Summary of Contents for Sanyo PLC-XP200L

  • Page 1 Multimedia Projector PLC-XP200L MODEL Projection lens is optional. ✽ Owner’s Manual...

  • Page 2: Features And Design

    This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 1.07 billion colors, and matrix liquid crystal display (LCD) technology. Functionally Rich ◆ This projector has many useful functions such...

  • Page 3: Table Of Contents

    Safety Instructions . . . . . . . . . . . . . . . . . 5 Air Circulation Installing the Projector in Proper Directions Moving the Projector Cautions in Handling the Projector Compliance .

  • Page 4: To The Owner

    The symbol mark and recycling systems described below apply to EU countries and do not apply to countries in other areas of the world. Your SANYO product is designed and manufactured with high quality materials and components which can be recycled and/or reused.

  • Page 5: Safety Instructions

    The openings should never be covered with cloth or other materials, and the bottom opening should not be blocked by placing the projector on a bed, sofa, rug, or other similar surface. This projector should never be placed near or over a radiator or heat register.

  • Page 6: Air Circulation

    Remove any dirt or dust that has accumulated on the projector. If the projector reaches a time set in the timer setting, a Filter replacement icon (Fig. 1) appears on the screen and WARNING FILTER indicator on the top panel lights up (see below), indicating that the filter replacement is necessary.

  • Page 7: Installing The Projector In Proper Directions

    Installing the Projector in Proper Directions Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe accident or fire hazard. This projector can project the picture in upward, downward, or inclined position in perpendicular direction to the horizontal plane.

  • Page 8: Moving The Projector

    For information about transporting the projector by courier or any other transport service, consult your dealer. – Do not put the projector in a case before it is cooled enough. Cautions in Handling the Projector Do not hold the lens or the top cover when lifting or moving the projector.

  • Page 9: Compliance

    Telephone No. : (818)998-7322 The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).

  • Page 10: Part Names And Functions

    Front Back Bottom Part Names and Functions q Indicators w Top Cover e Top Cover Release Button r Infrared Remote Receiver (Front) t Projection Lens (optional) y Light-Block Sheet u Adjustable Feet i Air Intake Vent o Filter Cover !0 Lamp Cover !1 Exhaust Vent CAUTION Hot air is exhausted from the exhaust vent.

  • Page 11: Rear Terminal

    (not supplied). USB CONNECTOR (Series B) Use this connector when controlling a computer with the remote control of the projector. Connect the USB terminal of your computer to this connector with the supplied USB cable (p.22). CONTROL PORT CONNECTOR...

  • Page 12: Rear Terminal

    The infrared remote receiver is also located in the front (pp.10, 16). Kensington Security Slot ✽ This slot is for a Kensington lock used to deter theft of the projector. *Kensington is a registered trademark of ACCO Brands Corporation. ✽...

  • Page 13: Side Control And Indicators

    Side Control and Indicators Side Control ON/STAND-By button Turn the projector on or off (pp.26–27). INPUT button Select an input source (pp.35–37). MENU button Open or close the On-Screen Menu (p.28). Point ed7 8 ( VOLUME + / – ) buttons –...

  • Page 14: Remote Control

    – Adjust the volume level (with Point or mute the sound (with Point !0 MOUSE POINTER button Move a pointer of the projector or a pointer for wireless mouse operation (p.34). !1 SELECT button – Execute the selected item (p.28).
  • Page 15 Remote Control !5 D .ZOOM button Select the Digital zoom +/- mode and resize the image (p.44). !6 INPUT 1 – 3 buttons Select an input source (INPUT 1 – INPUT 3) (pp.35–37). !7 KEySTONE button Correct keystone distortion (p.33). !8 ZOOM ed buttons Zoom in and out the images (p.32).

  • Page 16: Remote Control Battery Installation

    You can conveniently use both of the receivers (pp. 10, 56). ✔Note: • When hanging the projector from the ceiling, select the Infrared Remote Receiver which is located farther away from the fluorescent light (p.56). Wired Remote Control Transmitter The remote control can be used as a wired remote control.

  • Page 17: Remote Control Code

    Change the remote control code for the projector first before changing that for the remote control. See “Remote control” in the Setting Menu on page 55.

  • Page 18: Installation

    Rotate the adjustable feet and tilt the projector to the proper height; to raise the projector, rotate the both feet clockwise. To lower the projector or to retract the adjustable feet, rotate the both feet counterclockwise. To correct keystone distortion, press the KEYSTONE button on the remote control or select Keystone from the menu (see pages 15, 33, 44, 48).

