- Page 2 Service Data Table Engine and Electrical Name of part Project Complement Standard value Limit Ignition timing When idling N Or P position BTDC0±2° (When SCS is short ） Spark Plug Electrode space 1.0－1.1mm Ignition coil Ignition sequence 1－3－4－2 Starter Motor Mica Depth 0.4－0.5mm 0.15mm...
- Page 3 Pin Oil Clearance 0.050mm 0.020－0.038mm Recommended Recommended Engine Oil Honda Genuine oil ULTRA NEXT * Engine Oil (Honda's new fuel-saving oil) ULTRA Green (Honda fuel-saving oil) ULTRA LEO (API SN class SAE 0W-20) Or engine oil with API CERTIFICATION mark...
- Page 4 80kpa (0.82 kgf/cm )以上 アイドリング時 油温80℃、 － 330kpa (3.37 kgf/cm )以上 3,000rpm時 Radiator solution Specified liquid Honda Genuine Ultra e Coolant Engine / radiator specified quantity When 4.62L (including reserve tank capacity) decomposition At the time of 3.60L exchange Reserve tank capacity 0.475L...
- Page 5 ― Fluid(4WD car) At the time of 1.6L ― exchange Total amount 2.6L ― Designated Transmission Fluid Honda Genuine ultra ATF DW-1 Hydro Designated Fluid Honda Genuine 5P8 fluid Static Clutch Actuator Input shaft Input Shaft Thrust Clearance 0.15－0.24mm ―...
- Page 6 Rear wheel 9.0mm 8.0mm Disc shake ― 0.04mm Disk parallelism ― 0.015mm Pad thickness Front wheel 10.0mm 1.6mm Rear wheel 10.0mm 1.6mm Brake Fluid Designated Brake Fluid Honda Genuine Ultra Brake Fluid DOT3 or DOT4 Air Conditioner System...
- Page 7 Name of part Project Complement Standard value Limit Air Conditioner Designated lubrication oil SANDEN SP-A2(P/N 38899-5P6-004) System Amount of lubrication oil Capacitors 25mL (including receiver tank capacity) Receiver Tank 10mL Evaporator 35mL Pipe class 10mL Designate a refrigerant HFC-134a(R-134a) Refrigerant volume -25 Grams 0.430kg Compressor Designated lubrication oil...
- Page 8 (Red) turn off (Lights than minimum level, immediately up when get it checked by a Honda dealer parking brake applied) If it is lit with ABS warning light, please immediately check with the Lights when Honda dealer.
- Page 9 Honda dealer. To a problem Please stop the car immediately in a with the safe place. transmission, Go have it inspected by Honda flashes when dealer. you can not run Seat belt Lights when If the seat belt wear properly,...
- Page 10 Situation to Information Messages light light / blink ON when When lit, please immediately (Anti power mode receive a check in the Honda dealer. lock ON, then turns ABS (anti-lock brake system) P.197 brake off when System) engine starts warning...
- Page 11 P.192 warning ON, then turns light off when engine starts Lights when the VSA to Honda ON when Please have it inspected by Honda Smart power mode dealer ON, then turns system off when warning engine starts light Lights when...
- Page 12 Overheat P.270 Power ON when Lights while driving system power mode Please have it inspected warning ON, then turns immediately by Honda dealer. light off when engine starts Lights when the Power system is abnormal Directio Corresponds to...
- Page 13 OFF the system and turn ON Blinks when again. immobilizer If it frequently flashing, please have system is it inspected at Honda dealer unable to recognize the It will be lit when, information of There is another key and metal near...
- Page 14 Warning Name Situation to Information Messages light light / blink Informat When it detects When a message is displayed on the an anomaly, a multi-information display, indicator indicator message is lights, with reference to the relevant displayed in page of the warning light, please the multi- make the necessary treatment.
- Page 15 Warning Name Situation to Information Messages light light / blink Shift Displayed Shift operation P.180 position when power indicator mode is ON mode Lights in the current position Shift When 7-speed Shift operation P.180 indicator manual shift ✤ mode, it displays the gear position Flashing and...
- Page 16 Please lower the temperature by the temperature allowing the car to cool down. around the sensor is too high Lights when The system does not work. Please something have it inspected by Honda dealer. wrong with the system Yasith Mayabandara...
- Page 17 Honda Fit GP5 Driving Aids You may have already noticed that, there are various information displayed on the right hand side of the meter panel when you press the arrow keys on the right hand side of the steering wheel. This article describes about the information displayed and its effect on your driving.
