- Page 1 MAINTENANCE AND USER’S GUIDE 34900410 BRCI 3180 E 34900407 BRCIF 3380 E 34900408 BRCIF 3350 E...
- Page 2 pg. 1--10 ENGLISH Congratulations on purchasing this fridge, which has been designed using the latest technologies for an easy-to-use, environmentally friendly appliance. We recommend you read this guide and the technical datasheet carefully to find out everything you need to know about your new fridge.
-
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION ............2--2 INSTALLATION ..............3--3 OPERATION ................3--3 CONSERVATION ..............4--4 FREEZING ................5--5 DEFROSTING ................ 5--5 MAINTENANCE AND CLEANING ........6--6 ENERGY SAVING .............. 6--6 AVOIDING NOISE .............. 6--6 REVERSIBILITY OF THE DOOR .......... 6--7 PRODUCT AND APERTURE DIMENSIONS......7--8 INSTALLATION OF THE APPLIANCE IN THE COLUMN.. -
Page 4: Safety Information
Thank you for purchasing this product. Before using your refrigerator, please carefully read this instruction manual in order to maximize its performance. Store all documentation for subsequent use or for other owners. This product is intended solely for household use or similar applications such as: - the kitchen area for personnel in shops, offi ces and other working environments - on farms, by clientele of hotels, motels and other environments of a residential type - at bed and breakfasts (B &... -
Page 5: Installation
Scrapping old appliance • The socket is earthed and in compliance with the law. • The socket can withstand the maximum power load of the appliance, as indicated on the nameplate of the refrigerator. • The power supply voltage is within the amounts indicated on the nameplate of the refrigerator. -
Page 6: Conservation
CONSERVATION Freezer zone • To maintain the best flavour, nourishment and freshness of foods, it is Use the table below for the compartments advisable to store them in the refrigerator compartment as shown in Fig. 6 Freezing process can only occur in the compartments below, making sure to wrap them in aluminium or plastic sheets or in appropriate covered containers to avoid cross-contamination. -
Page 7: Freezing
FREEZING • Foods must be fresh. • Freeze small amounts of food at a time in order to freeze quickly. Never exceed the maximum amount indicated on the rating label. • During freezing, do not open the freezer door. • Food must be sealed, airtight. •... -
Page 8: Maintenance And Cleaning
IMPORTANT: Defrosting the freezer compartment To prevent cracking of the inside surfaces and plastic parts, follow (static products without NO-FROST technology) these suggestions: • Wipe away any food oils adhered to plastic components. When the layer of frost present in the freezer compartment •... -
Page 9: Product And Aperture Dimensions
REVERSING THE OPENING OF THE DOORS Remove the upper plate and Remove the upper door. Remove the middle hinge and its Remove the bottom door. hinge by screw driver. connecting pin underneath. Remove the right bottom hinge Use the opposite hinge and cover Reassemble the doors and hinges and left plastic plugs, and refit and fit into the left bottom. -
Page 10: Installation Of The Appliance In The Column
INSTALLATION OF THE APPLIANCE IN COLUMN Insert the appliance into the column, placing it on After ensuring the match between appliance door the opposite site of the hinges, and make sure 3-5 and column door, then screw the appliance upper mm distance gap. -
Page 11: Of The Appliance Doors
COUPLING OF THE PANELS OF THE PRECAUTIONS FOR CORRECT OPERATION BUILT-IN COLUMN OF THE APPLIANCE DOORS Once the product has been embedded, place the rear part of the column in contact with the wall so as to prevent access to the compres- The appliance is equipped with coupling devices for the appliance doors sor compartment. -
Page 12: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE REMEDY The inside illumination light bulb does not • Electricity absence. • The power cord is not properly plugged in. turn on. • Check whether the appliance is switched off. (see Temperature Adjustment). • Ensure that there is a current in the house. •... - Page 13 Part of the Hoover Group 11 Beacontree Plaza Gillette Way Reading RG2 0BS www.baumatic.co.uk Customer Care Telephone (0844) 692 3605 Spares Telephone (0844) 692 3606 10/2015...
