Please read these instructions carefully before using this product and save this manual for future use.
OPERATING INSTRUCTIONS
Contents
Getting Started
Introduction .................................................................
Description of Parts ..................................................
Preparation ...............................................................
First-time Operation ..................................................
Useful Information
On-screen Manual ....................................................
Handling and Maintenance .......................................
Reinstalling Software ................................................
Troubleshooting
Troubleshooting (Basic) ............................................
Appendix
LIMITED USE LICENSE AGREEMENT ...................
Specifi cations ...........................................................
Personal Computer
CF-H1
Model No.
series
2
3
10
12
14
18
19
21
23
27
28
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Panasonic Toughbook CF-H1ADBBZCM
Summary of Contents for Panasonic Toughbook CF-H1ADBBZCM
-
Page 1: Table Of Contents
For further information about the computer, you can refer to the on-screen manual. To access the on-screen manual page 18 “On-screen Manual” Please read these instructions carefully before using this product and save this manual for future use. OPERATING INSTRUCTIONS Contents Getting Started Introduction ... -
Page 2: Introduction
Introduction Thank you for purchasing this Panasonic computer. For optimum performance and safety, please read these instructions carefully. In these instructions, the names are referred as follows. “Windows Vista ® Business Service Pack 1” as “Windows” or “Windows Vista” “Microsoft ®... -
Page 3: Read Me First
<Only for model with a “CE ” mark on the Rear of the computer> Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this Personal Computer is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.doc.panasonic.de... - Page 4 Read Me First The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured Brown must be connected to the terminal which is marked with the letter L or coloured RED.
- Page 5 Failure to comply with these precautions violates safety standards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions* When in a hospital or other health care facility, observe the restrictions on the use of mobiles.
- Page 6 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the Panasonic Service Center or an experienced radio/TV technician for help. Notice for the products using LCD This product has a fl...
- Page 7 ACCESSORIES , LIFE SUPPORT SYSTEMS OR OTHER EQUIPMENTS/DEVICES/SYSTEMS THAT ARE INVOLVED WITH ENSURING HUMAN LIFE OR SAFETY. PANASONIC WILL NOT BE RESPONSIBLE FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES. AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems when used during critical phases of fl...
- Page 8 Use Only the Specifi ed AC Adaptor With This Product Using an AC adaptor other than the one supplied (attached to your product or supplied by Panasonic) may result in a fi re. Do Not Subject the AC Adaptor to Any Strong Impact Using the AC adaptor after a strong impact such as being dropped may result in electric shock, short circuit, or fi...
- Page 9 Use only the specifi ed battery pack (CF-VZSU53W) with your product. Use of battery packs other than those manufactured and supplied by Panasonic may present a safety hazard (generation of heat, ignition or rupture). When the Battery Pack Has Become Degraded, Replace...
-
Page 10: Description Of Parts
Description of Parts A: RFID Reader Button Reference Manual “RFID Reader” B: Barcode Reader Button <Model with Barcode Reader> C: Pen Holder D: LCD Reference Manual “Touch Screen Operation” E: Fingerprint Reader Reference Manual “Fingerprint Reader” F: LED Indicator : Power status Off: Power off/Hibernation Green: Power on Blinking green... - Page 11 Rear A: RFID Reader Reference Manual “RFID Reader”) B: Expansion Bus Connector C: Barcode Reader <Model with Barcode Reader> D: Strap E: Camera Reference Manual “Camera”) F: Battery 1 Case NOTE This computer contains a magnet and magnetic products at the battery cover. Avoid leaving metallic object or magnetic media in contact with these areas.
-
Page 12: Preparation
Preparation Confi rmation A Check and identify the supplied accessories. If you do not fi nd the described accessories, contact Panasonic Technical Support. • AC Adaptor ..1 Model No: CF-AA1633A • Digitizer Pen ... . . 1 •... - Page 13 About the battery for this computer This computer uses 2 battery packs. The battery is charged ( page 14) and power is consumed only on either battery pack. These operations switch to the other battery pack automatically. When the computer is connected to the Cradle (optional: CF-VEBH11U), the battery pack is charged when the AC adaptor is connected to the Cradle.
-
Page 14: First-Time Operation
When the CPU temperature is high, the computer may not start up to prevent overheating of the CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support. - Page 15 Setup Windows. A Follow the on-screen instructions. After turning on the computer, “Please wait while windows sets up your computer ...” appears, and then a small circle circulates on the screen. This will take a few minutes. Setup of Windows will take approximately 20 minutes. Go to the next step, confi rming each message on the display.
