PROGRAMMABLE DISPLAY
GT series
User's Manual
[Applicable Models ]
・GT01 / GT11 / GT21
・GT02 / GT02L / GT05 / GT12 / GT32
・GT03-E / GT32-R / GT32-E

Advertisement

Table of Contents
loading

Related Manuals for Panasonic GT32-R

Summary of Contents for Panasonic GT32-R

  • Page 1 PROGRAMMABLE DISPLAY GT series User's Manual [Applicable Models ] ・GT01 / GT11 / GT21 ・GT02 / GT02L / GT05 / GT12 / GT32 ・GT03-E / GT32-R / GT32-E WUME-GTH-02 2021.3 panasonic.net/id/pidsx/global...
  • Page 2 Copyright / Trademarks - This manual and its contents are copyrighted. - You may not copy this manual in whole or part, without written consent of Panasonic Industrial Devices SUNX Co., Ltd. - Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

  • Page 3: Table Of Contents

    2.1.1 GT01 / GT11 / GT21 ....................2-2 2.1.2 GT02 / GT02L ......................2-4 2.1.3 GT03-E ........................2-6 2.1.4 GT05 / GT12 / GT32 / GT32-R / GT32-E ..............2-8 2.2 Terminal Layouts of COM Port ..................2-12 2.2.1 GT01 ......................... 2-12 2.2.2 GT02 .........................
  • Page 4 3.1.7 GT21 Installation Method .................... 3-6 3.1.8 GT05 / GT32 / GT32-R / GT32-E Installation Method ..........3-7 3.1.9 GT02 / GT02L / GT03-E / GT12 Installation Method ..........3-8 3.1.10 Installing in Vertical Orientation ................3-9 3.1.11 Precaution When reinstalling GT ................3-9 3.2 Wiring the Power Supply ....................
  • Page 5 5.1 What to DO If Something Unusual Occurs (GT01/GT11/ GT21) ........5-2 5.2 What to DO If Something Unusual Occurs (GT02/GT02L/GT03- E/GT05/GT12/GT32/GT32-R/GT32-E) ..................5-5 5.3 Error Codes and How to Handle Them ................ 5-10 5.3.1 About Error Codes ....................5-10 5.3.2 GT Series Error Codes .....................
  • Page 6 6.9.4 Interface Specifications (GT32) ................6-37 6.9.5 Sound Output Specifications (GT32T1 Only)............6-38 6.10 GT32-R .......................... 6-39 6.10.1 General Specifications (GT32-R) ................6-39 6.10.2 Performance Specifications (GT32-R) ..............6-40 6.10.3 Function Specifications (GT32-R) ................6-41 6.10.4 Interface Specifications (GT32-R) ................6-42 6.11 GT32-E ..........................
  • Page 7 7.1.6 GT05 ........................... 7-7 7.1.7 GT11 ........................... 7-8 7.1.8 GT12 ........................... 7-9 7.1.9 GT21 ......................... 7-10 7.1.10 GT32 ........................7-11 7.1.11 GT32-R / GT32-E ....................7-12 7.2 Cable Specifications...................... 7-13 7.2.1 AIGT8142 ........................7-13 7.2.2 AIGT8152 ........................7-13 7.2.3 AIGT8160/AIGT8162/AIGT8165/AIGT8192 ............. 7-13 7.2.4 AIGT8175 ........................

  • Page 8: Before You Start

    Before You Start Usage conditions Operating environment (Use the unit within the range of the general specifications when installing) Ambient temperatures: 0 to +50 C (It varies according to models when installing the unit in a horizontal orientation or using a C-NET adapter and FP programmer II.) Ambient humidity should be 20 to 85% RH (at 25 C) and non-condensing.
  • Page 9 Power supply Twist the wires of the power supply. The unit has sufficient noise immunity against the noise generated on the power line. However, it is recommended to take measures for reducing noise such as using an isolating transformer before supplying the power.

  • Page 10: Manual To Be Used

     There are the following manual for the GT series. Please refer to a relevant manual for the unit and purpose of your use.  The manuals can be downloaded from our website: https://industrial.panasonic.com/ac/e/dl_center/manual/ Manual name Manual code GT series User’s Manual WUME-GTH GT series Reference Manual (GTWIN Ver.

  • Page 11: Available Functions And Gt Versions

    Available Functions and GT Versions We recommend to keep GT-series products up to date for use as usable functions will increase according to the upgrade. The latest version of GT can be installed by the tool. The upgrade of GTWIN is also necessary according to the upgrade of GT. Version of GT01 and available functions Function GT01...
  • Page 12 Version of GT02 and available functions Function GT02M2 GT02M0 GTWIN GT02G2 GT02M1 GT02G0 GT02G1 Parts Switch 1.00 or later 1.00 or later 2.A0 or later library Lamp 1.00 or later 1.00 or later 2.A0 or later Message 1.00 or later 1.00 or later 2.A0 or later Data...
  • Page 13 Version of GT02L and available functions Function GT02L GTWIN Parts Switch 1.00 or later 2.B0 or later library Lamp 1.00 or later 2.B0 or later Message 1.00 or later 2.B0 or later Data 1.00 or later 2.B0 or later Bar graph 1.00 or later 2.B0 or later Note1)
  • Page 14 Version of GT03-E and available functions Function GT03M-E GT03T-E GTWIN Parts Switch 1.00 or later 1.10 or later 2.E1 or later library Lamp 1.00 or later 1.10 or later 2.E1 or later Message 1.00 or later 1.10 or later 2.E1 or later Data 1.00 or later 1.10 or later...
  • Page 15 Version of GT05 and available functions Function GT05 GTWIN Parts Switch 1.00 or later 2.90 or later library Lamp 1.00 or later 2.90 or later Message 1.00 or later 2.90 or later Data 1.00 or later 2.90 or later Bar graph 1.00 or later 2.90 or later Clock...
  • Page 16 Version of GT11 and available functions Function GT11 GTWIN Parts Switch 1.00 or later 2.60 or later library Lamp 1.00 or later 2.60 or later Message 1.00 or later 2.60 or later Data 1.00 or later 2.60 or later Bar graph 1.00 or later 2.60 or later Note1)
  • Page 17 Version of GT12 and available functions Function GT12M1 GT12M0 GTWIN GT12G1 GT12G0 Parts Switch 1.00 or later 1.00 or later 2.97 or later library Lamp 1.00 or later 1.00 or later 2.97 or later Message 1.00 or later 1.00 or later 2.97 or later Data 1.00 or later...
  • Page 18 Version of GT21 and available functions Function GT21 GTWIN Parts Switch 1.00 or later 2.70 or later library Lamp 1.00 or later 2.70 or later Message 1.00 or later 2.70 or later Data 1.00 or later 2.70 or later Bar graph 1.00 or later 2.70 or later Note1)
  • Page 19 Version of GT32 and available functions Function GT32M GT32T1 GTWIN GT32T0 Parts Switch 1.00 or later 1.00 or later 2.80 or later library Lamp 1.00 or later 1.00 or later 2.80 or later Message 1.00 or later 1.00 or later 2.80 or later Data 1.00 or later...
  • Page 20 Version of GT32-R and available functions Function GT32M-R GT32T-R GTWIN Parts Switch 1.40 or later 1.40 or later 2.F0 or later library Lamp 1.40 or later 1.40 or later 2.F0 or later Message 1.40 or later 1.40 or later 2.F0 or later Data 1.40 or later...
  • Page 21 Version of GT32-E and available functions Function GT32M-E GT32T1-E GTWIN Parts Switch 1.00 or later 1.00 or later 2.C0 or later library Lamp 1.00 or later 1.00 or later 2.C0 or later Message 1.00 or later 1.00 or later 2.C0 or later Data 1.00 or later 1.00 or later...
  • Page 22 General-purpose serial SD memory card copy to password-protected GT Connection between multiple units with Modbus(RTU) master Output to Panasonic FP series "X" device. Jump to the previous screen from "Screen No. Error" screen Reverse display function GT01 Ver. 1.37 Jump to the previous screen from "Screen No.
  • Page 23 GTWIN GT-series version Additional functions version Ver.2.B1 GT01 Ver.1.39 -Bug fixing GT02 Ver.1.11 GT02L Ver.1.01 GT05 Ver.1.71 GT11 Ver.1.29 GT12 Ver.1.41 GT21 Ver.1.19 GT32 Ver.1.81 Ver.2.C0 GT02 Ver.1.30 New model (GT32-E) GT02L Ver.1.20 FP monitor function GT05 Ver.1.90 Added the mode to ignore CS/RS when using general- GT12 Ver.1.60 purpose serial communication.
  • Page 24 GT32 Ver.2.35 GT32-E Ver.1.35 Ver.2.F0 GT02 Ver.1.70 New model (GT32-R) GT02L Ver.1.60 Countdown timer function GT03-E Ver.1.10 180 degrees rotation display (GT03-E/GT32-R/GT32-E) GT05 Ver.2.30 GT12 Ver.1.A0 GT32 Ver.2.40 GT32-R Ver.1.40 GT32-E Ver.1.40 Ver.2.F1 GT05 Ver.2.40 Supports TFT LCD (GT05 monochrome)

