Yamaha NAVIGO Owner's Manual

Yamaha NAVIGO Owner's Manual

Wheelchair power add-on kits
Hide thumbs
Table of Contents

Advertisement

Quick Links

Wheelchair Power Add-on Kits
OWNER'S MANUAL
READ THIS MANUAL CAREFULLY!
It contains important safety information.
X0F-28199-B2

Advertisement

Table of Contents
loading

Related Manuals for Yamaha NAVIGO

Summary of Contents for Yamaha NAVIGO

  • Page 1 Wheelchair Power Add-on Kits OWNER’S MANUAL READ THIS MANUAL CAREFULLY! It contains important safety information. X0F-28199-B2...
  • Page 2 WARNING: This product can expose you to chemicals including phthalates and lead which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov CAUTION: Federal law restricts this device to sale by or on the order of a practitioner licensed by the law of the State in which he/she...

  • Page 3: Table Of Contents

    1.3. Operation Diagnosis Check 1.4. Assistive Operation Diagnosis Check 1.5. Warnings and Notes for the Operation 1.6. Warning Label Location Diagram Names of Parts 2.1. NAVIGO 24″ 2.2. NAVIGO 16″ 2.3. Controller 2.4. Assistant Controller (Optional) 2.5. Nickel Metal Hydride Battery (JWB2) 2.6.
  • Page 4 After You are Finished Riding the Wheelchair 48 5.1. Getting Out of the Wheelchair 5.2. Removing the Battery How to Use the Assistant Controller 6.1. Getting in the Wheelchair 6.2. Starting Assistant Travel Mode 6.3. After Assistant Operations are Finished 7. Handling the Batteries and Chargers 7.1. Types of Batteries Nickel Metal Hydride Battery and Charger 59...
  • Page 5 11.7. Parameter Settings 11.8. Smart Tune Settings 12. Maintenance, Daily Check, Periodic Inspection 106 12.1. Maintenance 12.2. Daily Checks 12.3. End of NAVIGO Use Recycling 13. Dimensions and Specifications 14. Troubleshooting, Repairs, Warranty 14.1. Before Requesting Repairs 14.2. Requesting Repairs and Inspections 14.3. Serial Number Location...
  • Page 6 Introduction This is a manual for the “NAVIGO” electric power unit for wheelchairs. Before you read this manual, check which product you are using. This product consists of the left and right drive units, the joystick-equipped controller, the battery, optional battery bag, the battery charger, and the optional assistant controller.

  • Page 7: Please Read Before Use

    The NAVIGO 24″ withstands a load of 275 lb (125 kg). Use with a total maximum load including the chair frame weight of 275 lb (125 kg). NAVIGO 16″ withstands a load of 220 lb (100 kg). Use with a maximum load included the chair frame weight of 220 lb (100 kg).

  • Page 8: Symbols Used In This Manual

    1.2. Symbols Used in This Manual This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. A WARNING indicates a hazardous situation which, if not avoid- WARNING ed, could result in death or serious injury.

  • Page 9: Operation Diagnosis Check

    1.3. Operation Diagnosis Check Depending on the extent of your disabilities, it may be dangerous to travel unaccompanied. Use this diag- nosis check as a guide to determine whether or not you can travel unaccompanied. WARNING ● Before using the wheelchair, be sure to assess your competence and determine whether or not you need an assistant. Moreover, in determining the necessity of an assistant, consult expert opinions as a point of reference.

