- Page 1 VC310 Digital Video Camcorder User Guide Model No. VS14314...
- Page 2 Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Important Safety Instructions
Important Safety Instructions 1. Read these instructions completely before using the equipment. 2. Keep these instructions in a safe place. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this equipment near water. Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. - Page 4 Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance Lead (Pb)
-
Page 5: Copyright Information
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic. com. The ViewSonic® Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. - Page 6 ® ViewSonic Digital Video Camcorder...
-
Page 7: Read This Before Using The Camcorder
• This User’s Manual is a general reference guide for the Camcorder. • The illustrations in this manual may not be the same as the actual design of your Camcorder and those you see on the LCD screen. -
Page 8: Table Of Contents
Read This Before Using the Camcorder ...2 Section 1 Getting to Know Your Camcorder ...4 Section 2 Getting Started ...7 Section 3 Enjoying the Record Mode ...10 Section 4 Enjoying the Playback Mode ...21 Section 5 Setting Your Camcorder ...26 Section 6 Viewing Photos and Videos on TV ...30... -
Page 9: Getting To Know Your Camcorder
With a color LCD monitor, you can view and examine the videos and photos easily. The 3” LCD touch panel is an ideal platform for you to operate your Camcorder. The menu options are accessible with your finger. With the touch panel, you can select the options directly and quickly. - Page 10 Front View Macro Switch Lens Light Rear View Playback LED Indicator HDMI Port TV Port Mini USB 2.0 Port Tele/Wide Button Speaker Microphone Record LED Indicator [Photo] Button [Video] Button LCD Touch Panel...
- Page 11 Side View Power Button [Playback] Button Pause Button Bottom View SD card Cover Tripod Socket...
-
Page 12: Getting Started
Follow u to push and eject the battery cover. Follow v to lift the cover. Loading the Battery Before using the Camcorder, you must load the supplied Lithium-ion rechargeable battery. 1. Insert the battery according to the correct polarity marks ( + or -). - Page 13 Inserting and Removing an SD Card (Optional) The Camcorder comes with an internal memory which allows you to store photos and videos. You can expand the memory capacity by using an optional SD memory card. 1. Insert the memory card into the slot. Please refer to the figure on the right side.
-
Page 14: Turning The Camcorder On
• To view stored videos and photos: Press [Playback Button] or touch the Playback mode. Turning the Camcorder Off • To turn off the Camcorder: You can either press [Power Button] for one second, or you can place the LCD panel back to its original position. Display Screen... -
Page 15: Enjoying The Record Mode
1. Switch to the Playback Mode. 2. For quick review, press it after recording. Power Button: 1. Press down for one second to turn on or turn off the Camcorder. Macro Switch: 1. Switch between Macro Mode and Normal Mode. -
Page 16: Lcd Monitor Information
LCD Monitor Information The indicators shown below may display on LCD when video and photo are recorded: Video Resolution Full HD (1080p 30 fps) HD (720p 60 fps) HD (720p 30 fps) VGA (640X480) Slow Motion (Record video at QVGA resolution.) Photo Resolution 16MP Recording time of the video that can still be taken at current... - Page 17 Scene Skin Night Backlight Black/White Classic Negative Self-timer enabled Motion Detection (Video Recording Only) Menu On Playback Mode On Digital Light On (10) Light On Light Off Stabilization (Video Recording Only) (11) (12) Macro Focusing On Date Printing On (Photo Only) (13) (14) SD Card Inserted...