  • Page 25: Features And Functions

    Chapter 1 Features and Functions...

  • Page 26: Features And Functions Of Gt Series

    The communication methods to PLCs support RS232C/RS422(RS485). Also it can be connected to PLCs manufactured by other companies. Structure adapted to surrounding environments IP67: GT02 / GT03-E / GT12 / GT32-R / GT32-E IP65: GT01 / GT02L / GT05 / GT11 / GT21 / GT32 High-intensity LED provided (LED backlight type) As the high-intensity LED is provided, the screen is bright, and the backlight does not need to be replaced.
  • Page 27 Power can be supplied to the 5 V DC type with only one communication cable. The power is supplied from the TOOL port of a PLC, therefore, the wiring man-hours can be significantly reduced. Applicable models: Panasonic FP series Mitsubishi Electric Corporation FX series Three methods are available to switch the screen.
  • Page 28 Through function is convenient for debugging A convenient “through” function makes it possible to transfer data from the GT and carry out PLC debugging at the same time that communication is going on between the GT and the FP series PLC. This significantly boosts efficiency in the workplace.
  • Page 29 The level of operators are managed with the security password. GT link function (GT02/GT02L/GT03-E/GT05/GT12/GT32/GT32-R/GT32-E) This function is used to connect multiple GT units (up to 32 units) to a single PLC (Panasonic FP series/FP7 series). RS485 communication is used.
  • Page 30 Logged data is saved in a SD memory card inserted in this unit in CSV format. This function is useful for obtaining the history of data. FP monitor function (GT02/GT02L/GT03-E/GT05/GT12/GT32/GT32-R/GT32-E) This function is used to monitor or change the settings and data of FP-series PLC on the GT screen.

  • Page 31: List Of Models

    1.2 List of Models 1.2.1 GT Series Main Unit COM port commu- Item Interface Power Front panel Model Display Backlight nication Model No. name specifications supply color specifi- cation Pure black AIG02MQ02D RS232C Silver AIG02MQ03D GT02M0 5 V DC RS422 Pure black AIG02MQ04D COM port...
  • Page 32 COM port commu- Item Interface Power Model Display Backlight nication Body color Model No. name specifications supply specifi- cation Pure black AIG05MQ02D 3-color RS232C Silver AIG05MQ03D GT05M (white, Pure black AIG05MQ04D RS422 mono- red, pink) (RS485) Silver AIG05MQ05D chrome COM port 3-color Pure black AIG05GQ02D...
  • Page 33 AIG32MQ03DR chrome Pure black AIG32MQ04DR GT32M-R COM port RS422 USB port (320x240 1-color (RS485) Silver AIG32MQ05DR (USB1.1 24 V GT32-R dots) compliant) (white) 4096- Pure black AIG32TQ02DR with SD memory RS232C color TFT Silver AIG32TQ03DR card slot GT32T-R color LCD...

  • Page 34: Gt Series Main Unit (Discontinued Models)

    1.2.2 GT Series Main Unit (Discontinued Models) COM port commu- Item Interface Power Front panel Model Display Backlight nication Model No. color name specifications supply specifi- cation Black AIGT0030B1 RS232C Ashgray AIGT0030H1 5 V DC RS422 Black AIGT0032B1 3-color LED (RS485) Ashgray AIGT0032H1...

  • Page 35: Options And Repair Parts

    For GT32-R/GT32-E AIG32810E GT01/GT11 repair 5 sets AIGT083 (4 pc/set) Attachment fittings For GT05/GT21 repair (2 pc/set) 5 sets AIGT28321 For GT32/GT32-R/T32-E repair 5 sets AIG32830 (2 pc/set) Attachment fittings For GT02/GT02L/GT12 repair (with 5 sets AIG12830 (4 pc each/set)
  • Page 36 Front panel For GT05 Sold separately AIG05800 protective 10 in set For GT11 AIGT280 sheet For GT12 AIG12800 For GT21 AIGT28021 For GT32/GT32-R Sold separately AIGT32800 Backup battery Backup for GT02M2,GT02G2/GT03T-E/ 1 pc AFPX-BATT battery GT05/GT12/GT32/GT32-R/GT32-E Commercial product Item name Contents Model No.

  • Page 37: Screen Creation Tool

    Windows XP Note 1) The latest version is provided free of charge via our website (https://industrial.panasonic.com/ac/e/dl_center/software/). (User registration is required. Free of charge) Note 2) The upgrade model is required for upgrading Ver.1 to Ver.2. Note 3) As for 64-bit Windows, only Windows7 and Windows8 are supported. Except for Windows7 and Windows8, use 32-bit windows.
  • Page 38 Contents Configurator WD IP address search tool Address setting for the GT in Ethernet communication Note) It can be downloaded from our website (https://industrial.panasonic.com/ac/e/dl_center/software/). (User registration is required. Free of charge) Screen transfer cable For connection between PC (USB) and Programmable Display (GT02/GT02L/GT03-E/GT05/GT12/...
  • Page 39 LAN cable (Ethernet port) (GT32T1) Either straight cable or crossing cable can be used. (MDI/MDI-X Automatic crossover function) 1-15...
  • Page 40 1-16...

  • Page 41: Names And Functions Of Parts

    Chapter 2 Names and Functions of Parts...

  • Page 42: Part Names

    2.1 Part Names 2.1.1 GT01 / GT11 / GT21 GT01/GT01R GT11 GT21...
  • Page 43 ○ Touch screen Various screens are displayed here. Switches can be operated and data entered simply by touching the touch screen. (A sheet is affixed to the touch panel to protect it from scratches when shipping. Please remove it before using the GT.) Optional protective sheets are available to protect the touch screen surface and keep it clean.

  • Page 44: Gt02 / Gt02L

    2.1.2 GT02 / GT02L GT02M2, GT02G2 GT02M0, GT02M1, GT02G0, GT02G1 GT02L...
  • Page 45 ○ Touch screen Various screens are displayed here. A touch panel is provided on the liquid crystal display panel, and switches can be operated and data entered simply by touching the panel. Optional protective sheets are also available to protect the touch panel and keep it clean. (A sheet is affixed to the touch panel to protect it from scratches when shipping.