- Page 18 3. The Average Fuel Consumption History Display This display shows the average fuel consumption for the last three journeys and the current one. A single power on to power off event is taken as a journey. You can get an idea about your previous driving styles from this display. 4.
- Page 19 7. Average vehicle speed display A/B This is the Average Vehicle Speed for trip A/B 8. Elapsed time display A/B This is the Elapsed Time for trip A/B Other Driving Aids 1. Ambient Meter The color of the meter ring turns from Green to Blue in respect to ECO Drive Display. 2.
- Page 20 Engine cooling system is Please be promptly received a abnormal check in the Honda dealer. Displayed when starter system While stepping on the brake, is abnormal please press and hold POWER button approximately 15 seconds until the power system is started.
- Page 21 Honda dealer immediately. approaching notification system Displays when you take out the Return the Honda smart key Honda smart key to outside and within the operating range, the close the door while power warning is canceled. mode is ON.
- Page 22 Displays when the battery level How to replace batteries P.240 of Honda smart key is low At the same time a warning sound is heard Auto light vehicles If it is displayed during the Display that there is an operation, manually control the abnormality in the auto light lighting system.
- Page 23 Displays when the battery level When battery low of Honda of Honda smart key is low or smart key P.266 When Honda smart key is not in the car. At the same time a warning...
- Page 24 (- 40 ° C or less) Or please move to place with a high temperature. Please consult your HONDA dealer if necessary. Displays with 12V battery Less likely to accelerate. Also, charging warning light.
- Page 25 When the capacity of the high- Park in a safe place, and the voltage battery is further select shift position to parking, reduced, it becomes necessary Keep in idling state to charge to stop for charging the high-voltage battery. 12V battery charging warning light is lit P.272 High-voltage battery charge is Please do not run the car until...
- Page 26 When the shift position other Please press the parking switch. than P is selected while starting the power system When the driver's side door When you leave the driver's opened while on a shift position seat, please press the parking other than P switch.
- Page 27 Display that there is a Please stop the car immediately possibility of failure in the at a safe place. electrical system Message is not abnormal if it Displayed when the power disappears. mode to OFF while driving Transmission warning light will light / blink when there is abnormal.
- Page 28 Display Settings Adjust Clock Set Clock Hour Change Minute Change 12/24 Display Hide Return Return...
- Page 29 Driving System Support Collision Mitigation Brake System * Default Return Adaptive Leading Car Cruise Control Detection Sound * No Default Return * Standard ACC settings Early Leading Car Return Warning Alert...
- Page 30 Suppression *Assist Timing Standard System Settings Timing Delay Assist without Warning Return Lane Assist Control * OFF Return Active Force Pedal Weak * Standard Return * ON Road Sign Recognition Return Return...
- Page 31 -3 to +3 offsetting Meter setting Ambient Temperature 1 Degree step Return Trip A Auto Reset Engine ON * Manual Return Trip B Auto Reset Engine ON * Manual Return White Blue Ambient Colour Display Setting Violet Amber Yellow Change when Drive Return...
- Page 32 Ambient Meter Setting Return Return * Synchronized Memory Link Unsynchronized Buzzer Return Honda Smartkey Setting Door have Buzzer * ON Return Return...
- Page 33 Light Setting Light Setting * 30 Return Auto Light Sensitivity * MID Return Return * Speed Link Door Auto Lock Gear Shift Link Door Lock Setting Unsynchronized Return * Gear Shift Link Door Automatic Unsynchronized Return...
- Page 34 * Activate Keyless Keyless Time * 30 Return * Activate Security Return Return Initialisation set Cancel Operating Return...
- Page 36 Vehicle Maintenance Log Make: Model: Year: Vehicle Number: Engine: Date of Mileage at Work Performed and Service Performed By Cost Notes Service Service Schedule...
- Page 37 Vehicle Maintenance Log Make: Model: Year: Vehicle Number: Engine: Date of Mileage at Work Performed and Service Performed By Cost Notes Service Service Schedule...
- Page 38 Vehicle Maintenance Log Make: Model: Year: Vehicle Number: Engine: Date of Mileage at Work Performed and Service Performed By Cost Notes Service Service Schedule...
- Page 39 Vehicle Maintenance Log Make: Model: Year: Vehicle Number: Engine: Date of Mileage at Work Performed and Service Performed By Cost Notes Service Service Schedule...
