NETGEAR WG511T Quick Installation Manual

108 Mbps Wireless PC Card 32-bit CardBus WG511T

Quick Installation Guide

Follow these quick steps to install your WG511T
These basic setup instructions assume that you will connect to an
access point, and you are not using WEP security. Please refer to the
online help and the Reference Manual on your CD for instructions
on configuring WEP, Ad-hoc mode, or advanced options.
Estimated Completion Time: 5-15 minutes for each notebook PC.
W XP
INDOWS B I
ASIC NSTALLATION
1. First, install the WG511T software.
a. Power on your notebook, let the operating system boot up
completely, and log in as needed.
b. Insert the Resource CD for the WG511T into your CD-
ROM drive. The CD main page shown below will load.
c. Click the Install Driver & Utility link.
d. Follow the InstallShield Wizard steps, and click Finish
when done to restart your computer.
2. N , WG511T W
EXT INSTALL THE IRELESS
a. Hold the PC Card with the Netgear logo facing up and insert
it into a CardBus slot. After a short delay, the Found New
Hardware Wizard displays.
Note: If a Windows XP
logo testing warning
appears, click Continue
Anyway to proceed.
b. Next you will be prompted to enable the NETGEAR Smart
Wireless Settings Utility configuration utility.
Click Yes to accept this option.
If you choose No, you must read the Windows XP
documentation for an explanation of how to use the
Windows XP wireless network configuration utility
You will also be prompted to choose the country you are
located in. Select your location from the list.
c. Click Finish to complete the installation. You
will see the WG511T system tray icon on the
lower right portion of the Windows task bar.
PC C . 3. N ,
ARD OW CONFIGURE YOUR
a. Click the
WG511T Smart Wireless Settings Utility.
The utility opens to the Settings tab page.
b. Change the Network Name SSID to match your network.
Tip: To view the available wireless networks, use the drop-
down list or the Networks tab and choose the one you want.
c. Click Apply to activate the connection.
Tip: Create work and home profiles. Then, activate
whichever one you need for your current location.
Note: The status bar at the bottom of the utility reports the speed
of your connection. 108 Mbps speed is only possible when your
wireless network has a 108 Mbps access point such as in the
Netgear WGT624 108 Mbps Wireless Firewall Router.
4. F ,
INALLY
a. Verify that the status monitor information at the bottom of
the utility matches your wireless network
b. Check the WG511T LEDs: both blinking alternately means
attempting to connect; both blinking together indicates a
good connection (fast blinking means data transmission);
off means the card is not plugged in.
c. Verify connectivity to the Internet or network resources.
Note: If you are unable to connect, see troubleshooting tips in
the Basic Installation section of the Reference Manual on the
NETGEAR 108 Mbps Wireless PC Card WG511T Resource CD
(SW-10036-01).
WG511T P
AND SAVE THE
icon in the Windows system tray to open the
VERIFY WIRELESS NETWORK CONNECTIVITY
.
ROFILE
.
