BroadOne™ LS110 Residential Femtocell
Release 14
Issue 1, May 2015
FNC-LS110-0014-100
User Guide
Fujitsu Network Communications Inc.
Fujitsu and Fujitsu Customer Use Only
shaping tomorrow with you
https://partners.fnc.fujitsu.com

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu BroadOne LS110 Residential Femtocell

Summary of Contents for Fujitsu BroadOne LS110 Residential Femtocell

  • Page 1 BroadOne™ LS110 Residential Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100 User Guide Fujitsu Network Communications Inc. Fujitsu and Fujitsu Customer Use Only https://partners.fnc.fujitsu.com...
  • Page 2 Communications Inc. does not warrant or represent that the contents of this document are error free. Furthermore, the contents of this document are subject to update and change at any time without notice by Fujitsu Network Communications Inc., since it reserves the right, changes in equipment design or components as progress in engineering methods may warrant.

  • Page 3: Table Of Contents

    22 Perform Initial Setup p. 23 Reset the Product p. 27 Troubleshooting p. 29 Specifications p. 32 Radio Frequency Energy p. 33 BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 4 Open Source Software p. 41 17.1 Guide to Micro Base Station Open Source Software p. 42 17.2 Open Source Software Licensing p. 45 BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 5: Welcome

    Screens and illustrations shown in this manual may differ from the actual product. In some cases, minor details or a part of a screen may be omitted to help clarify a point. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 6: Important Precautions

    Danger: If you experience any physical discomfort, such as itching or rashes, stop using the product immediately, and consult a dermatologist. People with certain physical conditions may experience such skin problems. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 7 Though not extremely hot, touching the product for a long time might cause low- temperature burns. Warning: Use only the supplied AC adapter. Using an AC adapter from another product could damage the product. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 8 Warning: Do not place the product close to magnetized objects, such as credit cards or floppy disks. Doing so might result in loss of recorded information. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 9: Exemptions And Liabilities

    It is recommended that you keep a copy of important data in your PC's hard disk, etc. Whatever the cause of fault or malfunction may be, the Company assumes no responsibility for alteration or loss of saved information. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 10: Customer Service

    "Performance parts for repair" refers to parts required for maintaining the functions of the product. If necessary, recycled parts that meet the Company's quality standards may be used for repair. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 11: What's In The Box

    GPS Antenna Also included in the box is a Quick Start Guide that may be used by experienced users for quick installation and setup. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 12: Ports And Reset Button

    For more information, refer to Reset the Product. • To restart the product without losing your settings, just press the Reset button. The product will restart. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 13: Leds

    If any LED is not steady green, refer to Steady Green — GPS measurement completed/normal Troubleshooting. operation Fast Blinking Green — GPS measurement incomplete or in progress BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 14: Before You Begin

    • Optional: Two screws of appropriate type (that is, wood, drywall, or concrete) and size if mounting the product on a wall • Optional: Network subscription document (For the Internet connection, network subscription is required.) BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 15: Installation And Setup

    In this chapter: Physically Mount the Product Connect the Product to a LAN Port Connect the GPS Antenna Connect the AC Adapter Perform Initial Setup BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 16: Physically Mount The Product

    (not included). Step 2 Align the mounting slots on the bottom of the product with the corresponding slots on the top of the stand. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 17: Mount The Product On A Wall

    Warning: Do not let go of the product until you are absolutely sure that it is securely fastened. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 18 Page 18 Installation and Setup Physically Mount the Product Step 3 Gently pull on the product to ensure that it is securely fastened. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 19: Connect The Product To A Lan Port

    LAN port. Internet Connection LAN Cable Modem/Router/ONU Wired Router Connect to the WAN port of the product. Figure 2: Internet Connection through Wired Router BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 20 LAN port. LAN Cable Connect to the WAN port of the product. Figure 3: Internet Connection through LAN Port Directly Installed in Wall BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 21: Connect The Gps Antenna

    When placing the receiving end of the GPS antenna, be aware that it must be in the same room or area as the product. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 22: Connect The Ac Adapter

    The product initializes automatically when powered on. Initialization takes approximately 3 minutes. When initialization is complete, proceed to the next step to perform initial setup. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 23: Perform Initial Setup

