Grizzly T33447 Instructions Manual

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The T33447 Rough Surface Mobile Base is
designed to give you a stable and mobile platform
upon which to mount machinery and equipment.
Inventory
Description
A. Right Front Corner Bracket ........................ 1
B. Left Front Corner Bracket ........................... 1
C. Right Rear Corner Bracket ......................... 1
D. Left Rear Corner Bracket ........................... 1
E. Side Rails 21" ............................................. 4
F.
Casters, 5" Swivel ...................................... 2
G. Wheels 5" ................................................... 2
H. Foot Pedals ................................................ 2
I.
Foot Pedal Springs ..................................... 2
J.
Foot Pedal Plungers ................................... 2
K. Adjustable Rubber Feet .............................. 2
L. Bearing Sleeves ......................................... 4
M. Shoulder Bolts M10-1.5 x 56 (Wheels) ....... 2
N. Shoulder Bolts M8-1.25 x 52 (Pedals) ........ 2
O. Hex Bolts M8-1.25 x 16 ............................ 24
P. Hardware (Not Shown)
—Lock Nuts M8-1.25 ................................ 10
Specifications
• Minimum Inside Dimensions .......... 19" x 21"
• Maximum Inside Dimensions .. 29
• Maximum Weight Capacity ............1200 lbs.