-
Page 18: Video Recording
Video Recording • Press [Video Button] to start recording. When a video is being recorded, a time indicator will display on the LCD monitor ( ). To stop recording, press it again. • To pause recording: Press [Pause Button] to pause recording ( press it again. -
Page 19: Using Light Function
Using Light Function • The setting allows you to extend the brightness of the objects that are dark or in the shadow. Using the on-screen button to change the settings. 1. Digital Light On ( ): To extend the dynamic range for backlight and high contrast sense so that the objects will be brighter and clearer. -
Page 20: Video Resolution
2. Touch to select the desired option. 3. Touch the Exit icon ( ) to exit. Stabilization Record with an effect of reducing Camcorder shake to result in more stable video. Operation 1. In the Video menu, touch the [Stabilization] icon on the screen. -
Page 21: Motion Detection
2. Touch to select [On] or [Off] ( 3. Touch the Exit icon ( ) to exit. 4. Camcorder will start to record video automatically if it detects a movement. Stop recording if it does not detect a movement. Slow Motion Record videos with slow motion effect. -
Page 22: Photo Resolution
2. Touch the [Photo] icon on the screen. Submenu of Photo will pop out on the screen. 3. The Photo submenu contains 3 options-- Resolution, ISO, and Self-Timer --for you to adjust the Camcorder settings. Photo Resolution Three resolution settings are available. - Page 23 Self-Timer The self-timer allows you to take photos with a ten-second time delay. The LED light on the front of the Camcorder will also blink. The speed of blinking will increase just before the photo is taken. Operation 1. In the Photo menu, touch the [Self-timer] icon on the screen.
- Page 24 • Negative: The image is converted as the negative of the normal. Operation 1. In the Effect menu, touch the [Scene] icon on the screen. 2. Touch to select the desired option. 3. Touch the Exit icon ( ) to exit. Note To avoid blurry photos, place the Camcorder on a flat, steady surface, or use a tripod when taking shots in the Night Mode. Display Screen Display Screen...
-
Page 25: White Balance
3. Touch the Exit icon ( ) to exit. Face Tracking (Photo Only) The Camcorder can detect human face(s) and focus on the face(s) automatically. This function can works with photo capturing. It is wonderful for capturing beautiful portraits in backlight situation. Operation 1. -
Page 26: Enjoying The Playback Mode
Section 4 Enjoying the Playback Mode Button Function The Buttons have the following functions in Playback Mode. Video Button: 1. Press to go the Record Mode Photo Button: 1. Press to go the Record Mode Tele Button: 1. Volume increase. /Zoom in the photo Wide Button 1. - Page 27 LCD Monitor Information Indicators on the LCD screen while in Playback Mode: Video Playback Mode Video Resolution Full HD (1080p 30 fps) HD (720p 60 fps) HD (720p 30 fps) VGA (640X480) Slow Motion (QVGA) Photo Resolution 16MP 00:09:25 Video playback time counter. 0003/0005 Current number/ Total number of photo/video.
-
Page 28: Operations For Playback Mode
Video fast forward Next video/photo (10) Delete Slideshow (11) Slideshow stop (12) Magnification Indicator Operations for Playback Mode The Playback Mode is for viewing and managing videos and photos on the built-in memory or on an SD Card. Operation 1. Press [Playback Button] or touch switch to the Playback mode. -
Page 29: Video Playback
Video Playback Operation 1. In the Video Playback mode, touch or pause the video. 2. Sweep to the right or touch video; sweep to the left or touch video. 3. While playing video, touch forward. 4. Touch to increase the volume; touch reduce the volume. -
Page 30: Photo Playback
Photo Playback Operation 1. In the Photo Playback mode, sweep to the right or touch to go to the previous photo; sweep to the left or touch to go to the next photo. 2. While the photo is selected, press [Tele Button] to magnify. (The magnification Indicator appears on the screen) 3. -
Page 31: Setting Your Camcorder
2. Touch the [Setting] icon on the screen. Submenu of Setting will pop out on the screen. 3. The Setting submenu contains 7 options for configuring your Camcorder setup. They are Sound (operation sound), TV, Language, Time Setting, Date Printing, Format, and Default Setting. Sound Enable or disable the keypad tone and the operation sound. -
Page 32: Time Setting
Language Use this option to select the language of the user interface. Operation 1. In the Setting menu, touch the [Language] icon on the screen. 2. Touch to select the desired option. 3. Touch the Exit icon ( ) to exit. Time Setting Operation 1. -
Page 33: Default Setting
• Yes: Format the built-in memory ( When there is no SD card in the Camcorder ) / SD Card (When there is an SD card in the Camcorder). • No: Do not format the built-in memory ( When there is no SD card in the Camcorder ) / SD Card (When there is an SD card in the Camcorder). - Page 34 The following table indicates the Camcorder’s default settings Setting Resolution Stabilization Motion Detection Slow Motion Pre-Record Time Lapse Self-Timer Scene White Balance Light Sound Language Date Printing Volume Default Factory Setting FHD (1080p 30) for Video 5MP for Photo Auto...