  • Page 46: Gt03-E

    2.1.3 GT03-E GT03M-E GT03T-E ○ Touch screen Various screens are displayed here. A touch panel is provided on the liquid crystal display panel, and switches can be operated and data entered simply by touching the panel. ○ USB port This is a connector for connecting the screen creation tool. The commercial USB cable can be used. ○...
  • Page 47 ○ COM port (PLC/external device connection port) and power supply terminal This is a communication port (RS232C or RS422) for connecting to a PLC, host PC, or microcomputer board, and a power supply terminal for operation. ○ Waterproof packing This assures that the front panel is waterproof. ○...

  • Page 48: Gt05 / Gt12 / Gt32 / Gt32-R / Gt32-E

    2.1.4 GT05 / GT12 / GT32 / GT32-R / GT32-E GT05 GT12 GT32 Standard High function...
  • Page 49 GT32-R / GT32-E...
  • Page 50 ○ Touch screen Various screens are displayed here. A touch panel is provided on the liquid crystal display panel, and switches can be operated and data entered simply by touching the panel. Optional protective sheets are also available to protect the touch panel and keep it clean. (A sheet is affixed to the touch panel to protect it from scratches when shipping.
  • Page 51 ○ COM port (PLC/external device connection port) and power supply terminal This is a communication port (RS232C or RS422) for connecting to a PLC, host PC, or microcomputer board, and a power supply terminal for operation. ○ Waterproof packing This assures that the front panel is waterproof. 2-11...

  • Page 52: Terminal Layouts Of Com Port

    2.2 Terminal Layouts of COM Port 2.2.1 GT01 5 V/RS232C type Pin name Name Signal direction Product No. +5 V  AIGT0030B1 Not connected AIGT0030H1 Send data GT→External device AIGT0130B1 AIGT0130H1 Receive data GT←External device AIGT0230B1 Not connected AIGT0230H1 Not connected Signal ground Note: There is no RS and CS (control lines).

  • Page 53: Gt02

    2.2.2 GT02 5 V/RS232C type Pin name Name Signal direction Product No. +5 V  Functional ground AIG02MQ02D Send data GT→External device AIG02MQ03D Receive data GT←External device AIG02GQ02D AIG02GQ03D Request to send GT→External device Clear to send GT←External device Signal ground 5 V/RS422(RS485) type Pin name Name...

  • Page 54: Gt02L

    2.2.3 GT02L 5 V/RS232C type Pin name Name Signal direction Product No. +5 V  Functional ground Send data GT→External device Receive data GT←External device AIG02LQ02D Request to send GT→External device Clear to send GT←External device Signal ground 5 V/RS422(RS485) type Pin name Name Signal direction...

  • Page 55: Gt11 / Gt12

    2.2.4 GT11 / GT12 24 V/RS232C type Pin name Name Signal direction Product No. +24 V AIGT2030B  AIGT2030H AIGT2130B Functional ground AIGT2130H Send data GT→External device AIG12MQ02D Receive data GT←External device AIG12MQ03D Request to send GT→External device AIG12MQ12D Clear to send GT←External device AIG12MQ13D AIG12GQ02D...

  • Page 56: Gt03-E / Gt21

    2.2.5 GT03-E / GT21 24 V/RS232C type Pin name Name Signal direction Product No. +24 V  Functional ground AIGT2230B AIGT2230H Send data GT→External device AIG03MQ03DE Receive data GT←External device AIG03TQ13DE Request to send GT→External device Clear to send GT←External device Signal ground 24 V/RS422(RS485) type Pin name...

  • Page 57: Gt05 / Gt32 / Gt32-R / Gt32-E

    2.2.6 GT05 / GT32 / GT32-R / GT32-E 24 V/RS232C type Pin name Name Signal direction Product No. +24 V AIG05MQ02D  AIG05MQ03D AIG05GQ02D Functional ground AIG05GQ03D Send data GT→External device AIG05SQ02D Receive data GT←External device AIG05SQ03D Request to send GT→External device...

  • Page 58: Connecting To Screen Creation Tool Gtwin

    2.3 Connecting to Screen Creation Tool GTWIN 2.3.1 TOOL Port Pin No. Name Abbre. Signal direction Signal ground Send data GT→External device Receive data GT←External device Not connected N.C. +5 V (+5V) Note:  The +5V of Pin 5 is reserved for the FP Programmer II. It should not be used for any other application. If using it, there is a restriction on the ambient temperature.

  • Page 59: Ethernet Port

    2.3.3 Ethernet Port Ethernet connection GT32T1 has an Ethernet port. Communication with our software such as GTWIN becomes available by connecting to a PC with a LAN cable. Ethernet communication function Screen transfer (Baud rate: fixed at 115200 bps. It takes at least 3 times longer than the transfer using USB.) Communication with our PLCs using the through function * Specifying the destinations to connect enables the communication with multiple units using a HUB.
  • Page 60 Required items for connection  LAN cable Either straight cable or crossing cable can be used. (MDI/MDI-X Automatic crossover function) Settings for Ethernet connection Follow the procedure below to communicate with the Ethernet connection. 1. Connect the GT to a PC with an Ethernet cable. 2.
  • Page 61 The settings of the GT can be specified with the IP address search tool of Configurator WD (Ver.1.11 or later). The IP search tool (Config WD. exe) can be downloaded for free from our website URL: http://industrial.panasonic.com/ac/e/dl_center/software/ (User registration is required.: Free of charge) 2-21...
  • Page 62 2-22...

  • Page 63: Installation And Wiring

    Chapter 3 Installation and Wiring...

  • Page 64: Installation

    3.1 Installation 3.1.1 Installation Environment When installing and using the GT series, always make sure the following conditions are observed. Usage conditions Operating environment (Use the unit within the range of the general specifications when installing) Ambient temperatures: 0 to +50 C (It varies according to models when installing the unit in a horizontal orientation or using a C-NET adapter and FP programmer II.) Ambient humidity should be 20 to 85% RH (at 25 C) and non-condensing.
  • Page 65 Static electricity Do not touch connector pins directly to prevent static electricity from causing damage. Always rid yourself of any static electricity before handling this product. If excessive static electricity is applied to the panel surface, the LCD panel may be damaged. Power supply Twist the wires of the power supply.

  • Page 66: Restriction According To Mounting Directions

    GT02L 60 mm GT03M-E 30 mm or more GT02 (50 mm or more GT05 recommended) GT03T-E GT12 60 mm 40 mm or more GT32 GT32-R GT32-E * It should be 40 mm or more when using a SD memory card.

  • Page 67: Ul/C-Ul Qualification

    GT05/GT21/GT32/ Galvanization, 4 pcs/unit M3 – 25 trivalent chromate GT32-R/GT32-E GT02/GT02L/GT03-E/GT12 dedicated screw The GT02/GT02L/GT03-E/GT12 dedicated screw is not sold on the open market. Using screws other than the dedicated screw will cause failures such as decrease of water-proof property.

  • Page 68: Gt01 And Gt11 Installation Method

    3.1.6 GT01 and GT11 Installation Method Secure the GT to the installation panel using the four fittings and four screws provided with the unit. 1. Place the GT in the installation panel. 2. Insert the fittings into the grooves provided in the GT, and tighten the screws to secure the GT to the installation panel.

  • Page 69: Gt05 / Gt32 / Gt32-R / Gt32-E Installation Method

    3.1.8 GT05 / GT32 / GT32-R / GT32-E Installation Method Secure the GT32 to the installation panel using the two fittings and four screws provided with the unit. 1. Place the GT main unit in the installation panel. 2. Insert the fittings into the grooves provided in the GT main unit, and tighten the screws to secure the GT main unit to the installation panel.

  • Page 70: Gt02 / Gt02L / Gt03-E / Gt12 Installation Method

    3.1.9 GT02 / GT02L / GT03-E / GT12 Installation Method Secure the GT12 or GT02 to the installation panel using the two fittings and four dedicated screws provided with the unit. 1. Place the GT main unit in the installation panel. 2.