  • Page 19: Lens Installation

    Removing the lens Shift the lens to the center position by using the Lens shift function (p. 30). Turn off the projector and unplug the AC power cord. While pressing the top cover release button on the top cover, slide the top cover toward front to remove it.
  • Page 20 Attaching the lens to the projector Turn off the projector and unplug the AC power cord. Fit the lens to the projector. Make sure that the lens is fully inserted to the projector. Push the Lens Lock Lever downward. Make sure that the lens is properly locked.
  • Page 21 Focus correction When the lens is attached to the projector and images are being projected onto the screen, the peripheral focus may be out of focus in some localized areas. If this happens, insert the one, of three sizes of spacers, in between the Lens Attachment and the lens to adjust the focus.

  • Page 22: Connecting To A Computer (Digital And Analog Rgb)

    G B R H/V V Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. (✽ = Cables not supplied with this projector.) • Serial Cross Cable ✽ • USB Cable Monitor Output...

  • Page 23: Connecting To Video Equipment (Video, S-Video)

    Composite Video Output (Y, Pb/Cb, Cr/Pr) cable Video Y - Pb/Cb - Pr/Cr Y - Pb/Cb - Pr/Cr = Cables not supplied with this projector.) ✽ Monitor Out Signal Table Input Terminal Monitor Out RGB (PC analog) D-sub15 RGB (SCART)

  • Page 24: Connecting For Audio Signal

    Audio cable (stereo) AUDIO IN I/II Unplug the power cords of both the projector and external equipment from the AC outlet before connecting cables. = Cables not supplied with this projector.) ✽ Audio Output Audio cable (stereo) AUDIO IN I/II...

  • Page 25: Connecting The Ac Power Cord

    NOTE ON THE POWER CORD AC power cord must meet the requirements of the country where you use the projector. Confirm the AC plug type with the chart below and proper AC power cord must be used.

  • Page 26: Basic Operation

    Lamp control status icon (see page 55) appear on the screen. If the projector is locked with a PIN code, PIN code Input Dialog Box will appear. Enter the PIN code as instructed below.

  • Page 27: Turning Off The Projector

    IN EVERY 24 HOURS. ✔ Note: • When the On start function is set to “On, ” the projector will be turned on automatically by connecting the AC power cord to an AC outlet (p.56). • The running speed of cooling fans is changed according to the temperature inside the projector.

  • Page 28: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Press the MENU button on the side control or the remote control to display the On-Screen Menu.

  • Page 29: Menu Bar

    Sound Menu Used to adjust the volume, mute the sound, or switch the Input pattern (p. 31). Setting Menu Used to set the projector’s operating configurations (pp. 52-60). Information Menu Display the input source information (p. 32). Advanced color/Color temp./White balance (R/G/B)/ Offset (R/G/B)/Sharpness/Gamma/Noise reduction/Progressive/ Reset/Store/Quit] (pp.

  • Page 30: Operating With Projector Control

    Shutter function allows you to completely block out light to the screen. Press the SHUTTER button to close the shutter inside the projector. To open up the shutter, press the SHUTTER button again. Refer to p.59 for detail of setting for the Shutter function.

  • Page 31: Sound Adjustment

    Input pattern This projector has two INPUT terminals [AUDIO IN I/ AUDIO IN II]. Input pattern allows you to set up INPUT 1, INPUT 2, and INPUT 3 to each INPUT for sound function.

  • Page 32: Operating With Remote Control

    INFO . button Information display can be used to confirm the current operating condition of the projector and the signal being projected through the projector. Press the INFO. button on the remote control to display the information window on the screen.

  • Page 33: Freeze Button

    MOUSE POINTER button Move the pointer on the screen with this button. POINTER button Press POINTER button on the remote control to display the Pointer on the screen. P-TIMER button Press the P-TIMER button on the remote control. The Timer display “00 : 00”...

  • Page 34: Pointer Function

    Basic Operation Pointer Function You can move the Pointer of the projector with the remote control to emphasize a part of the projected image. Press the POINTER button to activate the Pointer function. Use the MOUSE POINTER button to move the Pointer.

  • Page 35: Input Selection

    Input Side Control INPUT button INPUT button Side Control/Remote control Operation Press the INPUT button on the side control or the remote control. It switches to INPUT 1, INPUT 2, and INPUT 3 as you press the INPUT button. Before using the INPUT button on the side control or the remote control, you must select a correct input source by On-Screen Menu and the latest input source will be displayed.

