1-Inch Water Pump 2-Cycle Engine Operating Instructions
R E A D ALL IN S T R U C T IO N S A N D W A R N IN G S B E F O R E USING THIS
P R O D U C T .
This manual provides important information on proper operation & maintenance. Every effort has been
made to ensure the accuracy of this manual. These instructions are not meant to cover every possible
condition and situation that may occur. We reserve the right to change this product at any time without
prior notice.
IF T H E R E IS A N Y Q U E S T IO N A B O U T A C O N D IT IO N BEING SAFE OR
U N S A F E , DO N O T O P E R A T E THIS P R O D U C T !
H A V E Q U E S T IO N S OR P R O B L E M S ? C O N T A C T C U S T O M E R S E R V IC E .
If you experience a problem or need parts for this product, visit our website
http://www.buffalotools.com or call our customer help line at 1-866-460-9436, Monday-Friday,
8 AM - 4 PM Central Time. A copy of the sales receipt is required.
FOR C O N S U M E R USE O N L Y – N O T FOR P R O F E S S IO N A L USE.
KEEP THIS M A N U A L , SALES RECEIPT & A P P L IC A B L E W A R R A N T Y F O R
F U T U R E R E F E R E N C E .
CALIFORNIA PROPOSITION 65 : This product may contain chemicals, including lead, known to the
State of California to cause cancer and birth defects or other reproductive harm. Wash hands after
handling.
CALIFORNIA PROPOSITION 65 : According to the State of California, the exhaust from this water
pump contains chemicals known to cause cancer, birth defects, or other reproductive harm.
ITEM # WPUMP1

Advertisement

Table of Contents
loading

Summary of Contents for Buffalo Sportsman Series

  • Page 1 ITEM # WPUMP1 1-Inch Water Pump 2-Cycle Engine Operating Instructions R E A D ALL IN S T R U C T IO N S A N D W A R N IN G S B E F O R E USING THIS P R O D U C T .
  • Page 2: Table Of Contents

    100 miles of an authorized service center. For owners located more than 100 miles from an authorized service center, Buffalo Corp will, in its sole discretion, either pay for shipping costs to and from an authorized service center, provide for a service technician to come to the owner to make the warranty repair, or pay for the repair to be made at a local non-authorized service center.
  • Page 3: Recognize Safety Symbols, Words And Labels

    R E C O G N IZ E SAFETY S Y M B O L S , W O R D S & L A B E L S Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur.
  • Page 4: Important Safety Instructions

    Notice Regarding Emissions: Engines certified to comply with U.S. EPA emission regulations for SORE (Small Off Road Equipment) are certified to operate on regular unleaded gasoline and may include the following emission control systems: Three-Way Catalyst (TWC) (if equipped), and Engine Modifications (EM).
  • Page 5 High Temperatures: This product produces heat when in operation. Temperatures near the exhaust can exceed 150 Degrees Fahrenheit (65 Degrees Celsius). Do not touch hot surfaces. Observe all warning placards on this product denoting hot surfaces. Allow this product to cool for several minutes after use before touching the engine, muffler or other areas that are hot during operation and before storing indoors.
  • Page 6: General Product Specifications

    GENERAL PRODUCT SPECIFICATIONS PACKAGE CONTENTS 1-Inch Water Pump SPECIFICATIONS Engine 2-Stroke Engine Type 2-Cycle Engine Displacement 43cc Horsepower 1.4 HP Noise Level @ 7 meter 83 dB Runtime: 1 hour for full tank Requires: 0.5376 ounces of 2-Cycle Engine oil with 26 ounces of gasoline COMPONENTS Spark Plug : Type F6TC...
  • Page 7: Preparing The Water Pump For Use

    PREPARING THE WATER PUMP FOR USE STEP 1 When new from the package, this Water Pump contains no oil or gas in the engine crankcase. Add the correct quantity of oil / gas before operating this Water Pump for the first time. This Water Pump requires 2-cycle engine oil plus a mixture of gasoline to function.
  • Page 8: Break-In Period

    BREAK-IN PERIOD Breaking in an engine of any size is important to the life of the engine. The first twenty hours of operation is considered the break-in period for this Water Pump. For best results and an engine with fewer problems, it is suggested that you: Avoid heavy loads during the first twenty hours.
  • Page 9: Air Filter Maintenance

    Wear ANSI-approved safety gear, including safety goggles and heavy-duty work gloves when servicing this Water Pump. This Water Pump will work more efficiently with a clean air filter. The air filter should be checked every 25 hours of use, regardless of workload, and replaced every 100 hours regardless of workload. To clean or replace the air filter: 1.
  • Page 10: Storage

    STORAGE Do not store fuel/oil mix for more than 3 months. Never place any type of storage cover on this Water Pump while it is still hot. Prior to restarting, thaw out any possible ice from the Water Pump. The life of this Water Pump can be extended through proper maintenance procedures. When placing this Water Pump in storage for over fourteen days, following these procedures will increase its service life.
  • Page 11: Parts Diagram

    PARTS DIAGRAM / PARTS LIST TWPUMP 2-Inch Semi Trash / Water Pump Assembly And Operating Instructions  ...
  • Page 12 PARTS DIAGRAM / PARTS LIST TWPUMP 2-Inch Semi Trash / Water Pump Assembly And Operating Instructions  ...
  • Page 13 PARTS DIAGRAM / PARTS LIST TWPUMP 2-Inch Semi Trash / Water Pump Assembly And Operating Instructions  ...
  • Page 14 PARTS DIAGRAM / PARTS LIST 201906 TWPUMP 2-Inch Semi Trash / Water Pump Assembly And Operating Instructions  ...
