Operating Manual
Supplement for PC-MC22
Specifications
Parts
1
CPU*
Cache
BIOS
RAM
System
Video
Display
Panel
Video controller
Resolution/color
Keyboard
Pointing device
Drive
Hard disk
Floppy disk
(option/external)
3
Optical*
PC card slot
Audio system
I/O ports
Audio
Video
Others
Modem
Wireless
Radio
LAN
Frequency
Operating
Channels
LAN
5
Operating System*
Power
AC adapter
Battery
Battery life*
Battery charging
time
Dimensions
Weights
*AMD Mobile Athlon TM XP-M processor
-
PowerNow! Support
512 KB on die
Inside 256KB Flash EPROM
256M DDR SDRAM (PC2100) standard expandable to 768MB
-Max. 768MB
-Support PC2100
8/16/32MB shared with sysyem memory :Default 32MB
12.1 XGA TFT LCD
S3 ProSavage8 (Integrated in KN266)
-Resolution: 1024x768 (XGA)
-256K /16M color in LCD
IBM compatible keyboard
Intelligence Glide pad w/ 1 button(See-Saw type)
Approx. 40GB (C: Approx.30 GB(NTFS), D: Approx.10G(Fat32))
USB interface 3.5", 1.44MB/720KB
CD-R/RW& DVD-ROM Drive
Writing CD-R:24x(Max.)
*Re-writing CD-RW:24x(Max.)
Reading CD-ROM:24x(Max.),CD-R: 24x(Max.), CD-RW: 24x(Max.)
DVD-ROM: 8x(Max.), DVD-R: 4x(Max.), DVD-RW: 4x(Max.),
DVD+R: 4x(Max.) DVD+RW: 4x(Max.), DVD-RAM:2x(Max.)
Type II × 1 (PC Card Standard compliant) CardBus compliant
Stereo Two speakers (1W output), Built-in AC-link Audio Controller (Define
Sound chipset) AC'97 compliant
Audio output jack (stereo), external microphone jack, headphone jack
External VGA display connector
4 USB ports ,DirectHD Connector
RJ-11 modem x1 (V.90 standard, with Modem port cover. No support for
K56Flex, V92)
IEEE 802.11g compliant
Wi-Fi compliant
11 channels
100 BASE-TX/10 BASE-T
Microsoft® Windows® XP Home Edition Service Pack 1a
100-240V, 50-60 Hz
Rechargeable Li-ion battery
6
Approximately 1.6 hours
*Battery life varies depending on usage
Turned off/hibernation: About 4 hours
*Charging time varies depending on usage
Turned on: About 6 hours
*Charging time varies depending on the usage
281mm wide x 262mm deep x 22.5mm (min.) /33.5mm (max.) high (11.1"
x 10.4" x 0.89" (min.)/132" (max.) )
*No protuberance is included.
About 2.5 kg (5.6 lbs)
PC-MC22
1
Advertisement
Related Manuals for Sharp Actius PC-MC22
Summary of Contents for Sharp Actius PC-MC22
-
Page 1: Specifications
Supplement for PC-MC22 Specifications Parts CPU* *AMD Mobile Athlon TM XP-M processor Cache 512 KB on die BIOS Inside 256KB Flash EPROM System 256M DDR SDRAM (PC2100) standard expandable to 768MB -Max. 768MB -Support PC2100 Video 8/16/32MB shared with sysyem memory :Default 32MB Display Panel 12.1 XGA TFT LCD... -
Page 2: Re-Installation Instructions
Operating Temperature 10°C to 35°C (50°F to 95°F) environment Humidity 20% to 80% (non-condensation) *1 Complaints with AMD PowerNow! Technology *2 Supporting the buffer underrun protection technology which prevents the buffer underrun error occurred when the optical drive writes too fast for the buffer to supply data or if some other application is being used. - Page 3 3. NONPERMITTED USES. Without the express permission of PowerQuest, you may not (a) use, copy, modify, alter, or transfer, electronically or otherwise, the Software or documentation except as expressly permitted in this License Agreement, or (b) translate, reverse program, disassemble, decompile, or otherwise reverse engineer the Software.
-
Page 4: Backing Up The Data
9. This License Agreement constitutes the entire agreement between you and PowerQuest pertaining to its subject matter. This License Agreement is governed by the laws of the State of Utah. Any litigation arising from this license will be pursued only in the state or federal courts located in the State of Utah. Copyright 1994-2003, PowerQuest Corporation. - Page 5 Formatting the drives and re-installing Windows 1. Make sure the computer is turned off. 2. If any peripheral devices are connected to your computer, disconnect them. 3. Connect the AC adapter; then, turn on the computer. Be sure to connect the AC adapter. If the battery is completely discharged, the installation process will be canceled.
