Use & Care Guide
Manual de Uso y Cuidado
Manuel d'entretien et d'utilisation
400 Series
Canister Vacuum Cleaner
Aspiradora con tanque
Aspirateur-traîneau
Model/Modelo/Modèle: BC2005
Vacuum Cleaner Help Line:
1-877-531-7321 (US) / 1-844-608-3081 (CA)
8:00am - 5:00pm EST, M-F
www.kenmorefloorcare.com
Kenmore and the Kenmore logo are registered
trademarks of KCD IP, LLC and/or Transform SR
Brands LLC and are used under license.
Advertisement
Table of Contents
Related Manuals for Kenmore 400 Series
Summary of Contents for Kenmore 400 Series
- Page 1 Aspirateur-traîneau Model/Modelo/Modèle: BC2005 Vacuum Cleaner Help Line: 1-877-531-7321 (US) / 1-844-608-3081 (CA) 8:00am - 5:00pm EST, M-F www.kenmorefloorcare.com Kenmore and the Kenmore logo are registered trademarks of KCD IP, LLC and/or Transform SR Brands LLC and are used under license.
-
Page 2: Table Of Contents
Requesting Assistance or Service ...............Back page BEFORE USING YOUR NEW VACUUM CLEANER Read this Use & Care Guide. It will help you assemble and operate your new Kenmore vacuum cleaner in the safest and most effective way. For more information about vacuum cleaner care and operation, call the Vacuum Cleaner Help Line at 1-877-531-7321 (US) / 1-844-608-3081 (CA). -
Page 3: Kenmore Vacuum Cleaner Warranty
WITH PROOF OF SALE a defective product will be replaced free of charge. The Kenmore brand is used under license. Direct all claims for warranty service to: Cleva North America, Inc., 1-877-531-7321 (US) / 1-844-608-3081 (CA). This warranty does not cover filters or belts, which are expendable parts that can wear out from normal use within the warranty period. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions in this guide before assembling or using your vacuum cleaner. WARNING! Your safety is important to us. To reduce the risk of fire, electrical shock, injury to persons or damage when using your vacuum cleaner, follow basic safety precautions including the following: •... - Page 5 IMPORTANT SAFETY INSTRUCTIONS cleaner before connecting or • You are responsible for making sure disconnecting either hose or wand. that your vacuum cleaner is not used by • Hold plug when rewinding onto cord anyone unable to operate it properly. reel.
-
Page 6: Parts And Features
PARTS AND FEATURES It is important to know your vacuum cleaner’s parts and features to ensure its proper and safe use. Review these before using your vacuum cleaner. Handle & Hose Assembly Canister Telescoping Floor Nozzle REPLACEMENT PARTS Part Part No. (US) Part No. - Page 7 CANISTER ATTACHMENTS Bare Floor Tool (Stored in 3-in-1 Combination Tool Canister) Dust Bag (2-Pack) - 7 -...
- Page 8 HANDLE & HOSE ASSEMBLY TELESCOPING WAND Wand Release Button FLOOR NOZZLE Nozzle Release Button Swivel Carpet / Floor Selector NOTE: This model is not equipped ® with a PowerMate motorized nozzle. ® A PowerMate is available for additional purchase. For details call the Vacuum Cleaner Help Line or see kenmorefloorcare.com.
-
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS Before assembling the vacuum cleaner, check the PACKING LIST (page 2). Use this list to verify that you have received all the components of your new Kenmore vacuum cleaner. To remove: Press wand release button and WARNING pull up on handle. -
Page 10: Operating Instructions
ASSEMBLY INSTRUCTIONS the hose latch tab in to release and remove HOSE hose. To install: Line up the hose latch tab with CANISTER the notch in the canister hood, and insert hose into canister until it snaps into place. 1. Open the canister hood. 2. - Page 11 HOW TO START NOTE: To reduce the risk of electric shock, this vacuum cleaner has a polarized plug; one blade is wider than the other. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug.
- Page 12 HOW TO START Slide the switch forward to the FLOOR NOTE : This 3-way On/Off switch position to turn on canister motor suction ® can also be fitted with a PowerMate only. The FLOOR indicator button will motorized nozzle, which is sold separately. turn green, and the PowerMate brushroll ®...