  • Page 71: Installing In Vertical Orientation

    3.1.10 Installing in Vertical Orientation The normal orientation of GT series is horizontally long, however, they can be installed upright. Key Point: Select the vertical type when selecting a GT model in GTWIN. 3.1.11 Precaution When reinstalling GT When the GT is reinstalled after being removed from the panel, the water-proof packing should be replaced.

  • Page 72: Wiring The Power Supply

    3.2 Wiring the Power Supply 3.2.1 Wiring the Power supply The power supply should be wired by securely connecting the terminal on the rear of the main unit to the terminal. Use twisted wiring for the power supply In order to minimize influence from noise, the wiring for the power supply should be twisted. Insulate the power supply inside a protective circuit ...

  • Page 73: Grounding

    3.2.2 Grounding Be sure to ground when the influence of noise is great The unit is tolerant against noise in normal environments, but if the environment is particularly susceptible to noise, please ground. Use dedicated grounding  Make the grounding point as close as possible to the GT and keep the distance of the grounding wire short.

  • Page 74: Wiring The Com Port

    3.3 Wiring the COM Port Accessory communication connector/applicable wiring The communication connector used for the COM port (provided as an accessory with the main unit) has a screw-tightening type of terminal block. The wiring shown below should be used. Applicable wiring (twisted wiring) Size Conductor cross-section surface area AWG 28 to 16...
  • Page 75 Wiring method (1) Remove the sheath from the wire. (2) Insert the wire all the way into the terminal block, and tighten the screw in the clockwise direction to secure it. Precautions concerning wiring The following precautions should be observed, to avoid broken or disconnected wires. ...

  • Page 76: Precautions When Wiring Com Port

    3.4 Precautions when Wiring COM Port Precautions are different depending on communication conditions. Arrange wirings according to the following instructions. 3.4.1 GT01 (5 V DC) RS232C type Perform wiring and placement of the cable so that there is no impression of external noise on the cable and no induction.

  • Page 77: Gt02 / Gt02L (5 V Dc)

    3.4.2 GT02 / GT02L (5 V DC) RS232C type Perform wiring and placement of the cable so that there is no impression of external noise on the cable and no induction. Use shielded wires for distribution cables. (Recommended cable: AIGT8142) It conforms to CE marking.

  • Page 78: Rs232C Communication

    3. Perform grounding of the GT. GT01 / GT02 / GT12 GT11 GT03-E / GT21 GT05 / GT32 / GT32-R / GT32-E Key Point: The CE marking standards that the GT series conforms to European EMC directive 2004/108/EC European EMC standards For GT01/GT11/GT21 (EN61000-6-4 and EN61000-6-2)

  • Page 79: Rs422 (Rs485) Communication

    3. Perform grounding of the GT. GT01 / GT02 / GT12 GT11 GT03-E / GT21 GT05 / GT32 / GT32-R / GT32-E Key Point: The CE marking standards that the GT series conforms to European EMC directive 2004/108/EC European EMC standards For GT01/GT11/GT21 (EN61000-6-4 and EN61000-6-2)

  • Page 80: Precautions When Wiring Ethernet Port (Gt32T1)

    3.5 Precautions when Wiring Ethernet Port (GT32T1) Although more than one GT32T1 can be connected using a hub, communication is performed with one unit each. Specify each destination to communicate. Use a UTP cable (unshielded cable) for the Ethernet cable, and take measures for noises such as installing a ferrite core if necessary.

  • Page 81: Options

    GT05 AFPX-BATT Backup battery (The backup battery for the FP-X is used.) GT12 GT32 GT32-R/GT32-E Battery life Battery life, when operating at a normal temperature (25C), a normal humidity (65% RH), is as follows. GT model life GT11 Approx. 2 years...
  • Page 82 Internal data to be backed up Stored in Backup battery Screen data (base, keyboard, login) Flow display data Recipe data Stored in the F-ROM. Not required Write device FP monitor screen data Alarm history + Line graph sampling Logging data of Logging function Stored in the SRAM.

  • Page 83: How To Install The Battery (Lithium Button Battery)

    3.6.2 How to Install the Battery (Lithium Button Battery) (The figures below is explained using the GT11. Note: Do not touch the electronic parts when removing and installing the battery. 3.6.3 How to Install the Battery (Backup Battery) The figures below is explained using the GT32. 1.

  • Page 84: Dead Battery Mark

    3.6.4 Dead Battery Mark If the battery voltage drops too low, the battery mark is displayed at the bottom right of the GT screen. When the battery voltage drops It can be specified in the GTWIN configuration settings, whether or not the dead battery mark is displayed .

  • Page 85: About The Waterproof Packing

    Replacing the front panel protective sheet (For GT01R, GT02, GT02L, GT03-E, GT12, GT21, GT32, GT32-R and GT32-E) 1. Remove the peel-off film attached to the front panel protective sheet. 2. Attach the front panel protective sheet. Attach the front sheet to fit the liquid crystal part of GT. At this time, try not to allow the air to get in the attached face.
  • Page 86 3-24...

  • Page 87: Connecting With Plc

    Chapter 4 Connecting with PLC...

  • Page 88: Connection With Plc

    4.1 Connection with PLC How to connect with PLC ・Connecting between one GT and one PLC via 1:1 communication ・Connecting between one GT and multiple PLCs via 1:N communication (PLC multiple connection) ・Connecting between one PLC and multiple GTs via 1:N communication (GT link) ・Connecting using the general-purpose serial communication mode ・...

  • Page 89: Connecting To The Plcs Made By Other Companies

    4.1.3 Connecting to the PLCs made by Other Companies For information on the connection with PLCs manufactured by other companies, see the latest GTWIN HELP or our website (https://industrial.panasonic.com/ac/e/dl_center/manual) where you can get the manual. Reference: < Connection with Other Companies' PLCs Manual ARCT1F449E>...

  • Page 90: Rs232C Connection

    4.2 RS232C Connection 4.2.1 Difference of Terminal blocks Between GT Models Although the terminal blocks vary according to the GT models, the connection method is the same. The connection diagram for 24 V DC is described with the terminal blocks other than the one for GT01. 24 V DC type 24 V DC-type GT01 other than GT01...

  • Page 91: Rs232C Connection With Plc Tool Port

    4.2.2 RS232C Connection with PLC Tool Port Connecting with 5 V DC type Usable models PLC communication cable Programmable display FP-X FP Mini-DIN 5-pin FP0/FP0R AIGT8142 5 V DC type RS232C type loose-wire cable FP-e FP2/FP2SH Connecting to the TOOL port Note: Connecting to the COM port is not available.
  • Page 92 Connecting with 24 V DC type Usable models PLC communication cable Programmable display FP-X FP AIGT8162 Mini-DIN 5-pin FP0/FP0R AIGT8165 24 V DC RS232C type loose-wire cable AIGT8160 FP-e FP2/FP2SH Connecting to the TOOL port...

  • Page 93: Rs232C Connection With Fp-X Com Port

    4.2.3 RS232C Connection with FP-X COM Port Connecting to the COM port of FP-X Communication cassette Usable models PLC communication cable Programmable display AFPX-COM1 AFPX-COM2 5 V DC FP-X AFPX-COM3 Loose-wire cable RS232C type 24 V DC AFPX-COM4 AFPX-COM5 Connecting to the 1- channel type RS232C Connecting to the 2-channel type RS232C As for the connection to S2 and R2 for COM2, make the same connection as S1 and S2.
  • Page 94 Connecting to the 1-channel type RS485 and 1-channel type RS232C Connecting to the 1-channel type Ethernet and 1-channel type RS232C It cannot be connected with Ethernet.