  • Page 36: Computer Input Source Selection

    DVI (Digital Visual Interface) from being copied.The specification of HDCP is decided and controlled by Digital Content Protection, LLC. Should the specification be changed, this projector may not display the digital content protected by HDCP . WHEN SELECTING INPUT 2 (5 BNC INPUT jACKS ) When connecting the computer output [5 BNC Type (Green, Blue, Red, Horiz.

  • Page 37: Video Input Source Selection

    Video Input Source Selection Menu Operation WHEN SELECTING INPUT 1 (COMPUTER INPUT TERMINALS ) When connecting to video equipment, select the type of Video source in the Source Select Menu. RGB (Scart) When scart video equipment is connected to the INPUT 1 (ANALOG) terminal, select RGB (Scart).

  • Page 38: Computer Input

    WXGA, or UXGA (refer to “Compatible Computer Specifications” on pages 78–79). If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings. (Some computers need to be set manually.)

  • Page 39: Auto Pc Adjustment

    To store the adjusted parameters . The adjusted parameters from the Auto PC Adjustment can be stored in the projector. Once the parameters are stored, the setting can be done just by selecting Mode in PC SYSTEM Menu (p.38). See MANUAL PC ADJUSTMENT on pages 40–41.

  • Page 40: Manual Pc Adjustment

    Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-Scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those special signal formats. The projector has 10 independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer.
  • Page 41 Reset To reset the adjusted data, select Reset and press the SELECT button. A confirmation box appears and then select [Yes]. All adjustments will return to their previous figures. Mode free To clear the adjusted data, select Mode free and then press the SELECT button.

  • Page 42: Image Level Selection

    Use the Point ed buttons to move the red frame pointer to the desired image level and then press the SELECT button. Standard Normal picture level preset on the projector. Real Picture level with improved halftone for graphics. IMAGE 1–10 User preset picture adjustment in the Image Adjust Menu.

  • Page 43: Screen Size Adjustment

    True Provide the image in its original size. When the original image size is larger than the screen size (1024 x 768), the projector enters to the panning mode automatically. Use the Point ed7 8 buttons to pan the image. When adjusted, the arrows will turn red. When reached to the correction limits, the arrows will disappear.
  • Page 44 When this function is set to “On, ” the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On, ” the picture is left/right reversed.

  • Page 45: Video Input

    When Video System is PAL -M or PAL -N, select the system manually. PAL/SECAM/NTSC/NTSC4 .43/PAL-M/PAL-N If the projector cannot reproduce proper video image, select a specific broadcast signal format from among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL -N.

  • Page 46: Image Level Selection

    Image Select Menu icon. Use the Point ed buttons to move the red frame pointer to the desired image level and then press the SELECT button. Standard Normal picture level preset on the projector. Cinema Picture level adjusted with fine tone. IMAGE 1–10 User preset picture adjustment in the Image Adjust Menu.

  • Page 47: Screen Size Adjustment

    Screen Size Adjustment Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Screen Menu icon. Use the Point ed buttons to move the red frame pointer to the desired function and then press the SELECT button.
  • Page 48 When this function is set to “On, ” the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear When this function is set to “On, ” the picture is left/right reversed.

  • Page 49: Picture Image

    Image Adjustment Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Image Adjust Menu icon. Use the Point ed buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box.
  • Page 50 Picture Image COLOR SELECTION MODE (continued) COLOR M . Return to the COLOR MANAGEMENT POINTER. (If you press the MENU button on the side control or the remote control, it returns to the COLOR MANAGEMENT POINTER and you will need to reselect and readjust the color.) MENU Return to the IMAGE ADJUST Menu.
  • Page 51 Off ..Progressive scan mode is “Off. ” On ..Progressive scan mode is “On. ” Film . . . For watching a film. With this function, the projector reproduces pictures faithful to the original film quality.