- Page 13 ATTACHMENTS Use in dusting brush mode for cleaning CAUTION loose surfaces such as drapes. See ATTACHMENT USE TABLE (page 15). DO NOT attach or remove handle or wands while vacuum cleaner is ON. Dusting This could cause sparking and damage the electrical contacts or electronic Brush controls.
- Page 14 ATTACHMENTS ATTACHMENTS ON HANDLE ATTACHMENTS ON WAND NOTE 1. To remove floor nozzle from wand, press : If the floor nozzle is attached, the nozzle release button and pull to turn vacuum cleaner off before removing remove. handle from wand. 1.
- Page 15 ATTACHMENT USE TABLE CLEANING AREA Carpeted Between ATTACHMENT Furniture Drapes Stairs Bare Floors Walls Floors/Rugs Cushions Bare Floor Tool Floor Nozzle Dusting Brush Floor Nozzle Upholstery Brush 1. Always clean attachments before using on fabrics. 2. Press the carpet / floor selector on the floor nozzle to release the brush and squeegee for cleaning bare floors.
-
Page 16: Performance/Safety Features
PERFORMANCE/SAFETY FEATURES CHECK BAG INDICATOR THERMAL PROTECTOR This vacuum cleaner has a thermal When the vacuum cleaner is running with protector which automatically trips normal airflow, the CHECK BAG indicator to protect the vacuum cleaner from is green. The indicator turns to dark red overheating. -
Page 17: Canister Care
CANISTER CARE REMOVING CLOGS The vacuum cleaner creates suction that picks up dirt. Rapidly moving air carries the dirt to the dust bag through the airflow passages. The dust bag lets the air pass through, while it traps the dirt. For best cleaning results, keep the airflow passage open. - Page 18 CLEANING EXTERIOR AND ATTACHMENTS 1. Turn off and unplug vacuum cleaner. DO CAUTION NOT drip water on vacuum cleaner. Do not use attachments if they are wet. 2. To clean exterior, or to reduce static Attachments used in dirty areas, such as electricity and dust build-up, wipe outer under a refrigerator, should not be used surface with a clean, soft cloth that has...
- Page 19 DUST BAG CHANGING NOTE : DO NOT bend or crease the CAUTION middle of the cardboard when installing the bag into the bag mount slots. NEVER REUSE A DUST BAG. Very fine materials, such as carpet 6. Rotate bag mount down and install freshener, face powder, fine dust, bag into slots per illustration, pushing plaster, soot, new carpet lint, etc.
- Page 20 MOTOR SAFETY FILTER CLEANING 3. Wash filter in warm soapy water, rinse, then dry. Do not clean in dishwasher or install while damp. 4. Slide the filter back into place under the Plastic ribs in the bag cavity. Retainer 5. Replace the bag as outlined in the DUST BAG CHANGING (page 18-19) section.
- Page 21 EXHAUST FILTER CHANGING 4. Insert the new exhaust filter cartridge 6. Rotate filter cover down until it snaps into the filter cover with the rubber seal into place. upward. 5. To replace the exhaust filter cover, insert the two tabs on the cover into the slots at the top of the filter chamber.
-
Page 22: Troubleshooting
TROUBLESHOOTING Review this table to find do-it-yourself solutions for minor performance problems. Any other service needed call 1-877-531-7321 (US) / 1-844-608-3081 (CA) for assistance. WARNING Always turn off and unplug vacuum cleaner before performing maintenance to the vacuum cleaner. Failure to do so could result in electrical shock or personal injury. PROBLEM POSSIBLE CAUSE SOLUTION... - Page 23 TROUBLESHOOTING Vacuum cleaner picks up Slide the electronic suction control to a lower moveable rugs Suction too strong. power setting. -or- floor nozzle pushes too hard. Dirty power cord. Clean the power cord. Cord won’t rewind. Cord jammed. Pull out cord and rewind. Vacuum cleaner leaves marks on Wrong vacuuming pattern.