  • Page 10: Assistive Operation Diagnosis Check

    1.4. Assistive Operation Diagnosis Check Use the diagnosis check below as a guide to determine whether or not you can provide assistive operation. WARNING ● If an assistant is to accompany you and operate the wheelchair, be sure to assess his or her competence. Moreover, when assessing the assistant’s competence, consult expert opinions as a point of reference. If your judgment is based solely on your own opinion, you or other people around you may get injured.
  • Page 11 1.5.2. Powered Wheelchair Electromagnetic Interference (EMI) Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is pos- sible to unintentionally bring high levels of EM energy very close to the powered wheelchair’s control sys- tem while using these devices.
  • Page 12 CAUTION IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EF- FECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio wave sources Powered wheelchairs and motorized scooters (in this text, both will he referred to as powered wheel- chairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones.
  • Page 13 1.5.3. Before Use Each Day WARNING ● Perform the daily checks before use every day. Make a habit out of inspecting the wheelchair. Continued use of the wheelchair with a problem in the wheelchair body or the wheels may cause damage to the wheelchair while traveling, and may result in a rollover or fall.
  • Page 14 1.5.4. Handling the Wheelchair WARNING ● Modifying the unit or its mounting may adversely affect its performance and safety. Never make any modifications. ● If the wheelchair has parts that are foldable or detachable, do not operate the wheelchair with those parts folded or removed. ● When lifting the wheelchair, do not hold movable parts. ● Do not operate with any heavy baggage hanging over the backrest, or with any heavy objects in the compartment. The wheelchair could easily fall backward on an inclined slope, and may cause you or people around you to get injured.
  • Page 15 ● While operating the wheelchair, be careful not to get your hands tangled in the wheel spokes, wheel holes, etc. ● The wheels of the NAVIGO 16″ are not equipped with hand rims. When operating the NAVIGO 16″, do not manually drive the wheelchair by holding its rear tires or wheels. You may injure yourself. ● When moving past hedgerows and trees, maintain a suitable distance to prevent the rear wheels from coming into contact with twigs or other protruding items. If twigs or other...
  • Page 16 1.5.5. Getting In/Out of the Wheelchair, Seating WARNING ● When getting in the wheelchair by yourself or when the assistant has the user of the wheelchair get in the wheelchair, ensure that the wheelchair is on a level ground. If the user attempts to get in the wheelchair on an incline, he or she may lose balance and fall off the wheelchair.
  • Page 17 The weak electromagnetic waves emitted by the NAVIGO may affect other electronic devic- es, such as automatic doors and the anti-theft systems of stores. In this case, turn off the power and operate the wheelchair using the assistant operations or manual operation.
  • Page 18 WARNING ● Do not ride with clothing that is unsafe for wheelchairs, such as shown below. If you drive with such clothing, you or other people around you may get injured. Long scarves Clothing with loose sleeves Bare feet, sandals, slippers, Pants/skirts with wide hems ill-fitting footwear, etc.
  • Page 19 In the following environments and situations, you may need an assistant to accompany you and to oper- ate the wheelchair for you. In such cases, have an assistant accompany you. Traveling alone in these situations may lead to injury. Moreover, check to see if any dangers such as those shown below exist in the roads you use on a daily basis.
  • Page 20 1.5.8. Operation on Slopes WARNING The wheelchairs equipped with the NAVIGO are built to be lighter compared to other heavier electric wheelchairs that use a heavier general lead battery. For this reason, when a person sits in it, the overall center of gravity may be different. Therefore, use caution when traveling on a slope.
  • Page 21 1.5.9. Going Up/Down Curbs WARNING The wheelchairs equipped with the NAVIGO are built to be lighter compared to other electric wheelchairs that use a heavier general lead battery. For this reason, when a person sits in it, the overall center of gravity may be different. Therefore, use caution when traveling on a curb.
  • Page 22 WARNING ● When traveling over a curb, be careful not to lose your balance. ● When traveling over a curb, proceed at a right angle to the curb. Do not traverse the curb diagonally. ● Because the front casters are small, they are able to travel over only small curbs. There- fore, caution is necessary when traveling over curbs in power drive mode. ● When traveling between a sidewalk and a road, be careful of curbs. ● To travel over a curb or other obstacles with the assistant operations, turn off the assistant controller and go over it manually. If the assistant goes over a curb or other obstacles in power drive mode, the assistant could easily lose balance and the passenger or assistant could get injured if the wheelchair tips over.
  • Page 23 WARNING ● When crossing a street at a crosswalk with no traffic light, pay sufficient attention to the traffic. ● If there is a pedestrian signal light, obey the signal light. If the signal light is flashing green or is red, you must not start to cross the road. ● If the street is wide, the signal may change before you finish crossing. In such places, wait for the next green light to give yourself enough time to cross the street. ● At intersections where there are no traffic lights or crosswalks, stop in the following three stages. 1. Stop before entering the road. 2. Stop where you can be seen by automobiles. 3. Stop where you have a good view of the road. 1.5.11.
  • Page 24 1.5.12. Poor Road Conditions WARNING The wheelchairs equipped with the NAVIGO or the are built to be lighter compared to other electric wheelchairs that use a heavier general lead battery. For this reason, when a person sits in it, the overall center of gravity may be different. Therefore, use caution when traveling on uneven surface.
  • Page 25 1.5.13. Parking Lots WARNING ● Do not travel directly behind or in front of automobiles in parking lots. Drivers may not be able to see you if you are directly behind or in front of their automobiles. ● Do not travel between automobiles in parking lots. Otherwise, you could damage the auto- mobiles or be crushed when an automobile starts moving. 1.5.14. Using Public and Private Transportation WARNING ● When using public transportation, check to ensure that wheelchair use is allowed before- hand.
  • Page 26 1.5.15. Crowded Areas ● When getting in the wheelchair in a crowded area, do so with sufficient attention to your surroundings. If you bump into people or objects, your body may plunge forward, or people around you may get injured. ● When you are stopped in a crowded area, be sure to turn off the power. If a person in your surrounding area hits the joystick with his or her hand or arm, the wheelchair may start moving unexpectedly, causing injury to people around you.
  • Page 27 WARNING ● Avoid storing in direct sunlight or in places where the temperature can get high. ● Do not wash by directly hosing it down with water. Also, do not wash with using steam. The electronic devices can get damaged, which may lead to malfunction. ● Do not clean with solvents such as gasoline or paint thinner. This may damage the painting and plastic parts. 1.5.17. Assistant Operations in an Emergency WARNING ● During assistant operations in case of an emergency, the assistant should switch the clutch levers to the manual position, and move the wheelchair to a safe location.