  • Page 52: Setting

    Setting This projector has a Setting menu that allows you to set up other various functions. Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Setting Menu icon.
  • Page 53 After capturing the projected image, go to the Logo select function and set it to “User” . Then the captured image will be displayed the next time you turn on the projector. To cancel the Capture function, select [No]. ✔...
  • Page 54 Setting Logo PIN code lock This function prevents an unauthorized person from changing the screen logo. Off ..The screen logo can be changed freely from the Logo Menu. On ..The screen logo cannot be changed without a Logo PIN code.
  • Page 55 Quit icon and press the SELECT button to set the RC code. The same code should set on both the projector and the remote control. For example, operating the projector in “Code 7” , the remote control code also must be switched to “Code 7”...
  • Page 56 ✔ Note: • Be sure to turn off the projector properly (see “Turning Off the Projector” on page 27). If the projector is turned off in the incorrect sequence, the On start function does not work properly.
  • Page 57 Off ..Unlocked. On1 . . . Enter the PIN code every time turning on the projector. On2 . . . Enter the PIN code to operate the projector once the power cord is disconnected; as long as the AC power cord is connected, the projector can be operated without a PIN code.
  • Page 58 A NEW PIN CODE IN COLUMN OF THE PIN CODE NO . MEMO ON PAGE 83, AND KEEP IT SECURELy . IF yOU FORGET yOUR PIN CODE, THE PROjECTOR CAN NO LONGER BE STARTED . Enter a PIN code After a correct Logo PIN code is entered, the following dialog box appears.
  • Page 59 Management The Shutter Management function turns off the projection lamp when the projector is left with the shutter closed and the set time has passed away. The count-down time can be set between 5 and 180 minutes. When the count-down time has elapsed, the shutter will be opened up automatically and the lamp will be turned off to cool itself down.
  • Page 60 (Fig. 1) appears on the screen and the total accumulated time turns red, indicating that the filter replacement is necessary. If the filter is out of scroll and the projector reaches a time set in the timer setting, Fig. 2 appears on the screen, indicating that the filter cartridge replacement is necessary.

  • Page 61: Maintenance And Care

    This projector has an electrically operated filter which helps you to replace the filter easily. The projector monitors the condition of the filter at all time and replaces a filter with a new one automatically when it detects the clogging.

  • Page 62: Replacing The Filter Cartridge

    Replacing the Filter Cartridge Turn off the projector, and unplug the AC power cord from the AC outlet. First, clean up the dust on the projector and around the air vents. Press s on the filter cover to release the latch and open the filter cover.

  • Page 63: Resetting The Filter Counter

    Resetting the Filter Counter Be sure to reset the Filter counter after replacing the filter cartridge. Press the MENU button to display the On-Screen Menu. Use the Point 7 8 buttons to move the red frame pointer to the Setting Menu icon. Use the Point ed buttons to move the red frame pointer to Filter counter and then press the SELECT button.

  • Page 64: Lamp Replacement

    Maintenance and Care Lamp Replacement When the projection lamp of the projector reaches its end of life, the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights orange. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE indicator should light is depending on the lamp mode.

  • Page 65: Resetting The Lamp Counter

    Replacement lamp can be ordered through your dealer. When ordering, give the following information to the dealer. Model No . of your projector ● Replacement Lamp Type No . ● Lamp counter PLC-XP200L POA-LMP124 (Service Parts No. 610 341 1941) Maintenance and Care Select Reset and the “Lamp replacement counter Reset?” appears.

  • Page 66: Lamp Handling Precautions

    Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service.

  • Page 67: Cleaning The Projection Lens

    Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents, or other harsh chemicals might scratch the surface of the cabinet. When the projector is not in use, put the projector in an appropriate carrying case to protect it from dust and scratches.

  • Page 68: Warning Indicators

    Maintenance and Care Warning Indicators The WARNING indicators show the state of the function which protects the projector. Check the state of the WARNING indicators and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING TEMP.

  • Page 69: Appendix

    A problem may be noticed with your graphics controller rather than with the projector. (When you reconnect the projector, be sure to turn the computer and monitor off before you turn on the projector. Turn on equipment in the order of the projector and computer.) 6.
  • Page 70 – Projecting from excessive slant angle to the screen may cause keystone distortion and partial imperfect focus. – Make sure the projection screen is at least 4.6’ (1.4 m) away from the projector. – Check if “Contrast” or “Brightness” are adjusted properly. (See page 49) –...
  • Page 71 – Power management function runs by initial setting. Check “SETTING” section on page – When the filter cartridge replacement icon keeps appearing on the screen at turning on the projector for some time and no action is taken to replace the filter cartridge, the The power is turned off projector will be automatically shut down in 3 minutes after turning on to protect the automatically.