  • Page 95: Rs232C Connection With Fp Com Port

    4.2.4 RS232C Connection with FP COM Port Connecting to the COM port Usable models PLC communication cable Programmable display 5 V DC FP Loose-wire cable RS232C type 24 V DC Connecting to the 1-channel type RS232C Connecting to the 2-channel type RS232C As for the connection to S2 and R2 for COM2, make the same connection as S1 and S2.
  • Page 96 Connecting to the 1-channel type RS485 and 1-channel type RS232C The connections with either one unit or two units are available. 4-10...

  • Page 97: Rs232C Connection With Fp0/Fp0R Com Port

    4.2.5 RS232C Connection with FP0/FP0R COM Port Connecting to the COM port Usable models PLC communication cable Programmable display 5 V DC RS232C type RS232C type FP0R 24 V DC Connecting to the COM port of FP0/FP0R 4-11...

  • Page 98: Rs232C Connection With Fp-E Com Port

    4.2.6 RS232C Connection with FP-e COM Port Connecting to the COM port Usable models PLC communication cable Programmable display 5 V DC FP-e Loose-wire cable RS232C type 24 V DC Connecting to the FP-e (RS232C) 4-12...

  • Page 99: Rs232C Connection With Fp2/Fp2Sh Com Port

    4.2.7 RS232C Connection with FP2/FP2SH COM Port Connecting to the COM port FP2/FP2SH CPU unit FP2 Computer Communication Unit FP2 Multi Communication Unit Usable models PLC communication cable Programmable display FP2/FP2CH CPU unit FP2 Computer Communication Unit D-SUB 9-pin AIP81842 5 V DC RS232C type FP2 Multi...

  • Page 100: Rs422 Connection

    4.3 RS422 Connection 4.3.1 Difference of Terminal blocks Between GT Models Although the terminal blocks vary between the 5 V DC type and 24 V DC type, the connection method is the same. The connection diagram is described with the terminal block for 24 V DC. 24 V DC type 5 V DC-type GT01 5 V DC-type GT02/GT02L...

  • Page 101: Rs422 Connection With Fp-X Com Port

    4.3.2 RS422 Connection with FP-X COM Port Usable models PLC communication cable Programmable display 5 V DC FP-X AFPX-COM3 Loose-wire cable RS422/RS485 type 24 V DC Connecting to the FP-X Communication cassette, 1-channel type RS485/RS422 4.3.3 RS422 Connection with FP2/FP2SH COM Port Connecting to the COM port 4-15...
  • Page 102 Usable models PLC communication cable Programmable display FP2 Multi Communication D-SUB 9-pin 5 V DC RS422/ Communication block AIP81842 loose-wire cable 24 V DC RS485 type Unit FP2-CB422 Connecting to the FP2 Multi Communication Unit (MCU) + Communication block (RS422) 4-16...

  • Page 103: Rs422 Connection With C-Net Adapter

    4.3.4 RS422 Connection with C-NET Adapter Usable models PLC communication cable Programmable display AFP8536 AFP8532 5 V DC FP series C-NET adapter RS422/RS485 type AFP15401 24 V DC AFP15402 Connection method Communication settings on the PLC side Specify the setting to match with the setting for the GT using the tool software at the PLC side. C-NET adapter setting Set the termination (TERMINATE) to on.

  • Page 104: Rs485 Connection

    4.4 RS485 Connection 4.4.1 Difference of Terminal blocks Between GT Models Although the terminal blocks vary between the 5 V DC type and 24 V DC type, the connection method is the same. The connection diagram is described with the terminal block for 24 V DC. 24 V DC type 5 V DC-type GT01 5 V DC-type GT02/GT02L...

  • Page 105: Rs485 Connection With Fp0R Com Port

    4.4.2 RS485 Connection with FP0R COM Port Connecting to the COM port Usable models PLC communication cable Programmable display 5 V DC FP0R RS485 type Loose-wire cable RS422/RS485 type 24 V DC Connecting to the COM port of FP0R 4-19...

  • Page 106: Rs485 Connection With Fp-X Com Port

    4.4.3 RS485 Connection with FP-X COM Port Usable models PLC communication cable Programmable display AFPX-COM3 5 V DC FP-X AFPX-COM4 Loose-wire cable RS422/RS485 type 24 V DC AFPX-COM6 Connecting to the FP-X Communication cassette, 1-channel type RS485/RS422 Note: Check the usable GT models for 1:N communication. 4-20...
  • Page 107 Connecting to the 1-channel type RS485 and 1-channel type RS422 Note: Check the usable GT models for 1:N communication. 4-21...
  • Page 108 Connecting to the 2-channel type RS485 Note: Check the usable GT models for 1:N communication. 4-22...

  • Page 109: Rs485 Connection With Fp Com Port

    4.4.4 RS485 Connection with FP COM Port Connecting to the COM port Usable models PLC communication cable Programmable display AFPG803 5 V DC FP Loose-wire cable RS422/RS485 type 24 V DC AFPG806 Connecting to the 1-channel type RS485 Note: Check the usable GT models for 1:N communication. 4-23...
  • Page 110 Connecting to the 1-channel type RS485 and 1-channel type RS232C Note: Check the usable GT models for 1:N communication. 4-24...

  • Page 111: Rs485 Connection With Fp-E Com Port

    4.4.5 RS485 Connection with FP-e COM Port Connecting to the COM port Usable models PLC communication cable Programmable display 5 V DC FP-e RS485 type Loose-wire cable RS422/RS485 type 24 V DC Connecting to the FP-e (RS485) 4-25...

  • Page 112: Rs485Connection With Fp2/Fp2Sh

    4.4.6 RS485Connection with FP2/FP2SH Usable models PLC communication cable Programmable display FP2 Multi Communication 5 V DC RS422/ Communication block Loose-wire cable 24 V DC RS485 type Unit FP2-CB485 Connecting to the FP2 Multi Communication Unit (MCU) + Communication block (RS485) Note: Check the usable GT models for 1:N communication.

  • Page 113: Precautions When Communicating With Rs485

    4.4.7 Precautions When Communicating With RS485 When communication with the RS485, the transmission line for sending and receiving data is the same. Time taken until the connected device sends a response after sending a command from the If a response is sent too quickly, the GT may not be able to receive it. Adjust the time if necessary. For our FP series FP...

  • Page 114: Connection With A Plc

    4.5 Connection With a PLC 4.5.1 Automatic Communication Settings Function After turning on the power supply, if there is not response from the PLC connected to the GT, the GT switches to the automatic setting mode for the communication conditions. In the automatic setting mode, commands are sent to the PLC while changing the communication conditions in the sequence shown below.

  • Page 115: Through Function

    4.5.2 Through Function With the GT series, communication can be set to take place automatically between the COM port of a GT and TOOL port of a PLC in a “through function”. When the FP series/FP7 series tool software installed in the computer connected to the GT series as shown below is booted, PLC programs can be edited through the GT series.
  • Page 116 Note:  Precautions when using the through function The system should be set up so that the Timeout period in the FP series software (FPWIN) (A) is larger than the waiting time for communication retries of the GT COM port (B), meaning (A) > (B). If the system is set up so that A = B or A <...
  • Page 117 Procedure of making communication settings when using the through function 1. Match the communication settings of GT series to those of our PLC. The setting method of the GT series is as follows. For details of the setting method of our PLCs, refer to "4.5.3 Communication Settings of PLC using FPWIN GR"...
  • Page 118 2. Select "Browse for driver software on your computer" and specify a folder for storing the driver in the "Update Driver Software" dialog box. [Driver storage folder] ･For Windows7 (64-bit) \Program Files(x86) \Panasonic-ID SUNX Terminal\GTWIN\GTWIN_USB\x64 ･For other Windows OS \Program Files\Panasonic-ID SUNX Terminal\GTWIN\GTWIN_USB\x86 For details of "Update Driver Software", refer to "Procedure of...
  • Page 119 3. Set the network type of FPWIN. When using FPWIN GR 1. Select "Option (O)" > "Communication Settings (C)" from the menu bar. 2. Set the network type to "USB(GT)". When using FPWIN GR7 1. Select "Online (L)" > "Communication Settings (C)" from the menu bar. 2.