- Page 16 First-time Operation <Languages installed in this computer> • English • German • Spanish • Arabic • Chinese (Traditional) • Danish • Hungarian • Lithuanian • Portuguese (Brazilian) • Slovenian Change the language settings in the following menu. [start] - [Control Panel] - [Date, Time, Language, and Regional Options] - [Regional and Language Options] [Regional Options] - [Standards and Formats] [Languages] - [Language used in menus and dialogs]...
- Page 17 CAUTION Remember your password. If you forget the password, you cannot use the Windows operation system. Creating a password reset disk beforehand is recommended. NOTE PC Information Viewer This computer periodically records the management information of the hard disk, etc. The maximum data volume for each record is 1024 bytes.
-
Page 18: On-Screen Manual
Alternatively click [start] - [All Programs] - [Panasonic] - [Battery] - [Important Tips] or click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips]. NOTE When Adobe Reader update notice is displayed, we recommend you follow the on-screen procedure and update. -
Page 19: Handling And Maintenance
Handling and Maintenance Operation environment Temperature: Operation : 5 °C to 35 °C Storage : -20°C to 60 °C Humidity: Operation : 30% to 80% RH (No condensation) Storage : 30% to 90% RH (No condensation) Even within the above temperature/humidity ranges, using for a long time in an extreme environment will result in the product deterioration and will shorten the product life. - Page 20 Handling and Maintenance Maintenance To clean the computer Wipe with a soft dry cloth such as gauze. If needed, use alcohol cleaning agent to clean the computer. CAUTION Do not use ester contained agent, strong alkaline agent, benzene or thinner since it may adversely affect the surface causing discoloration, etc.
-
Page 21: Reinstalling Software
Back up important data to other media or an external hard disk before reinstallation. Preparation Prepare the following items: Product Recovery DVD-ROM Windows Vista Panasonic USB CD/DVD drive (optional) (refer to recent catalogs and other sources for information about the products available) Cradle (optional): Model No. CF-VEBH11U External keyboard Mouse Remove all peripherals (except for the CD/DVD drive). - Page 22 Reinstalling Software Turn on the computer. If the password is requested, enter the Supervisor Password. Perform the steps 3, 4 and 6 for setting up the computer ( Start the Setup Utility and change the settings as necessary. Perform Windows Update. pages 14 to 16).
-
Page 23: Troubleshooting (Basic)
Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the “Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact Panasonic Technical Support. You can also check the computer’s status in the PC Information Viewer Reference Manual “Checking the Computer’s Usage Status”). - Page 24 A Click [start] - [My Computer] and right-click [Local Disk(C:)], and click [Properties]. B Click [Tools] - [Check Now]. C Select the option in [Check disk options] and click [Start]. Start the computer in Safe Mode and check the error details. When the [Panasonic] boot screen disappears at startup, press and hold Menu is displayed.
- Page 25 The screen is dark. The screen might be darker when the AC adaptor is not connected. Adjust the brightness by using Panasonic Dashboard. As you increase the brightness, battery consumption increases. You can separately set the brightness for when the AC adaptor is connected and when not connected.
- Page 26 Troubleshooting (Basic) Touch Screen Operation The cursor does not work. Cannot point the correct position. Reference Manual The Reference Manual is not displayed. Cannot close full screen mode of Adobe Reader. Cannot choose the menu language of Adobe Reader. Others No response.
-
Page 27: Limited Use License Agreement
YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended results, and for the installation, use and results obtained therefrom. - Page 28 Bluetooth Stack for Windows ® by TOSHIBA, Wireless Switch Utility, Panasonic Hand Writing, Panasonic Dashboard, Application Button Setting Utility, Cleaning Utility, Wireless Connection Disable Utility* , Display Switch Utility, Battery Recalibration Utility, Infi neon TPM Professional Package , Protector Suite QL PC-Diagnostic Utility, MCA Platform Driver –...
- Page 29 Rated power consumption 23-E-1 Operations of this computer are not guaranteed except for the pre-installed OS and the OS which is installed by using the Product Recovery DVD-ROM provided by Panasonic. Must be installed before use. The Product Recovery DVD-ROM is required.
- Page 30 MEMO...
