- Page 1 XTS 163 XTS 163 DV OPERATOR MANUAL ISSUE 4...
- Page 2 Thank you and congratulations on choosing Parweld. This Owner’s Manual is designed to help you get the most out of your Parweld products. Please take time to read the Safety precautions. They will help you protect yourself against potential hazards in the workplace. With proper maintenance this equipment should provide years of reliable service.
-
Page 3: Table Of Contents
Contents Page 1.0 Safety Precautions 2.0 Product Description 3.0 Technical Specifications 4.0 Description of Controls 5.0 Installation 5.1 Unpacking the Machine 5.2 Location 5.3 Input and Grounding Connection 5.4 Output Polarity Connections 5.5 Torch Installation 5.6 Work Return Lead Connection 6.0 Operation 6.1 MMA Welding Guide 6.2 Basic TIG Welding Guide... -
Page 4: Safety Precautions
Insulate work clamp when not connected to work piece to prevent contact with any metal object. Protect yourself and others from flying sparks and hot metal. Be alert that welding sparks and hot materials from welding can easily go through small cracks and openings to adjacent areas. www.parweld.co.uk... -
Page 5: Product Description
BUILD UP OF GAS can injure or kill. Shut off shielding gas supply when not in use. Always ventilate confined spaces or use approved air-supplied respirator. Machine Model XTS 163 XTS 163 DV HOT PARTS can cause severe burns. Input voltage 230V +/- 10% 230/110V +/- 10% Do not touch hot parts with bare hands. -
Page 6: Description Of Controls
The XTS163 machine should only be used on 230v supply. Refer to currents. the specifi cations table for voltage tolerances. The XTS 163 DV will 5) Output power control knob for adjustment of the power output of automatically switch between 110 or 230V input without adjustment the machine in LIFT-TIG or MMA mode. -
Page 7: Torch Installation
Copper and alloys The most important factor is the high rate of heat conductivity of copper, making preheating of heavy sections necessary to give proper fusion of weld and base metal. www.parweld.co.uk... -
Page 8: Fault Finding
(d) Travel speed of current electrode is too high (c) Adjust (e) Scale or dirt on joint angle so the surface welding arc is directed more into the base metal (d) Reduce travel speed of electrode (e) Clean surface before welding. www.parweld.co.uk... - Page 9 Weld bead too Welding current is too Decrease weld wide and flat high current or undercut at edges of weld or excessive burn through www.parweld.co.uk...
- Page 10 Welding Poor work lead Ensure that the current connection to the work work lead has a reduces when piece reliable electrical welding connection to the work piece www.parweld.co.uk...
-
Page 11: Accessories
30PSI • Sensitive needle valve provides easy adjustment and the downward facing outlet connection eliminates hose kinking. Fittings • Fitted with standard ” BSP inlet and outlet connections Stock Code Description 706100 Flow Meter Mixed Gas 15 lpm www.parweld.co.uk... -
Page 12: Torch Exploded View
Air Cooled TIG Welding Torch 3/89 BSP Model Description Stock Code 12ft (3.8m) 25ft (7.6m) Valved Tig Torch c/w 2 Piece Power Cable and dinse connection WP17V-12-2-IX WP17V-25-2-IX Valved Flexible neck Tig Torch c/w 2 Piece Power Cable and dinse connection WP17VFX-12-2-IX WP17VFX-25-2-IX www.parweld.co.uk... - Page 13 Gas Lens Body .020” 0.5mm Bore 19 WP17VFX Torch Body Flexi-Valve 45V24 Gas Lens Body .040” 1.0mm Bore NI – Not Illustrated 45V25 Gas Lens Body 1/16” 1.6mm Bore 45V26 Gas Lens Body 3/32” 2.4mm Bore 45V27 Gas Lens Body 1/8” 3.2mm Bore www.parweld.co.uk...
-
Page 14: Ec Declaration Of Conformity
9.0 EC declaration of conformity Hereby we declare that the machines as stated below Type: XTS 163, XTS163 DV Conform to the EC Directives: Low Voltage Directive 2014/35/EEC EMC Directive 2014/35/EEC Harmonised European standard: EN/IEC 60974-1 This is to certify that the tested sample is in conformity with all provisions of the above detailed EU directives and product standards. -
Page 15: Weee Statement
WEE compliance outside the UK please contact your supplier/Importer Parweld is registered with a compliance scheme Official registration number is WEE/FD0255QV When your equipment reaches the end of its service life you should return it to Parweld where it will be reconditioned or processed for recycling. - Page 16 Parweld Limited Bewdley Business Park Long Bank Bewdley Worcestershire England DY12 2TZ tel. +44 1299 266800 www.parweld.co.uk info@parweld.co.uk...
