Unlock the Fuel Fill Door ■ 1If You Cannot Unlock the Fuel Fill Door What to Do If Unable to Unlock the Fuel Fill Door After taking these steps, contact a dealer to have the If you cannot unlock the fuel fill door, use the following procedure. vehicle checked.
Page 723: If You Cannot Open The Hatch
If You Cannot Open the Hatch ■ 1If You Cannot Open the Hatch What to Do If Unable to Open the Hatch When you open the hatch from inside, make sure If you cannot open the hatch, use the following procedure. there is enough space around the hatch, and it does 1.
Page 724: Refueling
Refueling Refueling From a Portable Fuel Container If you have run out of fuel and need to refuel your vehicle from a portable fuel 1Refueling From a Portable Fuel Container container, use the funnel provided with your vehicle. WARNING 1. Turn off the engine. 2.
Page 726: Information
Information This chapter includes your vehicle's specifications, locations of identification numbers, and other information required by regulation. Specifications ........726 Emissions Testing Identification Numbers Testing of Readiness Codes....731 Vehicle Identification Number (VIN), Warranty Coverages ......734 Engine Number, and Transmission Authorized Manuals......
Page 727: Specifications
Specifications ■ ■ ■ Vehicle Specifications Engine Specifications Light Bulbs Model Civic 91.38 cu-in (1,498 cm Headlights (Low Beam) Displacement 121.76 cu-in (1,996 cm No. of Passengers: Headlights (High Beam) DILKAR8P8SY Front Fog Lights DILKAR7H11GS Rear Parking/Daytime Running Lights Spark Plugs DILKAR7G11GS Total Front Side Marker Lights...
Page 728 ■ ■ ■ Brake/Clutch Fluid Engine Oil Tire Specified Honda Heavy Duty Brake Fluid DOT 3 Honda Genuine Motor Oil 0W-20 215/55R16 93H Recommended API Premium-grade 0W-20 detergent oil Size 215/50R17 91H 235/40R18 91W 3.4 US qt (3.2 L) ■...
Page 729: Identification Numbers
Identification Numbers Vehicle Identification Number (VIN), Engine Number, and Transmission Number Your vehicle has a 17-digit vehicle identification number (VIN) used to register your 1Vehicle Identification Number (VIN), Engine Number, and vehicle for warranty purposes, and for licensing and insuring your vehicle. Transmission Number The locations of your vehicle’s VIN, engine number, and transmission number are The interior vehicle identification number (VIN) is...
Page 730: Devices That Emit Radio Waves
Devices that Emit Radio Waves Each radio frequency device installed in the vehicle conforms to the requirements and standards of the regulation listed below: As required by the FCC: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
Page 731: Reporting Safety Defects
However, Transport Canada cannot become involved in individual problems between you, your dealer, or Honda Canada Inc. To contact Transport Canada’s Defect Investigations and Recalls Division, you may call 1-800-333-0510. For more information on reporting safety defects or about motor vehicle safety, go to http://www.tc.gc.ca/...
Page 732: Emissions Testing
Emissions Testing Testing of Readiness Codes Your vehicle has readiness code as part of the onboard self diagnostic system. 1Testing of Readiness Codes Some states use these codes for testing to verify whether your vehicle’s emissions The readiness codes are erased when the battery is components are working properly.
Page 733 uuEmissions TestinguTesting of Readiness Codes 7. Select a nearby, lightly traveled major highway where you can maintain a speed of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway D (continuously variable transmission) or 5th (manual). Do not use cruise control.
Page 734 uuEmissions TestinguTesting of Readiness Codes 8. Select a nearby, lightly traveled major highway where you can maintain a speed of 50 to 60 mph (80 to 97 km/h) for at least 20 minutes. Drive on the highway D (continuously variable transmission) or 5th (manual). Do not use cruise control.
Page 735: Warranty Coverages
Rust Perforation Limited Warranty – all exterior body panels are covered against rusting from the inside out for the specified time period, regardless of mileage. Accessory Limited Warranty – Honda accessories are covered under this warranty. Time and mileage limits depend on the type of accessory and other factors.
Page 736 Replacement Muffler Lifetime Limited Warranty – provides coverage for as long as the purchaser of the muffler owns the vehicle. Restrictions and exclusions apply to all these warranties. Please read the Honda warranty information booklet that came with your vehicle for precise information on warranty coverages.