    The home page opens. From the home page, you can configure or change settings by clicking the Setting button, view current settings by clicking the System Information button, and add or change the password by clicking the Fujitsu-HeNB button at the top of the page. From any other page, click TOP to return to this page.
  • Page 24 By default, the DHCP connection type is selected. Presently, only the DHCP and Static IP Address connection types are supported. The PPPoE connection type is not supported. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 25 Fill in all fields as required using the information provided by your service provider at the time of purchase. Required fields are indicated with a red asterisk (*). BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 26 Step 9 Confirm the Internet Connection by opening a Web browser on your smartphone or tablet and going to any Web address. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 27: Reset The Product

    Using a sharp-pointed object, such as a toothpick or pen, press and hold the Reset button for 10 seconds or longer, and then release the button. Step 3 Make sure that the product restarts. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 28 User Guide Page 28 Reset the Product Step 4 Go to Perform Initial Setup to perform initial setup again. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 29: Troubleshooting

    Be aware that some communication devices, such as certain cable TV set-top boxes, save the last Internet- connection settings in memory, so you may not be able to reconnect to the Internet. To erase these settings, BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 30 Radio frequency (RF) validation is in progress. When complete, the LTE LED should turn steady green, indicating normal operation. LTE LED is Slow Blinking Green NTP calibration error during synchronization LTE LED is Fast Blinking Orange Temperature alarm BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 31 GPS cable to get better GPS reception. After a few minutes, if the LED does not change to a steady green, contact customer support. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 32: Specifications

    Short-term: 23 to 122 °F (–5 to 50 °C) 5 to 95% Operating Humidity UL-60950-1 Electrical Safety FCC Part 15 Subpart B FCC Radiation Emission BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 33: Radio Frequency Energy

    The power level can be as high as 100 milliwatts. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 34: Fcc Radio Frequency Emission

    This product has been tested and found to comply with the FCC’s exposure criteria. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 35 The installation of the base unit should allow at least 20 centimeters between the base and persons to be in compliance with FCC RF exposure guidelines. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...

  • Page 36: Limited Warranty

    User Guide Page 36 Limited Warranty Limited Warranty Fujitsu warrants the LS110 Residential Femtocell against defects in materials and workmanship under normal use for 1 year from the date of purchase. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only...

  • Page 37: End-User License Agreement

    "Source" form shall mean the preferred form for making modifications, including but not limited to software source code, documentation source, and configuration files. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 38 (a) You must give any other recipients of the Work or Derivative Works a copy of this License; and (b) You must cause any modified files to carry prominent notices stating that You changed the files; and BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 39 You agree to indemnify, defend, and hold each Contributor harmless for any liability incurred by, or claims asserted against, such Contributor by reason of your accepting any such warranty or additional liability. BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 40 "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License. ============================================================================= BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 41: Open Source Software

    Open Source Software Open Source Software In this chapter: 17.1 Guide to Micro Base Station Open Source Software 17.2 Open Source Software Licensing BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 42: Guide To Micro Base Station Open Source Software

    GNU General Public License version 2 OSS name: attr,bash,bridge-utils,busybox,e2fsprogs,ebtables,ethtool,iptables, Linux_driver,linuxigd,lzo,nfs-utils,pciutils,perl,proftpd,readline,rfutil,rp-pppoe, sed,strongswan,tcp_wrappers,U-boot,udev,wireless-tools Use permission condition name: GNU General Public License version 2+ OSS name: Libgcc and libstdcxx BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 43 OSS name: Dhcp and bind Use permission condition name: MIT License OSS name: Curl, dropbear, libxml2, ncurses, and popt Use permission condition name: OpenSSL License BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 44 The following programs included in this software are assumed to be the one that only the range permitted by GNU LESSER GENERAL PUBLIC LICENSE Version 2.1 can do the rearrangement and the reverse engineering. File name: procps-3.2.8 libblkid-2.16 nss-mdns-0.8 BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...

  • Page 45: Open Source Software Licensing

    Also, for each author's protection and ours, we want to make certain that everyone understands that there is no warranty for this free software. If the software is modified by someone else and passed on, we want its recipients BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 46 License. (Exception: if the Program itself is interactive but does not normally print such an announcement, your work based on the Program is not required to print an announcement.) BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
  • Page 47 Program or its derivative works. These actions are prohibited by law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work based on BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 48 BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015...
  • Page 49 THE PROGRAM TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS ============================================================================= BroadOne LS110 Residential Fujitsu and Fujitsu Customer Use Only Femtocell Release 14 Issue 1, May 2015 FNC-LS110-0014-100...