  • Page 120: Communication Settings Of Plc Using Fpwin Gr

    4.5.3 Communication Settings of PLC using FPWIN GR Please read below to make PLC communication settings using the FPWIN GR. 1. Select "Option (O)" > "PLC Configuration". 2. Make the communication settings. Select “Tool Port" setting when connecting to the tool port or “COM Port" setting when connecting to the COM port.

  • Page 121: Communication Settings Of Plc Using Fpwin Gr7

    4.5.4 Communication Settings of PLC using FPWIN GR7 Please read below to make PLC communication settings using the FPWIN GR7. 1. Select "Options (O)" > "FP7 Configuration (C)" > "Built-in SCU". 2. Make the communication settings. Set the communication settings of the communication port connected to the GT to be the same as those of the GT.
  • Page 122 4-36...

  • Page 123: Troubleshooting

    Chapter 5 Troubleshooting...

  • Page 124: What To Do If Something Unusual Occurs (Gt01/Gt11/ Gt21)

    5.1 What to DO If Something Unusual Occurs (GT01/GT11/ GT21) Problem Cause Solution Screen is 1) Power is not on. 1) Supply the power supply to unit as per blank specifications. 2) (When only lamp and message parts are 2) Check the address of the substitute reference configured to the base screen) Value of device and the device values on the PLC side.
  • Page 125 Problem Cause Solution Screen 1) No screen number has been written to 1) Specify correct screen number. doesn’t the screen setting area (the first word switch in the basic communication area word device) from the PLC. 2) The screen number to which you are 2) Refer to Reference Manual.
  • Page 126 Problem Cause Solution Buzzer sounds Bit F of the first word in the basic Set the F bit to OFF on the PLC side. (Do not use the continuously communication area bit device is set basic communication area with ladder programs.) to ON.

  • Page 127: What To Do If Something Unusual Occurs (Gt02/Gt02L/Gt03-E/Gt05/Gt12/Gt32/Gt32-R/Gt32-E)

    5.2 What to DO If Something Unusual Occurs (GT02/GT02L/GT03-E/GT05/GT12/GT32/GT32-R/GT32-E) Problem Cause Solution Screen is blank 1) Power is not on. 1) Supply the power supply to unit as per specifications. 2) (When only lamp and message parts 2) Check the address of the substitute reference are configured to the base screen) device and the device values on the PLC side.
  • Page 128 Problem Cause Solution Screen is dim 1) The power voltage may be low. 1) Check the capacity of the power supply unit if it is enough for the GT’s power consumption. 2) The contrast is set too low. 2) Bring up the system menu and adjust the contrast. 3) The backlight is off due to the 3) Touching any area of the screen lights that area.
  • Page 129 Problem Cause Solution Buzzer sounds Bit F of the first word in the basic Set the F bit to OFF on the PLC side. (Do not use the continuously communication area bit device is set basic communication area with ladder programs.) to ON.
  • Page 130 Operation security function Message Cause Solution “Incorrect password.” Is An unregistered password was Enter the registered password. displayed on the login entered. screen. “Incorrect password.” Is An incorrect password was entered in Enter the registered password displayed on the the Current password field. correctly.
  • Page 131 When using the SD memory card. Data may be erased or the SD memory card may be damaged during the operation. Take measures for the situations as below. Problem Measures Transmitting GT configuration setting file using the logging function clears the information on the SRAM.

  • Page 132: Error Codes And How To Handle Them

    When an error occurs in the GT series, an error code displays at the top right of the screen. There are two types of error codes, GT series error codes and PLC error codes. For GT02 / GT02L / GT03-E / GT05 / GT12 / GT32 / GT32-R / GT32-E Code No.
  • Page 133 For GT02, GT02L, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Code No. Content Cause and solution 1) The value of BCC may be incorrect. Check if there is no calculation mistake. **0000 BCC error 2) There is a temporary error due to noise, etc. Re-supply power to the PLC and GT.
  • Page 134 Code No. Content Cause and solution General-purpose **1025 General-purpose memory shortage in the destination PLC. memory shortage The PLC (FP2/FP2SH) is set to the RUN mode. Change to the **1027 Remote mode error REMOTE mode or PROG. mode. Check if a device that cannot be forcibly operated in the PROG. **102D Forced operation error mode has been forcibly turned on or off.
  • Page 135 Check the data to be returned from the external device. from the external device. For GT02, GT02L, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Code No. Content Cause and solution 1) PLC connection cable is disconnected. Check the wiring of Time up error the connection cable and check for disconnection.
  • Page 136 A command for the address that writing is not available ER07 Data write inhibit error was sent. Check the address of the sent command. For GT02, GT02, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Error code Error name Measures The value of BCC may be incorrect. Check if there is no...

  • Page 137: When Connected To A Fp Series Plc

    Error codes which are sent from the PLC are listed in the table below. For information on other errors, refer to the user’s manual of the PLC used. For details, refer to the table of MEWTOCOL-COM communication errors in PLC user’s manuals.  When connected to Panasonic PLC For GT01, GT11 and GT21 Code No.
  • Page 138 For GT02, GT02L, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Code No. Content Cause and solution Data error 1) There is an error in the communication condition settings. Check A data error the PLC and GT baud rate and transfer format.
  • Page 139 PLC error ER61 A NAK error has been Verify the PLC settings. returned from the PLC. For GT02, GT02L, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Code No. Content Cause and solution NAK error ERFFFE A NAK error has been Verify the PLC settings.
  • Page 140 For GT02, GT02L, GT03-E, GT05, GT12, GT32, GT32-R and GT32-E Code No. Content Cause and solution Cannot be executed due to operation mode. (The PLC received the Change the mode of the PLC from the operation mode to the ER0001 command that cannot monitor mode.

  • Page 141: Specifications

    Chapter 6 Specifications...

  • Page 142: Gt01

    6.1 GT01 6.1.1 General Specifications Specifications AIGT0030B AIGT0032B AIGT0030B1 AIGT0032B1 AIGT0030H AIGT0032H AIGT0030H1 AIGT0032H1 Item AIGT0130B AIGT0132B AIGT0130B1 AIGT0132B1 AIGT0130H AIGT0132H AIGT0130H1 AIGT0132H1 AIGT0230B AIGT0232B AIGT0230B1 AIGT0232B1 AIGT0230H AIGT0232H AIGT0230H1 AIGT0232H1 Rated voltage 24 V DC 5 V DC Operating voltage 21.6 to 26.4 V DC 4.5 to 5.5 V DC range...

  • Page 143: Performance Specifications (Gt01)

    6.1.2 Performance Specifications (GT01) Specifications AIGT0030B1 AIGT0130B1 AIGT0230B1 AIGT0030H1 AIGT0130H1 AIGT0230H1 AIGT0030B AIGT0130B AIGT0230B Item AIGT0030H AIGT0130H AIGT0230H AIGT0032B1 AIGT0132B1 AIGT0232B1 AIGT0032H1 AIGT0132H1 AIGT0232H1 AIGT0032B AIGT0132B AIGT0232B AIGT0032H AIGT0132H AIGT0232H Display device STN monochrome LCD Resolution 128 (W) x 64 (H) dots Displayable area 70.38 (W) x 35.18 (H) mm Backlight...

  • Page 144: Function Specifications (Gt01)

    6.1.3 Function Specifications (GT01) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double or quadruple in height and width) True Type (GTWIN): 10 to 64 dots Windows (R): 10 to 64 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified Chinese, Traditional Chinese characters, Turkish, Russian and Vietnamese can...

