- Page 1 DIGITAL RADIOGRAPHY CXDI-Pro Instructions for Use...
-
Page 2: Note On Installation
6. For U.S.A. Rx only-Caution: Federal law restricts this device to sale by or on the order of a licensed practitioner. Note on installation • Request your sales representative or local Canon dealer to install the product. - Page 3 The information above, including information on batteries, is on our website in the official languages of each EU country. Please access https://global.canon/en/ifu/medcom/envfile/weee-battery- eu.pdf. Only for the United Kingdom This symbol indicates that this product is not to be disposed of with your household waste, according to the UK Waste Electrical and Electronic Equipment Regulations.
-
Page 4: Safety Information
Safety information Safety precautions Follow these safeguards and properly use the equipment to prevent injury and damage to any equipment/data. Operating/storage environment • Do not use or store the equipment near flammable chemicals such as alcohol, thinner, benzine, etc. If chemicals are spilled or evaporate, it could result in fire or electric shock through contact with electric parts inside the equipment. - Page 5 Canon dealers. The maximum temperature of the detector: 44°C*. * This is measured during Canon’s maximum load test when the ambient temperature is set to 35°C. Power supply and cables •...
- Page 6 Safety information Handling • Do not place anything on top of the equipment. The object may fall and cause an injury. Also, if metal objects such as needles or clips fall into the equipment, or if liquid is spilled, it could result in fire or electric shock. •...
- Page 7 Safety information • Do not place excessive weight on the equipment. Do not use the equipment in a manner that will subject it to local loads of 100 kg or more. If the load exceeds the limit, the inner device may be damaged. •...
- Page 8 • Should any of the following occur, immediately turn OFF the power to each piece of equipment, unplug the power cord from the AC outlet, and contact your sales representative or local Canon dealer: – When there is smoke, an odd smell or abnormal sound –...
- Page 9 Canon dealers. • Also contact your sales representative or local Canon dealers if other problems occur, such as harmful radio interference from this product to specified low-power radio stations for mobile object identification or amateur radio stations.
-
Page 10: Before Use
Safety information Notes for using the equipment When using the equipment, take the following precautions. Otherwise, problems may occur and the equipment may not function correctly. Before use • Sudden heating of the room in cold areas will cause condensation to form on the equipment. In this case, wait until the condensation evaporates before performing an exposure. - Page 11 Introduction This device provides digital image capture for conventional film/screen radiographic examinations. This device is intended to capture, for display, radiographic images of human anatomy, and to replace radiographic film/screen systems in all general purpose diagnostic procedures. This device is not intended for mammography applications. The image is obtained as the result of imaging X-rays passed through the human body with an X-ray flat panel detector and importing a digital signal output from the detector into the image processor.
-
Page 12: Operating Procedures
Operating procedures Preparations System startup Switch on the image-capture computer on which the control software is installed. Confirm that the control software starts and the initial settings screen is displayed on the monitor. Preparing to use the detector Attach a fully charged battery pack to the detector. Press the POWER switch of the detector to turn it on. -
Page 13: Data Processing
Operating procedures Checking exposed images When the exposed image is displayed on the monitor of the image-capture computer, confirm that the exposure conditions and target body part are correct, that there is no blurring due to patient movement, etc. Data processing Image processing such as LUT processing and frequency processing takes place using the image processing parameters set beforehand by the operator. - Page 14 Operating procedures List of detector status indication Standard Synchronization Mode Status indicators Detector status Power LED READY LED Power OFF Not illuminated Not illuminated Power ON Illuminated Not illuminated Linkage started Illuminated Flashing slowly in 4- second cycles (max. 8 seconds) Linkage ended Illuminated Illuminated (2 sec.)
- Page 15 Operating procedures Image processing adjustment To set the EIt value Elt value can be set in the processing parameter edit screen of the CXDI Control Software. Enter a value in the EIt text box referring to the current EI value. •...