  • Page 28: Warning Label Location Diagram

    1.6. Warning Label Location Diagram • Power Unit and Controller NAVIGO 16″ FRONT BACK...
  • Page 29 NAVIGO 24″ FRONT BACK...
  • Page 30 • Lithium Ion Battery (Back side) • Nickel Metal Hydride Battery...
  • Page 31 • Charger for Lithium Ion and Nickel Metal Hydride Battery (ESC3)

  • Page 32: Names Of Parts

    Names of Parts 2.1. NAVIGO 24″ Controller (Pages 28, 40, 42, 43) Rear tire (Page 33) Clutch lever (Pages 38, 50, 84, 86) Drive unit Upper holder Lower holder Upper holder lock lever Assistant controller (Optional) (Pages 28 and 50–53) Battery (Pages 29, 30, 54–80)

  • Page 33: Navigo 16

    2.2. NAVIGO 16″ Controller (Pages 28, 40, 42, 43) Rear tire (Page 33) Drive unit Upper holder Under holder Upper holder lock lever Assistant controller (Optional) (Pages 28 and 50–53) Battery (Pages 29, 30, 54–80) Anti-tip device (Page 32) Safety wheel...

  • Page 34: Controller

    2.3. Controller (Pages 35, 40–45) Joystick (Page 40) USB Power port Battery residual capacity indicator (Pages 40–43) Movement possible lamp Speed indicator (Page 42) Retracted anti-tip device warning lamp Power switch Speed selector (Page 40) switch (Page 42) Horn switch (Page 45) NOTICE ● The USB power port is used only to supply power. It does not feature any communication...

  • Page 35: Nickel Metal Hydride Battery (Jwb2)

    2.5. Nickel Metal Hydride Battery (JWB2) Indicator switch Grip (Handle) (Pages 36, 59, 62, 65) Release button (Yellow) (Page 49) Capacity indicator lamp (Pages 36, 59, 62 and 65) Battery fuse (Yellow 20 A) Contacts (Page 36) A code indicating the model (JWB2) A code indicating the model (JWB2) and the manufactured lot is printed.

  • Page 36: Lithium Ion Battery (Esb1)

    2.6. Lithium Ion Battery (ESB1) Grip (Handle) Capacity indicator lamp Indicator switch (Pages 36, 70, 75, 78) (Pages 36, 70, 73, 75, 78) Contacts (Page 36) Connector cover (Pages 75 and 77) Connector for charger (Pages 75 and 77) Manufactured date displayed (Bottom) (Page 74) Shows the model.

  • Page 37: Charger For Lithium Ion And Nickel Metal Hydride Battery (Esc3)

    2.7. Charger for Lithium Ion and Nickel Metal Hydride Bat- tery (ESC3) Power cord Charger plug for Lithium Ion Battery (Pages 75 and 78) (Pages 75 and 78) Contacts for Nickel Metal Hydride Battery (4 locations) Power plug Battery insertion slot for Nickel Metal Hydride Battery (Pages 63) Refresh switch...

  • Page 38: Before Sitting In The Wheelchair

    Check the safety wheels of the anti-tip device to ensure that they are in the correct position for oper- ation. In case of NAVIGO 24″ If the safety wheels are in the upward position, be sure to turn them to the downward position.
  • Page 39 (Check by pressing the tire with your finger.) Rear tire Rear tire If not enough, pump up to 65 PSI (450 kPa, 4.5kg/cm ) for NAVIGO 24″ or 50 PSI (345 kPa, 2.5kg/cm ) for NAVIGO 16″. NOTICE ● Please be advised the black tire may leave mark on floor or wall.
  • Page 40 Parking brakes Check to make sure that the park- ing brakes are applied. Push the wheelchair with the brakes applied on both wheels to ensure that the tires do not move. Check the parking brakes to en- sure that they do not wobble. Parking brake (example) Wheels...
  • Page 41 WARNING ● If the air pressure in the rear tires decreases, the parking brakes may become ineffective. Always keep the air pressure in the rear tires at the correct level. ● Continuing to use the wheelchair with a problem in the wheelchair body or the wheels may cause sudden damage to the wheelchair while traveling, and may result in a rollover or fall. ● If you find any unusual condition on the wheelchair in these inspections, contact your deal- Controller Check the controller to ensure that it is firmly secured to the wheelchair. (Try shaking and rocking the controller.) Check the joystick to ensure that it is in an easy-to-operate position.

  • Page 42: Checking Your Clothing

    3.2. Checking Your Clothing Wear bright-colored, easily visible clothing when operating the wheelchair. Do not operate the wheelchair while wearing clothing that is not suitable for wheelchair use. Refer to “1.5.6. General Operation” (Page 10). WARNING ● Do not travel with clothing that are not safe for wheelchairs. If you drive the wheelchair with such clothing, you or people in your surrounding area may become injured.
  • Page 43 <How to install a lithium ion (Li-ion 00) battery> Turn off the power switch. Insert the battery.  Pull the grip down to the side. ‚ Firmly insert the battery. Grip WARNING ● Do not drop or apply an impact to the battery. This may cause the battery to become damaged, overheat, or rupture. ● Do not insert the battery if the battery slot is dirty or wet.

  • Page 44: Riding The Wheelchair

    Riding the Wheelchair 4.1. Sitting in the Wheelchair Place the wheelchair in a level and stable location and turn off the power switch (yellow). Put the clutch levers of the left and right power units 24″ in the power drive position.  Power drive ..
  • Page 45 ● Get into the wheelchair in a level and stable location. If you park the wheelchair on an incline and try to get into it from there, you may lose your balance and fall out. ● When operating the NAVIGO 16″, have the assistant shift the left and right clutch levers. Even if there is no assistant, the individual in the wheelchair should still not shift the clutch levers.