-
Page 35: Viewing Photos And Videos On Tv
• Some functions may not be accessible while the Camcorder is connected to an HDTV. Connecting to a non-high-definition 4:3 TV 1. Connect one end of the AV cable to your Camcorder’s AV out port. 2. Connect the other end of the cable to a television. 3. The steps for viewing stored videos and photos on TV are exactly the same as for viewing them on the LCD screen. -
Page 36: Viewing Video & Photo On Pc
Transferring Photos or Videos to a Computer You can transfer photos or videos stored on your Camcorder to a computer and send them in e-mails to friends or post them on the web sites. To do this you should: 1. -
Page 37: Uploading Files To Internet
It helps you share them with your family and friends on the web site. To upload files to Internet: 1. Connect the Camcorder to your computer by using the supplied USB cable. 2. After making a USB connection, the AutoPlay window will appear. (It may be different based on OS recognition. - Page 38 3. The main screen appears automatically on the desktop. (To view the recorded clips on Internet Direct, it is necessary to install ArcSoft MediaImpression first. ) Note • The social media Web site may not be accessible in certain regions. • You must have internet access to upload videos to a Web site. 4. On the thumbnail screen, click on the up/down icon to change the pages. Click on the file(s) you want to upload.
- Page 39 6. Click on “ CANCEL” to stop uploading. To playback the video file: 1. Double click on the video clip on the thumbnail screen. 2. Click on the Play/Pause icon to play/pause. Click on the Return icon to return to the thumbnail preview screen.
-
Page 40: Specifications And System Requirements
Section 9 Specifications and System Requirements Specification Image sensor 5 Mega pixel CMOS sensor Operation modes Video record, Photo record Lens Fixed Focus (F 2.5) Focus range Macro Mode:20cm Normal Mode: 110 cm ~ infinite (HD+(720p 60) & HD(720p 30) ) Zoom 1X~16X (16X Digital zoom) Shutter... -
Page 41: System Requirements
System requirements • Microsoft Windows XP/Vista/7 • Intel Pentium 4, 2.4 GHz or above • 512 MB RAM • 1 GB free HDD space • Available USB port • CD-ROM Drive • 16-bit Color Display Note The LCD screen is manufactured using extremely high-precision technology, so over 99.99% of the pixels are operational for effective use. However, some tiny black and/or bright dots (white, red, blue or green) may appear on the LCD screen. These dots are a normal result of the manufacturing process, and do not affect the recording. -
Page 42: Section 10 Troubleshooting
The “!” means the SD card is low speed or is having wrong content inside. The way to solve this condition is to format SD card by the Camcorder instead of a PC (Please refer to the detailed Format instruction in User's Manual-Section 5). -
Page 43: Customer Support
(Mexico) Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America www.viewsonic.com/la/ (Peru) Macau www.hk.viewsonic.com... -
Page 44: Limited Warranty
Replacement product or parts may include remanufactured or refurbished parts or components. How long the warranty is effective: ViewSonic Digital Video Camcorder are warranted for 1 year for labor from the date of the first customer purchase. Who the warranty protects: This warranty is valid only for the first consumer purchaser. - Page 45 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon...
- Page 46 If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
- Page 47 E-Mail: rrrb@sureste.com Tijuana: Av Ferrocarril Sonora #3780 L-C Col 20 de Noviembre Tijuana, Mexico 4.3: ViewSonic Mexico Limited Warranty Villahermosa: Compumantenimietnos Garantizados, S.A. de C.V. AV. GREGORIO MENDEZ #1504 COL, FLORIDA C.P. 86040 Tel: 01 (993) 3 52 00 47 / 3522074 / 3 52 20 09 E-Mail: compumantenimientos@prodigy.net.mx...