  • Page 145: Interface Specifications (Gt01)

    (Baud rate: (Total length) (Baud rate: 19,200 bit/s) 115,200 bit/s) 115,200 bit/s) - MEWTOCOL (Protocol for PANASONIC PLC: FP series) - General-purpose serial (PANASONIC dedicated protocol) Protocol - Other companies’ PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 146: Gt02

    6.2 GT02 6.2.1 General Specifications (GT02) Specifications Item 24 V DC type 5 V DC Rated voltage 24 V DC 5 V DC Operating voltage range 21.6 to 26.4 V DC 4.5 to 5.5 V DC 1W or less Power consumption 1.9 W or less (80 mA or less) Note1) (200 mA or less)

  • Page 147: Performance Specifications (Gt02)

    6.2.2 Performance Specifications (GT02) Specifications Item GT02M GT02G Display device STN monochrome LCD Resolution 240 (W) x 96 (H) dots Displayable 88.5 (W) x 35.4 (H) mm area 3-color LED backlight (white, pink, 3-color LED backlight (green, Display Backlight red) orange, red) Backlight brightness can be adjusted on the menu screen or GTWIN Backlight...

  • Page 148: Function Specifications (Gt02)

    6.2.3 Function Specifications (GT02) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 96 dots Windows (R): 10 to 96 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 149: Interface Specifications (Gt02)

    120  － Terminal resistance value Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC FP7 series) General-purpose serial (PANASONIC dedicated protocol) Protocol for other companies' PLCs (For the details, refer to the latest GTWIN HELP.)

  • Page 150: Gt02L

    6.3 GT02L 6.3.1 General Specifications (GT02L) Item Specifications Rated voltage 5 V DC Operating voltage range 4.5 to 5.5 V DC Note1) Power consumption 1W or less (200 mA or less) 0 to +50 C Ambient temperature 20 to 85% RH (at 25 C), non-condensing Ambient humidity -20 to +60 C Storage temperature...

  • Page 151: Performance Specifications (Gt02L)

    6.3.2 Performance Specifications (GT02L) Item Specifications Display device STN monochrome LCD Resolution 160 (W) x 64 (H) dots Displayable 88.0 (W) x 35.2 (H) mm area Display Backlight LED backlight (white) Backlight brightness can be adjusted on the menu screen or GTWIN Backlight configuration settings.

  • Page 152: Function Specifications (Gt02L)

    6.3.3 Function Specifications (GT02L) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 64 dots Windows (R): 10 to 64 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 153: Interface Specifications (Gt02L)

    120  － Terminal resistance value Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Protocol for other companies' PLCs (For the details, refer to the latest GTWIN HELP.)

  • Page 154: Gt03-E

    6.4 GT03-E 6.4.1 General Specifications (GT03-E) Specifications Item GT03M-E GT03T-E Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 1.9 W or less (80 mA or less) 3.1 W or less (130 mA or less) -20 to +60 C Note1) Ambient temperature...

  • Page 155: Performance Specifications (Gt03-E)

    6.4.2 Performance Specifications (GT03-E) Specifications Item GT03M-E GT03T-E Display device TFT monochrome LCD TFT color LCD Resolution 320 (W) x 240 (H) dots Displayable area 70.6 (W) x 52.9 (H) mm Display Backlight 1-color LED backlight (white) Note1) Can be adjusted on the menu screen, GTWIN configuration settings or Backlight PLC.

  • Page 156: Function Specifications (Gt03-E)

    6.4.3 Function Specifications (GT03-E) Specifications Item GT03M-E GT03T-E Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 240 dots Windows (R): 10 to 240 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 157: Interface Specifications (Gt03-E)

    (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for our PLC: FP series) MEWTOCOL7 (Protocol for our PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.) Note1) 2) 3)

  • Page 158: Gt05

    6.5 GT05 6.5.1 General Specifications Specifications Item GT05S GT05M/GT05G Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 3.6 W or less (150 mA or less) 2.4 W or less (100 mA or less) Insulation method of Transformer insulation power supply part...

  • Page 159: Performance Specifications (Gt05)

    6.5.2 Performance Specifications (GT05) Specifications Item GT05S GT05M GT05G Display device 4096-color TFT color LCD TFT monochrome LCD Resolution 320 (W) x 240 (H) dots Displayable area 70.3 (W) x 52.7 (H) mm 70.6 (W) x 52.9 (H) mm Backlight 3-color LED 3-color LED Display...

  • Page 160: Function Specifications (Gt05)

    6.5.3 Function Specifications (GT05) Specifications Item GT05S GT05M/GT05G Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 240 dots Windows (R): 10 to 240 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 161: Interface Specifications (Gt05)

    (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 162: Gt11

    6.6 GT11 6.6.1 General Specifications (GT11) Item Specifications Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Note1) Power consumption 2.4 W or less (100 mA or less) 0 to +50 C Note2) Ambient temperature 20 to 85% RH (at 25 C), non-condensing Ambient humidity -20 to +60 C Storage temperature...

  • Page 163: Performance Specifications (Gt11)

    6.6.2 Performance Specifications (GT11) Specifications Item AIGT2030B/AIGT2030H AIGT2130B/AIGT2130H AIGT2032B/AIGT2032H AIGT2132B/AIGT2132H Display device STN monochrome LCD Resolution 240 (W) x 96 (H) dots Displayable area 96.0 (W) x 35.4 (H) mm Backlight 3-color LED backlight Display 1-color LED backlight (white) (green, orange, red) Backlight Can be set on the menu screen or GTWIN configuration settings.

  • Page 164: Function Specifications (Gt11)

    6.6.3 Function Specifications (GT11) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double or quadruple in height and width) True Type (GTWIN): 10 to 96 dots Windows (R): 10 to 96 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified Chinese, Traditional Chinese characters, Turkish, Russian and Vietnamese can...

  • Page 165: Interface Specifications (Gt11)

    Max. 500 m (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.) Note1) 2)

  • Page 166: Gt12

    6.7 GT12 6.7.1 General Specifications (GT12) Item Specifications Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 1.7 W or less (70 mA or less) Insulation method of Note1) Transformer insulation power supply part 0 to +50 C Ambient temperature 20 to 85% RH (at 25 C), non-condensing...

  • Page 167: Performance Specifications (Gt12)

    6.7.2 Performance Specifications (GT12) Item Specifications GT12M GT12G Display device STN monochrome LCD Resolution 320 (W) x 120 (H) dots Displayable 108.78 (W) x 40.78 (H) mm area Gradation 2 gradation/8 gradation (Selectable with GTWIN.) Display 3-color LED backlight 3-color LED backlight Backlight (white, pink, red) (green, orange, red)

  • Page 168: Function Specifications (Gt12)

    6.7.3 Function Specifications (GT12) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 120 dots Windows (R): 10 to 120 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 169: Interface Specifications (Gt12)

    (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 170: Gt21

    6.8 GT21 6.8.1 General Specifications (GT21) Item Specifications Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 4.8 W or less (200 mA or less) 0 to +50 C Note1) Ambient temperature 20 to 85% RH (at 25 C), non-condensing Ambient humidity -20 to +60 C Storage temperature...

  • Page 171: Performance Specifications (Gt21)

    6.8.2 Performance Specifications (GT21) Item Specifications Display device 256-color STN color LCD Resolution 320 (W) x 240 (H) dots Displayable area 98.0 (W) x 74.0 (H) mm Backlight 1-color LED backlight (white) Display Can be set on the menu screen or GTWIN configuration settings. Backlight brightness (There are some minor variations in the backlight brightness.) Contrast...

  • Page 172: Function Specifications (Gt21)

    6.8.3 Function Specifications (GT21) Item Specifications Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double or quadruple in height and width) True Type (GTWIN): 10 to 240 dots Windows (R): 10 to 240 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified Chinese, Traditional Chinese characters, Turkish, Russian and Vietnamese can...