  • Page 46: Moving The Wheelchair

    4.2. Moving the Wheelchair Turn on the power switch (yellow). When the power to the wheelchair is turned on, all the lamps on the controller illuminate. Then, after 1 second, the “retracted anti-tip device” warning lamp turns off, and the battery residual capacity indi- cator indicates the battery level.
  • Page 47 While traveling, if the load on the motor is too great, a buzzer (long Pi—, Pi—) sounds continuously. (a) Is the live load too great? The maximum load is 275 lb for NAVIGO 24″ and 220 lb (100 kg) for NAVIGO 16″. Do not ex- ceed the maximum load.

  • Page 48: Adjusting And Confirming The Maximum Speed

    4.3. Adjusting and Confirming the Maximum Speed With the speed selector switch, you can adjust and confirm the maximum speed. Move the switch up to increase the speed, and down to decrease it. Perform the following steps to adjust the maximum speed. Maximum speed Move the speed selector switch to change the selector switch speed.

  • Page 49: Checking The Residual Capacity Of The Battery During Operation

    4.4. Checking the Residual Capacity of the Battery during Operation You can always check the residual capacity of the battery with the LCD of the controller. Battery residual capacity indication Battery residual capacity indication The battery residual capacity indication varies according to the battery type. For the nickel metal hydride battery and lithium ion battery (gray case), the battery residual capacity is indicated in increments of 20%.

  • Page 50: Anti Theft Function

    4.5. Anti Theft Function How to Set the Anti Theft Function Turn on the power switch. Set the speed level 1 with the speed selector switch. Speed selector switch After releasing the switch once, hold the speed selector switch down and you will hear the beep sound. Press and hold the horn switch soon after the beep sound.

  • Page 51: Other Functions

    How to Unlock the Anti Theft Function Hold the speed selector switch up until the beep sound. Press and hold the horn switch after the beep sound. If you can hear the horn sound when you hold the horn switch, try again. Completed to unlock the anti theft function after “Pi”...

  • Page 52: Practicing Basic Operations

    4.7. Practicing Basic Operations Practice the basic operations on a safe, large, level ground. Basic Operations 1 In the beginning, adjust the maximum speed to a slow speed and learn how to use the joy-  stick. • Tilt the joystick in the direction you want to go. •...
  • Page 53 Practice in an actual location where you intend to use the wheelchair. Basic Operations 2 Sidewalk  • Be careful not to bump into pedestrians and obstruc- tions. • Adjust your operation to suit the road surface condi- tions. Up and down a level difference ‚...

  • Page 54: After You Are Finished Riding The Wheelchair

    After You are Finished Riding the Wheelchair 5.1. Getting Out of the Wheelchair WARNING ● After you are done traveling in power driver mode, be sure to turn the power off. If the power is on when you get off the wheelchair, your body may hit against the joystick, causing it to start moving, and you or people in your surrounding area may get injured. ● Get off the wheelchair in a level and stable location. If you park the wheelchair on an incline and try to get off it from there onto a bed or a chair, you may lose your balance and fall off the wheelchair. ● If you get off the wheelchair with the left and right clutch levers in the manual position and the parking brakes released, the wheelchair may move unexpectedly, causing you to fall off and injure yourself. When getting off the wheelchair, make sure that the left and right clutch levers are in the power drive position and the parking brakes are applied.

  • Page 55: Removing The Battery

    5.2. Removing the Battery Disconnect the battery from the wheelchair. Store the battery with the protective cap on it. <How to remove a nickel metal hydride (Ni-MH) battery> Turn off the power switch. Disconnect the battery by pulling Store the battery with the it straight outwards while press- protective cap on it.

  • Page 56: How To Use The Assistant Controller

    How to Use the Assistant Controller Even if you are using the wheelchair with assistive operation, read “3. Before Sitting in the Wheelchair”, “4. Riding the Wheelchair”, “5. After You are Finished Riding the Wheelchair”. 6.1. Getting in the Wheelchair Have the user get in the wheelchair according to “4.1.
  • Page 57 Adjust the Maximum speed as necessary. Turn the speed adjustment dial clockwise to increase speed, and counterclockwise to decrease speed. Slow Fast In the beginning, adjust it to a low speed. Gradually adjust the speed after you become accustomed to the operation. The speed can be adjusted steplessly within the range of 0.6 to 3 mph (1.0 to 4.8 km/h) forward and 0.2 to 1.1 mph (0.4 to 1.9 km/h) backward.
  • Page 58 If the power does not turn on Is the power for the controller turned on? If the power for the controller is turned on, the power for the assistant controller will not turn on. In this case, turn off the power switches on both controllers, and turn on the power for the assistant controller.

  • Page 59: After Assistant Operations Are Finished

    6.3. After Assistant Operations are Finished Park the wheelchair on a flat location. Turn off the power switch. Power switch Apply the parking brakes. Set the left and right clutch levers in the power drive position. Have the user get off the wheelchair. Disconnect the battery from the wheelchair.

