Technical specification ..................................................................1-2
Version variation ...........................................................................1-2
Service measurement setup..........................................................1-3
Service aids .................................................................................1-4
Instructions on CD playability ................................................2-1..2-2
Block diagram................................................................................3-1
Wiring diagram...............................................................................4-1
Disassembly diagram............ ........................................................5-1
Main board
Circuit diagram ..................................................................6-1..6-3
Layout diagram ..................................................................6-4..6-5
Servo board
Circuit diagram ..................................................................7-1..7-2
Layout diagram .........................................................................7-3
Exploded view diagram .................................................................8-1
©
Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by LX 1047 Service Audio
Version 1.1
All manuals and user guides at all-guides.com
Subject to modification
CED1700
/00/51/98
3141 785 35161

Advertisement

Table of Contents
loading

Summary of Contents for Philips CED1700

  • Page 1: Table Of Contents

    Exploded view diagram ..............8-1 © Copyright 2010 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2: Technical Specification

    • Tuner Enhancements: Auto search and store 178 x 100 x 185.4 mm • No. of preset stations: 18(FM), 12(AM) • Chassis: 2 Din • VERSION VARIATION Type /Versions: CED1700 Service policy Board in used: SERVO BOARD MAIN BOARD Type /Versions: CED1700...
  • Page 3 All manuals and user guides at all-guides.com MEASUREMENT SETUP Tuner FM Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz). Tuner AM (MW,LW) Bandpass LF Voltmeter...
  • Page 4: Service Aids

    All manuals and user guides at all-guides.com SERVICE AIDS WARNING All ICs and many other semi-conductors are susceptible to electrostatic discharges (ESD). Careless handling during repair can reduce life drastically. When repairing, make sure that you are connected with the same potential as the mass of the set via a wrist wrap with resistance.
  • Page 5: Instructions On Cd Playability

    All manuals and user guides at all-guides.com 2 - 1 INSTRUCTIONS ON CD PLAYABILITY Customer complaint "CD related problem" Set remains closed! check playability playability ok ? For flap loaders (= access to CD drive possible) "fast" lens cleaning cleaning method is recommended check playability playability...
  • Page 6 All manuals and user guides at all-guides.com 2 - 2 INSTRUCTIONS ON CD PLAYABILITY PLAYABILITY CHECK LIQUID LENS CLEANING Before touching the lens it is advised to clean the surface of the lens by blowing clean air over it. For sets which are compatible with CD-RW discs This to avoid that little particles make scratches on use CD-RW Printed Audio Disc ....7104 099 96611 the lens.
  • Page 7: Block Diagram

    All manuals and user guides at all-guides.com 3 - 1 3 - 1 SET BLOCK DIAGRAM...
  • Page 8: Wiring Diagram

    All manuals and user guides at all-guides.com 4 - 1 4 - 1 SET WIRING DIAGRAM...
  • Page 9: Disassembly Diagram

    All manuals and user guides at all-guides.com 5 - 1 5 - 1 SET DISASSEMBLY DIAGRAM MAIN UNIT DISSEMBLY INSTRUCTIONS Step1:Remove screw "A" as indicated to open the panel Step2:Open top cover be carefully to avoid scratch Step3:Remove screw "B" & "C" as indicated on right side Step4:Remove screw "D"...
  • Page 10: Circuit Diagram

    All manuals and user guides at all-guides.com 6 - 1 6 - 1 CIRCUIT DIAGRAM - MAIN BOARD AUDIO & VEDIO PART BAT+ C500 C310 100nF DVD_R 3.9nF DVD_B R500 0.1uF DVD_G C501 3.9nF DVD_VS DVD_HS DVD_V DVD_L R300 C300 10uF R501 100R...
  • Page 11 All manuals and user guides at all-guides.com 6 - 2 6 - 2 CIRCUIT DIAGRAM - MAIN BOARD POWER PART 1 BAT+ AP1507 U900 BAT+ DVD_+5V 100uH/2A L900 100uH/15A L901 Q903 ACC_DET 8550 R906 R907 1.5K 6.8K CD910 BAT+ R902 R908 D901 ZD901...
  • Page 12 All manuals and user guides at all-guides.com 6 - 3 6 - 3 CIRCUIT DIAGRAM - MAIN BOARD POWER PART 2 Blue Tooth Module CN100 7703R R104 3.3K RA_R TU_R C101 C102 R105 CN702 100nF 47uF CON2 1.8nF ANT1 CD700 C704 MCU_+5V BT_+5V...
  • Page 13: Layout Diagram

    All manuals and user guides at all-guides.com 6 - 4 6 - 4 LAYOUT DIAGRAM - MAIN BOARD COMPONENT SIDE...
  • Page 14 All manuals and user guides at all-guides.com 6 - 5 6 - 5 LAYOUT DIAGRAM - MAIN BOARD COPPER SIDE...
  • Page 15: Circuit Diagram

    All manuals and user guides at all-guides.com 7 - 1 7 - 1 CIRCUIT DIAGRAM - SERVO BOARD PART 1...
  • Page 16 All manuals and user guides at all-guides.com 7 - 2 7 - 2 CIRCUIT DIAGRAM - SERVO BOARD PART 2...
  • Page 17 All manuals and user guides at all-guides.com 7 - 3 7 - 3 LAYOUT DIAGRAM - SERVO BOARD...
  • Page 18: Exploded View Diagram

    All manuals and user guides at all-guides.com 8 - 1 8 - 1 EXPLODED VIEW DIAGRAM 6503 6501 CD01...
