    ENGLISH ElectricPAK Owner’s Manual Table of Contents PRODUCT INFORMATION - - - - - - - - - 3 Description - - - - - - - - - - - - - - 3 UNPACKING & INSPECTION - - - - - - - - 3...
  • Page 2 Risk of bodily injury, electric shock, or to comply with national and local electrical and plumbing codes equipment damage. and within Pioneer Pump recommendations may result in electri- • This equipment must not be used by children or persons with...

  • Page 3: Product Information

    PRODUCT INFORMATION Description Pioneer ElectricPAKs include a rigidly mounted electric motor and Pioneer pump in either a Pioneer prime or a standard centrifugal configuration supported by a modular frame intended for fixed installations. The rigid mount between pump and motor maintains coupling alignment during transportation and operation, increasing the time between coupling inspections.

  • Page 4: Physical Installation

    PHYSICAL INSTALLATION Foundation 3. Check that guards are in their proper place and that fasteners are tightened. 4. Use skids for unloading if facilities are not available for lifting the materials off the carrier’s vehicle. Full Fork Insertion Proper Lifting Points Lifting Point Tie Down Points Fork Pockets...

  • Page 5: Piping Installation

    Reference pump manual for specific piping installations. In general, complete the following: • Ensure couplings are aligned. NOTE: Generally, alignment is not needed because of the ElectricPAK’s motor stool. • Properly support all suction and discharge piping to avoid strain on the pump.

  • Page 6: Maintenance

    MAINTENANCE MAINTENANCE Risk of severe injury or death. • To minimize risk of electrical shock, disconnect power before working on or around the system. • When lifting or moving heavy components, use suitable lifting equipment, in good condition, rated for at least 5 times the weight of the materials being moved.