  • Page 60: Handling The Batteries And Chargers

    Read “8. Nickel Metal Hydride Battery and Charger” if you are using a nickel metal hydride battery, and “9. Lithium Ion Battery and Charger” if you are using a lithium ion battery. Recycling the battery The battery for NAVIGO is a recyclable battery that contains valuable re- sources. Contact the dealer to recycle your used batteries.
  • Page 61 WARNING ● If you mishandle either of these batteries or their chargers, it may result in heat generation, rupture, electric shock, or injury. Be sure to adhere to the items below. Do not recharge the battery using a charger other than the designated charger, or use the battery on anything other than the specified wheelchair. Do not touch the metal terminals of the battery or charger directly with your fingers or clean the terminals with a wet towel. Otherwise, electric shock or a short circuit could result. Do not disassemble or modify the battery.
  • Page 62 WARNING ● If you mishandle either of these batteries or their chargers, it may result in heat generation, rupture, electric shock, or injury. Be sure to adhere to the items below. Do not store the battery in a place where children or pets could come near it. Do not drop or subject the battery to impact. Do not use a broken or damaged battery.
  • Page 63 WARNING ● If you mishandle either of these batteries or their chargers, it may result in heat generation, rupture, electric shock, or injury. Be sure to adhere to the items below. The charger can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the charger in a safe way and understand the hazards involved.
  • Page 64 WARNING ● If you mishandle either of these batteries or their chargers, it may result in heat generation, rupture, electric shock, or injury. Be sure to adhere to the items below. Do not insert the cords or other items into the Nickel Metal Hydride battery sock- If the battery or the charger is deformed or has an unusual odor, or if you notice any other abnormality, do not use the battery or charger.

  • Page 65: Nickel Metal Hydride Battery And Charger

    Nickel Metal Hydride Battery and Charger 8.1. Features of the Nickel Metal Hydride Battery (JWB2) • Equipped with Battery Management Control System (BMC). (built-in microprocessor) This is a system that uses a computer to track charge/discharge status, operating conditions, and temperature. •...
  • Page 66 Storing the battery Store batteries in a cool, dry area. (A location with a tem- perature between 50 – 77°F (10 – 25°C) is optimal for storing.) Fully charge the battery that you do not plan to use for a long period of time (30 days or more).

  • Page 67: Characteristics And Handling Of The Nickel Metal Hydride Battery (Jwb2)

    8.3. Characteristics and Handling of the Nickel Metal Hydride Battery (JWB2) Ambient temperatures Depending on the ambient temperature, the distance that can be traveled becomes shortened. In order to maximize the battery’s performance, it is recommended that you use the battery under the following conditions.
  • Page 68 Battery’s deterioration characteristics All batteries are consumables. A battery gradually deteriorates and its capacity decreases over time and with use. The extent to which the capacity decreases by deterioration depends on the use conditions. For a nickel metal hydride battery, its capacity will decrease to approximately 60% of that of a new battery after 300 charge/discharge cycles, under normal use.

  • Page 69: How To Charge The Nickel Metal Hydride Battery (Jwb2)

    8.4. How to Charge the Nickel Metal Hydride Battery (JWB2) NOTICE ● Do not use this charger if the power cord is wound around the unit. Otherwise, the charger may overheat and be damaged. ● Make sure that the charging plug and the battery charging connector are free of dust, dirt, oil, and moisture. Also, do not insert any metallic object or other foreign substance into the plug or the connector, for this may cause the charger to malfunction or damage the battery. ● Do not place the charger in locations exposed to direct sunlight, near a heater or other heat source, or where the temperature may drop below freezing.
  • Page 70 Charging  Place the charger on a flat, stable surface with the charge indicator lamp facing up. ‚ Insert the charger plug into the charger and insert the power plug into the residential power outlet. Power plug Residential power outlet Power cord Charger plug Charger...
  • Page 71 Assuming the charging process started from an empty state, the time it takes from start to completion of the charging process is typically 2.5 to 3 hours. If charging in a location with a high temperature or if charging a brand new battery, this may take longer.
  • Page 72 WARNING ● Be sure to store the disconnected battery with the protective cap on it. Exposed contacts can cause short circuits and lead to a fire or battery rupture. • If you are unable to charge the battery Refer to “14. Troubleshooting, Repairs, Warranty”. • If the vehicle has traveled a long distance or on a long uphill grade, or if it has been left out- side in the cold for a long time, the battery temperature may not be suitable for charging.

  • Page 73: Refresh Charging The Nickel Metal Hydride Battery (Jwb2)

    8.5. Refresh Charging the Nickel Metal Hydride Battery (JWB2) A refresh charging is required on a nickel metal hydride battery to eliminate the memory effect. When the battery is inserted to the charger, if the refresh lamp (orange) on the charger flashes, press the refresh switch to perform a refresh charge cycle.

  • Page 74: Charger (Esc3) Indicator Lamps

    Tips on charging • It is recommended that you charge the battery while you are sleeping. • Since the refresh charging process recharges after discharging all of its remaining elec- tricity, it will take a long time if you perform it on a battery with a high residual capacity. It is recommended that you perform a refresh charging on a battery that is drained as much as possible.
  • Page 75 Battery capacity Charger lamp indication Description indicator lamps Lit or flashing red The charger has detected a problem in the charger or the battery, and is unable to charge. Stop charging by disconnecting the charger plug and the power plug. Check the battery, charger, and cord connection for any problem, and then try charging again.