  • Page 72: Menu Tree

    Image Adjust Image Adjust Input H-sync freq. V-sync freq. Screen Language Lamp status Power management Remote Control Shutter management Projector 5 - 180 Min Security Key lock PIN code lock Remote control Simple mode RC code SERIAL NO. 0–63 On/Off...
  • Page 73 Computer Input System ✽ System displayed in the System Menu varies depending on the input signal. PC Adjust Auto PC adj. Fine sync. Total dots Position H Position V Current mode Clamp Display area - H Display area - V Reset Mode free Store...
  • Page 74 RC code Code 1 Code 8 Quit Both/Front/Back Ready Shut down 1–30 Min. Quit On/Off Finger/Arrow/Dot Key lock Projector Remote Control PIN code lock Off/On1/On2 PIN code change Quit Protection Remote control On/Off Projector On/Off Management 5 - 180 Min.

  • Page 75: Indicators And Projector Condition

    The projector is preparing for stand-by or the projection lamp ✽ is being cooled down. The projector cannot be turned on until cooling is completed and the POWER indicator lights green. The projection lamp is being cooled down in the Power ✽...
  • Page 76 ✽ cannot be turned on until cooling is completed.) The lamp cannot light up. (The lamp has been cooled down enough and the projector is in stand-by mode and ready to be ✽ turned on with the ON/STAND-BY button.) The lamp has been used overtime. Replace the lamp immediately and then reset the lamp counter.
  • Page 77 WARNING FILTER indicator on the top panel lights up. Replace the filter as soon as possible. If the filter is out of scroll and the projector reaches a time set in the timer setting, Fig. 3 appears on the screen and the WARNING FILTER indicator lights up.

  • Page 78: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V- and H-Frequency mentioned below and less than 180 MHz of Dot Clock. ON-SCREEN RESOLUTION DISPLAy VGA 1 640x480 VGA 2 720x400 VGA 3...
  • Page 79 When an input signal is digital from the DVI terminal, refer to the chart below. ON-SCREEN RESOLUTION H-Freq . DISPLAy (kHz) D-VGA 640x480 31.470 D-480p 720x480 31.470 D-575p 720x575 31.250 D-SVGA 800x600 37 .879 D-XGA 1024x768 43.363 D-WXGA 1 1366x768 48.360 D-WXGA 2 1360x768...

  • Page 80: Technical Specifications

    Appendix Technical Specifications Mechanical Information Projector Type Dimensions (W x H x D) Net Weight Feet Adjustment Panel Resolution LCD Panel System Panel Resolution Number of Pixels Signal Compatibility Color System High Definition TV Signal Scanning Frequency Optical Information Projection Lamp...

  • Page 81: Optional Parts

    PJ-Net Organizer Plus IIC Lens Replacement The lens of this projector can be replaced with other optional lens. This feature enables you to use the projector for wide variety of uses. For installation and replacement of the lens, always contact the sales dealer. The projector lens must be installed or replaced by well-trained sales or service engineers.

  • Page 82: Configurations Of Terminals

    Appendix Configurations of Terminals ANALOG/ MONITOR OUT (Mini D-sub 15 pin) DIGITAL DVI-D (DVI 24 PIN) USB CONNECTOR (Series B) CONTROL PORT CONNECTOR (D-sub 9 pin) Input Red Input +5V Power Green Input Ground (Vert.sync.) Blue Input Ground No Connect DDC Data Ground (Horiz.sync.) Horiz.

  • Page 83: Pin Code Number Memo

    PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No.

  • Page 84: Dimensions

    Appendix Dimensions Unit: inch (mm) 6.5º MAX 5.75 (146) 14.57 (370) 4.33 (110) 5.20 (132) 4.33 (110) 4.13 (105) Screw Holes for Ceiling Mount Screw: M6 Depth: 0.393 (10.0)

  • Page 85: Serial Control Interface

    Serial Control Interface This projector provides a function to control and monitor the projector's operations by using the RS-232C serial port. Operation Connect a RS-232C serial cross cable to CONTROL PORT on the projector and serial port on the PC.

  • Page 86: Functional Execution Command

    Appendix Functional Execution Command Format The command is sent from PC to the projector with the format below; 'C' [Command] 'CR' Command: two characters (refer to the command table below. -The projector decodes the command and returns the 'ACK' with the format below;...

  • Page 87: Status Read Command

    'Character string' with the format below; Command Function Status Read Temperature Read The tables on page 86 and 87 show the typical command lists for controlling the projector. Please consult your local dealer for further information of other commands. Projector Projector status Return...
  • Page 88 KR7AL SANyO Electric Co ., Ltd .
