UVL-FCU Ultraviolet Lamp Kits for
Fan Coil and PTAC Units
APPLICATION
Honeywell UVL-FCU kits make it possible to realize all the
benefits of germicidal UV light in limited space
applications including most of the fan coil units and
PTACs found on the market today. The kit features a low-
profile lamp with metal shield and mounting magnet as a
means for locating the UV light within these units for
optimum UV exposure particularly where space is limited.
FEATURES
• UV-C light irradiates coil, killing mold, bacteria and
viruses
• Installs in the tightest spaces such as PTACs and Fan
Coil Units
• Weather resistant remote mountable UV lamps with
magnetic mounting shield
• 18-32 or 110-277 VAC power supply with flexible
mounting options
• Reduces system maintenance
• Kit includes power supply, 6 foot lamp cable, UV lamp
and shield, magnetic mounting hardware and panel
indicator
SPECIFICATIONS
Models:
See Table 1.
Part Number
UVL-FCU-LINE FCU/PTAC 110-277 Vac, 50/60 Hz
UVL-FCU-LOW FCU/PTAC 18-32 Vac, 60 Hz
* Power supply not available for purchase outside of kit
Table 1. Models.
Description
Efficiencies:
99.9% disinfection of irradiated surfaces when properly
positioned
Approvals:
ETL/CSA, RoHS standard 2011/65/EU
EPA Est. No. 075179-FL-2
Electrical Ratings:
Power Rating:
UVL-FCU-LINE: 120-277 Vac, 50/60 Hz
UVL-FCU-LOW: 18-32 Vac, 60Hz
Current Rating:
UVL-FCU-LINE: 0.51 A @ 120 Vac, 0.22 A @ 277 Vac
UVL-FCU-LOW: 0.68 A, 16 VA
Dimensions:
Power Supply:
UVL-FCU-LINE: 5.0 in x 1.1 in x 2.4 in (127 mm x 27.9
mm x 61.0 mm)
UVL-FCU-LOW: 4.1 in x 1.7 in x 1.8 in (104 mm x 43.2
mm x 45.7 mm)
Bulb: 1 inch diameter x 14 inch length (25.4 mm diameter
x 356 mm length)
Spectrum:
100% 254 nm Germicidal UV-C
Bulb Type:
Shielded Quartz Hot Filament
Bulb Life:
18000 hours
Accessories:
UVL-FCU-LAMP Replacement UV-C lamp
Replacement Lamp
UVL-FCU-LAMP
(MFG# TUVL-200EZ)
UVL-FCU-LAMP
(MFG# TUVL-200EZ)
PRODUCT DATA
Power Supply*
(MFG# TUVP-ST-CE)
(MFG# TUVP-ER)
31-00403-02