  • Page 76: Lithium Ion Battery And Charger

    Lithium Ion Battery and Charger 9.1. Features of the Lithium Ion Battery (ESB1) • Has a higher energy capacity compared to the nickel metal hydride battery. • Equipped with Battery Management Control System (BMC). (built-in microprocessor) This is a system that uses a computer to track charge/discharge status, operating conditions, and temperature.
  • Page 77 Storing the battery Store batteries in a cool, dry area. (A location with a tem- perature between 50 to 77°F (10 to 25°C) is optimal for storing.) If you are not planning on using the battery for a long pe- riod of time (30 days or more), charge it so that 3 of the capacity indicator lamps comes on, and then store it.

  • Page 78: Characteristics And Handling Of The Lithium Ion Battery (Esb1)

    9.3. Characteristics and Handling of the Lithium Ion Bat- tery (ESB1) Ambient temperatures Depending on the ambient temperature, the distance that can be traveled becomes shortened. In order to maximize the battery’s performance, it is recommended that you use the battery under the following conditions.
  • Page 79 Battery’s deterioration characteristics All batteries are consumables. A battery gradually deteriorates and its capacity decreases over time and with use. The extent to which the capacity decreases by deterioration depends on the use conditions. For a lithium ion battery, its capacity will decrease to approximately 60% of that of a new bat- tery after 700 charge cycles, under normal use.
  • Page 80 If you forget the date you started to use the lithium ion battery. The battery’s manufactured date is printed on its bottom. Use it as a reference. 180831 Manufactured August(8) 31, 2018 • The start date of battery usage is defined as the date the user charged the battery for the first time after shipment from the factory.

  • Page 81: How To Charge The Lithium Ion Battery (Esb1)

    9.4. How to Charge the Lithium Ion Battery (ESB1) There are two ways to charge the battery; by removing it from the wheelchair (tabletop charging), or while it is still attached to the wheelchair (on-vehicle charging). NOTICE ● Do not use this charger if the power cord is wound around the unit. Otherwise, the charger may overheat and be damaged. ● Make sure that the charging plug and the battery charging connector are free of dust, dirt, oil, and moisture.
  • Page 82 Charging the battery out of the unit (tabletop charging)  Place the charger on a flat, stable surface with the charge indicator lamp facing up. ‚ Check that the protective cap is on the battery. If the protective cap is not attached, be sure to attach it.
  • Page 83  After charging has completed, unplug the char- Charger plug ger plug and the power plug, then securely close the battery’s connector cover. Connector cover Power plug NOTICE ● Do not pull on the power cord. This can cause the wires to break. Charging the battery attached to the wheelchair (on-vehicle charging)  Prepare for charging. Remove any bags and luggage from the backrest, and anything else that can potentially tangle the charge cable.
  • Page 84 … Check that the charge lamp (green) on the charger turns on. If the charge lamp does not comes on green, see “9.6. Charger (ESC3) Indicator Lamps”. Charge lamp  While charging, you can check the charge sta- tus using the capacity indicator lamps on the battery.

  • Page 85: The Temperature Of The Lithium Ion Battery (Esb1) During Charging

    9.5. The Temperature of the Lithium Ion Battery (ESB1) during Charging Charge the battery in an environment with a temperature of 50 to 77°F (10 to 25°C). • To protect the battery, if the internal temperature of the battery is Charge lamp under 32°F (0°C) or over 104°F (40°C), charging does not start.

  • Page 86: Charger (Esc3) Indicator Lamps

    9.6. Charger (ESC3) Indicator Lamps The charger (ESC3) for the lithium ion battery has a charge lamp to indicate the battery and charging conditions accord- ing to the lamp’s color and whether it is on or flashing. The lamp indications are explained in the following table. Charge lamp Battery capacity Charger lamp indication...

  • Page 87: Wheelchair Transporting And Storing Instructions

    10. Wheelchair Transporting and Storing Instructions Please refer to the Warnings in “1.5.16. Transporting and Storing the Wheelchair” on page 20 to 21. 10.1. Loading the Wheelchair in a Car Turn off the power of the wheelchair. Remove the battery. Be sure to remove the battery from the wheelchair so that its power will not turn on unexpectedly during transport.
  • Page 88 WARNING ● Be sure to store the disconnected battery with the pro- tective cap on it. Exposed contacts can cause short circuits and lead to a fire or battery rupture. Protective cap Load the wheelchair into the car. Gently load the wheelchair by holding the frame portion with both hands. Secure the wheelchair. Secure the wheelchair to prevent it from moving or hitting any sur- rounding objects.

  • Page 89: Unloading The Wheelchair From A Car

    10.2. Unloading the Wheelchair from a Car Unload the wheelchair from the car. Reattach the removed parts, detached units back to their original places, and unfold the wheelchair. Check that the parking brakes are applied. Check that the anti-tip device is in the correct position. When unloading: •...

  • Page 90: Storing The Wheelchair

    10.3. Storing the Wheelchair Apply the parking brakes and set the left and right clutch levers in the power drive position. Turn off the power and remove the battery. Store the wheelchair indoors where there is less humidity. To wipe off dirt or spots before storing, use a tightly wrung-out towel.