-
Page 16: Troubleshooting
If the problem persists, turn off the detector, consult your sales representative or local Canon dealer, and inform them of the details of the problem, error codes or error messages. -
Page 17: Maintenance And Inspection
Maintenance Maintenance and inspection If any problem is found during the following inspections and cannot be resolved, please contact your sales representative or local Canon dealer. Daily inspection Cable (1) Ensure that the cables are not damaged and the cable jackets are not torn so as to expose the inside of the cables. -
Page 18: Monthly Inspection
Maintenance Monthly inspection (1) Conduct a Performance Test. (2) Regularly conduct a Self-diagnosis. Yearly inspection (1) Perform a Performance Test or Self-diagnosis using a phantom or resolution chart, etc. (2) Check the EI value captured. Irregular inspection (1) Perform calibration in the following circumstances. - When exposure conditions have changed significantly - When images appear strange in some way - When the installation environment has changed significantly... -
Page 19: Main Specifications
Specifications Main specifications Detector Environmental requirements: Operation Temperature: 5°C to 35°C Humidity: 30% to 80% RH (without condensation) Atmospheric pressure: 613 to 1060 hPa Storage (unpacked) Temperature: 5°C to 40°C Humidity: 30% to 85% RH (without condensation) Atmospheric pressure: 613 to 1060 hPa Transportation and storage (in packages at point of purchase) Temperature: –30°C to 50°C... - Page 20 Specifications Battery Pack LB-4A Type: Lithium ion battery Operation temperature range: 5°C to 35°C Rated voltage: 11.1 V DC Capacity: Typ. 1660 mAh / Min. 1600 mAh Cycle life: Approx. 300 cycles (fully charged to fully discharged) Dimensions and mass: Approx.
-
Page 21: Access Point
Specifications Access point Use a product that satisfies the following requirements. • Supports IEEE 802.11a/b/g/n/ac. • Supports WPA2 or WPA3. • Supports 10/100/1000BASE-T Ethernet network interface. Characteristics Spatial resolution properties A typical MTF value at 2 cycle/mm, RQA5 is 0.35, with measurement error of less than ±10%. -
Page 22: Regulatory Information
Member State in which the user and/or patient is established. Electronic instructions for use Instructions for use are available on the website for viewing and download by customers. • https://global.canon/en/ifu/medcom/index.html For details, please contact your sales representative or local Canon dealer. - Page 23 Regulatory information EMD (Electromagnetic Disturbances) This product is suitable for use in all establishments other than domestic and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes. Details of markings on the equipment Direct current Alternating current Type B applied part...
-
Page 24: System Components
System components Component products are available either individually or as part of a set. CXDI-Pro system (Unit: pieces) Detector Sensor Unit: CXDI-703C Wireless...........1 Battery pack: LB-4A...............2 CXDI Control Software CXDI Control Software NE: CSW-120R ........1 Ready indicator: RI-3A Hook-and-loop fastener (fastener hooks, fastener loops) (One pair is already applied to the product).... - Page 25 System components Optional function of software Scatter Correction for CXDI Series Advanced Edge Enhancement Free Rotation for CXDI Series *1 Improve the reduction in contrast caused by scattered radiation. *2 Enhance the display of catheters, bony parts, such foreign matter as gauze, etc., in a captured image.
-
Page 26: Service Information
Consumables The following consumable can deteriorate because of its characteristics and structure. For purchase of consumables, contact your sales representative or local Canon dealer. • Battery Pack LB-4A (Cycle life: Approx. 300 cycles) • Battery cover (Replacement period: Approx. every 2 years) Technical Description For the technical description, see the user’s manual of the product. - Page 28 *BT8-1855-EN01* Manufacturer: CANON INC. 9-1, Imaikami-cho, Nakahara-ku, Kawasaki, Kanagawa 211-8501, Japan Telephone: (81)-3-3758-2111 Revision Date: 2021-11 BT8-1855-EN01 1121P0.001 © CANON INC. 2021...
