Linksys WRT54G3G-ST Quick Installation Manual

Package Contents
• Wireless-G Router for Mobile Broadband
• Setup CD-ROM with User Guide
• Quick Installation Guide
• Power Adapter
• RJ-45 Ethernet Cable
24 .
GHz
Wireless-G
802.11g
Router for Mobile Broadband
Wireless Quick Installation
WRT54G3G-ST
Model No. Model No.
There are three ways you can set up
the Wireless-G Router for Internet
connection. Select one.
1. Mobile Broadband Service Only
2. Broadband WAN Service Only
3. Broadband WAN and Mobile
Broadband Service
Before you begin, make sure that
you have the following:
Mobile Broadband Service Only:
An activated Mobile Broadband Data
Card and your Mobile Broadband
Data Card Service information.
Broadband WAN Service Only:
A broadband modem and settings
for your Internet connection.
Broadband WAN and Mobile
Broadband Service:
Activated Mobile Broadband Data
Card, Mobile Broadband Data Card
Service information, a broadband
modem, and settings for your
broadband Internet connection.
A
Insert the Setup CD-ROM into
your CD-ROM drive. The Setup
Wizard should run
automatically, and the
Welcome screen should
appear. If it does not, click the
Start button and choose Run. In
the field that appears, enter
D:\SetupWizard.exe (if "D" is
the letter of your CD-ROM
drive).
B
On the Welcome screen, click
the Click Here to Start button if
this is the first time you are
running the Setup Wizard.
C
Continue to the step for your
setup type.
B
1 Setting Up the Router for Mobile
Broadband Service Only
A
Click the Mobile Broadband
Only radio button to configure
the Router for mobile
broadband service.
A
B
Make sure the Router is
powered off. Insert your mobile
broadband data card into the
Router's Data Card Slot on the
top panel of the Router. Then
Click Next.
B
C
Connect the included yellow
Ethernet network cable to the
Ethernet network port of your
computer.
Click Next.
C
D
Connect the other end of the
cable to one of the yellow
Ethernet ports labeled 1-4 on
the side panel of the Router.
If necessary, connect any
additional computers or other
devices to the Router.
Click Next.
D
E
Connect the power adapter to
the Router's Power port. Plug
the other end into an electrical
outlet.
Click Next.
F
Make sure the LEDs on the
Router light up. The Power LED
will flash for a few seconds
while the Router goes through
E
its self-diagnostics test. This LED
will be solidly lit when the self-
test is complete. If it does not
stop flashing, refer to "Appendix
A: Troubleshooting" in the user
guide on the CD-ROM.
Click Next.
G
Follow the on-screen
instructions to complete the
setup and configuration.
F
NOTE:
If you want to make advanced
configuration changes, refer to "Chapter
8: Configuring the Wireless-G Router for
Mobile Broadband" in the user guide on
the CD-ROM.
2 Setting Up the Router for
Broadband WAN service Only
A
Click the Broadband WAN
Only radio button to configure
the Router for broadband WAN
service.
A
B
Make sure the Router is
powered off. Disconnect the
Ethernet network cable from
your computer. (This is the
cable that connects the
computer to your modem.)
Then Click Next.
B
C
Connect the cable from the
modem to the Internet port on
the Router. (This is the same
cable that you just
disconnected from your
computer.) Click Next.
C