  • Page 91: Boarding An Airplane

    10.4. Boarding an Airplane Once your plane trip has been determined, inform your airline company in advance, that you will be using an electric wheelchair, and follow their instructions. At this time, provide the airline company with details of your wheelchair. In particular, see the specifications for the battery you are using, below: ■...

  • Page 92: Wheelchair Disassembly And Adjustment

    11.1. Removing and Installing the Unit The power units of the NAVIGO can be removed from the frame when replacing the current wheels with manual wheels or when transporting the wheelchair. Removing the power units from the frame ...
  • Page 93 „ Attach the cap to prevent dirt or water from entering the connector. Connector … Place the wheelchair so that it will not become unstable when the power units are removed. (For example, as shown in the figure.)  Release the parking brakes. ...
  • Page 94 „ Push in each power unit completely. Check to ensure that the two balls “a” on the end of the axle can be seen completely. … Pull each power unit to ensure that it will not come off.  Place the power units in their normal position, and then apply the parking brakes.
  • Page 95  Install the battery. Click! WARNING ● When a person is sitting in the wheelchair, do not remove or install the wheels. The person riding in the wheelchair or people around the wheelchair may get injured. ● After the power units are installed to the frame, be sure to check that the balls on the end of each axle can be seen, and that the units will not come off if pulled. If the axles are not secured, the axles could suddenly come off while the wheelchair is traveling and the wheel- chair could tip over, causing serious injury.

  • Page 96: How To Remove And Install The Battery Bag

    11.2. How to Remove and Install the Battery Bag Remove the battery. Battery Bag Remove the coupler at cable tip and install a cap. Remove the hook-and-loop fastener underneath of Belt battery bag. Remove the hook-and-loop fastener of battery bag band part and remove the battery bag.
  • Page 97 NOTICE ● Attach the hook-and-loop fastener (male) at both edges of belt to entire surface. Slide the belt and adjust the two (2) belt edges to the vi- Frame cinity of vehicle center as much as possible. Belt Belt Edge Frame Belt Belt Edge NOTICE ● The belt edges should not be near the frame or touching moving parts (as shown incorrectly in the “NG” inset drawing). ● Make sure the belt is taut. A slack or loose belt could allow the battery bag to come off or the belt could get caught in moving parts.
  • Page 98 Case of Battery Bag Band Tip Part not Reaching to Battery Frame Attach the fitting tape aligned to the band part tip of bat- Battery Bag tery bag. Band Part of Battery Bag (10) After feeding the band part of battery bag through the frame, attach the fitting tape of band edge part to the Fitting Tape band.

  • Page 99: Anti-Tip Device

    Fastener 11.3. Anti-tip Device The anti-tip device of the NAVIGO can be turned upwards. Do so when going over bumps with the assis- tant operations. Immediately after going over a bump, return the anti-tip device to its original position. NAVIGO 24″...
  • Page 100 Returning the turned anti-tip device to its original posi- tion Pull the lock knob and turn the anti-tip device downward without touching the lock lever until you hear a click. Lock lever Anti-tip device Move the anti-tip device back and forth and side to side to ensure that it is locked in position.
  • Page 101 In case of NAVIGO 16″ Placing the safety wheels in an upward-facing position  Press in the lock pin on the underside with your Lock pin finger. ‚ Turn the anti-tip device 180° while the lock pin is pressed in. Placing the safety wheels in a downward-facing position Lock pin ...

  • Page 102: Controller Holder

    11.4. Controller Holder Handling of the controller holders is difference depends on their type. • Adjusting the mounting position of the controller The Mounting position and angle of the controller can be adjusted. Consult with your dealer on this adjustment. •...
  • Page 103 WARNING ● Do not remove the controller from the upper holder with the power on, and do not turn on the power after removing it. The joystick may tilt, causing the wheel- Power chair to move unexpectedly, and this may result in in- jury to you or other people in your surrounding area. ● Never travel in power drive mode with the controller removed from the upper holder.
  • Page 104 11.4.1. Vertical type controller holders (Standard) Adjusting the mounting position of the controller The Mounting position and angle of the controller can be ad- justed. Consult with your dealer on this adjustment. How to retract the controller Turn off the power switch. Move the upper holder lock lever outward.
  • Page 105 Insert the controller into the lower holder. Lower holder To return the controller to its original position, reverse the procedure. 11.4.2. Parallel arm type controller holders (Optional) Adjusting the mounting position of the controller • Adjusting the Horizontal position The Mounting position can be adjusted for 3 positions of Center, inner and outer side. Turn off the power switch.
  • Page 106 • Adjusting the Forward/Backward, angle and direction Consult with your dealer on this adjustment. Forward/Backward Angle Direction How to retract the controller Turn off the power switch. Moving the controller with pulling up the Lock lever. Lock lever The moving range is wider than the range of the fixed position.
  • Page 107 11.4.3. Horizontal type controller holders (Optional) Adjusting the mounting position of the controller • Adjusting the position, angle and direction Consult with your dealer on this adjustment. Position Angle Direction How to retract the controller Turn off the power switch. Turn the controller while the lock lever of the holder is pushed forward.