  • Page 173: Interface Specifications (Gt21)

    Max. 500 m (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.) Note1) 2)

  • Page 174: Gt32

    6.9 GT32 6.9.1 General Specifications (GT32) Specifications Item GT32M GT32T0 GT32T1 Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 10 W or less (410 mA or less) 12 W or less (500 mA or less) Insulation method of Transformer insulation power supply part...

  • Page 175: Performance Specifications (Gt32)

    6.9.2 Performance Specifications (GT32) Item Specifications GT32M GT32T0 GT32T1 Display device Blue-white STN monochrome LCD 4096-color TFT color LCD Resolution 320 (W) x 240 (H) dots Displayable area 113.2 (W) x 86.4 (H) mm 110.8 (W) x 83.6 (H) mm Display Backlight CFL backlight...

  • Page 176: Function Specifications (Gt32)

    6.9.3 Function Specifications (GT32) Specifications Item GT32M GT32T0/GT32T1 Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 240 dots Windows (R): 10 to 240 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 177: Interface Specifications (Gt32)

    (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 178: Sound Output Specifications (Gt32T1 Only)

    Support media We recommend SLC SD memory cards and SLC SDHC memory cards. For details on operation confirmed SD memory card and SDHC memory card, visit “https://industrial.panasonic.com/ac/e/fasys/information/sd- card/index.jsp”. Conforms to SD standard. Supported format standard (Please download formatting software for SD memory cards from the SD Association website.)

  • Page 179: Gt32-R

    6.10 GT32-R 6.10.1 General Specifications (GT32-R) Specifications Item GT32M-R GT32T-R Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 4.8 W or less (200 mA or less) 7.2 W or less (300 mA or less)

  • Page 180: Performance Specifications (Gt32-R)

    6.10.2 Performance Specifications (GT32-R) Item Specifications GT32M-R GT32T-R Display device TFT monochrome LCD TFT color LCD Resolution 320 (W) x 240 (H) dots Displayable area 115.2 (W) x 86.4 (H) mm Display Note1) Backlight 1-color LED backlight (white) Can be adjusted on the menu screen, GTWIN configuration settings Contrast or PLC.

  • Page 181: Function Specifications (Gt32-R)

    6.10.3 Function Specifications (GT32-R) Specifications Item GT32M-R GT32T-R Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 240 dots...

  • Page 182: Interface Specifications (Gt32-R)

    (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 183: Gt32-E

    6.11 GT32-E 6.11.1 General Specifications (GT32-E) Specifications Item GT32M-E GT32T-E Rated voltage 24 V DC Operating voltage range 21.6 to 26.4 V DC Power consumption 4.8 W or less (200 mA or less) 7.2 W or less (300 mA or less) Insulation method of Transformer insulation power supply part...

  • Page 184: Performance Specifications (Gt32-E)

    6.11.2 Performance Specifications (GT32-E) Item Specifications GT32M-E GT32T-E Display device TFT monochrome LCD TFT color LCD Resolution 320 (W) x 240 (H) dots Displayable area 115.2 (W) x 86.4 (H) mm Display Note1) Backlight 1-color LED backlight (white) Can be adjusted on the menu screen, GTWIN configuration settings Contrast or PLC.

  • Page 185: Function Specifications (Gt32-E)

    6.11.3 Function Specifications (GT32-E) Specifications Item GT32M-E GT32T-E Displayable fonts Fixed (GTWIN): 1/4 width (8 x 8), half width (16 x 8), full width (16 x 16) (Double, quadruple or octuple in height and width) True Type (GTWIN): 10 to 240 dots Windows (R): 10 to 240 dots Character types English, Japanese, Korean, German, French, Italian, Spanish, Simplified...

  • Page 186: Interface Specifications (Gt32-E)

    (Total length) (Baud rate: 19200 bit/s) (Baud rate: 115200 bit/s) Protocol MEWTOCOL (Protocol for PANASONIC PLC: FP series) MEWTOCOL7 (Protocol for PANASONIC PLC: FP7 series) General-purpose serial (PANASONIC dedicated protocol) Other companies' PLC protocols (For the details, refer to the latest GTWIN HELP.)

  • Page 187: Dimensions And Other Documentation

    Chapter 7 Dimensions and Other Documentation...

  • Page 188: Dimensions

    7.1 Dimensions 7.1.1 GT01/GT01R Installation dimensions Panel cutout dimensions...

  • Page 189: Gt02

    7.1.2 GT02 Installation dimensions Panel cutout dimensions...

  • Page 190: Gt02L

    7.1.3 GT02L Installation dimensions Panel cutout dimensions...

  • Page 191: Gt03M-E

    7.1.4 GT03M-E Installation dimensions Panel cutout dimensions...

  • Page 192: Gt03T-E

    7.1.5 GT03T-E Installation dimensions Panel cutout dimensions 87.5 ＋1 Applicable panel thickness: 1.0 to 5.0 mm connector (Unit: mm)

  • Page 193: Gt05

    7.1.6 GT05 Installation dimensions Panel cutout dimensions...

  • Page 194: Gt11

    7.1.7 GT11 Installation dimensions Panel cutout dimensions...

  • Page 195: Gt12

    7.1.8 GT12 Installation dimensions Panel cutout dimensions...

  • Page 196: Gt21

    7.1.9 GT21 Installation dimensions Panel cutout dimensions 7-10...
  • Page 197 7.1.10 GT32 GT32M Back view GT32T0 GT32T1 Installation dimensions Panel cutout dimensions 7-11...

  • Page 198: Gt32-R / Gt32-E

    7.1.11 GT32-R / GT32-E Installation dimensions Panel cutout dimensions 7-12...

  • Page 199: Cable Specifications

    7.2 Cable Specifications 7.2.1 AIGT8142 7.2.2 AIGT8152 7.2.3 AIGT8160/AIGT8162/AIGT8165/AIGT8192 7-13...

  • Page 200: Aigt8175

    7.2.4 AIGT8175 7.2.5 AIP81842 7-14...

  • Page 201: Bin/Hex/Bcd Code Correspondence Table

    7.3 BIN/HEX/BCD Code Correspondence Table Decimal Hexadecimal Binary Binary Coded Decimal 0000 00000000 00000000 0000 0000 0000 0000 0001 00000000 00000001 0000 0000 0000 0001 0002 00000000 00000010 0000 0000 0000 0010 0003 00000000 00000011 0000 0000 0000 0011 0004 00000000 00000100 0000...

  • Page 202: Ascii Code Table

    7.4 ASCII Code Table 7-16...

  • Page 203: Record Of Changes

    Sixth edition - Added new models GT03-E (Monochrome and Color types) ARCT1F511E-6 Nov.2013 Seventh edition ARCT1F511E-7 Sep.2014 Eighth edition - Added new model GT32-R ARCT1F511E-8 Mar.2016 Ninth edition -Added the description of through function. -Error correction WUME-GTH-01 Feb. 2020 Tenth edition "3.1.3 Installation Space"...
  • Page 204 [Scope of warranty] In the event that Panasonic Industrial Devices SUNX confirms any failures or defects of the Products by reasons solely attributable to Panasonic Industrial Devices SUNX during the warranty period, Panasonic Industrial Devices SUNX shall supply the replacements of the Products, parts or replace and/or repair the defective portion by free of charge at the location where the Products were purchased or delivered to your premises as soon as possible.
  • Page 206 Please contact ..Panasonic Industrial Devices SUNX Co., Ltd. https://panasonic.net/id/pidsx/global Please visit our website for inquiries and about our sales network. © Panasonic Industrial Devices SUNX Co., Ltd. 2021 March, 2021 WUME-GTH-02...

This manual is also suitable for:

Gt01Gt11Gt21Gt02Gt02lGt05 ... Show all

Table of Contents