Page 737 uuWarranty Coveragesu ■ Canadian Owners Please refer to the warranty manual that came with your vehicle. ■ EPA Contact Information An owner may obtain further information concerning emission warranties or report violations of the terms of the emission warranties by contacting: Director, Light-Duty Vehicle Center, U.S.
Page 738: Authorized Manuals
■ Service Express For electronic copies of service publications, you can purchase a subscription to Service Express. Visit www.techinfo.honda.com for pricing and options. ■ For U.S. Owners Manuals can be purchased from Helm Incorporated. You can order a manual by phone at 1 (800) 782-4356 (credit card orders only), or online at www.helminc.com.
Page 739: Customer Service Information
Customer Service Information Honda dealership personnel are trained professionals who should be able to deal 1Customer Service Information with any problems you may encounter with your vehicle. If, however, you are faced When you call or write, please give us the following...
Page 740 Index Index Numbers Defrosting the Windshield and Display Setup ........250, 292 Windows ..........235 Error Messages........343 7-Speed Manual Shift Mode ....461 Dust and Pollen Filter ....... 681 General Information ........ 345 Operation ..........462 Recirculation/Fresh Air Mode ....234 Home Screen...........
Page 741 Automatic Brake Hold......606 Brightness Control Child Seat for Infants ........ 75 Indicator ..........94, 606 (Instrument Panel)......201, 202 Child Seat for Small Children ....76 Automatic Brake Hold System Built-in Key ..........161 Installing a Child Seat with a Lap/Shoulder Indicator ..........
Page 742 Operating the Shift Lever ..28, 458, 460 Doors ............160 Emergency ..........720 Shift Lever Does Not Move...... 705 Auto Door Locking ........175 Emergency Engine Stop ......701 Shifting........... 457, 459 Auto Door Unlocking....... 175 Emergency Hatch Opener......722 Controls ............
Page 743 Economy ..........629 HomeLink® Universal Transceiver ... 398 Automatic Import of Cellular Phonebook Gauge ............. 113 Honda App License Agreement ....347 and Call History ......413, 431 Instant Fuel Economy....... 119, 145 Honda Sensing® ........ 32, 495 Automatic Transferring....411, 430 Low Fuel Indicator ........
Page 744 Immobilizer System........179 Malfunction Indicator Lamp ....95, 709 Indicator ..........104 NORMAL Mode ....... 103, 478 Jack (Wheel Nut Wrench) ......694 Indicators............ 90 Parking Brake and Brake System Jump Starting ........... 702 Adaptive Cruise Control (ACC)....543 (Amber) ........... 94, 712 Adaptive Cruise Control (ACC) with Low Parking Brake and Brake System Speed Follow ........
Page 745 Load Limits ..........445 Tires ............668 Recommended Engine Oil ....... 648 Locking/Unlocking ........160 Transmission Fluid ........657 Viscosity..........648 Auto Door Locking/Unlocking ....175 Under the Hood ........645 Open Source Licenses ......361 Childproof Door Locks ......174 Malfunction Indicator Lamp....
Page 746 Pregnant Women........51 Road Departure Mitigation ..... 584 Selecting a Child Seat......... 77 Puncture (Tire) ......... 691 On and Off ..........587 Selector Knob (Audio)......248 Setting the Clock ........158 Settings ............. 129 Shift Lever......28, 457, 459, 463 Radio (FM/AM) .........
Page 747 Sunglasses Holder ........221 Winter............. 676 Turn Signals..........189 Supplemental Restraint System (SRS) ..56 Tools............690 Indicators (Instrument Panel) ....101 Switches Towing Your Vehicle........ 447 (Around the Steering Wheel)..8, 9, 186 Emergency ..........720 System Message Indicator ......102 TPMS Unlocking the Doors........
Page 748 Wallpaper..........278 Warning Indicator On/Blinking....708 Warning Labels .......... 88 Warnings .......... 128, 154 Warranties (Warranty Manual provided separately) ..........734 Watts ............726 Wear Indicators (Tire) ......673 Wheel Nut Wrench (Jack Handle)... 694 Wi-Fi Connection ........328 Window Washers ........197 Adding/Refilling Fluid ......

Honda Civic Hatch 2022 Owner's Manual

Of Your Vehicle, You May Request a Complimentary Printed

Safe Driving

Instrument Panel

Controls

Features

Driving

Maintenance

Handling the Unexpected

Quick Links

Chapters

Related Manuals for Honda Civic Hatch 2022

Summary of Contents for Honda Civic Hatch 2022