  • Page 108: Assistant Controller (Optional)

    Consult with your dealer on this adjustment. 11.7. Parameter Settings The settings of the features and characteristics of the NAVIGO can be changed to fit your usage. These changes are performed by changing the “parameter settings”. Consult with your dealer on changing the parameter settings.
  • Page 109 ‚ Buzzer sound This function is for sounding a buzzer when the power is turned on, or when an error such as disengaged clutches occurs. Setting 1 .... The buzzer sound is enabled. (Default setting) Setting 2 .... The buzzer does not sound when the power is turned on, the maximum speed is adjusted, the controller is operated with the clutch levers in the manual position, etc.

  • Page 110: Smart Tune Settings

    11.8. Smart Tune Settings The settings of the features and characteristics of NAVIGO can be changed to fit your usage. These changes are performed by changing the “parameter settings” with using PC and the Smart Tune software. Consult with your dealer on changing the parameter settings.
  • Page 111 Driving Parameters You can adjust settings such as speed, acceleration, and joystick sensitivity.  Preset mode Select from 3 preset modes. Setting 1 .... Soft mode Setting 2 .... Normal mode (Default setting) Setting 3 .... Sports mode ‚ Free mode You can fine-adjust such settings as the speed, acceleration, motor torque.

  • Page 112: Maintenance, Daily Check, Periodic Inspection

    12. Maintenance, Daily Check, Periodic Inspection It is recommended that the NAVIGO be inspected periodically at the dealer. (Inspection is fee-based) To ensure long-term durability, we recommend that your perform regular inspections every 6 months after initial use. Sample Inspection Form...

  • Page 113: Maintenance

    [Cleanup] If the NAVIGO becomes dirty due to normal use, use a tightly wrung-out towel to wipe off any dirt. If the dirt is excessive, use a towel and neutral detergent to remove the dirt. After removing the dirt, be sure to wipe off any remaining detergent.
  • Page 114 If the rubber covers are damaged or lost, contact the dealer for replacements. If you continue to use the NAVIGO when these parts are damaged or not installed, dust or water could enter the unit and cause it to malfunction.

  • Page 115: Daily Checks

    12.3. End of NAVIGO Use Recycling When the NAVIGO is at the end of its service life and must be disposed, contact your local government office first for recycling and follow their instructions. Or contact your dealer to recycle your used NAVIGO...

  • Page 116: Dimensions And Specifications

    *2 Maximum height of curbs that can be gone over is depended on the Wheelchair’s caster size. *3 The value is the load capacity for the NAVIGO. When the wheelchair is completely assembled, the total weight of the rider and luggage must not exceed the load capacity of the wheelchair frame.
  • Page 117 Battery and Charger Nickel-Metal Hydride Lithium-ion Model JWB2 ESB1 Rechargeable Dry Battery Type with built in microprocessor Battery Nominal output voltage 24 V 25 V Rated output (5-hour rate) 6.7 Ah (160.8 Wh) 11.8 Ah (295 Wh) Model ESC3 Automatic Charging Charging method controlled by the microprocessor Rated input during charging...

  • Page 118: Troubleshooting, Repairs, Warranty

    14. Troubleshooting, Repairs, Warranty If you have flat tires, contact your dealer. The tire structure of NAVIGO is same to bicycle tires. Most of cycle shops can repair the flat tires. 14.1. Before Requesting Repairs Check the following troubleshooting tables. Flashing When Operating the Wheelchair Problem LCD Indication Buzzer Check Point What to Do Beeps (Pi Pi) Are the clutch levers in the manual drive...
  • Page 119 Problem LCD Indication Buzzer Check Point What to Do Beeps (Pi —) It will stop beeping once the load is re- Is there a large load being applied? repeatedly duced. Is there a large load being applied, causing Lighten the load so that the motor will not the motor to overheat? overheat.
  • Page 120 When Charging with ESC3 (Ni-MH Nickel Metal Hydride Battery) Charger LED Battery LED Problem Check Point What to Do Indication Indication Connect the power cord to a power Is the power cord connected? source. If it can be charged, the charger is nor- mal.
  • Page 121 When Charging with ESC3 (Li-ion 00 Lithium Ion Battery) Charger LED Battery LED Problem Check Point What to Do Indication Indication Connect the power cord to a power Is the power cord connected? source. If it can be charged, the charger is nor- mal.

  • Page 122: Requesting Repairs And Inspections

    14.2. Requesting Repairs and Inspections For your inspection, repair, and service needs, contact the dealer from which you purchased NAVIGO. When contacting the dealer, your product serial number may be required. Refer to below to check the se- rial number, and provide it to the dealer.

  • Page 123: Warranty Statement

    NAVIGO Wheelchair Power Add-on Kit is properly operated, maintained and stored as specified in the applicable Owner’s Manual. The owner of the NAVIGO Wheelchair Power Add-on Kit shall give notice to an authorized Yamaha JW dealer of any and all apparent defects within ten (10) days...
  • Page 124 Examples of abuse and neglect include, but are not limited to: 1. Improper installation of the NAVIGO Wheelchair Power Add-on Kit or mounting and using the product on equipment incompatible with its design and operating parameters.
  • Page 125 NAVIGO OWNER’S MANUAL ©2021 by Yamaha Motor Corporation, U.S.A. December 2021 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
