The PACSystems RSTi Network Interface and I/O family provides a cost effective, modular
distributed I/O system. The RSTi network is ideally suited for distributed applications such as
water/wastewater, process control, packaging and assembly. You can easily add RSTi
modules to the system to build functional remote I/O stations to meet your application
requirements.
Sr. Number
A set of interconnected RSTi modules can be chosen to suit the application and connected
as a slave on a PROFIBUS or a PROFINET network. An RSTi Network Adapter provides the
interface between the network and the RSTi modules. The Network Adapter and I/O modules
selected for an application constitute an I/O station.
GFK-2746B PACSystems* RSTi PROFIBUS and PROFINET Network Adapter–August 2013
Label
Removable Switch of
Terminal Block
Tester Pin Hole
Screw less Connection
System
I/O Status Display LED
System-Data Pin (6 Pins)
Module Number Marking
(Header Type)
Header Type Module (16
points)
Field Power Pin (2 pins)
Chapter 1. Introduction
Sr. Number
RTB (Removable Terminal
Block)
Reserved communication
Port (Useful to only
manufacturer)
PUSH Lock for DIN rail
Fieldbus Connector (actual
connector depends upon the
type network adapter)
Module Number Marking (on
the Removable terminal
Block
Node ID or station address
setting (either rotary or dip
switches depends upon the
type of network adapter)
Label
