Sanyo PLC-XP200L Specifications

7000 ANSI LUMENS
PLC-XP200L
XGA Portable Multimedia Projector
World's First QuaDrive Optical Engine Allows More Rich Color Reproduction
SANYO projector engineering introduces their latest LCD Engine, called QuaDrive,
which adds a Color Control Device to traditional 3LCD (red/green/blue) systems. The
first projector to launch this innovative new QuaDrive engine is the PLC-XP200L. The
additional color panel in the QuaDrive optical engine allows the XP200L to
automatically control the amount of yellow light in the image, producing higher
luminosity with improved color accuracy and clarity.
Achieves 7,000 Lumens of Brightness, the Best in its Class for Brighter Displays
The demand for even brighter projectors continues to come from the field as systems
integrators are asked to install video displays in extremely large venues such as
convention halls, conference rooms, auditoriums and houses of worship. However, as
brightness levels increase on 3LCD projectors, there is a reverse effect in color
reproduction. Colors become noticeably washed out, lacking vibrancy and realism.
SANYO's innovative solution overcomes the limitations of 3LCD technology, opening
the way for new projectors capable of extremely high luminosity without the trade off in
color accuracy. Coupled with the impressive high contrast ratio of 2200:1, the XGA
resolution (1024x768) XP200L is capable of generating clearer, richer and more
beautiful images.
Active Maintenance Filter (AMF) for Easy Maintenance, the Industry's Longest
Lasting Filter
Minimal maintenance and repair was essential for the XP200L, so it was outfitted with
SANYO's exclusive Active Maintenance Filter (AMF). AMF is a single filter cartridge
that contains the equivalent of 10 filters, lighting the burden of maintenance. It also has
an airflow sensor to detect when the airflow is obstructed by dust. The AMF system
automatically advances a clean section of filter when needed. When the last section of
filter material becomes obstructed an on-screen graphic appears telling the user to
change the cartridge. Each filter lasts approximately 10,000 hours with a cartridge
lifecycle of about 2 years the filters are easy to replace due to the side loading access
on the projector. To further increase reliability and performance, the PLC-XP200L uses
SANYO's unique Durable Inorganic Optical System (DIOS).
Network Connectivity
An optional PJ-Net Camera (POA-PN03C) and PJ Master Software (POA-PJNM01)
allow for control and administration of multiple projectors via a network. The user can
monitor the actual picture and check projector status and control projector functions via
any web browser. A warning notification will be automatically sent to the registered.
users' emails whenever the projector encounters problems.
Build in Mechanical Shutter
To prevent light from entering the presenter's eyes when in front of the projected
image, a special mechanical shutter has been included behind the lens, open/close
controllable with the remote control, which will temporarily darken the screen.
Issued 05/09
TRUE XGA
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 888-337-1215 (toll-free)
Fax 818.717.2719
www.sanyoprojectors.com
MULTIMEDIA PROJECTOR
S p e c i f i c a t i o n s
Resolution
Brightness (typical)
Uniformity
LCD Panel System
Number of Pixels
Contrast Ratio
Projection Image (diagonal)
Aspect Ratio
Throw Distance
Zoom/Focus
Power Lens Shift
Digital Keystone Correction
Projection Lens
Lens Throw Ratio
Projection Lamp
Scanning Frequency
Dot Clock
Color System
Computer Compatibility
Voltage
BTU Rating
dB Rating
Power Consumption
Dimensions (WxHxD)
Net Weight
User Maintenance
Input Terminal Panel 1
Input Terminal Panel 2
Input Terminal Panel 3
Additional Input Terminals
Output Terminals
Included Accessories
Optional Accessories • POA-PN03C - PJ-Net Camera
• POA-PJNM01 - PJ-Master
• Serial Control Cable (POA-MCSRL)
• 610 334 3747 - Replacement Filter (POA-FIL131)
• 610 341 1941 - Replacement Lamp
• 645 097 4069 - Replacement Remote
• Optional Lenses (see below)
Warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.
Optional Lens Specifications
On-Axis
Short Zoom
Short Fixed
LNS-W32 LNS-W31A
Part No.
Zoom No Power
0.8:1 1.3 – 1.8:1
Throw Ratio
U/D Ratio 1:1 10:0 – 1:1
2.5 2.5 – 3.1
F Stop
6.7" 7.6"
Length
3.3 lbs. 4.0lbs.
Weight
XGA (1024 x 768)
7000 ANSI Lumens
90% (Corner to Corner)
1.3" TFT Poly-Si x 3 / Color Control x 1
2,359,296 (786,432 x 3)
2200:1 (full on/off)
Dependent on Lens
4:3
Dependent on Lens
Dependent on Lens
Up/Down Ratio 10:0 – 1:1
Left/Right Ratio 3:2 – 2:3 (dependent on lens)
Vert. +/- 40°, Horiz. +/- 20°
Lens Sold Separately
Dependent on Lens
330W NSHA
H 15-100kHz; V 48-100Hz
180 MHz
PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
UXGA,SXGA+,SXGA,WXGA,XGA,SVGA, VGA,MAC
100-240V AC; 50/60/Hz (auto sense/select)
1703
35 dBA
499W
14.6" x 7.4" x 17.3"
25.08 lbs
replace air filter, replace lamp assembly
D-Sub 15 x1 • DVI–D x1 (w/HDCP)
• Audio x 1(Swichable : mini jack)
RGBHV or Composite/Component video (BNC x5)
• Audio x 1(mini jack))
Composite/Component video (RCA x3) • S-Video x1
• Audio x 1(Swichable : mini jack)
Wired remote control jack x 1 (mini jack)
• USB(type B) x 1 • Control port x 1 (D-sub 9pin)
D-Sub 15 x 1 • Variable Audio out x 1(mini jack)
Wired/Wireless I/R Remote control w/Mouse pad
• Owner's Manual(CD-ROM & quick reference guide)
• Batteries (two "AAA") • AC Power Cord • VGA Cable
• USB Control Cables • Lens Attachment (POA-LNA03)
Three Years Parts and Labor; 90 Days Lamp;
Quick Repair Program Under Warranty
Standard Long
Zoom Zoom
LNS-S31 LNS-T31A
Power Power
1.8 – 2.3:1 2.3 – 4.2:1
10:0 – 1:1 10:0 – 1:1
1.7 – 2.0 2.0 – 2.9
7.4" 8.5"
2.9 lbs. 4.0lbs.
© 2008 SANYO
Ultra Long
Zoom
LNS-T32
Power
4.2 – 6.0:1
10:0 – 1:1
2.1 – 2.7
7.5"
3.3 lbs.
