- Page 1 INSTRUCTION MANUAL MANUEL D'INSTRUCTION MANUAL DE INSTRUCCIONES Pneumatic Brad Nailer Cloueur Pneumatique Polyvalent Clavadora Neumática para Clavos de Cabeza Redonda AF505N 014916 IMPORTANT: Read Before Using. IMPORTANT: Lire avant usage. IMPORTANTE: Leer antes de usar.
-
Page 2: Specifications
ENGLISH (Original instructions) SPECIFICATIONS Model AF505N Air pressure 4.0 - 8.0 kgf/cm G (60 - 115 PSIG) Nail length 15 mm (5/8") - 50 mm (2") Nail capacity 100 pcs. Min. hose diameter 6.5 mm (1/4") Dimensions (L X H X W) 260 mm X 237 mm X 64 mm (10-1/4"... - Page 3 Make sure there is no one below working correctly. when working in high locations, and secure 33. Ask Makita's Authorized service centers for the air hose to prevent danger if there is periodical inspection of the tool.
-
Page 4: Installation
CAUTION: INSTALLATION Low air output of the compressor, or a long or • Selecting compressor smaller diameter air hose in relation to the nailing frequency may cause a decrease in the driving capability of the tool. Lubrication /min) 004295 To insure maximum performance, install an air set (oiler, Nailing frequency (times/min) regulator, air filter) as close as possible to the tool. -
Page 5: Functional Description
FUNCTIONAL DESCRIPTION ASSEMBLY CAUTION: CAUTION: Always disconnect the hose before adjusting or Always disconnect the hose before carrying out • • checking function on the tool. any work on the tool. Load the same kind, size and uniform length of •... -
Page 6: Operation
The direction of exhaust air can be changed 360 Connecting air hose degrees of angle by turning the exhaust cover with a hand. 1. Air fitting 2. Air socket Removing nails CAUTION: Do not use deformed nails or nail strip. Failure to •... -
Page 7: Maintenance
Nails Nail 014925 When the tool is not to be used for an extended period 004310 of time, lubricate the tool using pneumatic tool oil and Handle nail coils and their box carefully. If the nail coils store the tool in a safe place. Avoid exposure to direct have been handled roughly, they may be out of shape sunlight and/or humid or hot environment. -
Page 8: Optional Accessories
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Nails • Air hoses • Safety goggles •...
