Summary of Contents for Baumatic BAMW2330-P

  • Page 1 BAMW2330-P...
  • Page 2 BAMW2330-P Microwave Oven Instruction Manual...
  • Page 3 Welcome to Think Appliances Thank you for selecting a quality product from Think Appliances. We have taken the time to ensure that your appliance is of the highest possible standard and will give you years of use in your home. Please take the time to call our Customer Care centre on our free call number 1800 444 357 To register your 3 year parts and labour warranty (some conditions apply –...
  • Page 4 4) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. PLEASE- ONLY HAVE A QUALIFIED PERSON INSTALL THIS APPLIANCE, ALL, REPAIRS MUST ONLY BE CARRIED OUT BY A BAUMATIC ENGINEER OR ITS AUTHORISED AGENTS OTHERWISE THIS WILL INVALIDATE YOUR WARRANTY.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS: MICROWAVE SPECIFICATIONS…………………………………………………………..6 INSTALLING YOUR OVEN…………………………………………………………………..6 GROUNDING INSTRUCTIONS………………………………………………………………7 RADIO INTERFERENCE………………………………………………………………….…..7 IMPORTANT SAFETY INSTRUCTIONS…………………………………………………….8 MICROWAVE COOKING PRINCIPLES…………………………………………………….10 UTENSILS GUIDE……………………………………………………………………………10 MICROWAVE PART NAMES ....................11 CONTROL PANEL........................12 HOW TO SET THE OVEN CONTROLS ................13 CLEANING AND CARE ......................16 BEFORE YOU CALL FOR SERVICE ..................

  • Page 6: Microwave Specifications

    MICROWAVE SPECIFICATIONS Power Consumption: 230V, 50Hz, 900W (Microwave) 1000W (Grill) Rated Microwave Power Output: 900W Operation Frequency: 2450MHz Outside Dimensions: 305mm(H)x508mm(W)x405mm(D) Oven Cavity Dimensions: 214mm(H)x332mm(W)x346mm(D) Oven Capacity: 23Litres Cooking Uniformity: Turntable System{Φ314mm} Net weight: Approx. 16.5Kg INSTALLING YOUR OVEN 1) Make sure that all the packing materials are removed from the inside of the door.

  • Page 7: Grounding Instructions

    GROUNDING INSTRUCTIONS PLEASE NOTE: This appliance must be grounded. This oven is equipped with a cord with a grounding wire and a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electrical shock by providing an escape wire for the electric current.

  • Page 8: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using the electrical appliance basic safety precautions should be followed, including the following. To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1) Read all instructions before using the appliance. 2) Use this appliance only for its intended use as described in this manual.
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS – CONT: 8) Eggs in their shell and whole hard boiled eggs should not be heated in microwave ovens as they may explode even after microwave heating has ended. 9) Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts before cooking.

  • Page 10: Microwave Cooking Principles

    MICROWAVE COOKING PRINCIPLES Arrange food carefully. Place thickest areas towards outside of dish. Watch cooking time. Cook for the shortest amount of time indicated and add more as needed. Food severely overcooked can smoke or ignite. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.

  • Page 11: Microwave Part Names

    MICROWAVE PART NAMES 1. Door safety lock system 2. Oven Window 3. Oven Air Vent 4. Shaft 5. Roller Ring 6. Glass Tray 7. Control Panel 8. Door Release button 9. Grill Heater 10. Metal Rack...

  • Page 12: Control Panel

    CONTROL PANEL DISPLAY SCREEN: Cooking time, power, programme indicators and clock time are shown POWER: Press to select Microwave power level. GRILL: Press to set a grill cooking program (up to 60 minutes) COMBINATION: Cooking with combined microwave and grill power. TIME/ MENU: Turn the dial to set the oven clock time and input cooking time.

  • Page 13: How To Set The Oven Controls

    HOW TO SET THE OVEN CONTROLS Each time a button is touched, a beep will sound to acknowledge the touch. SETTING THE CLOCK TIME FOR EXAMPLE: Suppose you want to set the oven clock time to 8:30 (A.M. or P.M.). Press CLOCK/WEI.ADJ.
  • Page 14 HOW TO SET THE OVEN CONTROLS COMBINATION 1 The longest cooking time is 60 minutes. 30% time for Microwave cooking, 70% for Grill cooking. Use for fish, potatoes or au gratin. FOR EXAMPLE: Suppose you want to set Combination 1 cooking for 25 minutes. Press STOP/CANCEL button.
  • Page 15 HOW TO SET THE OVEN CONTROLS AUTO DEFROST The oven can be used to defrost meat, poultry, and seafood. The defrosting time and power level are automatically set once the food category and the weight are programmed. The frozen food weight ranges from 100g to 1800g. FOR EXAMPLE: suppose you want to defrost 600g of shrimp.

  • Page 16: Cleaning And Care

    CLEANING AND CARE: The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition would lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

  • Page 17: Before You Call For Service

    BEFORE YOU CALL FOR SERVICE: If the oven fails to operate: Check to ensure that the oven is plugged is securely. If it is not, remove the plug from the outlet, wait 10 seconds, and plug it in again securely. Check for a blown circuit fuse or a tripped main circuit breaker.
